Sonic Safety HG-1000 User manual

Wireless Security &Safety System
HG-1000
OWNER’SMANUAL

1
Table of Contents
Introduction (HG-1000) …………………………………………………………………..
3
System Package ……………………………………………………………..
3
Optional Accessories ………………………………………………………..
3
Planning for Installation ………………………………………………………………….
4
Choosing Location ………………………………………………………….. 4
Setting Alarm Zones …………………………………………………………
4
Installing the Back-up Battery ………………………………………………
4
Power the Main Console ……………………………………………………
4
Connecting the Telephone Line …………………………….………………
5
Setting the Antenna ………………………………………………………….
5
Mounting the Main Console …………………………………………………
5
About Password …………………………………………………………….. 5
Others …………………………………………………………………………
5
About the Main Console Operation …………………………………………………….
6
LCD Panel illustration. ……………………………………………………….
6
Function for Installer-Factory Default Password ………………………….
8
Function for Master-Factory Default Password ……………………….….
14
Check Function ……………………………………………………………….
15
Speed Dial Function ………………………………………………………….
15
Arm or Disarm via the Telephone Line ……………………………………..
15
Auto Dialer Priority… …………………………………………………………
16
LCD “MSG”Message Indicating on LCD …………………………………..
16
SR-129 Remote Control Handset………………………………………………………..
17
HG-120 PIR MotionDetector …………………………………………………..………..
18
HG-122/HG-123 Door/Window Detector ………………………………………….……
21
SS-206 Mini Siren …………………………………………………………………………
24
Summary of Main Console Programmed ………………………………………………
25
Specificationsof Security System ……………………………………………………….
26

2
Important Safety Instruction
•Read Instructions –All the safety and operating instructions should be read before operating this
equipment. These instructions should be retained for future reference
•Heed Warnings –All warnings on the equipment and in the operating instructions should be
adhered to. All instructions regarding care and operation of this equipment should be followed.
•Power Sources –Equipment should only be connected to the power supply specified in the
operating instructions or as marked on the equipment.
•Grounding or Polarization –Take precautions that the equipment is properly grounded. Take
note that the power supply is fitted in the correct input jack ( marked DC 12V ), and auxiliary units
( external siren and strobe light ) are fitted into the correct external jack points.
•Power-Cord Protection –Keep cable cords and plugs clear of other objects, particularly at the
point where they exit the equipment.
•Cleaning –Clean the equipment by wiping with a soft cloth, ( do not use any abrasive agents or
water ).
•Non-use Periods –Power cords should be unplugged from the outlet when left unused for a long
period of time.
•Object and Liquid Entry –Take care not to drop objects or liquids on any part of the equipment.
•Damage Requiring Service –The alarm should be serviced by a qualified service personnel
when:
-The power-supply cord or the plug has been damaged,or
-Objects have fallen, or liquid has been spilled onto the equipment,or
-The equipment has been exposed to rain,or
-The equipment does not appear to operate normally or exhibits a marked change in
performance,or
-The equipment has been dropped, and/or the enclosure has been damaged.
•Servicing –Do not attempt to service the appliance beyond that described in the operating
instructions. All other servicing should be referred to a Qualified Distributor’s Service Personnel.
•System Maintenance –Under normal use your system requires virtually no maintenance other
than regular testing. It is recommended that you test your system once a week, and replace the
batteries at least once every 6 months ( or as needed ).
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE
IMPORTANT NOTE: IF YOU RETURN TO YOUR PREMISES AND FIND THAT
THE ALARM IS IN PROGRESS, DO NOT ENTER, AS A FIRE OR AN INTRUDER
MAY BE PRESENT. GO TO A NEIGHBOR AND CONTACT THE RELEVANT
LOCAL AUTHORITIES FROM THERE.

3
Introduction
Thank you for choosing our wireless home security system. This Security System is high-quality,
reliable and versatile security system. This system built in Auto-dialer function. To ensure the best
performance of your system, please read this manual thoroughly and follow the precautions and
instructions presented. These systems are designed to be simple and easy to install and maintain.
Wireless easy to use
:No messy and expensive wiring is required to install the
system.
Expandability : You can add different kinds of accessories to the system to
create a more complex system as your future needs may
require.
Flexibility :You can choose the kinds of sensors and response actions for
the system.
Personalized : Program the system to notify whoever you choose in the case
of alarm activation.
System Package
HG-1000 X 1 Main Console
SR-129
X 1 Remote Control Handset
HG-120
X 1 PIR Motion Detector
HG-122
X 1 Door/Window Detector (12V battery)
SS-206
X 1 Wired Mini Siren
Optional Accessories
SR-117 Panic Watch Transmitter HR-126
Range Extender
HG-118
Smoke Detector SS-207
Wired External Siren with Strobe Light
HG-123
Door/Window Detector (9V)
8KR-700
Rechargeable Battery (for HG-1000)
HG-124
Door Keypad 8KR-
180
Rechargeable Battery (for HR-126)
HG-125
Gas Detector

4
Planning for Installation
#
ARMED
POWER
1 2 3
45 6
789
0
MICROPROCESSOR CONTROL KEYPAD
DISARMPANIC
HOME
AWAY
The security system is designed to be as flexible as possible in order to meet your present needs, and
also to adapt as your needs change. For the reason, we recommend that you read and consider the
following information and plan your system before installing devices.
Choosing Location
It is important to try and place the Main Console in an area central. This way.It can let all the sensors
transmit signals with maximum efficiency. In additional, The Main Console must be placed near a power
outlet and telephone jack, because the system needed to be connected with them.
Setting Alarm Zones
Before installation, you shall have the sensors learn into Main Console via system learning mode of the
Main Console. This system allows to install maximum 63 wireless sensors.
Installing the Back-up Battery
Remove the battery cover of the Main Console and install the backup battery set to ensure security
system in normal operation when AC adapter out of work.
Powering the Main Console
1. Attach the end of the adapter into the connector provided at the back inside of the console.
2. Locate the AC adapter, plug the AC adaptor to power outlet.
3. Shown as the LCD screen while power on.
00 HOME SECURITY
Disarmed
Welcome

5
Connecting the Telephone Line
To correct the Main Console to the telephone line, Please follow these steps:
1. Locate the two phone jacks on the back inside of the main console. These phone jacks are
marked “ Phone “ and “ Line “.
2. Connect one end of the telephone cord that came with the system into the connector
labeled Line. Connect the other end of that cord into the wall jack.
3. Connect a telephone to the Main Console through the phone jack.
4. Set the back cover and fix it securely. (Before setting the back cover, you need to finish the Battery
and AC Adaptor installation)
Setting the Antenna
Carefully extend the antenna upward in order to maximize the range of communication
between sensors and the Main console.
Mounting the Main Console
The Main Console may be set on a table top, or mounted on a wall. To mount the console on a wall,
follow these steps.
1. Remove the two black rubber pads and store them away for future use.
2. Measure and fix screws into the wall so that the two screws fit into grooves left under removed
pads.
3. Connect all wire connection to the jacks on the back inside. and replace to back cover.
4. Set the console onto the screws and carefully allow the console to drop into the groove securely
from inside.
About Passwords
This system provides two sets of password for setting the system. A〉”Install ”B〉”Master ”
A〉”Install ”: You can use this password to set the system, such as telephone numbers or record
message…etc
B〉”Master ”: This password is used for setting “ Arm”( Arm away or Arm home) or “Disarm”the system.
When the system is finished installation, your family members only need to “ Arm” or “Disarm”the
system.
Others
We recommend that you install and program the console after installing the other components (sensors)
of the system. This is to ensure that all of the components are working together properly.

6
About the Main Console operation
The Main Console is the heart of the security system. It monitors the sensors and the responds
according to how it is programmed, whenever the sensoris activated. The controls shown on the Main
Console may look complex at the first sight, however, most procedures are straightforward and easy.
Please review the illustration below which labels all of the parts of the Main Console.
LCD Panel Illustration
#
1 2 3
45 6
7 8 9
0
MICROPROCESSOR CONTROL KEYPAD
LEGEND
1 . NUMERIC AND #, BUTTONS
2 . BURGLARY BUTTON
3 . FIRE BUTTON
4 . MEDICAL EMERGENCY BUTTON
5 . SP DIAL BUTTON
6 . CHECK BUTTON
7 . CANCEL BUTTON
8 . ENTER BUTTON
9 . AWAY BUTTON 17 . OUTPUT TERMINAL JACKS
16 . ANTENNA
15 . SPEAKER
14 . LCD PANEL
13 . ARMED LED INDICATOR
12 . POWER LED INDICATOR
11 . MIC 20 . DC POWER JACK
19 . TEL LINE JACK
18 . TELEPHONE JACKS
10 . HOME BUTTON
1. Numeric keys and
#,* keys : For telephone setting included pound and star keys.
2. Burglary Button : SP DIAL button together with Burglary Button
3. Fire Button : SP DIAL button together with Fire Button
4. Medical
Emergency : SP DIAL button together with Fire Button
5. SP DIAL button : Press SP DIAL button together with 4, 5 or 6 to activate
3-emergency dialing
6. Check : Press CHECK button to review sensor setting and check
recording message… ...
7. Cancel : Press CANCEL button to go back to previous menu or deleted
MSG.
8. Enter : Press ENTER to confirm program entry.
9. Away : Key-in the “ Master ” code then press AWAY button to arm at
away mode
10. Home : Key-in the “ Master ” code then press HOME button to arm at
home mode
11. Mic : To record the messages and use for two way communication voice
input.

7
12. Power LED : Indicates the AC Adaptor power is on or off.
13. Armed LED : When the light ‘on’, system is armed; the light ‘off’, system is
disarmed.
14. LCD Panel : Display the message
15. Speaker : Sounds alarm and plays back messages
16. Antenna : Antenna
17. Output Jack : Connect the external siren
18. Phone Jack : Connect to phone set
19. Line Jack : Connect to Telephone line from wall
20. DC Power Jack
: DC supply input
Notice : The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance
requirements, no change to the antenna or the device is permitted. Any
change to the antenna or the device could result in the device exceeding the
RF exposure requirements and void user’s authority to operate the device.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.

8
Function for Installer –Factory Default Password :123456
1. Enter password to start the menu. LCD shown as below(Enter the password and do
the function setting according to your need)
lIncorrect password entering will show “ Access Denied” and will emit beep sound
warning.
lIf 3 incorrect password are entered, keyboard disabled and locked (LCD shown as below).
Try it again after one minute idle or use Remote Control Handset ( DISARM button) to
disarm the system.
lIf 9 incorrect password are entered, (has 3 times keyboard locked, system disabled and
locked, LCD shown as below). It will trigger alarm but won’t dial out the phone number.
you can use Remote Control Handset (DISARM button) to disarm the system.
2. If the password is correct (default 123456), It will have beep sound and LCD panel shown as
below.
3. Select the Number setting
0 -SET Function menu : Press 0 to start setting
(1) 0-T : For time setting (Default is 30 seconds.) minimum 1 second, maximum
255 seconds.
Press 0button, will go to time setting (exit, alarm, entry) time
Access Denied
HOME SECURITY
KEYBOARD LOCKED
System Lock
SYS_OPTS: 0-SYS_OPTS
1 –SEQ 2 –REPLAC 3 -CLR
Access Granted
Install Mode
Code : ******
Setting : 0 –T 1 2 3 4 5 6 –P
7 –MSG 8 –DIAL 9 -CODE
Setting : Time 1 -Exit
2 –Alarm 3 -Entry

9
Press 1button, setting delay time for exiting house. The default time is 30 Sec, you can
set the time from 1 to 255 Sec. Press Enter button to finish the setting.
Press 2button, setting alarm time for triggering alarm, The default time is 30 Sec, you
can set the time from 1 to 255 Sec. Press Enter button to finish the setting.
Press 3button, setting delay time for entering house, The default time is 30 Sec, you
can set the time from 1 to 255 Sec. Press Enter button to finish the setting.
(2) 123456-PNumeric key :To set telephone number ( can set 6 sets phone number and each
number up to 20 digits)
EX. Press 1 Button, the LCD panel shown as below.
Setting 1, 2or 3:For neighbors, relative friends and family members
to notify in case of emergencies.
Setting 4:The first priority dial in case of Burglary. ( check
police dept if acceptable or other people)
Setting 5: The first priority dial in case of Fire. ( check fire
dept if acceptable or other people)
Setting 6: The first priority dial in case of Medical help.
(check hospital if acceptable or other people )
(3) 7-MSG : To set recorded message which contains 1segment of message and maximum to
25 seconds. If the recorded message is less than 25 Sec, press ENTER to end
the recorded message. When alarm is triggered,it will play recorded voice
message.
Press 7to start message recording (it will automatically count down from 25
Sec).
Setting : Time
1 –Exit : 30 Sec
Setting : Time
2 –Alarm : 30 Sec
Setting : Time
3 –Entry : 30 Sec
Setting : Phone Num : 1
********************
Setting : Message Rec
Sel Msg : 1 25 Sec

10
When finished recording message, it will automatically playback recorded message one
time and LCD panel shown as below.
(4) 8–DIAL : To set Dial mode.(default is 2-ALL to dial all telephone sets)
Press 1for single attempt dial. ( if one of the telephone set is acceptable, it will stop to
dial other’s telephone set)
Press 2for 3 cycles attempt dial.( it will be in turn to dial all the telephone set, when the
phone number is dial out and has been picked, the picked number will stop to dial)
(5) 9 –CODE : To make password change. (factory defaults, 1-Install :123456, 2-Master : 135246). If
you want to change the password, key-in 6 digits and will automatically show
“OK”( max set 6 digits), if the word if less than 6 digits, you can press ENTER
after key-in the number and it will show ”OK”.
Press 1and in the change Install code menu.
Press 2and in the change Master code menu.
1-SEQ : " Sequent" for code learning to set zone location . First of all, all the sensors
need to be learned into main console and main console can receive the
signal if the sensor is triggered. When sensor is learned into main console,
main console will set the learning order for the sensor. This system allows
Setting : Dialer Mode
1 –Single 2 –All 1
Setting : Change Code
1 –Install : 1 2 3 4 5 6
Setting : Change code
2 –Master : 1 3 5 2 4 6
Setting : Message Play
Sel Msg : 1 25 Sec
Setting : Dialer Mode
1 –Single 2 –All 2
Setting : Change Code
1 –Install 2 –Master
Setting : Dialer Mode
1 –Single 2 –All 2
2

11
to set Zone numbers maximum to 63 addresses. It is recommend that you
use a pen on the sensor back label to mark the sensor location, You can
also replace or clear sensor for changing sensor.
In the system menu,
Press 1and into the sequential programming mode
( 01 sensor learning order)
The method for sensors learning:
1. PIR Motion Detector :
First install Battery and push the Power Switch from OFF to C position. PIR sensor LED will
light on for 1 Sec, it means that the sensor transmit 1 sec signal. Or you can move in the
front of PIR, It will detect your movement and transmit 1 sec signal. The sensor will be
learned into main console.
2. Door / WindowDetector :
First to install Battery and let the magnetic switch from close to open, the led will light on for
1 Sec, The sensor will be learned into main console.
3. Remote Control handset :
First to install Battery and press PANIC button, the led will light on for 1 Sec, The
sensor will be learned into main console.
4. Panic Watch :
First to install Battery and press RED button, the led will light on for 1 Sec, The sensor
will be learned into main console.
5. Smoke Detector :
First to install Battery and press S1 button, the led will light on for 1 Sec, The sensor will
be learned into main console.
6. Gas Detector :
Plug the AC power and press the TEST button, the led will light on for 2 Sec, The sensor
will be learned into main console.
7. When the sensor is learned into main console, It will show the message as below. At the
time it will automatically switch to next sensor learning mode
8. If the sensor has been learned in main console. Main console will show the sensor has
been learned in memory and not allow same sensor to learn into main console.
Sequential Pgming
Trigger Sensor 01
SYS_OPTS: 0-SYS_OPTS
1 –SEQ 2 –REPLAC 3 –CLR
Sequential Pgming
Sensor Added
Sequential Pgming
Trigger Sensor 02
Sensor Already
Exists in System 02

12
9. If sensors have learned and reach 63 zone numbers, LCD panel showsmemory full
message.
NOTE :1. Sensors belong to 24 hours included:
Smoke Detector, Gas Detector, Panic Watch, Remote Control Handset(PANIC button)
2. Distinguish A-AWAY and H-HOME mode:
When system is armed in HOME mode, Main Console will neglect the transmission
signal from the PIR Detector.
2-REPLAC : To replace the sensor. (When sensor is faulty or needs replacement)
To replace the original sensor, only need to key-in sensor learned order
number. Finish the number key-in and press ENTER , system will ask
for relearning the Sensor, you can trigger the sensor and learn the sensor
into the main console.
Note: Please use the same type sensor to replace the old one.
Press 2to go to replace sensor mode. LCD panel shows as below.
Once replace is finish, It will go back to upper menu.
Replace Sensor
Enter Sensor Num :
Sequential Pgming
Mem Full 63
Trigger Sensor To
Replace 01
SYS_OPTS: 0-SYS_OPTS
1 –SEQ 2 –REPLAC 3 -CLR

13
3-CLR : Clear Sensors (1 -Single 2–All )
Select 1-Single, you can key-in learned sensor order code and press ENTER .
It will clear the sensor. If select 2-All, It will clear all learned sensors.
Press 3and go into clear mode.
Press 1and key-in learned sensor order code then press ENTER ,It will clear this sensor.
Press 2, It will show the “Are you sure ? ”. press ENTER It will clear all
learned sensors.
Clear Sensor
1 –Single 2 -All
Clear Sensor
Clear OK Num : xx
Clear Sensor
Are You Sure ? Enter
Clear Sensor
Waiting ..…
Clear Sensor
Clear All OK
Clear Sensor
1 –Single Num: xx

14
Function for Master –Factory Default Password –135246
1. To enter Master code –135246, LCD display shown as below
lWhen the password is incorrect, It will introduce Beep …Warning sound. LCD display
shown as below.
lIf the password is correct, It will introduce a long Beep sound. LCD display shown as
below.
You can select the arm mode to set as below:
A -AWAY : Press AWAY button to set “ Armed -Away “ alert,(Armed LED always lights on)
H-HOME : Press HOME button to set “ Armed -Home “ alert,( Armed LED always blinks)
NOTE:1. Sensors belong to 24 hours included:
Smoke Detector, Gas Detector , Panic Watch
Remote Control Handset ( PANIC button).
2.Distinguish A-AWAY and H-HOME mode:
When system is armed in HOME mode, Main console will neglect the transmission
Code : ******
MASTER
A-AWAY H-HOME
00 HOME SECURITY
Armed AWAY
Access Granted
Master Mode :
Access Denied
00 HOME SECURITY
Armed HOME
00 HOME SECURITY
Disarmed

15
signal from the PIR Detector.
Check Function
To press CHECK button to check the memory data you have installed previously without any
password, but you can only review not allow to change the data in ‘Check’ Mode. Following with the
menu structure as below.
Check :
0 –T: To review (1-Exit) Exit time, (2-Alarm) Alarm time, (3-Entry) Entry time.
123456 –P :To review phone number sets.
7 –MSG : To review recorded message
8 –DIAL : To review dial mode.
Speed Dial Function
lPress and hold SP DIAL button and assigned button, Main console will automatically execute
the autodial and alarm, if you want to cancel the autodial and alarm when they are activated,
Please key-in Master password to cancel them or use Remote Control disarm button to stop it.
lSP DIAL + 4, the autodial order is: phone 4 →phone 1 →phone 2 →phone 3
(Intruder happened condition)
lSP DIAL + 5, the autodial order is: phone 5 →phone 1 →phone 2 →phone 3
(Fire happened condition)
lSP DIAL + 6, the autodial order is: phone 6 →phone 1 →phone 2 →phone 3
(Medical help happened condition)
Arm or Disarm Via the Telephone Line (for Tone Mode)
This function allowsyou to dial your home telephone from outside to Arm or Disarm your security
system. When hear a long ‘Beep’ sounds after 10 rings in the phone, then enter ‘Master code’135246
(default) if the password is correct, it will respond a long Beep sounds in the phone then to respond the
system status at this moment(if the password is less than 6 digits, need to use # button to finish the
password entry). One ‘Beep’ sound means in ‘Armed-Away’, two ‘Beep’ sound means in ‘Armed-Home’
and three ‘Beep’ sound means in ‘Disarm’. At this moment you can key-in (1, 2 or 3 ). Main console will
respond the relative message.
Respond message as below:
lPress 1means in ‘Armed-Away’and in the phone will hear one ‘Beep’sound.
lPress 2means in ‘Armed-Home’and in the phone will hear two ‘Beep’sound .
lPress 3means in ‘Disarm’and in the phone will hear three ‘Beep’sound.
If the system has been programmed in ‘Armed-Away’ or ‘Armed-Home’ status previously, you
need to ‘Disarm’ it first to reset the status. If you do not disarm first, and press ‘1’ or ’2’ directly,
the system will emit ‘bi-bi-bi’ to reject your setting. So press ‘3’ to disarm it.
Check : 0 –T 1 2 3 4 5 6 –
P
7 –MSG 8 –DIAL

16
Auto-dialer priority
This system stores up to six (6) telephone numbers in the Main Console. If it is triggered and alarm is
activated, the auto-dialer will call the pre-set 4 sets telephone numbers and play your pre-recorded
message.
If system is triggered
Burglary help -It will automatically dial phone 4 →phone 1 →phone 2 →phone 3
call sequentially by 3 cycles attempt (4, 1, 2, 3). When telephone
answered, it will playback message 2 times
Fire help -It will automatically dial phone 5 →phone 1 →phone 2 →phone 3,
call sequentially by 3 cycles attempt (5, 1, 2, 3). When telephone
answered, it will playback message 2 times
Medical help -It will automatically dial phone 6 →phone 1 →phone 2 →phone 3,
call sequentially by 3 cycles attempt (6, 1, 2, 3). When telephone
answered, it will playback message 2 times
LCD “MSG” : Message indicating on LCD
This system will leave warning message on LCD panel while sensors opened or triggered or in low
battery. It also emits3short ‘Beep’at every 10 Sec. to remind you in the meantime, It can be stored first
5 messages and displayed on the LCD. If you want to check or delete the MSG, the system need to be
in disarm mode. LCD display shown as below.
Press ENTER button to read the message. Press ENTER again will read next message…etc.
Press CANCEL button to delete all ‘MSG’. It will show as below.
00 HOME SECURITY
Disarmed MSG
63 DOOR SENSOR
01 Open
MESSAGE DELETED

17
Remote Control Handset
The key chain Remote Control Handset is a convenient way to arm ( Home / Away mode) or disarm this
system. Before using the sensor, it is necessary to learn into main console.
DC12V
LEGEND
1. TRANSMIT LED
2. DISARM KEY
3. AWAY KEY
4. HOME KEY
5. PANIC KEY
6. BATTERY
1. TRANSMIT LED : When press any button on panel, LED will light on
2. DISARM : Press this button to disarm the system or clear message
3. AWAY :Press this button to set the system in AWAY mode
4. HOME : Press this button to set the system in HOME mode
5. PANIC : Press this button will trigger the alarm and activate auto-dialing.
6. BATTERY COMPARTMENT : For 12V alkaline battery
Zone Address Setting
Enter the Installer code and press ‘1’ to start learning sensor into the system, to press
PANIC button for 1 sec, the red LED also light on 1 sec. the main console emits a long ‘Beep’,
LCD panel shows ‘Sensor Added’. The sensor has been setting successfully.
To Arm or Disarm with the Remote Control Handset
lWhen system is set in AWAY mode.
lWhen system is set in HOME mode.
lPress the PANIC button, immediately to trigger the alarm.
63 REMOTE SENSOR
Armed AWAY
63 REMOTE SENSOR
Armed HOME
63 REMOTE SENSOR
01 Panic

18
P.I.R Motion Detector
The PIR Motion Detector is designed to detect the movement of object in rooms or hallway. The
effective range of the motion sensor is 30 feet long, and with an 84 degree horizontal angle.
Before using the sensor, the sensor needed to be learned into main console. If main console is armed
in HOME mode. Even if PIR Triggered, the main console will neglect the PIR signal.
Main Features :
1. LED :When PIR has detected any moving of human. The red LED will blink for one
sec. It means to transmit out a signal to Main Console. When the battery power
is down to low level, It will send out a low voltage signal.
The red LED will blink for one sec. If Main Console receives the signal, will leave
some message on the display.
2. C/OFF/WSWITCH :
lWhen the switch is set on “C –Continue” position, the PIR continually detects at
interval every 3 to 5 seconds after detecting the movement of human (dog ,cat).It is
an idea for checking
lWhen the switch is set on “OFF”position, It will turn off the power, the PIR does
not detect at all.
lWhen the switch is set on “W -Wait”position, the PIR detects at every 2 minutes to
3minutes after detecting the movement of human ( dog, cat). “W ”position set
mode will save the power.
3. DETECTING SENSITIVITY : (1 , 2 , 4) select the sensor to high ,medium or low
sensitivity.
4. BATTERY : Remove the Battery cover and insert one 9V alkaline battery.
5. ARM & HOLDER : For mounting on the wall.
6. BATTERY COVER

19
Replace the Battery
lWhen the sensor send the low battery voltage signal to main console. Please replace a
new battery for the sensor. In the main console, the LCD display shown the message as
below
Zone Address Setting
Enter the Installer password and the main console is in learning mode, after installing the battery on the
PIR. Set the power switch from “OFF ”to “C ”position. In the PIR panel, The red LED will blink for 1
sec, It means to transmit out a signal for 1 sec or to activate PIR sensor by detecting people pass by,
then the Main Console emits one ‘Beep’ and LCD displays ‘Sensor Added’, it means the PIR has
learned into the system successfully.
When main console is in armed mode, If PIR detects the movement of human or animals (cat,
dog), it will leave message on the LCD display as below.
Notes on the Position when Install
Motion sensors detect the movement of humans and animals within their range. In order to prevent
false alarms,we recommend that you do not install any motion sensor in the following areas:
Do not install any motion sensor in the following areas:
lWhere there is a device that causes rapid temperature change or rapid heat transfer.for
instance, near an air conditioner, fire place, heater or other intermittent heat sources.
lWhere the sensor will be exposed to direct sunlight.
lNear large electrical devices and/or high output radio frequency sources, like the
refrigerator, microwaves computers, and light dimmers.
lWhere the effective range of the sensor is covered or blocked by furniture.
lWhere pets enter and exit freely, for instance -a cat or dog door.
lDirectly opposite any large object with flat reflecting properties, like large windows or
mirrors.
lIn a bathroom or other area that is exposed to moisture and extreme temperature change.
63 PIR SENSOR
01 Low battery
63 PIR SENSOR
01 Zone
