Sonotechnique CPD16 User manual

sonotechnique
CPD16
MIDI/GPIO INTERFACE
INSTALLATION MANUAL
STANDARD EDITION
Document # CPD16 manual V1.1.DOC November 2005
Tel: [phone]
Fax: [phone]
www.sonotechnique.ca

•Rack Installation
The CPU unit should be installed in a proper ventilated Rack.
Default to proper ventilation may result in premature circuit degradation.
•Rear panel connector layout
CPD16
sonotechnique
Audio I/O GPI Outputs GPI Inputs Serial 1Serial 2/Midi
•Front View
CPD16
sonotechnique
ABCDEFGH ON33 34 35 36
2 CPD16, installation guide

CPD16, installation guide 3
•Audio I/O connector
D25 Female chassis connector pin assignment
PIN # Description Notes
1 Audio 1 monitor Input Left (+) From Audio 1 source Left (+)
14 Audio 1 monitor Input Left (-) From Audio 1 source Left (-)
2 Analog Ground
15 Audio 1 monitor Input Right (+) From Audio 1 source Right (+)
3 Audio 1 monitor Input Right (-) From Audio 1 source Right (-)
16 Analog Ground
4 Audio 1 monitor Output Left (+) To Audio 1 destination Left (+)
17 Audio 1 monitor Output Left (-) To Audio 1 destination Left (-)
5 Analog Ground
18 Audio 1 monitor Output Right (+) To Audio 1 destination Right (+)
6 Audio 1 monitor Output Right (-) To Audio 1 destination Right (-)
19 Analog Ground
7 Audio 2 monitor Output Left (+) To Audio 2 destination Left (+)
20 Audio 2 monitor Output Left (-) To Audio 2 destination Left (-)
8 Analog Ground
21 Audio 2 monitor Output Right (+) To Audio 2 destination Right (+)
9 Audio 2 monitor Output Right (-) To Audio 2 destination Right (-)
22 Analog Ground
10 Audio 2 monitor Input Left (+) From Audio 2 source Left (+)
23 Audio 2 monitor Input Left (-) From Audio 2 source Left (-)
11 Analog Ground
24 Audio 2 monitor Input Right (+) From Audio 2 source Right (+)
12 Audio 2 monitor Input Right (-) From Audio 2 source Right (-)
25 Analog Ground
13 Not connected

•GPI Outputs (1-16)+(33-36)
D25 Female chassis connector pin assignment
PIN # Description Notes Notes 2
1 GPI Output 1 Open Collector 100mA / 30V
14 GPI Output 14 Open Collector 100mA / 30V
2 GPI Output 2 Open Collector 100mA / 30V
15 GPI Output 15 Open Collector 100mA / 30V
3 GPI Output 3 Open Collector 100mA / 30V
16 GPI Output 16 Open Collector 100mA / 30V
4 GPI Output 4 Open Collector 100mA / 30V
17 GPI Output 33 Open Collector 100mA / 30V Red Light
5 GPI Output 5 Open Collector 100mA / 30V
18 GPI Output 34 Open Collector 100mA / 30V Green Light
6 GPI Output 6 Open Collector 100mA / 30V
19 GPI Output 35 Open Collector 100mA / 30V
7 GPI Output 7 Open Collector 100mA / 30V
20 GPI Output 36 Open Collector 100mA / 30V
8 GPI Output 8 Open Collector 100mA / 30V
21 Dgnd
9 GPI Output 9 Open Collector 100mA / 30V
22 Dgnd
10 GPI Output 10 Open Collector 100mA / 30V
23 Dgnd
11 GPI Output 11 Open Collector 100mA / 30V
24 Dgnd
12 GPI Output 12 Open Collector 100mA / 30V
25 5 Volts Fused at 500mA
13 GPI Output 13 Open Collector 100mA / 30V
Q1
NPN
Q2
NPN
Q3
NPN
Q4
NPN
Open Collector 1
Open Collector 2
Open Collector 15
Open Collector 16
DGnd
Equivalent Circuit
4 CPD16, installation guide

•GPI Inputs (1-16)+(33-36)
D25 Female chassis connector pin assignment
PIN # Description Notes Notes 2
1 GPI Input 1 Opto-isolator 1K series 5 Volts Min / 30mA max
14 GPI Input 14 Opto-isolator 1K series 5 Volts Min / 30mA max
2 GPI Input 2 Opto-isolator 1K series 5 Volts Min / 30mA max
15 GPI Input 15 Opto-isolator 1K series 5 Volts Min / 30mA max
3 GPI Input 3 Opto-isolator 1K series 5 Volts Min / 30mA max
16 GPI Input 16 Opto-isolator 1K series 5 Volts Min / 30mA max
4 GPI Input 4 Opto-isolator 1K series 5 Volts Min / 30mA max
17 GPI Input 33 Opto-isolator 1K series 5 Volts Min / 30mA max
5 GPI Input 5 Opto-isolator 1K series 5 Volts Min / 30mA max
18 GPI Input 34 Opto-isolator 1K series 5 Volts Min / 30mA max
6 GPI Input 6 Opto-isolator 1K series 5 Volts Min / 30mA max
19 GPI Input 35 Opto-isolator 1K series 5 Volts Min / 30mA max
7 GPI Input 7 Opto-isolator 1K series 5 Volts Min / 30mA max
20 GPI Input 36 Opto-isolator 1K series 5 Volts Min / 30mA max
8 GPI Input 8 Opto-isolator 1K series 5 Volts Min / 30mA max
21 GPI common 1-8 Opto-isolator 1-8 common
9 GPI Input 9 Opto-isolator 1K series 5 Volts Min / 30mA max
22 GPI common 9-16 Opto-isolator 9-16 common
10 GPI Input 10 Opto-isolator 1K series 5 Volts Min / 30mA max
23 GPI common 33-36 Opto-isolator 33-36 common
11 GPI Input 11 Opto-isolator 1K series 5 Volts Min / 30mA max
24 Dgnd
12 GPI Input 12 Opto-isolator 1K series 5 Volts Min / 30mA max
25 5 Volts Fused at 500mA
13 GPI Input 13 Opto-isolator 1K series 5 Volts Min / 30mA max
Equivalent Circuit
1K
1K
1K
1K
Opto-Isolator 1
Opto-Isolator 2
Opto-Isolator 7
Opto-Isolator 8
Opto-Isolator common 1-8
CPD16, installation guide 5

6 CPD16, installation guide
•Serial 2 / MIDI.
D9 Female chassis connector pin assignment
PIN # Description Notes
1 No Connection
6 No Connection
2 Midi RX - Equivalent to Midi input, Din 5, pin 5
7 Midi RX + Equivalent to Midi input, Din 5, pin 4
3 Midi TX + Equivalent to Midi output, Din 5, pin 4
8 Midi TX - Equivalent to Midi output, Din 5, pin 5
4 No Connection
9 No Connection
5 Dgnd Equivalent to Midi output, Din 5, pin 2
•Serial 1 / RS232.
D9 Female chassis connector pin assignment
PIN # Description Notes
1 No connection
6 No connection
2 TX TX RS 232
7 No connection
3 RX TX RS 232
8 No connection
4 No connection
9 No connection
5 Digital Ground

CPD16, installation guide 7
Operation Mode:
As per firmware 1.0
Mode 0 is the normal operating mode as configured by file dump into CPD16 via the configuration software.
Mode 1 to D are not valid.
Mode E is a diagnostic mode, see below.
Mode F is the monitor mode, this the mode that you have to be to dump the configuration file.
Mode E
Diagnostic mode.
In this mode, the CPD16 will echo all GP inputs to their respective GP output.
All Audio channel will be muted.
The front LED A & B are lighted, Ctl Room A & Ctl Room B muted.
Led C to H will count up in binary mode.
Mode 0
Normal mode.
In this mode, the CPD16 will respond to GP Inputs and midi messages as configured in the dumped file.
Led A & B will display the status of the Ctl Room A & B respectively.
Lighted = Muted
Led C to H are not used and will be off.
Led 33 represent the red light signal state “on air “. GPO 33
Led 34 represent the Green light signal. GPO34
Led 35 & 36 represent the state of GPO 35 & 36

5 5
4 4
3 3
2 2
1 1
D D C C B B A A
5 Volts
DGnd DGnd
GPI out 1
GPI in 1 GPI in 1 GPI in 2
GPI out 2
5 Volts
DGnd DGnd
GPI out 3
GPI in 3 GPI in 4
GPI out 4
5 Volts
DGnd DGnd
GPI out 5
GPI in 5 GPI in 6
GPI out 6
5 Volts
DGnd DGnd
GPI out 7
GPI in 7 GPI in 8
GPI out 8
GPI in 2 GPI in 3 GPI in 4 GPI in 5 GPI in 6 GPI in 7 GPI in 8 GPI in common 1-8 5 Volts
DGnd
DGnd GPI out 1 GPI out 2 GPI out 3 GPI out 4 GPI out 5 GPI out 6 GPI out 7 GPI out 8 5 Volts
5 Volts
5 Volts
5 Volts
GPI out 33
GPI out 33
GPI out 34
GPI out 34
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 typical IO wiring / 4 ch.
B
13Thursday, November 24, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 typical IO wiring / 4 ch.
B
13Thursday, November 24, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 typical IO wiring / 4 ch.
B
13Thursday, November 24, 2005
sonotechnique CPD
GPI Inputs
GPI Outputs
ON OFF
CH. 1 CH. 2 CH. 3 CH. 4
Red Light Green Light
The GPI Output Internal 5 Volts source is limited to a total of 500mA. If more current is needed or higher voltage, you will need an external power source
RxRx
1 2
A B
SW1SW1
1 2
A B
SW4SW4
13 25 12 24 11 23 10 22 9 21 8 20 7 19 6 18 5 17 4 16 3 15 2 14 1
P1 DB25 Male P1 DB25 Male
1 2
A B
SW7SW7
RxRx
RxRx
+
-V
K1 relay solid state
+
-V
K1 relay solid state
1 2
A B
SW8SW8
1 2
A B
SW2SW2
RxRx
RxRx RxRx
13 25 12 24 11 23 10 22 9 21 8 20 7 19 6 18 5 17 4 16 3 15 2 14 1
P2 DB25 Male P2 DB25 Male
1 2
A B
SW5SW5
RxRx
+
-V
K2 relay solid state
+
-V
K2 relay solid state
1 2
A B
SW6SW6
1 2
A B
SW3SW3
RxRx

5 5
4 4
3 3
2 2
1 1
D D C C B B A A
Mic Shield Mic Shield
Mic Cold Mic Hot
Mic Cold Mic Hot Ecoute Shield Ecoute Shield
Ecoute DroiteEcoute Droite
Ecoute Gauche Ecoute Gauche
DGnd GPI out 1 GPI out 2 GPI in 1 GPI in 2 GPI in common 1-8 5 Volts
5 Volts
5 Volts
5 Volts GPI out 1 GPI out 2
GPI out 33
GPI out 33
GPI out 34
GPI out 34
DGnd GPI in 1 GPI in 2
Title Size Document Number Rev Date: Sheet of
cpd16 typical wiring.dsn A1.1 CBC-Radio existing turret
B
23Thursday, November 24, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 typical wiring.dsn A1.1 CBC-Radio existing turret
B
23Thursday, November 24, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 typical wiring.dsn A1.1 CBC-Radio existing turret
B
23Thursday, November 24, 2005
sonotechnique CPD
ON OFF
Tourelle existante modifié
CPD16 GPI Inputs
CPD16 GPI Outputs
Red Light Green Light
Ecoute Microphone
Red
Red
Violet
Violet
D2 Vert D2 Vert
R1 220R R1 220R R2
220R R2 220R
13 25 12 24 11 23 10 22 9 21 8 20 7 19 6 18 5 17 4 16 3 15 2 14 1
P2 DB25 Male cable P2 DB25 Male cable
1
12 23 34 45 56 67 7
CN1 XLR7 Male CN1 XLR7 Male
+
-
V
K1 relay solid state
+
-
V
K1 relay solid state
SW1SW1 D1
Rouge D1 Rouge
SW2SW2
1 2 3
J1
1/4 STEREO
J1
1/4 STEREO
13 25 12 24 11 23 10 22 9 21 8 20 7 19 6 18 5 17 4 16 3 15 2 14 1
P1 DB25 Male cable P1 DB25 Male cable
+
-
V
K2 relay solid state
+
-
V
K2 relay solid state
13 25 12 24 11 23 10 22 9 21 8 20 7 19 6 18 5 17 4 16 3 15 2 14 1
P3' DB25 Femelle Chassis P3' DB25 Femelle Chassis
13 25 12 24 11 23 10 22
9
21
8
20
7
19
6
18
5
17
4
16
3
15
2
14
1
P3
DB25 Male Cable
P3
DB25 Male Cable

5 5
4 4
3 3
2 2
1 1
D D C C B B A A
Midi Input - pint 5 Midi Output + pint 4 Midi Input + pint 4 Midi Output - pint 5 Midi Output Shield
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 Midi adapter
A
33Friday, October 14, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 Midi adapter
A
33Friday, October 14, 2005
Title Size Document Number Rev Date: Sheet of
cpd16 Typical wiring.dsn A CPD16 Midi adapter
A
33Friday, October 14, 2005
sonotechnique CPD
CPD16 Midi IN
CPD16 Midi Out
1
4
2
5
3
JR1 DIN 5 R JR1 DIN 5 R
1
4
2
5
3
JR2 DIN 5 R JR2 DIN 5 R
5 9 4 8 3 7 2 6 1
P1 DB9 male P1 DB9 male
