Vidicode APRESA Series User manual

Call Recorder APRESA
&
Call Recorder APRESA Compact
Installation Manual
V 2.20
(VC1988)

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 2
Care and Maintenance
THIS EQ IPMENT M ST BE EARTHED
FOR SAFETY REASONS
Keep the APRESA dry. If it gets et, ipe it
dry immediately ith a soft, clean cloth.
Liquids might contain minerals that corrode
the electronic circuits.
Use and store the APRESA only in
temperature conditions bet een 0 and 40
degrees Celsius. Temperature extremes can
shorten the life of electronic devices and
distort or melt plastic parts.
Keep the APRESA a ay from excessive
dust and dirt.
Do not use aggressive chemicals, cleaning
solvents or strong detergents to clean the
APRESA.
LICENSES
=
€
Store your APRESA licenses in a safe place
as you may need these in the future.

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 3
This manual as ritten to support and guide customers in the installation process of the hard are and
soft are of the:
All products of VIDICODE
APRESA STANDARD 4 SERVER
APRESA S PER MICRO 1 SERVER
APRESA S PER MICRO 4 SERVER
APRESA COMPACT
APRESA SOFTWARE ONLY

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 4
How to use this manual.
You may ant to install a complete “VIDICODE made” APRESA server hile others ant to install the
APRESA soft are-only on their alternative hard are.
Also, the expansion of existing APRESA systems may need some guidance. Expanding an APRESA
system involves adding recording channels, increasing storage capacity or adding/ changing a RAID
volume.
Connecting the APRESA to the telecommunication infrastructure, the correct approach to signal tapping,
ill be an issue that most users ill have to deal ith.
The purpose of this manual is to support you in an effective ay. The document starts by presenting a
road map that ill guide you to the applicable sections for your situation. You ill easily find the chapters
that are relevant for your situation by using the flo chart.
For a list of VIDICODE APRESA Article codes refer to chapter 9.
THIS MAN AL IS FREQ ENTLY PDATED WITHO T ANY NOTIFICATION
YO ARE STRONGLY ADVISED TO DOWNLOAD THE NEWEST RELEASE OF THE MAN AL
FROM THE WEBSITE BELOW
www.vidicode.com

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 5
C
CO ON NT TE EN NT TS S
ROAD MAP ............................................................................................................................................................ 8
1. INSTALLATION START .................................................................................................................................... 9
1.1. SITUATIONS ........................................................................................................................................... 9
1.1.1. The “made by VIDICODE” APRESA Server / APRESA Compact. ............................................................. 9
1.1.2. So tware only ...................................................................................................................................... 9
1.1.3. Upgrading an existing APRESA ............................................................................................................ 9
1.2. PACKAGE CONTENTS, MATERIALS AND TOOLING ................................................................................. 10
1.2.1. Package contents ............................................................................................................................ 10
1.2.2. Advised Materials .............................................................................................................................. 11
1.2.3. Advised tooling .................................................................................................................................. 11
2. INTROD CTION TO THE APRESA SERVER ................................................................................................... 12
2.1. THE BLACK 19” HOUSING .................................................................................................................. 13
FRONT SIDE, DOOR CLOSED ................................................................................................................................ 13
BACK SIDE, C2SBC-Q MOTHERBOARD, STANDARD PSU ................................................................................... 14
BACK SIDE, C2SBC-Q MOTHERBOARD REDUNDANT PSU.................................................................................. 14
2.1.1. Enclosure ......................................................................................................................................... 15
2.1.2. Motherboard / CPU / RAM / PSU ........................................................................................................ 15
2.1.3. Hard drive (various con igurations possible) ......................................................................................... 15
2.1.4. DVD r/w ............................................................................................................................................ 16
2.1.5. Supported PCI inter ace card .............................................................................................................. 16
2.1.6. Supported PCIe inter ace card ............................................................................................................ 16
2.1.7. Environmental speci ication ................................................................................................................ 16
2.1.8. Approvals ......................................................................................................................................... 16
2.2. THE BLUE 19” HOUSING ....................................................................................................................... 1
FRONT SIDE, DOOR CLOSED ................................................................................................................................ 1
FRONT SIDE, DOOR OPENED ................................................................................................................................ 1
BACK SIDE, X9-SCM MOTHERBOARD. (OBSOLTE) ......................................................................................... 18
BACK SIDE, X10-SLL MOTHERBOARD. .............................................................................................................. 18
2.3. SPECIFICATIONS OF THE “BLUE” APRESA SERVER ....................................................................................... 19
2.3.1. Enclosure ......................................................................................................................................... 19
2.3.2. Motherboard / CPU / RAM / PSU ........................................................................................................ 19
2.3.3. Hard drive (various con igurations possible) ......................................................................................... 19
2.3.4. DVD r/w ............................................................................................................................................ 20
2.3.5. Supported PCI inter ace card .............................................................................................................. 20
2.3.6. Supported PCIe inter ace card ............................................................................................................ 20
2.3.7. Environmental speci ication ................................................................................................................ 20
2.3.8. Approvals ......................................................................................................................................... 20
2.4. THE APRESA-COMPACT ..................................................................................................................... 21
FRONT SIDE, DOOR CLOSED ................................................................................................................................ 21
2.5. SPECIFICATIONS OF THE APRESA-COMPACT SERVER .................................................................................... 23
2.5.1. Enclosure ......................................................................................................................................... 23
2.5.2. Motherboard / CPU / RAM / PSU ........................................................................................................ 23
2.5.3. Hard drive ......................................................................................................................................... 23
2.5.4. Supported PCIe interface cards ..................................................................................................... 23
2.5.5. Environmental speci ication ................................................................................................................ 24
2.5.6. Approvals ......................................................................................................................................... 24
3. APRESA BASE SOFTWARE ........................................................................................................................... 25
3.1. HARDWARE REQUIREMENTS ................................................................................................................ 26
3.2. INTERFACE CARD INSTALLATION PROCEDURE ...................................................................................... 26
3.3. SOFTWARE INSTALLATION PROCEDURE FROM THE CD ..................................................................................... 2
3.3.1. Attach monitor & keyboard ................................................................................................................. 27
3.3.2. BIOS setup ....................................................................................................................................... 27
3.3.3. Prepare an installation CD .................................................................................................................. 27

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 6
3.3.4. Installation rom CD ........................................................................................................................... 28
3.3.5. APRESA BASE SOFTWARE License Activation .................................................................................. 32
3.3.6. Base So tware Update ....................................................................................................................... 37
3.3.7. Channel License Activation ................................................................................................................ 38
3.3.8. Codec license Activation (optional) ...................................................................................................... 40
3.3.9. General APRESA con iguration .......................................................................................................... 40
3.4. APRESA AND VIRTUAL MACHINES .............................................................................................................. 40
4. MO NTING .................................................................................................................................................... 41
4.1. LOCATION CONSIDERATIONS ....................................................................................................................... 41
4.2. MOUNTING APRESA INTO A 19 INCH CABINET ............................................................................................... 42
4.3. APPLY POWER TO THE APRESA. ................................................................................................................ 42
5. TELECOM WIRING ......................................................................................................................................... 43
5.1. INTRODUCTION ........................................................................................................................................ 43
5.2. CONNECTOR LOCATIONS ........................................................................................................................... 45
5.3. GENERAL REMARKS ABOUT WIRING .............................................................................................................. 45
5.4. WIRING AUDIO TAPS ................................................................................................................................ 46
5.4.1. Balanced signals ............................................................................................................................... 46
5.4.2. Un-balance signals ............................................................................................................................ 47
5.4.3. Wiring using the RJ11 Patch Box ........................................................................................................ 48
5.4.4. Direct wiring ( NOT using a Patch Box ) .............................................................................................. 48
5.5. WIRING ANALOG TELEPHONY (POTS) TAPS .......................................................................................... 50
5.6. WIRING TDM TELEPHONY TAPS ................................................................................................................ 51
5.6.1. 2-Wire Vs. 4-Wire .............................................................................................................................. 51
5.6.2. Wiring schemes ................................................................................................................................. 51
5. . WIRING ISDN2 TELEPHONY TAPS (BASIC RATE ISDN) .................................................................................. 54
5.8. WIRING ISDN E1/T1 TELEPHONY TAPS ...................................................................................................... 55
5.9. CONFIGURATION OF VOIP TELEPHONY RECORDING ........................................................................................ 5
5.9.1. Trunk Side Recording ........................................................................................................................ 57
5.9.2. Station Side Recording ...................................................................................................................... 58
5.9.3. VoIP topology 1 ................................................................................................................................. 60
5.9.4. VoIP topology 2 ................................................................................................................................. 61
5.9.5. VoIP topology 3 ................................................................................................................................. 62
5.9.6. VoIP topology 4 ................................................................................................................................. 63
5.9.7. VoIP topology 5 ................................................................................................................................. 64
5.9.8. VoIP topology 6 ................................................................................................................................. 65
5.9.9. VoIP topology 7 ................................................................................................................................. 66
5.10. CONFIGURATION OF TETRA COMMUNICATION RECORDING............................................................................... 66
5.11. PATCH PANELS ........................................................................................................................................ 6
5.11.1. RJ11 Patch panel ......................................................................................................................... 67
5.11.2. he apping Patch box .............................................................................................................. 68
6. EXPANDING APRESA .................................................................................................................................... 69
6.1. ADDING RECORDING CHANNELS .................................................................................................................. 69
6.1.1. Channel license upgrade .................................................................................................................... 69
6.1.2. Installation o inter ace cards .............................................................................................................. 70
6.1.3. Installation of interface modules .................................................................................................... 70
6.2. INCREASING THE STORAGE CAPACITY .................................................................................................. 2
6.3. BUILDING OR CHANGING A SOFTWARE RAID VOLUME ...................................................................................... 2
7. BACK P AND RESTORE BACK P ................................................................................................................. 73
8. MAINTENANCE .............................................................................................................................................. 74
9. APPLICABLE VIDICODE ARTICLE CODES FOR APRESA ............................................................................... 75
10. RED NDANT POWER S PLLY ...................................................................................................................... 77
11. STORAGE OPTIONS ...................................................................................................................................... 79
11.1. CONFIGURATION .................................................................................................................................. 9
11.2. GENERAL INFORMATION ...................................................................................................................... 80

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 7
11.3. HOW TO REPLACE A FAILING HARD DRIVE IN A HARDWARE-RAID VOLUME ................................... 80
11.4. HOW TO REPLACE A FAILING HARD DRIVE IN A SOFTWARE-RAID VOLUME ..................................... 81
11.5. ADVISED HARDWARE RAID CONTROLLER CARD ................................................................................. 82
11.6. REBUILDING OF THE REPLACED DRIVE IN PROGRESS ............................................................................ 83
12. INTERFACE CARD SPECIFICATIONS ............................................................................................... 84
12.1. ATP-24A/PCI+/2.0 / ATP-24A/PCIE+/2.0 / ATP-24A/PCIE+/3.0 ..................................................... 85
12.2. DST-24B/PCI+/2.0 / DST-24B/PCIE+/2.0 .......................................................................................... 86
12.3. DTP-X0C/PCI+ / DTP-X0C/PCIE+ .................................................................................................... 8
13. GNU GENERAL PUBLIC LICENSE. ..................................................................................................... 88
14. TERMINILOGY EXPLAINED ................................................................................................................ 89
15. COPYRIGHT AND TRADEMAR S ...................................................................................................... 92
16. FCC STATEMENT .................................................................................................................................... 92
17. ROHS 2 STATEMENT ............................................................................................................................. 92

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 8
ROAD MAP
APRESA
INSTALLATION
APRESA SERVER
ART 010.04601
APRESA COMPACT
IP5 (5 VoIP)
ART 010.04700
APRESA COMPACT
IP10 (10 VoIP)
ART010.04705
APRESA COMPACT
D8 (8TDM/4 ISDN)
ART010.04710
APRESA COMPACT
A8 (8 ANALOG)
ART010.04705
APRESA
BASE SO TWARE
ART 010.04602
APRESA CH-
EXPANSION
ART 0.046XX
START
SO TWARE
ONLY !
ULL
SYSTEM!
UPGRADE
EXISTING
SYSTEM
HARDWARE
REQUIREMENS
INTER ACE CARD
INSTALLATION
INSTALLATION
O APRESA
SO TWARE
ACTIVATION
O APRESA
LICENSE
(ON LINE)
Y
VOIP
EXPANSION
?
N
INTER ACE CARD OR
INTER ACE MODULE
INSTALLATION
OTHER
INTRODUCTION
TO THE
APRESA
SERVER
ACTIVATE
CHANNEL /
CODEC LICENSE
(ON LINE)
MOUNTING O APRESA AND GENERAL INSTALLATION
ISSUES
CON IGURE APRESA :
USERS / USERGROUPS/
I/ CARD SETTINGS
ETC
TELECOM WIRING
COMMISSIONING
END
ACTIVATE CHANNEL / CODEC LICENSE
(ON LINE)
DWG1129_1
2
3.1
3.2
3.3
3.3.5
3.3.6
3.3.7
3.3.8
4
3.3.6
3.3.7
3.3.8
AND
CHAPTER 6
3.2
5
SEE ADMIN
MANUAL OR
ULL
DETAILS

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 9
1. INSTALLATION START
Generally, e distinguish 3 different situations of use of this document. You are advised to follo the
relevant path for your particular situation as indicated by the roadmap. The numbers in the roadmap link
to the chapters of interest, avoiding unnecessary reading of irrelevant chapters.
At the end of this chapter you find a list of required materials and tooling to do the job right.
1.1. Situations
1.1.1. The “made by VIDICODE” APRESA Server / APRESA Compact.
The APRESA is available on the market as a turn key product, either a 19” rack or a desktop version.
You ill find the APRESA soft are already installed and running on the product. Channel licenses are
activated and interface cards ill be installed according to your purchase order by VIDICODE. You are
advised to read the introduction and the go directly to the mounting, soft are configuration, telecom
iring, and commissioning sections.
1.1.2. Software only
You prefer to use your o n choice of hard are for a variety of reasons. In other ords, you have the
liberty to select your preferred server manufacturer like HP, Dell, etc. or use a virtual machine.
As a guide, e have listed the (minimum) hard are requirements of such a system. Refer to the
chapter “Hard are requirements”. To install the APRESA soft are image and do the channel licensing
one is advised to follo the directions as described in the chapter “Soft are installation”.
For the installation of interface cards in your hard are you must follo the directions of the
manufacturer or vendor of that machine.
Finally process the soft are configuration, telecom ire-tapping and commissioning section.
1.1.3. pgrading an existing APRESA
If you ant to upgrade an existing APRESA system ith additional channels or interface card(s) you can
go to the “Upgrade existing installations” chapter.
Existing APRESA systems need channel upgrade hen customer business expands after time and
more and more phones needs to be recorded. Adding and configuration of ne channels in soft are is
easy, the main effort here is hard are installation
Note that the APRESA Compact supports standard (NORAID) hard drive only, and is limited to max. 10
channel VoIP or 8 channel TDM or 8 channel Analog (POTS/audio).

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 10
1.2. Package contents, materials and Tooling
1.2.1. Package contents
Open the package carefully, and make sure that none of the items that are listed belo are missing.
This product has a very high level of flexibility and inherently there is no standard package content. To
help you in checking the delivery read the follo ing:
Package = “VIDICODE APRESA server”
1x APRESA SERVER
1x S&U LICENSE Support & Upgrade license
2x KEY (FOR DOOR LOCK)
1x POWER CORD 2 pcs ith optional redundant po er supply
1x QUICK GUIDE FOR INSTALLATION
1x GUARANTEE / REGISTRATION FORM
1x VIDICODE APPLICATION CD ONLY for the manuals
1x APRESA BASE SW INSTALLATION CD
1x APRESA BASE SOFTWARE LICENSE
1x APRESA CLIENT SOFTWARE LICENSE
?x CHANNEL / CODEC LICENSE Acc. to the channels/codec ordered.
1x PATCHBOX RJ11/RJ21 For every ATP / DST interface card installed
1x RJ21/RJ21 CABLE, LENGTH=1M For every ATP / DST interface card installed
Package = “VIDICODE APRESA-Compact server”
1x APRESA-COMPACT SERVER
1x S&U LICENSE Support & Upgrade license
1x POWER CORD
1x QUICK GUIDE FOR INSTALLATION
1x GUARANTEE / REGISTRATION FORM
1x VIDICODE APPLICATION CD ONLY for the manuals
1x APRESA BASE SW INSTALLATION CD
1x APRESA BASE SOFTWARE LICENSE
1x APRESA CLIENT SOFTWARE LICENSE
1x CHANNEL / CODEC LICENSE Acc. to the channels/codec ordered.
1x PATCHBOX RJ11/RJ21 Only if a ATP / DST interface card is installed
1x RJ21/RJ21 CABLE, LENGTH=1M Only if a ATP / DST interface card is installed

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 11
Package = “Software Onl ” (e-mail or postal package)
1x QUICK GUIDE FOR INSTALLATION Image from Vidicode WEB-site
1x S&U LICENSE Support & Upgrade license
1x VIDICODE LICENCING TERMS
1x GUARANTEE / REGISTRATION FORM
1x APRESA BASE SOFTWARE LICENSE
1x APRESA CLIENT SOFTWARE LICENSE
?x CHANNEL / CODEC LICENSE Acc. to the channels/codec ordered.
?x INTERFACE CARD ATP/DST/DTP Depends on the channels ordered.
1x PATCHBOX RJ11/RJ21 For every ATP / DST interface card ordered
1x RJ21/RJ21 CABLE, LENGTH=1M For every ATP / DST interface card ordered
Note that the last 3 items may be drop shipped directly from a third party.
Package = “Upgrade”
?x CHANNEL LICENSE Depends on the channels ordered.
?x INTERFACE CARD ATP/DST/DTP Depends on the channels ordered.
1x PATCHBOX RJ11/RJ21 For every ATP / DST interface card installed
1x RJ21/RJ21 CABLE , LENGTH=1M For every ATP / DST interface card installed
Note that the last 3 items may be drop shipped directly from a third party.
If any item is missing or damaged, please contact your local reseller for replacement or other
service.
1.2.2. Advised Materials
We advise you to check the follo ing list of materials before you start installing the system.
19” Rack scre s and cage nuts Modular ire 4P/6P/8P
Modular plugs RJ45 T-splitter(s)
RJ12 T-Splitter(s) RJ21 cable(s) 3,5 or 10m length
Tapping Patch box (-es) RJ48C to BNC adapter
Coaxial T-Splitter(s)
1.2.3. Advised tooling
We advise you to check the follo ing list of tooling of before you start installing the system:
- Standard installers tooling kit;
- RJ modular connector crimp tool

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 12
2. INTROD CTION TO THE APRESA SERVER
The APRESA server is available on the market in 3 types of housing:
1. The “BLACK” or the “BLUE” 19” RACK-MOUNT HOUSING, the standard APRESA.
These versions are based on industrial-grade PC server components. Both
are fully compatible ith 19-inch server cabinets and ill take 4U cabinet
space. All basic controls, indicators and the DVD drive are safely placed
behind a lockable door. Please note that the door-lock-keys are universal
(e.g. identical bet een different APRESA units). The sole purpose of the
DVD is to accommodate soft are installation. Because the soft are is pre-
installed by VIDICODE, the DVD has no immediate function. The DVD is
used hen soft are must be re-installed in the future for hatever reason.
2. The DESKTOP housing, the APRESA-Compact
This version is based on standard quality PC components build in a desktop
housing. It is intended to be a small scale- and lo cost recording solution.
The unit has no DVD drive so, the user must attach a USB-DVD drive hen
reinstalling the soft are.
All APRESA-options ordered are pre-installed by VIDICODE:
You ill find APRESA license, CHANNEL licenses, CODEC licenses, etc. and the APRESA
soft are on CD in the delivery. These are just for your safekeeping only. You need these
items only hen you ant to re-install the soft are.
Interface card(s) that are ordered for this machine ill be pre-installed.
The follo ing sub-sections describe the 3 types of housing in functional and specifications detail.

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 13
2.1. The BLACK 19” housing
(this model is obsolete)
Front side, door closed
Front side, door opened
Call Recor derS ilver Line
Apr esa
vidicode
LOCK DOOR
MOUN ING HOLES
2X USB 2.0
(NO USED)
VEN ILA ON
DWG1 130 _01
HANDLE
BAR
HANDLE
BAR
1
0
RE S E
KB -LK
KB -LK
P OW E R
H.D .D
DVD
RESET
BUTTON
NUM LOCK BUTTON
(NOT USED)
POW ER LED
HARD DISC
ACTIVITY LED
NUM LOCK LED
(NOT USED)
DOOR (OPENED)
DWG1131_0
POW ER
SW ITCH
DVD

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 14
Back side, C2SBC-Q motherboard, standard PSU
Back side, C2SBC-Q motherboard redundant PSU
• This housing also accommodates the X9-SCM motherboard. Refer to the next
section for information.
• The PSU alarm mute button location may be located elsewhere on your unit.
Specifications of the “BLACK” APRESA server
DWG11 33_ 0
MAINS POW ER
EN RIES
NO USED
I/F CARD#1 I/F CARD#2 I/F CARD#3 I/F CARD#4
NO USED NO USED
0
1
POW ER PACK
S A US LED
POW ER SW I CH
PSU ALARM
MU E BU ON
I/F CARDS
SLO S
DWG1 132_0
NO USED
I/F CARD#1 I/F CARD#2 I/F CARD#3 I/F CARD#4
NO USED NO USED
0
1
PC E HERNE VOIP E HERNE
6XUSB2.0
(NO USED)
3X PC SOUND CARD
(NO USED)
KEYBOARD AND MOUSE
(NO USED)
DISPLAY
(NO USED
SERIAL RS232
(NO USED)
MAINS POW ER
EN RY
POW ER SW I CH
(NO ON ALL MODELS)

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 15
2.1.1. Enclosure
TYPE : KI-N407
COLOR : Black (Textured)
WEIGHT : 15 Kg (approximately, varies ith different models)
DIMENSIONS
-Height : 177 mm (4U)
-Width : 482 mm (19” RACK mounting brackets standard)
440 mm (desktop, 19” brackets removed)
-Depth : 510 mm (Including handle bars, exclusive cables)
SLIDING RAIL : Optionally available
# 3.5” DRIVES : 5 INTERNAL
# 5.25” DRIVES : 3 EXTERNAL
# USB : 2pcs on front / 6pcs at the back (Not used)
COOLING : Front 120mm chassis FAN 1600 RPM
ACCESS CTRL : Controls / indicators are placed behind a lockable door
CONTROLS : -RESET Button
-ON/OFF S itch
-NUMLOCK S itch (Not used)
-PSU Alarm mute button (models ith redundant PSU only)
INDICATORS : -Po er
-Hard drive ACTIVITY
-NUMLOCK SWITCH INDICATOR (not used)
2.1.2. Motherboard / CP / RAM / PS
!!!!! if the X9-SCM motherboard is mounted skip to the next section !!!!!
MOTHERBOARD : SUPER MICRO C2SBC-Q-O (Socket 775)
(for all specifications : .supermicro.com)
CPU : INTEL PENTIUM E6600/2CORE/FSB1066/2MB Cache or
INTEL PENTIUM E5700/2CORE/FSB 800/2MB Cache or equivalent
(for all specifications: .intel.com)
RAM : DDR2 4GBYTE @ 800MHZ Standard
DDR2 8GBYTE @ 800MHZ Max.
PSU : 300W Standard
500W Optional
(for all specifications: .supermicro.com)
Optional: 1+1 redundant po er supply
PCI : 4 slots
PCI-e : 2 slots
2.1.3. Hard drive (various configurations possible)
INTERFACE : SATA 3GBIT/SEC
SIZE : 3.5 INCH

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 16
RPM : 7200
CACHE : 16MByte
QUALITY GRADE : 24/7
CAPACITY : 1TBYTE (standard configuration)
Optional 1or 2 TBYTE
RAID VOLUMES : Optional, RAID1 or RAID5 (Soft are RAID)
2.1.4. DVD r/w
INTERFACE : SATA 3GBit/SEC
SIZE : 5.25“
SPEED : 22X
MANUFACTURER : LG (or equivalent)
2.1.5. Supported PCI interface card
All cards belo are designed for the standard PCI card slot.
ANALOG : SYNWAY TYPE ATP- 24A/PCI+/2.0 : 8CH / 16CH or 24CH
SYNWAY TYPE ATP- 24A/PCI+/3.0 : 8CH / 16CH or 24CH
TDM : SYNWAY TYPE DST- 24B/PCI+/2.0 : 8CH / 16CH or 24CH
ISDN E1/T1 : SYNWAY TYPE DTP- 30C/PCI+/2.0 : 30CH / 1TRUNK
ISDN60 (E1) : SYNWAY TYPE DTP- 60C/PCI+/2.0 : 60CH / 2TRUNK
ISDN120(E1) : SYNWAY TYPE DTP-120C/PCI+/2.0 : 120CH / 4TRUNK
2.1.6. Supported PCIe interface card
All cards belo are designed for the PCIe X1 card slot.
note : These interface cards ill ork also in PCIe X4/X8/X16/X32 slots.
ANALOG : SYNWAY TYPE ATP- 24A/PCIe+/2.0 : 8CH / 16CH or 24CH
SYNWAY TYPE ATP- 24A/PCIe+/3.0 : 8CH / 16CH or 24CH
TDM : SYNWAY TYPE DST- 24B/PCIe+/2.0 : 8CH / 16CH or 24CH
ISDN E1/T1 : SYNWAY TYPE DTP- 30C/PCIe+/2.0 : 30CH / 1TRUNK
ISDN60 (E1) : SYNWAY TYPE DTP- 60C/PCIe+/2.0 : 60CH / 2TRUNK
ISDN120(E1) : SYNWAY TYPE DTP-120C/PCIe+/2.0 : 120CH / 4TRUNK
2.1.7. Environmental specification
TEMPERATURE RANGE : +10….+35 °C (Operating) or - 10 - + 65 °C (Storage)
HUMIDITY : 8%-90% No condensing, operating and storage.
2.1.8. Approvals
EMC APPROVAL : EN55022 / EN55024 / FCC15
SAFETY : EN60950

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 17
2.2. TH BLU 19” HOUSING
Front side, door closed
Front side, door opened
POWER HDD
VIDICODE
APRESA
DWG11 71_00
VE NT IL AT IO N
LOCK
DOOR HANDLE
BAR
M OUT ING
HOLE
POWER LED HARD DRIVE
ACT IVIT Y LED
POWER HDD
VIDICODE
APRESA
DWG1172_00
VE NT IL AT IO N HOL ES
RESET ON/O
USB
DVD OPENED DOOR
US B (NOT USED)
OPT IONAL SA T A BAY EJECT

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 18
Back side, X9-SCM motherboard. (OBSOL E)
Back side, X10-SLL motherboard.
IN ERFACE CARDS
SLO S
DWG1186_00
I/F CARD#1 I/F CARD#2 I/F CARD#3
0
1
PC E HERNE
VOIP E HERNE
4XUSB2.0
(NO USED)
DISPLAY (NO USED
SERIAL RS232
(NO USED)
MAINS
POWER
EN RY
POWER SWI CH
(NO ON ALL MODELS)
NO USED NO USED
IPMI
NO USED
IN ERFACE CARDS
SLO S
DWG1173_00
I/F CARD#1 I/F CARD#2 I/F CARD#3 I/F CARD#4
0
1
PC E HERNE
VOIP E HERNE
2XUSB2.0
(NO USED)
KEYBOARD AND MOUSE
(NO USED) DISPLAY (NO USED
SERIAL RS232 (NO USED)
POWER SWI CH
(NO ON ALL MODELS)
NO USED NO USED
IPMI
I/O (ALARM) OP ION

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 19
2.3. Speci ications o the “BLUE” APRESA server
2.3.1. Enclosure
TYPE : KI-N4058BLUE
COLOR : Blue doors, Black sheet metal (Textured)
WEIGHT : 15 Kg (approximately, varies ith different models)
DIMENSIONS
-Height : 177 mm (4U)
-Width : 482 mm (19” RACK mounting brackets standard)
440 mm (desktop, 19” brackets removed)
-Depth : 510 mm (Including handle bars, exclusive cables)
SLIDING RAIL : Optionally available
# 3.5” DRIVES : 5 INTERNAL
# 5.25” DRIVES : 3 EXTERNAL
# USB : 2pcs On front / 6pcs at the back (Not used)
COOLING : Front 120mm chassis FAN 1600 RPM
ACCESS CTRL : Controls / indicators are placed behind a lockable door
CONTROLS : -RESET Button
-ON/OFF S itch
INDICATORS : -Po er
-Hard drive ACTIVITY
2.3.2. Motherboard / CP / RAM / PS
MOTHERBOARD : SUPER MICRO X10-SSL (Socket 1150)
(for all specifications: .supermicro.com)
CPU : INTEL PENTIUM BX80646G3240 3.1 GHz 3MB cache
(for all specifications: .intel.com)
RAM : DDR3 4 GBYTE @ 1300 MHZ , ECC, Standard
DDR3 32GBYTE @ 1600MHZ ECC, Max.
PSU : 300W Standard
500W Optional
(for all specifications: .supermicro.com
PCI : 0 slots
PCI-e : 3 slots
2.3.3. Hard drive (various configurations possible)
INTERFACE : SATA 6GBIT/SEC
SIZE : 3.5 INCH
RPM : 7200
CACHE : 16MByte
QUALITY GRADE : 24/7
CAPACITY : 1T BYTE (standard configuration)
Optional 1or 2 TBYTE
RAID VOLUMES : Optional, Soft are RAID1 or Soft are RAID5

INSTALLATION MANUAL APRESA COPYRIGHT © 2011-2017 VIDICODE ® 20
2.3.4. DVD r/w
INTERFACE : SATA 6GBit/SEC
SIZE : 5.25“
SPEED : 22X
MANUFACTURER : LG (or equivalent)
2.3.5. Supported PCI interface card
This model has NO support for legacy PCI interface cards.
2.3.6. Supported PCIe interface card
All cards belo are designed for the PCIe X1 card slot.
note : These interface cards ill ork also in PCIe X4/X8/X16/X32 slots.
ANALOG : SYNWAY TYPE ATP- 24A/PCIe+/2.0 : 8CH / 16CH or 24CH
SYNWAY TYPE ATP- 24A/PCIe+/3.0 : 8CH / 16CH or 24CH
TDM : SYNWAY TYPE DST- 24B/PCIe+/2.0 : 8CH / 16CH or 24CH
ISDN E1/T1 : SYNWAY TYPE DTP- 30C/PCIe+/2.0 : 30CH / 1TRUNK
ISDN60 (E1) : SYNWAY TYPE DTP- 60C/PCIe+/2.0 : 60CH / 2TRUNK
ISDN120(E1) : SYNWAY TYPE DTP-120C/PCIe+/2.0 : 120CH / 4TRUNK
2.3.7. Environmental specification
TEMPERATURE RANGE : +10 …. +35 °C (Operating) or - 10 …. + 65 °C (Storage)
HUMIDITY : 8%-90% No condensing, operating and storage.
2.3.8. Approvals
EMC APPROVAL : EN55022 / EN55024 / FCC15
SAFETY : EN60950
