Sony Ericsson K660i User manual

Test Instruction, Mechanical
1208-1843 Rev 1
Test Instruction, Mechanical
Applicable for K660i
Contents
1Abstract..............................................................................................................2
2Test Procedure..................................................................................................2
2.1 Test flow................................................................................................2
3Pre-Test Preparations.......................................................................................2
3.1.1 Software Update....................................................................................2
3.1.2 Verify Software Version.........................................................................2
3.1.3 Update Software Version ......................................................................3
4Service Tests.....................................................................................................3
4.1.1 Main Display Test..................................................................................3
4.1.2 LED/Illumination Test ............................................................................3
4.1.3 Keyboard Test.......................................................................................3
4.1.4 Speaker Test.........................................................................................4
4.1.5 Earphone Test.......................................................................................4
4.1.6 Microphone Test....................................................................................4
4.1.7 Vibrator Test..........................................................................................4
4.1.8 Camera Test..........................................................................................4
4.1.9 Video Camera Test ...............................................................................5
4.1.10 Memory stick test ..................................................................................5
4.1.11 FM Radio Test.......................................................................................5
4.1.12 Real Time Clock Test............................................................................5
4.1.13 Total Call Time test ...............................................................................6
4.1.14 Security Test .........................................................................................6
5Manual Tests......................................................................................................6
5.1 On The Air Call To Mobile.....................................................................6
5.2 Bluetooth Test.......................................................................................6
5.3 System Connector Test.........................................................................7
6Revision History................................................................................................8
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 2(8)
1 Abstract
This document describes the process used for flashing software upgrades and how to
functionally test the mobile phone.
If there are any failures, the mobile must be repaired according to the troubleshooting
guide or sent to a higher repair level.
2 Test Procedure
To verify all components within Mechanical repair package all tests must be
performed.
2.1 Test flow
It’s OK to return the phone to the customer if the unit is passing these steps of testing
without any failures. If there are any failures, the phone must be repaired according
to the troubleshooting guide or sent to higher repair level.
3 Pre-Test Preparations
3.1.1 Software Update
Update to latest signalling software and run the service activities software from
EMMA III.
3.1.2 Verify Software Version
NOTE! Remove the SIM-card before testing.
To verify if the phone needs new software, you have to check the Software Version in
the phone. Current Software Versions are checked through the following steps:
1. Start up the phone.
2. Enter the Service Tests Menu by pressing the sequence ¨Ï§§Ï§Ïwith the
navigate buttons and the Ïon the keypad.
3. Select Service info.
4. Select SW Information.
5. Check the file revisions on the display.
6. Press OK to return to the Service info menu.’
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 3(8)
3.1.3 Update Software Version
Update the software in the phone by doing the following steps:
1. Make sure that the phone’s battery is fully charged or use a battery eliminator.
Connect correct flash cable and interface according to the Installation instruction.
2. Logon to the EMMA III server, and follow the instructions
4 Service Tests
4.1.1 Main Display Test
To verify the display:
1. Select “Main display” from the “Service Tests” menu.
2. The display toggles between four different test patterns.
Make sure that there are no dots missing and that the colours and contrast is OK.
3. Press the “Centre Navi” key to go back to the service tests menu.
4.1.2 LED/Illumination Test
To verify that the backlights are OK:
1. Select “LED/illumination” from the “Service Tests” menu.
2. Check that the backlight in the display and the keyboard is toggle between on
and off.
3. Press the “OK” key to go back to the service tests menu.
4.1.3 Keyboard Test
To verify that all the keys are working:
1. Select “Keyboard” from the “Service Tests”.
2. Press all keys on the keypads, the camera key and up/down keys on the right
side and the on/off button on the top. If they are ok a text feedback is displayed
showing the information which key was pressed. All keys should be tested.
3. If you stop pressing keys the phone will return to the service test menu.
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 4(8)
4.1.4 Speaker Test
Warning! Do NOT hold the phone to your ear while performing this test.
To verify the Speaker function:
1. Select “Speaker” from the “Service Tests” menu.
2. Adjust the volume on the right side of the phone and make sure that the speaker
is working properly.
3. Press the “Ok” key to go back to the service tests menu.
4.1.5 Earphone Test
To verify the Earphone function:
1. Select “Earphone” from the “Service Tests” menu.
2. Adjust the volume on the right side of the phone and make sure that the
earphone is working properly.
3. Press the “Ok” key to go back to the service tests menu.
4.1.6 Microphone Test
This test is intended to test the microphone. Therefore, the earphone should be
tested before this test is entered.
1. Select “Microphone” from the “Service Tests” menu.
2. The phone will start to record and after that the sound is played in the speaker.
Make sure that the record sounds have a load and clear sound.
3. After the sound has been replayed the test case will return to “Service Test”
menu.
4.1.7 Vibrator Test
To verify the vibrator function:
1. Select “Vibrator” from the “Service Tests” menu.
2. Press any key (except the Centre Navi Key) and the vibrator will vibrate 3 times.
3. Press the “Ok” key to go back to the service tests menu.
4.1.8 Camera Test
To verify the camera functionality:
1. Select Camera from the “Service Tests” menu.
2. The camera function will now starts and are visible in the display. Make sure that
the contrast and light is OK.
3. Press the “back” key to go back to the service tests menu.
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 5(8)
4.1.9 Video Camera Test
To verify the Video call camera functionality:
1. Select Video call camera from the “Service Tests” menu.
2. The video call camera function will now start and is visible in the display, then
make sure that the contrast and light is OK.
3. Press the “back” key to go back to the service tests menu.
4.1.10 Memory stick test
This test is to verify if the communication to the memory stick is working.
1. Insert a memory stick in to the memory stick holder on the left hand-side of the
phone.
2. Select “Memory Stick” from the “Service tests” menu.
3. Make sure that the phone will detect the memory stick.
4. Remove the memory stick from the holder.
5. Press the “Ok” key to go back to the service tests menu.
4.1.11 FM Radio Test
This test will check if the inbuilt FM radio is working.
Hands free equipment is used in this test.
1. Switch on phone wait until start-up screen appears, select normal mode when
“insert SIM card” message appears on the screen then enter test mode
sequence.
2. Select “FM radio” from the “Service Tests” menu.
Connect the hands free equipment to the system connector and tune in a well-known
FM-Radio channel. Verify that it’s possible to switch between different radio channels
and that the sound is clear.
3. Press the “Ok” key to go back to the service tests menu.
4.1.12 Real Time Clock Test
This test will check if the built in real time clock works.
1. Select “Real time clock” from the “Service Tests” menu.
After approximately 5 seconds you will get information whether the clock is ok or
not.
2. Press the “Ok” key to go back to the service tests menu.
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 6(8)
4.1.13 Total Call Time test
This test will show you the Total Call Time of the phone.
1. Select “Total Call Time” from the “Service Tests” menu
and you will get information regarding the “Total Call Time” of this phone.
2. Press “Ok” key to return to the service tests menu.
4.1.14 Security Test
This test will check if the security device keys
1. Select “Security” from the “Service Tests” menu, then select “Device Key
Test”. After approximately 5 seconds you will get information whether the
Security keys are ok.
2. Press the “Ok” key to go back to the service tests menu.
5 Manual Tests
5.1 On The Air Call To Mobile
To verify the function of the speaker, microphone, polyphonic ring signal and
volumes button.
1. Insert an operator SIM card and start the phone.
2. Set up a call from another phone to the mobile phone.
3. Answer the phone call.
4. Check that the polyphonic ring signal is working and that the backlight switches
on OK.
5. Also check that the quality of the sound both in the mobile phone and the other
phone are OK.
6. Press the volume key up and down and check that the volume in the phone is
altered.
7. End the call.
8. Check that the ending procedure is OK and that the speech time is displayed.
5.2 Bluetooth Test
To verify that the Bluetooth communication is working:
1. Insert a SIM card, connect a battery and start the unit.
2. Activate the Bluetooth function by entering Connectivity/Bluetooth and turn it on.
3. Set up a link between the phone and another Bluetooth compatible device. If a
connection can be established the Bluetooth module is considered working.
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 7(8)
5.3 System Connector Test
Hands free equipment and a charger are used in this test, to check the functionality
of the System Connector.
1. Insert a SIM card, connect a battery and start the unit.
2. Connect the Hands free equipment to the system connector and set up a call and
listen if you can speak/hear in the hands free set.
3. Connect the charger to the system connector and see if the phone starts to
charge and if the charging is indicated in the display.
Company Internal ©Sony Ericsson Mobile Communications AB

Test Instruction, Mechanical
1208-1843 Rev 1 8(8)
6 Revision History
Rev. Date Changes / Comments
1 2008-02-29 First Release
