Sony TDM-BT10 User manual

TDM-BT10 [GB] 4-122-062-12(1)TDM-BT10 [GB] 4-122-062-12(1)
Bluetooth®
Wireless
Audio Adapter
4-122-062-12(1)
TDM-BT10
©2008 Sony Corporation
GB Operating Instructions
FR Mode d’emploi
ES Manual de instrucciones
DE Bedienungsanleitung
NL Gebruiksaanwijzing
IT Istruzioni per l’uso
SE Bruksanvisning
PL Instrukcja obsługi
DK Betjeningsvejledning
FI Käyttöohjeet
PT Manual de Instruções DE
NL
IT
SE
PL
GB
FR
ES
DK
FI
PT
Printed in Malaysia

TDM-BT10 [GB] 4-122-062-11(1)
2
GB
WARNING
To reduce the risk of re or electric
shock, do not expose this apparatus
to rain or moisture.
e unit is not disconnected from
the AC power source (mains) as
long as the connected AV system is
connected to the wall outlet.
e nameplate is located on the
bottom exterior.
Do not install the appliance in a
conned space, such as a bookcase or
built-in cabinet.
To prevent re or shock hazard, do
not place objects lled with liquids,
such as vases, on the apparatus.
Install this system so that the power
cord can be unplugged from the wall
socket immediately in the event of
trouble.
Notice for customers: the
following information is only
applicable to equipment sold in
countries applying EU directives
e manufacturer of this product
is Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japan.
e Authorized Representative for
EMC and product safety is Sony
Deutschland GmbH, Hedelnger
Strasse 61, 70327 Stuttgart, Germany.
For any service or guarantee matters
please refer to the addresses given
in separate service or guarantee
documents.
For the customers in Europe
Hereby, Sony Corporation declares
that this TDM-BT10 Bluetooth
Wireless Audio Adapter is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/
EC. For details, please access the
following URL:
http://www.compliance.sony.de/
Use of this radio equipment is not
allowed in the geographical area
within a radius of 20 km from the
centre of Ny-Alesund, Svalbard in
Norway.
e Bluetooth word mark and logos
are owned by the Bluetooth SIG, Inc.
and any use of such marks by Sony
Corporation is under license.
Other trademarks and trade names
are those of their respective owners.

3
GB
TDM-BT10 [GB] 4-122-062-11(1)
Table of Contents
Features................................4
How to use the unit ................5
Getting Started
Unpacking............................6
Location of parts..................6
Connecting to
an AV system....................7
Pairing ..................................8
What is pairing? ......................8
Using the Unit
Listening to music ............ 11
Controlling the Bluetooth
audio source device
– AVRCP ...........................13
Additional
Information
Precautions ....................... 14
Troubleshooting............... 16
What is Bluetooth
technology?.......................18
Initializing ......................... 19
Specications.................... 20
Disposal of Old
Electrical &
Electronic
Equipment
(Applicable in the
European Union
and other European
countries with
separate collection systems)
is symbol on the product or on
its packaging indicates that this
product shall not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of
electrical and electronic equipment.
By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused
by inappropriate waste handling
of this product. e recycling of
materials will help to conserve
natural resources. For more detailed
information about recycling of this
product, please contact your local
Civic Oce, your household waste
disposal service or the shop where
you purchased the product.
GB

TDM-BT10 [GB] 4-122-062-11(1)
4
GB
Features
You can enjoy music, using Bluetooth wireless technology, played on
a Bluetooth audio source device (mobile phone, digital music player,
etc.)*1, by connecting this unit to an AV system with a DIGITAL MEDIA
PORT (DMPORT) jack.
You can operate your Bluetooth audio source device via Bluetooth
connection with the control buttons on the AV system and those of
the remote supplied with the AV system for basic operation (play,
stop, etc.).*2
is unit supports Bluetooth version 2.0 + EDR (Enhanced Data
Rate) for higher quality audio with less interference and lower power
consumption.
Example
This unit AV system with
DIGITAL MEDIA
PORT (Sony DAV
series, etc.)
Bluetooth mobile phone
or other Bluetooth audio
source device
*1Bluetooth audio source devices to be connected with this unit are required to
support A2DP (Advanced Audio Distribution Prole).
*2Bluetooth audio source devices to be connected with this unit are required to
support AVRCP (Audio/Video Remote Control Prole).
Notes
DIGITAL MEDIA PORT is occasionally abbreviated as DMPORT.
For details on how to operate the devices to be connected, refer to the operating
instructions supplied with each device.
For details regarding compatible Bluetooth devices, visit the following URL.
Customers in Europe
http://support.sony-europe.com

5
GB
TDM-BT10 [GB] 4-122-062-11(1)
How to use the unit
1. Pairing
Register a Bluetooth mobile phone and this unit with each other.
RESET
Bluetooth
mobile phone
This unit
Pairing AV system
For more details, see page 8.
2. Bluetooth connection
Operate the Bluetooth mobile phone to make the Bluetooth
connection.
RESET
Connection
3. Listening to music
Enjoy listening to music played on a Bluetooth mobile phone
through an AV system connected to this unit. Playback, stop,
or pause operation is possible with the control buttons on the
connected AV system and those of the remote supplied with the
AV system.
RESET
Stereo audio signal
(Streaming)
For more details, see page 11.

TDM-BT10 [GB] 4-122-062-11(1)
6
GB
Getting Started
Unpacking
Bluetooth Wireless Audio Adapter (1)
Operating Instructions (1)
Location of parts
OPR button (page 8, 12)
DIGITAL MEDIA PORT cable (page 7)
RESET button (page 19)
Status indicator
Status Status indicator
Ready Lights up for 2 seconds, and then turns o
Pairing mode Flashes very quickly*
Connection possible Flashes slowly*
Connecting Constantly on
Disconnecting Flashes quickly*
*e indicator turns o when the DMPORT function is not selected at the
connected AV system.

7
GB
TDM-BT10 [GB] 4-122-062-11(1)
Connecting to an AV system
1 Connect the DIGITAL MEDIA PORT cable of this unit to the
DIGITAL MEDIA PORT (DMPORT) jack of an AV system.
Make sure the AV system is turned o before connecting.
To DIGITAL
MEDIA PORT
jack
This unit
AV system
Connect the cable so that both marks
are aligned. To remove the DIGITAL
MEDIA PORT cable from the DMPORT
jack, press both side buttons and pull
it out.
2 Turn on the AV system connected to this unit, and select
the DIGITAL MEDIA PORT function.
e indicator lights up for 2 seconds to indicate “Ready.”
For details on how to select the DIGITAL MEDIA PORT function,
refer to the operating instructions supplied with the AV system.

TDM-BT10 [GB] 4-122-062-11(1)
8
GB
Pairing
What is pairing?
Bluetooth devices need to be “paired” with each other beforehand.
Once Bluetooth devices are paired, there is no need for pairing again,
except in the following cases:
Pairing information is deleted aer repair, etc.
is unit can be paired with up to 8 Bluetooth audio source devices.
If a new device is paired thereaer, the device with the oldest
registration among the 8 paired devices is replaced by the new one.
is unit is initialized (page 19). All pairing information is deleted.
Check that the DMPORT function is selected at the connected AV
system before operating the unit.
1 Press and hold the OPR button for 3 seconds or more.
OPR
e indicator starts ashing very quickly and this unit enters pairing
mode.
Note
Pairing mode is canceled automatically if pairing is not achieved within
5 minutes, or manually by pressing the OPR button. If pairing mode is
canceled midway, start over from step 1.

9
GB
TDM-BT10 [GB] 4-122-062-11(1)
2 Perform pairing procedure on the Bluetooth audio source
device to detect this unit.
e list of detected devices appears on the display of the Bluetooth
audio source device.
is unit is displayed as “TDM-BT10.”
If “TDM-BT10” is not displayed, repeat from step 1.
Notes
When pairing, be sure to place both the Bluetooth devices within 1 m of
each other.
Some devices cannot display the list of detected devices.
To operate the Bluetooth audio source device, refer to the operating
instructions of the device.
3 Select “TDM-BT10”on the display of the Bluetooth audio
source device.
4 If Passkey* input is required on the Bluetooth audio
source device, input“0000”.
When Bluetooth pairing is complete, the indicator ashes slowly
and pairing information is memorized on this unit.
*Passkey may be called “Passcode,” “PIN code,” “PIN number,” or “Password.”
Continued

TDM-BT10 [GB] 4-122-062-11(1)
10
GB
5 Start the Bluetooth connection from the Bluetooth audio
source device.
Some Bluetooth audio source devices may connect with the unit
automatically when pairing is completed.
Note
If you disconnect this unit or the Bluetooth audio source device, before a
connection is complete, pairing information is not memorized, and pairing
will not be completed.
When pairing with a Bluetooth audio source device that cannot display a
list of detected devices or that has no display
You may pair the device by setting both this unit and the Bluetooth audio source
device to pairing mode. For details, refer to the operating instructions supplied
with the device.
If pairing is not complete
Start over from step 1.
Note
Passkey of this unit is xed to “0000”. is unit cannot be paired with a Bluetooth
audio source device whose Passkey is not “0000”.
Tip
To pair with other Bluetooth audio source devices, repeat steps 1to 5for each
device.

11
GB
TDM-BT10 [GB] 4-122-062-11(1)
Using the Unit
Listening to music
is unit supports the SCMS-T content protection method. You can
listen to music or audio content protected by this method when the
connected Bluetooth audio source device supports the SCMS-T content
protection.
Check the following before operating the unit.
e Bluetooth audio source device is turned on.
Pairing of this unit and the Bluetooth audio source device is complete.
e Bluetooth audio source device supports the transmitting music
function (prole: A2DP*).
*For detail on proles, see page 18.
e DMPORT function is selected at the connected AV system.
1 Check to see if the indicator ashes slowly, indicating
connection is possible.
Note
If the indicator turns o, press the OPR button momentarily, or perform the
pairing procedure again.
2 Start the Bluetooth connection from the Bluetooth audio
source device.
To operate the Bluetooth audio source device, refer to the operating
instructions of the device.
3 Start music playback on the Bluetooth audio source
device.
Note
Aer connection is complete, the indicator becomes constantly on.
Continued

TDM-BT10 [GB] 4-122-062-11(1)
12
GB
To nish connecting
Terminate the Bluetooth connection by any of the operations below.
Operate the Bluetooth audio source device to terminate the connection. For
details, refer to the operating instructions supplied with the device.
Turn o the Bluetooth audio source device or the AV system.
Press the OPR button momentarily. When the disconnection is complete, the
indicator ashes slowly.
Note
In the following cases, you need to make the Bluetooth connection again.
e Bluetooth connection is disconnected once.
e power of the Bluetooth audio source device does not turn on, or the
Bluetooth signal is o.
e Bluetooth audio source device is in sleep mode.
e Bluetooth connection has not been established.
To turn o the Bluetooth signal
Even if you stop Bluetooth communication with the Bluetooth audio
source device, this unit continues to send out signals. You can stop the
signal completely by the operations below.
When the indicator is on (When the Bluetooth connection is established):
Press momentarily the OPR button to stop Bluetooth communication with the
Bluetooth audio source device. (e indicator ashes.) en press momentarily
the OPR button again to turn o the signal from the unit. (e indicator turns
o.)
When the indicator is ashing (When the Bluetooth connection is possible):
Press momentarily the OPR button to turn o the signal from the unit. (e
indicator turns o.)

13
GB
TDM-BT10 [GB] 4-122-062-11(1)
Controlling the Bluetooth audio source device
– AVRCP
If the Bluetooth audio source device connected with this unit supports
AVRCP (Audio/Video Remote Control Prole), you can operate the
Bluetooth audio source device with the control buttons on the AV
system and those of the remote supplied with the AV system.
Refer to the operating instructions supplied with the Bluetooth audio
source device on how to operate it.
Note
Operation of the Bluetooth audio source device by this unit will vary depending on
its specication.
Button Function
Start playback
/Pause/Stop
Short Press of
/Skip to previous/next
Long Press of
/Fast-rewind/Fast-forward
/Fast-rewind/Fast-forward
Depending on the Bluetooth audio source devices, the operation may dier.

TDM-BT10 [GB] 4-122-062-11(1)
14
GB
Additional Information
Precautions
Bluetooth wireless technology
operates within a range of about
10 m. Maximum communication
range may vary depending on
obstacles (person, metal, wall, etc.)
or electromagnetic environment.
IDSET
RX
TX
OPR
This unit
Steel cabinet
Optimal performance
Limited performance
Bluetooth audio
source device
e following conditions may
aect the sensitivity of Bluetooth
communication.
ere is an obstacle such as a
person, metal, or wall between
this unit and Bluetooth audio
source device.
A device using 2.4 GHz
frequency, such as a wireless
LAN device, cordless telephone,
or microwave oven, is in use
near this unit.
is unit is installed horizontally
on a desk made of steel.
Because Bluetooth devices and
wireless LAN (IEEE802.11b/g) use
the same frequency, microwave
interference may occur and
resulting in communication speed
deterioration, noise, or invalid
connection if this unit is used near
a wireless LAN device. In such a
case, perform the following.
Use this unit at least 10 m away
from the wireless LAN device.
If this unit is used within 10 m
of a wireless LAN device, turn
o the wireless LAN device.
Install this unit and Bluetooth
audio source device as near to
each other as possible.
Microwaves emitting from a
Bluetooth device may aect the
operation of electronic medical
devices. Turn o the AV system
connected to this unit and other
Bluetooth devices in the following
locations, as it may cause an
accident.
where inammable gas is
present, in a hospital, train,
airplane, or a gas (petrol) station
near automatic doors or a re
alarm
Refer to “To turn o the Bluetooth
signal” (page 12) for further details
regarding how to quit Bluetooth
connection of this unit.

15
GB
TDM-BT10 [GB] 4-122-062-11(1)
is unit supports security
capabilities that comply with the
Bluetooth standard to provide
a secure connection when the
Bluetooth wireless technology
is used, but security may not be
enough depending on the setting.
Be careful when communicating
using Bluetooth wireless
technology.
We do not take any responsibility
for the leakage of information
during Bluetooth communication.
Connection with all Bluetooth
devices cannot be guaranteed.
A device featuring Bluetooth
function is required to conform
to the Bluetooth standard
specied by Bluetooth SIG, and
be authenticated.
Even if the connected device
conforms to the above
mentioned Bluetooth standard,
some devices may not be
connected or work correctly,
depending on the features or
specications of the device.
Depending on the device to be
connected, it may require some
time to start communication.
On safety
Do not drop, hit, or otherwise
expose the unit to strong shock of
any kind. is could damage the
product.
Do not disassemble or attempt to
open any parts of the unit.
On placement
Do not place the unit in any of the
following locations.
Direct sunlight, near a heater,
or other extremely high-
temperature location
Dusty location
An unsteady or inclined surface
Location exposed to large
amounts of vibration
Bathroom or other high-
humidity location
In a car subject to the direct rays
of the sun
Notes when using with a
mobile phone
You cannot use this unit to talk over
the telephone, even if the Bluetooth
connection between this unit and a
mobile phone is established.
For details on operation of your
mobile phone when receiving a
telephone call while transmitting
music using the Bluetooth
connection, refer to the operating
instructions supplied with the
mobile phone.
Others
If you have any questions or
problems concerning this unit that
are not covered in this manual,
please consult your nearest Sony
dealer.
Should any problem persist, consult
your nearest Sony dealer.

TDM-BT10 [GB] 4-122-062-11(1)
16
GB
Troubleshooting
If you run into any problems using this unit, use the following checklist.
Should any problem persist, consult your nearest Sony dealer.
No sound
Check the connection between
this unit and the AV system.
Check that both this unit and the
Bluetooth audio source device are
turned on.
Ensure that this unit is not too
far from the Bluetooth audio
source device, or this unit is
not receiving interference from
a wireless LAN, other 2.4 GHz
wireless device, or microwave
oven.
Check that the Bluetooth
connection is established
properly between this unit and
the Bluetooth audio source
device.
Turn up the volume of the AV
system.
Turn up the volume of the
Bluetooth audio source device
as high as possible to the extent
that sound is not distorted. For
details on volume adjustment,
refer to the operating instructions
supplied with the Bluetooth audio
source device.
Pair this unit and the Bluetooth
audio source device again.
Check that music is being played
on the Bluetooth audio source
device.
Low sound level
Turn up the volume of the
Bluetooth audio source device
as high as possible to the extent
that sound is not distorted. For
details on volume adjustment,
refer to the operating instructions
supplied with the Bluetooth audio
source device.
Turn up the volume of the AV
system.
Distorted sound
Turn o the bass boost function
or equalizer function of the
Bluetooth audio source device.
Turn down the volume of the
Bluetooth audio source device
to the point where the sound is
no longer distorted. For details,
refer to the operating instructions
supplied with the Bluetooth audio
source device.

17
GB
TDM-BT10 [GB] 4-122-062-11(1)
Sound skips or the
correspondence distance
is short.
If a device that generates
electromagnetic radiation, such as
a wireless LAN, other Bluetooth
device(s), or a microwave oven
is nearby, move away from such
sources.
Remove any obstacle between
this unit and the Bluetooth audio
source device or move away from
the obstacle.
Locate this unit and the Bluetooth
audio source device(s) as near as
possible.
Re-position this unit.
Re-position the Bluetooth audio
source device.
Pairing cannot be done.
Bring this unit and the Bluetooth
audio source device closer
together.
Verify Bluetooth audio source
device has passkey of “0000”.
Turn o the Bluetooth function
of all other unused Bluetooth
device(s).
The Bluetooth audio
source device cannot
connect to this unit.
Turn o the Bluetooth function
of all other unused Bluetooth
device(s).
Sound is delayed.
If you watch a TV or a DVD
through Bluetooth connection via
this unit, sound may lag behind
the picture.
Continued

TDM-BT10 [GB] 4-122-062-11(1)
18
GB
Communication system
and compatible Bluetooth
prole of this unit
Prole is standardization of the
function for each Bluetooth
device specication. is unit
and the Bluetooth audio source
device need to support the
following Bluetooth version and
proles to work together:
Communication system: Bluetooth
Specication version 2.0 + EDR
Compatible Bluetooth proles:
A2DP (Advanced Audio
Distribution Prole)
AVRCP (Audio/Video Remote
Control Prole)
What is Bluetooth
technology?
Bluetooth wireless technology
is a short-range wireless
technology that enables wireless
data communication between
digital devices, such as a mobile
phone or digital music player.
Bluetooth wireless technology
operates within a range of about
10 m.
Connecting two devices as
necessary is common, but some
devices can be connected to
multiple devices at the same
time.*
You do not need to use a
cable for connection since
Bluetooth technology is a
wireless technology, nor is it
necessary for the devices to face
one another, such is the case
with infrared technology. For
example, you can use such a
device in a bag or pocket.
Bluetooth wireless technology is
a global standard supported by
thousands of companies. ese
companies produce products
that meet the global standard.
*is unit cannot be connected to
multiple devices at the same time.

19
GB
TDM-BT10 [GB] 4-122-062-11(1)
Initializing
You can reset this unit to its default setting and delete all pairing
information.
1 If the Bluetooth connection has been established
between this unit and the Bluetooth audio source device,
press the OPR button to stop Bluetooth communication
with the Bluetooth audio source device.
2 Use a thin pointed object (such as a paper clip) to press
the RESET button to initialize this unit.
e indicator ashes twice, and this unit is reset to the default.
All pairing information is deleted.

TDM-BT10 [GB] 4-122-062-12(1)
20
GB
Specications
General
Communication system
Bluetooth Specication version 2.0 +
EDR (Enhanced Data Rate)
Output
Bluetooth Specication Power Class 2
Maximum communication range
Line of sight approx. 10 m*1
Frequency band
2.4 GHz band (2.4000 GHz 2.4835
GHz)
Modulation method
FHSS
Compatible Bluetooth proles*2
A2DP (Advanced Audio Distribution
Prole)
AVRCP (Audio/Video Remote
Control Prole)
Supported codecs*3
SBC*4, MP3
Supported content protection
method
SCMS-T
Transmission range (A2DP)
20 20,000 Hz (Sampling frequency
44.1 kHz)
DIGITAL MEDIA PORT connector
18 pin
DIGITAL MEDIA PORT cable length
Approx. 1 m
Power requirements
DC 5 V, 0.1 A (via DIGITAL MEDIA
PORT)
Dimensions
Approx. dia. 44 × 16 mm high
Mass
Approx. 55 g (including cable)
*1e actual range will vary
depending on factors such
as obstacles between devices,
magnetic elds around a
microwave oven, static electricity,
reception sensitivity, antenna’s
(aerial) performance, operating
system, soware application, etc.
*2Bluetooth standard proles
indicate the purpose of Bluetooth
communication between devices.
*3Codec: Audio signal compression
and conversion format
*4Subband Codec
MPEG Layer-3 audio coding
technology and patents licensed from
Fraunhofer IIS and omson.
“DIGITAL MEDIA PORT” and
“DMPORT” are names for the
standard specication used to
connect various portable audio
devices to AV products from Sony
Corporation.
Design and specications are subject
to change without notice.
