— 1 —
TA-AV661
US Model
SPECIFICATIONS
AV CONTROL INTEGRATED AMPLIFIER
MICROFILM
SERVICE MANUAL

— 2 —
TABLE OF CONTENTS
Section Title Page
SECTION 1.GENERAL ...................................................... 3
SECTION 2.DIAGRAMS
2-1. Circuit Boards Location ..................................................... 4
2-2. Printed Wiring Board — Display Section — ..................... 6
2-3. Schematic Diagram — Display Section — ........................ 9
2-4. IC Pin Function
• IC401 System Control (µPD78043AGF-033-3B9)........ 12
2-5. Schematic Diagram — Main Section — .......................... 13
2-6. Printed Wiring Board — Main Section — ....................... 17
SECTION 3. EXPLODED VIEWS
3-1. Front Panel Section .......................................................... 21
3-2. Back Panel Section ........................................................... 22
3-3. Chassis Section................................................................. 23
SECTION 4. ELECTRICAL PARTS LIST .................. 24
SAFETY CHECK-OUT
After correcting the original service problem, perform the
following safety checks before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage. Check
leakage as described below.
LEAKAGE
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers’ instructions to
use these instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit”
indication is 0.75 V, so analog meters must have an accurate
low-voltage scale. The Simpson 250 and Sanwa SH-63Trd
are examples of a passive VOM that is suitable. Nearly all
battery operated digital multimeters that have a 2V AC range
are suitable. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
To Exposed Metal
Parts on Set
0.15µF 1.5k AC
voltmeter
(0.75V)
Earth Ground
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED
LINE WITH MARK !ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
[Lighting of all FLs and LEDs]
While pressing 3button, connect the power supply plug to the
outlet, the FL tubes and LEDs light up.
[Key Check]
With all the FLs and LEDs lit, when the 3button and
WOOFER ON/OFF button are pressed simultaneously, “SET **”
is displayed.
When the 3button and WOOFER ON/OFF button are pressed
simultaneously again, the Key Check mode is set and “KEY 0” is
displayed.
Each time a button other than POWER is pressed, the display
will count up to “KEY 30”.
A button already pressed will not be counted when pressed again.
When the button is pressed for the 31st time, “AMP” is displayed
and the key check mode is ended.
Note: The ** of “SET **” differs according to the version of the
microprocessor.
To exit the test mode, press the POWER button.
• Abbreviation
FL : Fluorescent Indicator Tube

— 3 —
SECTION 2
GENERAL
FRONT PANEL
This section is extracted from
instruction manual.
REAR PANEL
12345 6 789!º
!¡ !™!£!¢ !∞ !§ !¶ !• !ª @º @¡ @™@£ @¢
!£ PRESET MODE buttons
(MEMORY, USER, SOUND FIELD)
!¢ VIDEO 1 button
!∞ VIDEO 2 button
!§ VIDEO 3 button
!¶ VIDEO 4 button
!• TAPE button
!ª CD button
@º TUNER button
@¡ PHONO button
@™ EQ FLAT button
@£ WOOFER ON/OFF button
@¢ VIDEO 4 INPUT jack
(VIDEO, AUDIO L/R)
1POWER button
2CENTER MODE button
3DOLBY PRO LOGIC indicator
4SURROUND MODE buttons
(DOLBY, HALL, SIMULATED)
5/ /¢/›/ button
6Display Window
7CONTROL MODE buttons
(EQ, CENTER, REAR, WOOFER)
8Numeric buttons (1-5)
9SUPER WOOFER indicator
!º MASTER VOLUME knob
!¡ HEADPHONES jack
!™ DISPLAY button

— 21 —
SECTION 3
EXPLODEDVIEWS
NOTE:
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in
the exploded views are not supplied.
• Hardware (# mark) list and accessories and pack-
ing materials are given in the last of this parts list.
3-1. FRONT PANEL SECTION
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
1 4-980-107-01 KNOB (VOL)
2 3-350-426-01 SPRING, RING
3 4-977-358-11 CUSHION (8X12.5)
4 4-979-937-11 FILTER
5 4-979-942-21 WINDOW
6 4-979-937-01 FILTER
7 4-963-404-21 EMBLEM (5-A), SONY
8 4-979-934-11 PANEL, FRONT
*9 4-982-462-01 HOUSE, LED
10 4-980-108-01 BUTTON (PRE)
11 4-979-930-01 BUTTON (F-8)
12 4-979-931-01 INDICATOR
13 4-979-936-01 BUTTON (P-T)
*14 A-4389-305-A DISP BOARD, COMPLETE
*15 4-921-941-01 CUSHION (FL)
*16 4-971-014-11 HOLDER, FL TUBE
17 1-769-867-11 WIRE (FLAT TYPE) (5 CORE)
18 4-951-620-01 SCREW (2.6X8), +BVTP
19 1-773-286-11 WIRE (FLAT TYPE) (29 CORE)
*20 1-661-167-11 VR BOARD
21 3-704-366-01 SCREW (CASE) (M3X8)
*22 4-982-682-01 CASE (414532)
23 4-979-932-01 ESCUTCHEON (V)
FL401 1-517-513-11 INDICATOR TUBE, FLUORESCENT
1
23
5
7
8
10
11
12
12
13
14
15
16
17
18
19
20 21
21
21
#1
#1
FL401
15
69
9
4
Supplied with RV401
22
23
Thecomponentsidentifiedbymark!
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.

— 22 —
3-2. BACK PANEL SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
*52 1-659-607-11 VIDEO 4 BOARD
*53 A-4389-312-A EQ BOARD, COMPLETE
*54 1-661-163-11 REAR SP BOARD
*55 1-659-613-11 VIDEO BOARD
*56 4-979-954-52 PANEL, BACK
*57 3-703-244-00 BUSHING (2104), CORD
58 3-704-515-01 SCREW (BV/RING)
!CNP901 1-690-609-21 CORD, POWER
The componentsidentified bymark !
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.
56
57
CNP901
#1
#1
#1
#1
54
#1
#1
58
#1
#1
55
53
not supplied
52

— 23 —
3-3. CHASSIS SECTION
#1
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
*101 4-979-946-01 PLATE (432), BOTTOM
102 X-3371-405-1 FOOT (SMALL) ASSY
*103 1-661-168-11 HP BOARD
*104 1-661-166-11 T-2 BOARD
*105 1-661-165-11 T-1 BOARD
106 1-769-867-11 WIRE (FLAT TYPE) (5 CORE)
*107 1-661-164-11 POWER BOARD
*108 A-4389-302-A MAIN BOARD, COMPLETE
109 1-773-286-11 WIRE (FLAT TYPE) (29 CORE)
!F904 1-533-310-11 FUSE, GLASS TUBE (6.3A 125V)
!F905 1-533-310-11 FUSE, GLASS TUBE (6.3A 125V)
!F906 1-533-310-11 FUSE, GLASS TUBE (6.3A 125V)
!F907 1-533-310-11 FUSE, GLASS TUBE (6.3A 125V)
!T901 1-429-458-11 TRANSFORMER, POWER
101
102
103
104 105
108 109
#1
#1
#1
#1
#1 #1
#1
#1
#1
#1
#1
#1 #1
#1
#2 #3
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
106
#1 #1
T901
#2
107
F905
F906
F907
F904
#1
#1
Thecomponentsidentified bymark!
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.

— 24 —
Note:
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 4
ELECTRICAL PARTS LIST
*A-4389-305-A DISP BOARD, COMPLETE
********************
*4-921-941-01 CUSHION (FL)
*4-971-014-11 HOLDER, FL TUBE
< CAPACITOR >
C401 1-125-486-11 DOUBLE LAYERS 0.22F 5.5V
C402 1-104-664-11 ELECT 47uF 20% 25V
C403 1-161-494-00 CERAMIC 0.022uF 25V
C404 1-126-964-11 ELECT 10uF 20% 50V
C405 1-124-903-11 ELECT 1uF 20% 50V
C406 1-161-494-00 CERAMIC 0.022uF 25V
C407 1-136-173-00 FILM 0.47uF 5% 50V
C408 1-161-494-00 CERAMIC 0.022uF 25V
C409 1-161-494-00 CERAMIC 0.022uF 25V
C411 1-124-903-11 ELECT 1uF 20% 50V
C412 1-124-903-11 ELECT 1uF 20% 50V
C413 1-161-494-00 CERAMIC 0.022uF 25V
C417 1-162-306-11 CERAMIC 0.01uF 30% 16V
C418 1-162-306-11 CERAMIC 0.01uF 30% 16V
C421 1-162-290-31 CERAMIC 470PF 10% 50V
C422 1-162-290-31 CERAMIC 470PF 10% 50V
C423 1-162-290-31 CERAMIC 470PF 10% 50V
C424 1-162-290-31 CERAMIC 470PF 10% 50V
C425 1-162-290-31 CERAMIC 470PF 10% 50V
C501 1-126-956-91 ELECT 0.1uF 20% 50V
C502 1-130-489-00 MYLAR 0.033uF 5% 50V
C503 1-124-464-11 ELECT 0.22uF 20% 50V
C504 1-126-956-91 ELECT 0.1uF 20% 50V
C505 1-130-483-00 MYLAR 0.01uF 5% 50V
C506 1-130-493-00 MYLAR 0.068uF 5% 50V
C507 1-126-956-91 ELECT 0.1uF 20% 50V
C508 1-130-480-00 MYLAR 0.0056uF 5% 50V
C509 1-130-489-00 MYLAR 0.033uF 5% 50V
C510 1-126-956-91 ELECT 0.1uF 20% 50V
C511 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C512 1-130-483-00 MYLAR 0.01uF 5% 50V
C513 1-126-956-91 ELECT 0.1uF 20% 50V
C514 1-162-294-31 CERAMIC 0.001uF 10% 50V
C515 1-130-478-00 MYLAR 0.0039uF 5% 50V
C516 1-126-956-91 ELECT 0.1uF 20% 50V
C517 1-162-288-31 CERAMIC 330PF 10% 50V
C518 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C519 1-126-956-91 ELECT 0.1uF 20% 50V
C520 1-162-286-31 CERAMIC 220PF 10% 50V
C521 1-124-925-11 ELECT 2.2uF 20% 100V
< CONNECTOR >
*CN401 1-568-848-11 SOCKET, CONNECTOR 5P
*CN402 1-568-871-11 SOCKET, CONNECTOR 29P
CN405 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< DIODE >
D401 8-719-987-63 DIODE 1N4148M
D402 8-719-987-63 DIODE 1N4148M
D403 8-719-987-63 DIODE 1N4148M
D404 8-719-987-63 DIODE 1N4148M
D405 8-719-987-63 DIODE 1N4148M
D406 8-719-014-73 DIODE UZP-5.6BC-TP
D407 8-719-933-36 DIODE HZS6B1L
D411 8-719-301-49 DIODE SEL2810A (HALL)
D412 8-719-301-49 DIODE SEL2810A (SIMULATED)
D413 8-719-301-49 DIODE SEL2810A (DOLBY)
D414 8-719-032-98 DIODE SEL5820A (DOLBY PROLOGIC)
D415 8-719-032-98 DIODE SEL5820A (DOLBY PROLOGIC)
D416 8-719-032-98 DIODE SEL5820A (SUPER WOOFER)
D417 8-719-032-98 DIODE SEL5820A (SUPER WOOFER)
D418 8-719-301-49 DIODE SEL2810A (EQ)
D419 8-719-301-49 DIODE SEL2810A (CENTER)
D420 8-719-301-49 DIODE SEL2810A (REAR)
D421 8-719-301-49 DIODE SEL2810A (WOOFER)
D422 8-719-987-63 DIODE 1N4148M
D423 8-719-987-63 DIODE 1N4148M
D424 8-719-987-63 DIODE 1N4148M
D425 8-719-987-63 DIODE 1N4148M
D431 8-719-987-63 DIODE 1N4148M
D501 8-719-987-63 DIODE 1N4148M
D502 8-719-987-63 DIODE 1N4148M
D503 8-719-987-63 DIODE 1N4148M
D504 8-719-987-63 DIODE 1N4148M
D505 8-719-987-63 DIODE 1N4148M
D506 8-719-987-63 DIODE 1N4148M
D507 8-719-987-63 DIODE 1N4148M
DISP
The componentsidentified bymark!
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board
name.

— 25 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< FLUORESCENT INDICATOR >
FL401 1-517-513-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC401 8-759-366-87 IC uPD78043AGF-033-3B9
IC402 8-749-920-83 IC GP1U52XB
IC403 8-759-000-48 IC MC14052BCP
< COIL >
L401 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q401 8-729-900-36 TRANSISTOR DTC124ES
Q402 8-729-900-63 TRANSISTOR DTA124ES
Q403 8-729-900-36 TRANSISTOR DTC124ES
Q404 8-729-900-36 TRANSISTOR DTC124ES
Q405 8-729-900-36 TRANSISTOR DTC124ES
Q406 8-729-900-36 TRANSISTOR DTC124ES
Q407 8-729-900-36 TRANSISTOR DTC124ES
Q408 8-729-900-36 TRANSISTOR DTC124ES
Q411 8-729-900-63 TRANSISTOR DTA124ES
Q412 8-729-900-63 TRANSISTOR DTA124ES
Q413 8-729-900-63 TRANSISTOR DTA124ES
Q414 8-729-900-63 TRANSISTOR DTA124ES
Q415 8-729-900-63 TRANSISTOR DTA124ES
Q416 8-729-900-63 TRANSISTOR DTA124ES
Q417 8-729-900-63 TRANSISTOR DTA124ES
Q418 8-729-900-63 TRANSISTOR DTA124ES
Q431 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R401 1-247-807-31 CARBON 100 5% 1/4W
R402 1-249-429-11 CARBON 10K 5% 1/4W
R403 1-247-807-31 CARBON 100 5% 1/4W
R404 1-249-429-11 CARBON 10K 5% 1/4W
R405 1-247-807-31 CARBON 100 5% 1/4W
R406 1-247-807-31 CARBON 100 5% 1/4W
R407 1-247-807-31 CARBON 100 5% 1/4W
R408 1-247-807-31 CARBON 100 5% 1/4W
R409 1-247-807-31 CARBON 100 5% 1/4W
R410 1-247-807-31 CARBON 100 5% 1/4W
R411 1-247-807-31 CARBON 100 5% 1/4W
R412 1-247-807-31 CARBON 100 5% 1/4W
R413 1-247-807-31 CARBON 100 5% 1/4W
R414 1-247-807-31 CARBON 100 5% 1/4W
R415 1-247-807-31 CARBON 100 5% 1/4W
R416 1-249-433-11 CARBON 22K 5% 1/4W
R417 1-249-429-11 CARBON 10K 5% 1/4W
R418 1-249-429-11 CARBON 10K 5% 1/4W
R419 1-249-429-11 CARBON 10K 5% 1/4W
R420 1-249-429-11 CARBON 10K 5% 1/4W
R421 1-247-903-00 CARBON 1M 5% 1/4W
R422 1-247-807-31 CARBON 100 5% 1/4W
R423 1-247-807-31 CARBON 100 5% 1/4W
R424 1-247-807-31 CARBON 100 5% 1/4W
R425 1-247-807-31 CARBON 100 5% 1/4W
R428 1-247-807-31 CARBON 100 5% 1/4W
R429 1-247-807-31 CARBON 100 5% 1/4W
R430 1-247-807-31 CARBON 100 5% 1/4W
R431 1-247-807-31 CARBON 100 5% 1/4W
R432 1-247-807-31 CARBON 100 5% 1/4W
R433 1-247-807-31 CARBON 100 5% 1/4W
R434 1-249-429-11 CARBON 10K 5% 1/4W
R435 1-249-429-11 CARBON 10K 5% 1/4W
R436 1-249-429-11 CARBON 10K 5% 1/4W
R440 1-249-437-11 CARBON 47K 5% 1/4W
R441 1-249-437-11 CARBON 47K 5% 1/4W
R442 1-249-437-11 CARBON 47K 5% 1/4W
R443 1-249-437-11 CARBON 47K 5% 1/4W
R444 1-249-437-11 CARBON 47K 5% 1/4W
R445 1-249-437-11 CARBON 47K 5% 1/4W
R446 1-249-437-11 CARBON 47K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R448 1-249-437-11 CARBON 47K 5% 1/4W
R449 1-249-437-11 CARBON 47K 5% 1/4W
R450 1-249-437-11 CARBON 47K 5% 1/4W
R451 1-249-437-11 CARBON 47K 5% 1/4W
R452 1-249-437-11 CARBON 47K 5% 1/4W
R453 1-249-437-11 CARBON 47K 5% 1/4W
R454 1-249-437-11 CARBON 47K 5% 1/4W
R455 1-249-437-11 CARBON 47K 5% 1/4W
R456 1-249-437-11 CARBON 47K 5% 1/4W
R457 1-249-437-11 CARBON 47K 5% 1/4W
R458 1-247-807-31 CARBON 100 5% 1/4W
R459 1-247-807-31 CARBON 100 5% 1/4W
R460 1-249-413-11 CARBON 470 5% 1/4W F
R463 1-247-807-31 CARBON 100 5% 1/4W
R464 1-247-807-31 CARBON 100 5% 1/4W
R466 1-249-396-11 CARBON 18 5% 1/4W F
R469 1-249-419-11 CARBON 1.5K 5% 1/4W F
R470 1-249-401-11 CARBON 47 5% 1/4W F
R471 1-249-403-11 CARBON 68 5% 1/4W F
R472 1-247-807-31 CARBON 100 5% 1/4W
R473 1-249-407-11 CARBON 150 5% 1/4W F
R474 1-249-407-11 CARBON 150 5% 1/4W F
R475 1-249-409-11 CARBON 220 5% 1/4W F
R476 1-249-411-11 CARBON 330 5% 1/4W
R477 1-249-413-11 CARBON 470 5% 1/4W F
R478 1-249-415-11 CARBON 680 5% 1/4W F
R479 1-249-417-11 CARBON 1K 5% 1/4W F
R480 1-249-419-11 CARBON 1.5K 5% 1/4W F
R481 1-249-421-11 CARBON 2.2K 5% 1/4W F
R482 1-249-423-11 CARBON 3.3K 5% 1/4W F
DISP

— 26 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R483 1-249-427-11 CARBON 6.8K 5% 1/4W F
R484 1-249-431-11 CARBON 15K 5% 1/4W
R485 1-249-419-11 CARBON 1.5K 5% 1/4W F
R486 1-249-401-11 CARBON 47 5% 1/4W F
R487 1-249-403-11 CARBON 68 5% 1/4W F
R488 1-247-807-31 CARBON 100 5% 1/4W
R489 1-249-407-11 CARBON 150 5% 1/4W F
R490 1-249-407-11 CARBON 150 5% 1/4W F
R491 1-249-409-11 CARBON 220 5% 1/4W F
R492 1-249-411-11 CARBON 330 5% 1/4W
R493 1-249-413-11 CARBON 470 5% 1/4W F
R494 1-249-415-11 CARBON 680 5% 1/4W F
R495 1-249-417-11 CARBON 1K 5% 1/4W F
R496 1-249-419-11 CARBON 1.5K 5% 1/4W F
R497 1-249-421-11 CARBON 2.2K 5% 1/4W F
R498 1-249-423-11 CARBON 3.3K 5% 1/4W F
R499 1-249-427-11 CARBON 6.8K 5% 1/4W F
R500 1-249-431-11 CARBON 15K 5% 1/4W
R501 1-247-903-00 CARBON 1M 5% 1/4W
R502 1-247-881-00 CARBON 120K 5% 1/4W
R503 1-249-429-11 CARBON 10K 5% 1/4W
R504 1-247-903-00 CARBON 1M 5% 1/4W
R505 1-247-881-00 CARBON 120K 5% 1/4W
R506 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-247-903-00 CARBON 1M 5% 1/4W
R508 1-249-441-11 CARBON 100K 5% 1/4W
R509 1-249-429-11 CARBON 10K 5% 1/4W
R510 1-247-903-00 CARBON 1M 5% 1/4W
R511 1-249-441-11 CARBON 100K 5% 1/4W
R512 1-249-429-11 CARBON 10K 5% 1/4W
R513 1-247-903-00 CARBON 1M 5% 1/4W
R514 1-249-440-11 CARBON 82K 5% 1/4W
R515 1-249-430-11 CARBON 12K 5% 1/4W
R516 1-247-903-00 CARBON 1M 5% 1/4W
R517 1-249-441-11 CARBON 100K 5% 1/4W
R518 1-249-428-11 CARBON 8.2K 5% 1/4W F
R519 1-247-903-00 CARBON 1M 5% 1/4W
R520 1-249-440-11 CARBON 82K 5% 1/4W
R521 1-249-417-11 CARBON 1K 5% 1/4W F
R522 1-249-441-11 CARBON 100K 5% 1/4W
< SWITCH >
S469 1-554-303-21 SWITCH, TACTILE (POWER)
S470 1-554-303-21 SWITCH, TACTILE (CENTER MODE)
S471 1-554-303-21 SWITCH, TACTILE (DOLBY)
S472 1-554-303-21 SWITCH, TACTILE (HALL)
S473 1-554-303-21 SWITCH, TACTILE (SIMULATED)
S474 1-554-303-21 SWITCH, TACTILE (DISPLAY)
S475 1-554-303-21 SWITCH, TACTILE (EQ FLAT)
S476 1-554-303-21 SWITCH, TACTILE (¢)
S477 1-554-303-21 SWITCH, TACTILE (›)
S478 1-554-303-21 SWITCH, TACTILE ( )
DISP
S479 1-554-303-21 SWITCH, TACTILE ( )
S480 1-554-303-21 SWITCH, TACTILE (EQ)
S481 1-554-303-21 SWITCH, TACTILE (CENTER)
S482 1-554-303-21 SWITCH, TACTILE (REAR)
S483 1-554-303-21 SWITCH, TACTILE (WOOFER)
S484 1-554-303-21 SWITCH, TACTILE (WOOFER ON/OFF)
S485 1-554-303-21 SWITCH, TACTILE (1 (ROCK))
S486 1-554-303-21 SWITCH, TACTILE (2 (POPS))
S487 1-554-303-21 SWITCH, TACTILE (3 (CLASSIC))
S488 1-554-303-21 SWITCH, TACTILE (4 (MOVIE))
S489 1-554-303-21 SWITCH, TACTILE (5 (GAME))
S490 1-554-303-21 SWITCH, TACTILE (PHONO)
S491 1-554-303-21 SWITCH, TACTILE (TUNER)
S492 1-554-303-21 SWITCH, TACTILE (CD)
S493 1-554-303-21 SWITCH, TACTILE (TAPE)
S494 1-554-303-21 SWITCH, TACTILE (VIDEO 1)
S495 1-554-303-21 SWITCH, TACTILE (VIDEO 2)
S496 1-554-303-21 SWITCH, TACTILE (VIDEO 3)
S497 1-554-303-21 SWITCH, TACTILE (VIDEO 4)
S498 1-554-303-21 SWITCH, TACTILE (USER)
S499 1-554-303-21 SWITCH, TACTILE (SOUND FIELD)
S500 1-554-303-21 SWITCH, TACTILE (MEMORY)
< VIBRATOR >
X401 1-577-101-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
*A-4389-312-A EQ BOARD, COMPLETE
******************
< CAPACITOR >
C220 1-162-294-31 CERAMIC 0.001uF 10% 50V
C221 1-162-306-11 CERAMIC 0.01uF 30% 16V
C222 1-162-306-11 CERAMIC 0.01uF 30% 16V
C235 1-130-493-00 MYLAR 0.068uF 5% 50V
C236 1-124-903-11 ELECT 1uF 20% 50V
C237 1-130-488-00 MYLAR 0.027uF 5% 50V
C238 1-124-902-00 ELECT 0.47uF 20% 50V
C239 1-130-483-00 MYLAR 0.01uF 5% 50V
C240 1-130-498-00 MYLAR 0.18uF 5% 50V
C241 1-130-478-00 MYLAR 0.0039uF 5% 50V
C242 1-130-493-00 MYLAR 0.068uF 5% 50V
C243 1-130-474-00 MYLAR 0.0018uF 5% 50V
C244 1-130-489-00 MYLAR 0.033uF 5% 50V
C245 1-162-292-31 CERAMIC 680PF 10% 50V
C246 1-130-484-00 MYLAR 0.012uF 5% 50V
C247 1-162-287-31 CERAMIC 270PF 10% 50V
C248 1-130-479-00 MYLAR 0.0047uF 5% 50V
C250 1-126-963-11 ELECT 4.7uF 20% 50V
C270 1-162-294-31 CERAMIC 0.001uF 10% 50V
C271 1-162-306-11 CERAMIC 0.01uF 30% 16V
EQ
¢
¢

— 27 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C272 1-162-306-11 CERAMIC 0.01uF 30% 16V
C275 1-124-907-11 ELECT 10uF 20% 50V
C276 1-124-907-11 ELECT 10uF 20% 50V
C277 1-126-961-11 ELECT 2.2uF 20% 50V
C285 1-130-493-00 MYLAR 0.068uF 5% 50V
C286 1-124-903-11 ELECT 1uF 20% 50V
C287 1-130-488-00 MYLAR 0.027uF 5% 50V
C288 1-124-902-00 ELECT 0.47uF 20% 50V
C289 1-130-483-00 MYLAR 0.01uF 5% 50V
C290 1-130-498-00 MYLAR 0.18uF 5% 50V
C291 1-130-478-00 MYLAR 0.0039uF 5% 50V
C292 1-130-493-00 MYLAR 0.068uF 5% 50V
C293 1-130-474-00 MYLAR 0.0018uF 5% 50V
C294 1-130-489-00 MYLAR 0.033uF 5% 50V
C295 1-162-292-31 CERAMIC 680PF 10% 50V
C296 1-130-484-00 MYLAR 0.012uF 5% 50V
C297 1-162-287-31 CERAMIC 270PF 10% 50V
C298 1-130-479-00 MYLAR 0.0047uF 5% 50V
C300 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
*CN109 1-766-719-11 CONNECTOR, BOARD TO BOARD 10P
< IC >
IC121 8-759-633-78 IC M5289P
IC122 8-759-633-78 IC M5289P
IC123 8-759-081-01 IC NJU7305L
< RESISTOR >
R221 1-247-895-00 CARBON 470K 5% 1/4W
R222 1-247-895-00 CARBON 470K 5% 1/4W
R223 1-247-895-00 CARBON 470K 5% 1/4W
R224 1-247-895-00 CARBON 470K 5% 1/4W
R225 1-247-895-00 CARBON 470K 5% 1/4W
R226 1-247-895-00 CARBON 470K 5% 1/4W
R227 1-247-895-00 CARBON 470K 5% 1/4W
R228 1-249-427-11 CARBON 6.8K 5% 1/4W F
R230 1-249-441-11 CARBON 100K 5% 1/4W
R271 1-247-895-00 CARBON 470K 5% 1/4W
R272 1-247-895-00 CARBON 470K 5% 1/4W
R273 1-247-895-00 CARBON 470K 5% 1/4W
R274 1-247-895-00 CARBON 470K 5% 1/4W
R275 1-247-895-00 CARBON 470K 5% 1/4W
R276 1-247-895-00 CARBON 470K 5% 1/4W
R277 1-247-895-00 CARBON 470K 5% 1/4W
R278 1-249-427-11 CARBON 6.8K 5% 1/4W F
R280 1-249-441-11 CARBON 100K 5% 1/4W
R291 1-249-416-11 CARBON 820 5% 1/4W F
R292 1-249-429-11 CARBON 10K 5% 1/4W
R293 1-249-416-11 CARBON 820 5% 1/4W F
R294 1-249-429-11 CARBON 10K 5% 1/4W
R295 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
*1-661-168-11 HP BOARD
*********
< CAPACITOR >
C811 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C812 1-164-159-11 CERAMIC 0.1uF 50V
C861 1-162-302-11 CERAMIC 0.0022uF 30% 16V
< CONNECTOR >
CN406 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
< JACK >
J801 1-569-113-11 JACK, LARGE TYPE (HEADPHONES)
**************************************************************
*A-4389-302-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-163-11 ELECT 4.7uF 20% 50V
C116 1-162-282-31 CERAMIC 100PF 10% 50V
C117 1-124-261-00 ELECT 10uF 20% 50V
C118 1-130-480-00 MYLAR 0.0056uF 5% 50V
C119 1-130-473-00 MYLAR 0.0015uF 5% 50V
C120 1-126-301-11 ELECT 1uF 20% 50V
C121 1-124-589-11 ELECT 47uF 20% 16V
C122 1-124-589-11 ELECT 47uF 20% 16V
C123 1-162-306-11 CERAMIC 0.01uF 30% 16V
C124 1-164-159-11 CERAMIC 0.1uF 50V
C125 1-164-159-11 CERAMIC 0.1uF 50V
C126 1-162-286-31 CERAMIC 220PF 10% 50V
C127 1-162-600-11 CERAMIC 4700PF 10% 16V
C128 1-136-165-00 FILM 0.1uF 5% 50V
C130 1-164-159-11 CERAMIC 0.1uF 50V
C131 1-126-963-11 ELECT 4.7uF 20% 50V
C133 1-126-963-11 ELECT 4.7uF 20% 50V
C135 1-101-005-00 CERAMIC 22000PF 50V
C136 1-130-491-00 MYLAR 0.047uF 5% 50V
C137 1-126-923-11 ELECT 220uF 20% 10V
C138 1-126-964-11 ELECT 10uF 20% 50V
C139 1-126-964-11 ELECT 10uF 20% 50V
C140 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-964-11 ELECT 10uF 20% 50V
C142 1-126-923-11 ELECT 220uF 20% 10V
C146 1-136-165-00 FILM 0.1uF 5% 50V
C147 1-136-165-00 FILM 0.1uF 5% 50V
C148 1-124-902-00 ELECT 0.47uF 20% 50V
MAIN
HPEQ

— 28 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C149 1-126-963-11 ELECT 4.7uF 20% 50V
C151 1-164-159-11 CERAMIC 0.1uF 50V
C152 1-164-159-11 CERAMIC 0.1uF 50V
C165 1-126-163-11 ELECT 4.7uF 20% 50V
C166 1-162-282-31 CERAMIC 100PF 10% 50V
C167 1-124-261-00 ELECT 10uF 20% 50V
C168 1-130-480-00 MYLAR 0.0056uF 5% 50V
C169 1-130-473-00 MYLAR 0.0015uF 5% 50V
C170 1-126-301-11 ELECT 1uF 20% 50V
C177 1-162-600-11 CERAMIC 4700PF 10% 16V
C181 1-126-963-11 ELECT 4.7uF 20% 50V
C183 1-126-963-11 ELECT 4.7uF 20% 50V
C185 1-124-902-00 ELECT 0.47uF 20% 50V
C186 1-126-963-11 ELECT 4.7uF 20% 50V
C187 1-136-167-00 FILM 0.15uF 5% 50V
C188 1-126-962-11 ELECT 3.3uF 20% 50V
C189 1-136-167-00 FILM 0.15uF 5% 50V
C190 1-136-167-00 FILM 0.15uF 5% 50V
C191 1-126-962-11 ELECT 3.3uF 20% 50V
C192 1-136-167-00 FILM 0.15uF 5% 50V
C193 1-126-963-11 ELECT 4.7uF 20% 50V
C194 1-124-902-00 ELECT 0.47uF 20% 50V
C195 1-126-963-11 ELECT 4.7uF 20% 50V
C196 1-124-902-00 ELECT 0.47uF 20% 50V
C197 1-136-165-00 FILM 0.1uF 5% 50V
C198 1-136-165-00 FILM 0.1uF 5% 50V
C199 1-126-967-11 ELECT 47uF 20% 16V
C200 1-124-902-00 ELECT 0.47uF 20% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-162-292-31 CERAMIC 680PF 10% 50V
C205 1-164-159-11 CERAMIC 0.1uF 50V
C206 1-162-286-31 CERAMIC 220PF 10% 50V
C207 1-124-925-11 ELECT 2.2uF 20% 100V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-162-306-11 CERAMIC 0.01uF 30% 16V
C211 1-124-903-11 ELECT 1uF 20% 50V
C212 1-130-489-00 MYLAR 0.033uF 5% 50V
C213 1-130-473-00 MYLAR 0.0015uF 5% 50V
C214 1-130-489-00 MYLAR 0.033uF 5% 50V
C215 1-126-923-11 ELECT 220uF 20% 10V
C216 1-126-923-11 ELECT 220uF 20% 10V
C217 1-164-159-11 CERAMIC 0.1uF 50V
C230 1-124-903-11 ELECT 1uF 20% 50V
C231 1-136-165-00 FILM 0.1uF 5% 50V
C232 1-124-903-11 ELECT 1uF 20% 50V
C233 1-136-165-00 FILM 0.1uF 5% 50V
C234 1-126-964-11 ELECT 10uF 20% 50V
C281 1-136-165-00 FILM 0.1uF 5% 50V
C282 1-124-903-11 ELECT 1uF 20% 50V
C283 1-136-165-00 FILM 0.1uF 5% 50V
MAIN
C284 1-126-964-11 ELECT 10uF 20% 50V
C301 1-126-964-11 ELECT 10uF 20% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-162-282-31 CERAMIC 100PF 10% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C311 1-124-902-00 ELECT 0.47uF 20% 50V
C312 1-136-172-00 FILM 0.39uF 5% 50V
C313 1-136-166-00 FILM 0.12uF 5% 50V
C315 1-124-902-00 ELECT 0.47uF 20% 50V
C321 1-126-964-11 ELECT 10uF 20% 50V
C322 1-104-664-11 ELECT 47uF 20% 25V
C323 1-164-159-11 CERAMIC 0.1uF 50V
C324 1-124-902-00 ELECT 0.47uF 20% 50V
C325 1-126-964-11 ELECT 10uF 20% 50V
C326 1-104-664-11 ELECT 47uF 20% 25V
C327 1-164-159-11 CERAMIC 0.1uF 50V
C328 1-124-902-00 ELECT 0.47uF 20% 50V
C330 1-126-964-11 ELECT 10uF 20% 50V
C331 1-104-664-11 ELECT 47uF 20% 25V
C332 1-164-159-11 CERAMIC 0.1uF 50V
C333 1-124-902-00 ELECT 0.47uF 20% 50V
C351 1-126-964-11 ELECT 10uF 20% 50V
C361 1-126-964-11 ELECT 10uF 20% 50V
C371 1-126-964-11 ELECT 10uF 20% 50V
C372 1-104-664-11 ELECT 47uF 20% 25V
C373 1-164-159-11 CERAMIC 0.1uF 50V
C374 1-124-902-00 ELECT 0.47uF 20% 50V
C375 1-126-964-11 ELECT 10uF 20% 50V
C376 1-104-664-11 ELECT 47uF 20% 25V
C377 1-164-159-11 CERAMIC 0.1uF 50V
C378 1-124-902-00 ELECT 0.47uF 20% 50V
C379 1-126-964-11 ELECT 10uF 20% 50V
C380 1-126-964-11 ELECT 10uF 20% 50V
C381 1-104-664-11 ELECT 47uF 20% 25V
C382 1-164-159-11 CERAMIC 0.1uF 50V
C701 1-126-963-11 ELECT 4.7uF 20% 50V
C702 1-162-286-31 CERAMIC 220PF 10% 50V
C703 1-162-286-31 CERAMIC 220PF 10% 50V
C704 1-126-963-11 ELECT 4.7uF 20% 50V
C705 1-162-191-31 CERAMIC 2.2PF 10% 50V
C706 1-126-967-11 ELECT 47uF 20% 50V
C707 1-136-165-00 FILM 0.1uF 5% 50V
C708 1-130-493-00 MYLAR 0.068uF 5% 50V
C711 1-124-667-11 ELECT 10uF 20% 100V
C712 1-124-667-11 ELECT 10uF 20% 100V
C713 1-124-667-11 ELECT 10uF 20% 100V
C714 1-126-923-11 ELECT 220uF 20% 10V
C731 1-126-963-11 ELECT 4.7uF 20% 50V
C732 1-162-286-31 CERAMIC 220PF 10% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-104-664-11 ELECT 47uF 20% 25V

— 29 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C735 1-162-191-31 CERAMIC 2.2PF 10% 50V
C736 1-126-967-11 ELECT 47uF 20% 50V
C737 1-136-165-00 FILM 0.1uF 5% 50V
C738 1-130-493-00 MYLAR 0.068uF 5% 50V
C740 1-126-968-11 ELECT 100uF 20% 50V
C741 1-126-964-11 ELECT 10uF 20% 50V
C742 1-126-964-11 ELECT 10uF 20% 50V
C743 1-126-968-11 ELECT 100uF 20% 50V
C744 1-126-964-11 ELECT 10uF 20% 50V
C751 1-126-963-11 ELECT 4.7uF 20% 50V
C752 1-162-286-31 CERAMIC 220PF 10% 50V
C753 1-162-286-31 CERAMIC 220PF 10% 50V
C754 1-126-963-11 ELECT 4.7uF 20% 50V
C755 1-162-191-31 CERAMIC 2.2PF 10% 50V
C756 1-126-967-11 ELECT 47uF 20% 50V
C757 1-136-165-00 FILM 0.1uF 5% 50V
C758 1-130-493-00 MYLAR 0.068uF 5% 50V
C781 1-126-963-11 ELECT 4.7uF 20% 50V
C782 1-162-286-31 CERAMIC 220PF 10% 50V
C783 1-162-286-31 CERAMIC 220PF 10% 50V
C784 1-104-664-11 ELECT 47uF 20% 25V
C785 1-162-191-31 CERAMIC 2.2PF 10% 50V
C786 1-126-967-11 ELECT 47uF 20% 50V
C787 1-136-165-00 FILM 0.1uF 5% 50V
C788 1-130-493-00 MYLAR 0.068uF 5% 50V
C801 1-126-963-11 ELECT 4.7uF 20% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-294-31 CERAMIC 0.001uF 10% 50V
C804 1-162-191-31 CERAMIC 2.2PF 10% 50V
C805 1-104-664-11 ELECT 47uF 20% 25V
C806 1-126-964-11 ELECT 10uF 20% 50V
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-130-493-00 MYLAR 0.068uF 5% 50V
C821 1-104-664-11 ELECT 47uF 20% 25V
C822 1-126-964-11 ELECT 10uF 20% 50V
C823 1-126-933-11 ELECT 100uF 20% 10V
C824 1-104-664-11 ELECT 47uF 20% 25V
C825 1-126-964-11 ELECT 10uF 20% 50V
C851 1-162-306-11 CERAMIC 0.01uF 30% 16V
C901 1-110-592-11 ELECT 8200uF 99% 71V
C902 1-110-592-11 ELECT 8200uF 99% 71V
C903 1-126-955-11 ELECT 4700uF 20% 35V
C904 1-126-955-11 ELECT 4700uF 20% 35V
C905 1-106-367-00 MYLAR 0.01uF 5% 200V
C906 1-106-367-00 MYLAR 0.01uF 5% 200V
C907 1-106-375-12 MYLAR 0.022uF 5% 200V
C908 1-106-375-12 MYLAR 0.022uF 5% 200V
C909 1-126-967-11 ELECT 47uF 20% 50V
C910 1-126-967-11 ELECT 47uF 20% 50V
C911 1-104-664-11 ELECT 47uF 20% 25V
C912 1-104-664-11 ELECT 47uF 20% 25V
C913 1-126-933-11 ELECT 100uF 20% 10V
C914 1-126-933-11 ELECT 100uF 20% 10V
C915 1-126-964-11 ELECT 10uF 20% 50V
C916 1-126-964-11 ELECT 10uF 20% 50V
C918 1-126-964-11 ELECT 10uF 20% 50V
C919 1-104-664-11 ELECT 47uF 20% 25V
< CONNECTOR >
*CN101 1-568-844-11 SOCKET, CONNECTOR 29P
CN102 1-770-721-11 CONNECTOR, BOARD TO BOARD 4P
CN104 1-770-832-11 CONNECTOR, BOARD TO BOARD 6P
CN106 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
*CN108 1-766-715-11 CONNECTOR, BOARD TO BOARD 10P
CN403 1-750-194-11 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D301 8-719-987-63 DIODE 1N4148M
D302 8-719-987-63 DIODE 1N4148M
D303 8-719-933-36 DIODE HZS6B1L
D304 8-719-933-36 DIODE HZS6B1L
D701 8-719-815-85 DIODE 1S1585
D702 8-719-815-85 DIODE 1S1585
D731 8-719-987-63 DIODE 1N4148M
D751 8-719-815-85 DIODE 1S1585
D781 8-719-987-63 DIODE 1N4148M
D821 8-719-987-63 DIODE 1N4148M
D822 8-719-987-63 DIODE 1N4148M
D851 8-719-987-63 DIODE 1N4148M
D852 8-719-987-63 DIODE 1N4148M
D853 8-719-987-63 DIODE 1N4148M
D901 8-719-510-68 DIODE D5SBA20F01
D902 8-719-510-68 DIODE D5SBA20F01
D903 8-719-001-21 DIODE UZL-9H1
D904 8-719-001-21 DIODE UZL-9H1
D905 8-719-002-67 DIODE UZL-33H
D909 8-719-933-36 DIODE HZS6B1L
< GROUND TERMINAL >
*EB701 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-634-51 IC M5218AP
IC102 8-759-805-14 IC LC7822
IC103 8-759-248-74 IC LA2785
IC104 8-759-341-23 IC LV1011
IC107 8-759-634-51 IC M5218AP
IC108 8-759-634-51 IC M5218AP
IC109 8-759-634-51 IC M5218AP
IC110 8-759-634-51 IC M5218AP
IC112 8-759-281-42 IC TC9210P
IC113 8-759-281-42 IC TC9210P

— 30 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
IC114 8-759-281-42 IC TC9210P
IC120 8-759-000-49 IC MC14066BCP
IC170 8-759-000-49 IC MC14066BCP
IC301 8-759-634-51 IC M5218AP
IC701 8-749-010-34 IC STK4241MK2
IC702 8-749-920-10 IC STK4172MK2
IC703 8-759-085-89 IC LM3875-S
IC821 8-759-111-68 IC uPC1237HA
< JACK >
J101 1-766-558-41 JACK, PIN 8P
(TAPE REC OUT, CD/TUNER/PHONO IN)
J102 1-766-558-31 JACK, PIN 8P
(VIDEO2 AUDIO IN/OUT, VIDEO 3 AUDIO IN,TAPE IN)
J103 1-573-028-31 JACK, PIN 4P
(VIDEO 1 VIDEO IN/OUT, VIDEO1 AUDIO IN/OUT)
< COIL >
L101 1-410-521-11 INDUCTOR 100uH
L102 1-410-521-11 INDUCTOR 100uH
L701 1-420-872-00 COIL, AIR-CORE
L751 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q104 8-729-900-36 TRANSISTOR DTC124ES
Q105 8-729-900-36 TRANSISTOR DTC124ES
Q106 8-729-900-36 TRANSISTOR DTC124ES
Q201 8-729-900-36 TRANSISTOR DTC124ES
Q231 8-729-900-36 TRANSISTOR DTC124ES
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q331 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q332 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q333 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q381 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q382 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q701 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q731 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q751 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q781 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q821 8-729-900-63 TRANSISTOR DTA124ES
Q822 8-729-900-36 TRANSISTOR DTC124ES
Q823 8-729-900-63 TRANSISTOR DTA124ES
Q824 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q901 8-729-209-15 TRANSISTOR 2SD2012
Q902 8-729-141-83 TRANSISTOR 2SB1094-LK
Q903 8-729-030-19 TRANSISTOR 2SB1640
Q909 8-729-030-18 TRANSISTOR 2SD2525
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-417-11 CARBON 1K 5% 1/4W F
R103 1-249-423-11 CARBON 3.3K 5% 1/4W F
R104 1-249-417-11 CARBON 1K 5% 1/4W F
R105 1-249-417-11 CARBON 1K 5% 1/4W F
R106 1-249-417-11 CARBON 1K 5% 1/4W F
R107 1-249-417-11 CARBON 1K 5% 1/4W F
R108 1-249-417-11 CARBON 1K 5% 1/4W F
R109 1-249-417-11 CARBON 1K 5% 1/4W F
R110 1-249-417-11 CARBON 1K 5% 1/4W F
R111 1-249-433-11 CARBON 22K 5% 1/4W
R112 1-249-433-11 CARBON 22K 5% 1/4W
R113 1-249-433-11 CARBON 22K 5% 1/4W
R115 1-249-437-11 CARBON 47K 5% 1/4W
R116 1-249-415-11 CARBON 680 5% 1/4W F
R117 1-247-897-11 CARBON 560K 5% 1/4W
R118 1-249-437-11 CARBON 47K 5% 1/4W
R119 1-249-441-11 CARBON 100K 5% 1/4W
R120 1-249-409-11 CARBON 220 5% 1/4W F
R121 1-249-425-11 CARBON 4.7K 5% 1/4W F
R122 1-249-417-11 CARBON 1K 5% 1/4W F
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-249-417-11 CARBON 1K 5% 1/4W F
R126 1-249-428-11 CARBON 8.2K 5% 1/4W F
R127 1-249-417-11 CARBON 1K 5% 1/4W F
R131 1-249-441-11 CARBON 100K 5% 1/4W
R133 1-249-427-11 CARBON 6.8K 5% 1/4W F
R134 1-249-441-11 CARBON 100K 5% 1/4W
R140 1-249-441-11 CARBON 100K 5% 1/4W
R141 1-249-417-11 CARBON 1K 5% 1/4W F
R142 1-249-417-11 CARBON 1K 5% 1/4W F
R143 1-249-417-11 CARBON 1K 5% 1/4W F
R144 1-249-435-11 CARBON 33K 5% 1/4W
R145 1-249-431-11 CARBON 15K 5% 1/4W
R146 1-249-441-11 CARBON 100K 5% 1/4W
R147 1-249-411-11 CARBON 330 5% 1/4W
R148 1-247-903-00 CARBON 1M 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-417-11 CARBON 1K 5% 1/4W F
R153 1-249-423-11 CARBON 3.3K 5% 1/4W F
R154 1-249-417-11 CARBON 1K 5% 1/4W F
R155 1-249-417-11 CARBON 1K 5% 1/4W F
R156 1-249-417-11 CARBON 1K 5% 1/4W F
R157 1-249-417-11 CARBON 1K 5% 1/4W F
R158 1-249-417-11 CARBON 1K 5% 1/4W F
R159 1-249-417-11 CARBON 1K 5% 1/4W F
R160 1-249-417-11 CARBON 1K 5% 1/4W F
R165 1-249-437-11 CARBON 47K 5% 1/4W
R166 1-249-415-11 CARBON 680 5% 1/4W F
R167 1-247-897-11 CARBON 560K 5% 1/4W
R168 1-249-437-11 CARBON 47K 5% 1/4W
R169 1-249-441-11 CARBON 100K 5% 1/4W
R170 1-249-409-11 CARBON 220 5% 1/4W F
R176 1-249-428-11 CARBON 8.2K 5% 1/4W F
R177 1-249-417-11 CARBON 1K 5% 1/4W F

— 31 —
R181 1-249-441-11 CARBON 100K 5% 1/4W
R183 1-249-427-11 CARBON 6.8K 5% 1/4W F
R184 1-249-441-11 CARBON 100K 5% 1/4W
R201 1-249-429-11 CARBON 10K 5% 1/4W
R232 1-249-438-11 CARBON 56K 5% 1/4W
R233 1-249-432-11 CARBON 18K 5% 1/4W
R234 1-247-883-00 CARBON 150K 5% 1/4W
R235 1-249-416-11 CARBON 820 5% 1/4W F
R236 1-247-899-11 CARBON 680K 5% 1/4W
R237 1-249-441-11 CARBON 100K 5% 1/4W
R282 1-249-438-11 CARBON 56K 5% 1/4W
R283 1-249-432-11 CARBON 18K 5% 1/4W
R284 1-247-883-00 CARBON 150K 5% 1/4W
R285 1-249-416-11 CARBON 820 5% 1/4W F
R286 1-247-899-11 CARBON 680K 5% 1/4W
R287 1-249-441-11 CARBON 100K 5% 1/4W
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R302 1-249-441-11 CARBON 100K 5% 1/4W
R303 1-249-417-11 CARBON 1K 5% 1/4W F
R304 1-249-427-11 CARBON 6.8K 5% 1/4W F
R305 1-249-426-11 CARBON 5.6K 5% 1/4W
R306 1-249-433-11 CARBON 22K 5% 1/4W
R307 1-249-433-11 CARBON 22K 5% 1/4W
R308 1-249-433-11 CARBON 22K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-247-901-11 CARBON 820K 5% 1/4W
R311 1-247-807-31 CARBON 100 5% 1/4W
R312 1-249-441-11 CARBON 100K 5% 1/4W
R313 1-247-878-00 CARBON 91K 5% 1/4W
R314 1-249-418-11 CARBON 1.2K 5% 1/4W F
R315 1-249-427-11 CARBON 6.8K 5% 1/4W F
R316 1-249-432-11 CARBON 18K 5% 1/4W
R317 1-249-429-11 CARBON 10K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-249-425-11 CARBON 4.7K 5% 1/4W F
R320 1-249-437-11 CARBON 47K 5% 1/4W
R331 1-249-441-11 CARBON 100K 5% 1/4W
R332 1-249-421-11 CARBON 2.2K 5% 1/4W F
R333 1-249-429-11 CARBON 10K 5% 1/4W
R334 1-249-441-11 CARBON 100K 5% 1/4W
R335 1-249-421-11 CARBON 2.2K 5% 1/4W F
R336 1-249-429-11 CARBON 10K 5% 1/4W
R337 1-249-441-11 CARBON 100K 5% 1/4W
R338 1-249-421-11 CARBON 2.2K 5% 1/4W F
R339 1-249-429-11 CARBON 10K 5% 1/4W
R341 1-249-437-11 CARBON 47K 5% 1/4W
R342 1-249-437-11 CARBON 47K 5% 1/4W
R343 1-249-437-11 CARBON 47K 5% 1/4W
R344 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-417-11 CARBON 1K 5% 1/4W F
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-417-11 CARBON 1K 5% 1/4W F
R354 1-249-427-11 CARBON 6.8K 5% 1/4W F
R355 1-249-426-11 CARBON 5.6K 5% 1/4W
R357 1-249-433-11 CARBON 22K 5% 1/4W
R358 1-249-437-11 CARBON 47K 5% 1/4W
R359 1-249-441-11 CARBON 100K 5% 1/4W
R360 1-249-437-11 CARBON 47K 5% 1/4W
R361 1-249-429-11 CARBON 10K 5% 1/4W
R362 1-249-417-11 CARBON 1K 5% 1/4W F
R363 1-249-429-11 CARBON 10K 5% 1/4W
R381 1-249-441-11 CARBON 100K 5% 1/4W
R382 1-249-421-11 CARBON 2.2K 5% 1/4W F
R383 1-249-429-11 CARBON 10K 5% 1/4W
R384 1-249-441-11 CARBON 100K 5% 1/4W
R385 1-249-421-11 CARBON 2.2K 5% 1/4W F
R386 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-249-441-11 CARBON 100K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-413-11 CARBON 470 5% 1/4W F
R704 1-249-439-11 CARBON 68K 5% 1/4W
R705 1-249-425-11 CARBON 4.7K 5% 1/4W F
R706 1-249-421-11 CARBON 2.2K 5% 1/4W F
R707 1-249-421-11 CARBON 2.2K 5% 1/4W F
R708 1-249-417-11 CARBON 1K 5% 1/4W F
R709 1-249-417-11 CARBON 1K 5% 1/4W F
R710 1-249-433-11 CARBON 22K 5% 1/4W
!R711 1-208-601-11 WIREWOUND 0.1 10% 2W F
R712 1-249-433-11 CARBON 22K 5% 1/4W
R713 1-249-393-11 CARBON 10 5% 1/4W F
R714 1-249-393-11 CARBON 10 5% 1/4W F
R715 1-249-393-11 CARBON 10 5% 1/4W F
R716 1-249-393-11 CARBON 10 5% 1/4W F
!R721 1-249-405-11 CARBON 100 5% 1/4W F
!R722 1-249-405-11 CARBON 100 5% 1/4W F
R723 1-249-429-11 CARBON 10K 5% 1/4W
R724 1-247-887-00 CARBON 220K 5% 1/4W
R725 1-249-425-11 CARBON 4.7K 5% 1/4W F
R731 1-249-417-11 CARBON 1K 5% 1/4W F
R732 1-249-439-11 CARBON 68K 5% 1/4W
R733 1-249-413-11 CARBON 470 5% 1/4W F
R734 1-249-439-11 CARBON 68K 5% 1/4W
R735 1-249-421-11 CARBON 2.2K 5% 1/4W F
R736 1-249-421-11 CARBON 2.2K 5% 1/4W F
!R737 1-249-417-11 CARBON 1K 5% 1/4W F
R738 1-249-417-11 CARBON 1K 5% 1/4W F
R739 1-249-433-11 CARBON 22K 5% 1/4W
!R740 1-208-602-11 WIREWOUND 0.22 10% 2W F
R741 1-249-433-11 CARBON 22K 5% 1/4W
R742 1-249-393-11 CARBON 10 5% 1/4W F
!R743 1-249-405-11 CARBON 100 5% 1/4W F
!R744 1-249-405-11 CARBON 100 5% 1/4W F
R751 1-249-417-11 CARBON 1K 5% 1/4W F
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
Thecomponentsidentified bymark!
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.

— 32 —
Ref. No. Part No. Description Remark
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-413-11 CARBON 470 5% 1/4W F
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-425-11 CARBON 4.7K 5% 1/4W F
R756 1-249-421-11 CARBON 2.2K 5% 1/4W F
R757 1-249-421-11 CARBON 2.2K 5% 1/4W F
R758 1-249-417-11 CARBON 1K 5% 1/4W F
R759 1-249-417-11 CARBON 1K 5% 1/4W F
R760 1-249-433-11 CARBON 22K 5% 1/4W
!R761 1-208-601-11 WIREWOUND 0.1 10% 2W F
R762 1-249-433-11 CARBON 22K 5% 1/4W
R763 1-249-393-11 CARBON 10 5% 1/4W F
R764 1-249-393-11 CARBON 10 5% 1/4W F
R765 1-249-393-11 CARBON 10 5% 1/4W F
R766 1-249-393-11 CARBON 10 5% 1/4W F
R770 1-249-417-11 CARBON 1K 5% 1/4W F
R781 1-249-417-11 CARBON 1K 5% 1/4W F
R782 1-249-439-11 CARBON 68K 5% 1/4W
R783 1-249-413-11 CARBON 470 5% 1/4W F
R784 1-249-439-11 CARBON 68K 5% 1/4W
R785 1-249-421-11 CARBON 2.2K 5% 1/4W F
R786 1-249-421-11 CARBON 2.2K 5% 1/4W F
!R787 1-249-417-11 CARBON 1K 5% 1/4W F
R788 1-249-417-11 CARBON 1K 5% 1/4W F
R789 1-249-433-11 CARBON 22K 5% 1/4W
!R790 1-208-602-11 WIREWOUND 0.22 10% 2W F
R791 1-249-433-11 CARBON 22K 5% 1/4W
R792 1-249-393-11 CARBON 10 5% 1/4W F
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-439-11 CARBON 68K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W F
R804 1-249-439-11 CARBON 68K 5% 1/4W
R805 1-249-393-11 CARBON 10 5% 1/4W F
R811 1-249-416-11 CARBON 820 5% 1/4W F
R812 1-249-416-11 CARBON 820 5% 1/4W F
R813 1-260-094-11 CARBON 390 5% 1/2W
R821 1-249-431-11 CARBON 15K 5% 1/4W
R822 1-249-429-11 CARBON 10K 5% 1/4W
R823 1-249-439-11 CARBON 68K 5% 1/4W
R824 1-249-441-11 CARBON 100K 5% 1/4W
R825 1-249-427-11 CARBON 6.8K 5% 1/4W F
R827 1-249-429-11 CARBON 10K 5% 1/4W
R828 1-249-417-11 CARBON 1K 5% 1/4W F
R829 1-249-425-11 CARBON 4.7K 5% 1/4W F
R831 1-249-435-11 CARBON 33K 5% 1/4W
R832 1-249-437-11 CARBON 47K 5% 1/4W
R833 1-249-438-11 CARBON 56K 5% 1/4W
R834 1-249-435-11 CARBON 33K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R838 1-249-437-11 CARBON 47K 5% 1/4W
!R851 1-215-885-00 METAL OXIDE 68 5% 2W F
R861 1-249-416-11 CARBON 820 5% 1/4W F
R862 1-249-416-11 CARBON 820 5% 1/4W F
R863 1-260-094-11 CARBON 390 5% 1/2W
!R901 1-215-906-11 METAL OXIDE 15 5% 3W F
!R902 1-215-888-00 METAL OXIDE 220 5% 2W F
R903 1-249-419-11 CARBON 1.5K 5% 1/4W F
R904 1-249-419-11 CARBON 1.5K 5% 1/4W F
R905 1-249-419-11 CARBON 1.5K 5% 1/4W F
R906 1-249-419-11 CARBON 1.5K 5% 1/4W F
!R907 1-215-869-11 METAL OXIDE 1K 5% 1W F
R908 1-249-427-11 CARBON 6.8K 5% 1/4W F
R909 1-249-423-11 CARBON 3.3K 5% 1/4W F
!R921 1-215-906-11 METAL OXIDE 15 5% 3W F
R961 1-247-807-31 CARBON 100 5% 1/4W
R962 1-247-807-31 CARBON 100 5% 1/4W
R964 1-247-807-31 CARBON 100 5% 1/4W
R965 1-247-807-31 CARBON 100 5% 1/4W
R966 1-247-807-31 CARBON 100 5% 1/4W
R967 1-247-807-31 CARBON 100 5% 1/4W
R968 1-247-807-31 CARBON 100 5% 1/4W
R969 1-247-807-31 CARBON 100 5% 1/4W
R970 1-247-807-31 CARBON 100 5% 1/4W
R971 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
RY851 1-755-141-11 RELAY
RY852 1-515-920-11 RELAY (24V)
RY853 1-515-920-11 RELAY (24V)
< TERMINAL >
TM801 1-694-055-11 TERMINAL BOARD (SP)
(FRONT/CENTER/WOOFER SPEAKERS)
< VIBRATOR >
X101 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
**************************************************************
*1-661-164-11 POWER BOARD
*************
< CAPACITOR >
!C951 1-113-925-11 ELECT 0.01uF 20% 250V
C952 1-130-487-00 MYLAR 0.022uF 5% 50V
C953 1-124-557-11 ELECT 1000uF 20% 25V
C954 1-161-494-00 CERAMIC 0.022uF 25V
C955 1-124-463-00 ELECT 0.1uF 20% 50V
C956 1-162-306-11 CERAMIC 0.01uF 30% 16V
C957 1-162-306-11 CERAMIC 0.01uF 30% 16V
C958 1-124-907-11 ELECT 10uF 20% 50V
C959 1-162-306-11 CERAMIC 0.01uF 30% 16V
MAIN POWER
Ref. No. Part No. Description Remark
Thecomponentsidentifiedbymark!
or dotted line with mark !are critical
for safety.
Replace only with part number
specified.
