XM-1002HX
SERVICE MANUAL
CORRECTION - 1
Correct your Service Manual as shown below.
(SPM-99018)
US Model
Canadian Model
AEP Model
UK Model
E Model
r
! : Indicates corrected portion
Page INCORRECT CORRECT
10
Sony Corporation
Mobile Electronics Company
9-925-785-91
99G0277-1
Printed in Japan © 1999.7
Published by Quality Assurance Dept.
JW77
JW71
JW72
JW73
D907 D908 D909
JW64
JW65
JW66
JW67
JW68
JW69 JW70
JW74
JW75
JW76
JW77
JW71
JW72
JW73
D907 D908 D909
JW64
JW65
JW66
JW67
JW68
JW69 JW70
JW74
JW75
JW76
14
#
#
^
^

XM-1002HX
SERVICE MANUAL
STEREO POWER AMPLIFIER
SPECIFICATIONS
US Model
Canadian Model
AEP Model
UK Model
E Model
Other Specifications
Circuit system OTL (output transformerless) circuit
Pulse power supply
Inputs RCA pin jacks
High level input connector
Outputs Speaker terminals
Through out pin jacks
Speaker impedance 1* – 8 Ω(stereo)
2* – 8 Ω(when used as a bridging amplifier)
Maximum outputs (HI-CURRENT/HI-VOLTAGE)
120/230 W x 2 (at 4 Ω)
380/580 W (monaural) at 4 Ω
Rated outputs (HI-CURRENT/HI-VOLTAGE)
(supply voltage at 14.4 V)
50/100 W x 2 (20 Hz – 20 kHz, 0.04% THD,
at 4 Ω)
70/140 W x 2 (20 Hz – 20 kHz, 0.1% THD,
at 2 Ω)
140/280 W (monaural) (20 Hz – 20 kHz, 0.1% THD,
at 4 Ω)
Frequency response
+0.5
5 Hz – 50 kHz ( –3 dB)
Harmonic distortion 0.005% or less (at lkHz, 4 Ω)
Input level adjustment range
0.2 – 4.0 V (RCApin jacks)
0.4 – 8.0 V (High level input)
AUDIO POWER SPECIFICATIONS (US model)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
100/50 watts per channel minimum continuous average power into
4 ohms, both channels driven from 20 Hz to 20 kHZ with no more
than 0.04% total harmonic distortion per Car AudioAd Hoc
Committee standards.
High-pass filter 50 – 200 Hz, –12 dB/oct
Low-pass filter 50 – 200 Hz, –12 dB/oct
Low boost 0 – 10 dB (40 Hz)
Power requirements 12 V DC car battery (negative ground)
Power supply voltage10.5 – 16 V
Current drain at rated output : 26 A
(4 HI-VOL TAGE mode)
Remote input : 2 mA
Dimensions Approx. 258 x 50 x 320 mm
(10 l/4x 2 x 12 5/8in.)
(1/h/p) not incl. projecting parts and controls
Mass Approx. 3.3 kg (7 lb, 4 oz.) not incl. accessories
Supplied accessories Mounting screws (4),
Terminal cap (1)
Design and specifications are subject to change without notice.
* HI-CURRENT only
1
Ver 1.1 2001. 08
Sony Corporation
e Vehicle Company
Shinagawa Tec Service Manual Production Group
9-925-785-12
2001H0400-1
© 2001. 8

– 2 –
Specifications ............................................................................. 1
1. SERVICING NOTE ....................................................... 2
2. GENERAL ....................................................................... 3
3. DISASSEMBLY
3-1. Bottom Plate, Panel (Front), Panel (Rear) Removal ....5
3-2. Amplifier Board Removal ............................................5
4. ELECTRICAL ADJUSTMENT................................. 6
5. DIAGRAMS
5-1. Block Diagram..............................................................7
5-2. Printed Wiring Boards ..................................................9
5-3. Schematic Diagram.....................................................13
6. EXPLODEDVIEW...................................................... 15
7. ELECTRICAL PARTS LIST .................................... 16
TABLE OF CONTENTS
SECTION 1
SERVICING NOTE
CANCELLINGTHE PROTECTOR DURING SERVICING
Cut JW219 on the amplifier board to cancel the protector.
After servicing always be sure to return JW219 to its original state.
JW89
IC902 JW219
C801 T901
PROTECTOR OFF

– 7 – – 8 –
SECTION 5
DIAGRAMS
XM-1002HX
5-1. BLOCK DIAGRAM
• Signal path.
F

– 13 – – 14 –
XM-1002HX
5-3. SCHEMATIC DIAGRAM rRefer to page 9 forWaveforms. rRefer to page 9 for IC Block Diagrams.

– 16 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
• CAPACITORS
uF : µF
• COILS
uH : µH
• Abbreviation
G : German
When indicating parts by reference num-
ber, please include the board.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
*A-3313-748-A AMPLIFIER BOARD, COMPLETE
*************************
< CAPACITOR >
C101 1-12 -047-11 ELECT 4.7uF 20% 50V
C102 1-12 -047-11 ELECT 4.7uF 20% 50V
C103 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C104 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C105 1-1 3-231-11 CERAMIC CHIP 15PF 5% 50V
C10 1-13 -1 7-00 FILM 0.15uF 5% 50V
C107 1-13 -1 7-00 FILM 0.15uF 5% 50V
C108 1-12 -047-11 ELECT 4.7uF 20% 50V
C109 1-12 -047-11 ELECT 4.7uF 20% 50V
C110 1-12 -047-11 ELECT 4.7uF 20% 50V
C111 1-1 3-243-11 CERAMIC CHIP 47PF 5% 50V
C112 1-12 -047-11 ELECT 4.7uF 20% 50V
C113 1-12 -957-11 ELECT 0.22uF 20% 50V
C114 1-12 -008-11 ELECT 47uF 20% 1 V
C115 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C117 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C118 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C119 1-1 4-222-11 CERAMIC CHIP 0.22uF 25V
C120 1-1 4-222-11 CERAMIC CHIP 0.22uF 25V
C121 1-104- 1-11 ELECT 330uF 20% 1 V
C123 1-12 -008-11 ELECT 47uF 20% 1 V
C124 1-104-999-11 MYLAR 0.1uF 10% 200V
C12 1-102-951-00 CERAMIC 15PF 5% 50V
C127 1-1 5-319-11 CERAMIC CHIP 0.1uF 50V
C128 1-10 -383-00 MYLAR 0.047uF 5% 200V
C130 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C201 1-12 -047-11 ELECT 4.7uF 20% 50V
C202 1-12 -047-11 ELECT 4.7uF 20% 50V
C203 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C204 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C205 1-1 3-231-11 CERAMIC CHIP 15PF 5% 50V
C20 1-13 -1 7-00 FILM 0.15uF 5% 50V
C207 1-13 -1 7-00 FILM 0.15uF 5% 50V
C208 1-12 -047-11 ELECT 4.7uF 20% 50V
C209 1-12 -047-11 ELECT 4.7uF 20% 50V
C210 1-12 -047-11 ELECT 4.7uF 20% 50V
C211 1-1 3-243-11 CERAMIC CHIP 47PF 5% 50V
C212 1-12 -047-11 ELECT 4.7uF 20% 50V
C213 1-12 -957-11 ELECT 0.22uF 20% 50V
C214 1-12 -008-51 ELECT 47uF 20% 1 V
C215 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C217 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C218 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C219 1-1 4-222-11 CERAMIC CHIP 0.22uF 25V
C220 1-1 4-222-11 CERAMIC CHIP 0.22uF 25V
C221 1-1 4-222-11 CERAMIC CHIP 0.22uF 25V
C222 1-1 3-251-11 CERAMIC CHIP 100PF 5% 50V
C223 1-12 -008-11 ELECT 47uF 20% 1 V
C224 1-104-999-11 MYLAR 0.1uF 10% 200V
C22 1-102-951-00 CERAMIC 15PF 5% 50V
C227 1-1 5-319-11 CERAMIC CHIP 0.1uF 50V
C228 1-10 -383-00 MYLAR 0.047uF 5% 200V
C230 1-1 3-239-11 CERAMIC CHIP 33PF 5% 50V
C801 1-124-282-00 ELECT 22uF 20% 1 V
C802 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C803 1-12 -9 7-11 ELECT 47uF 20% 10V
C804 1-12 -95 -11 ELECT 0.1uF 20% 50V
C805 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C80 1-128-551-11 ELECT 22uF 20% 25V
C807 1-1 3-133-00 CERAMIC CHIP 470PF 5% 50V
C808 1-1 3-133-00 CERAMIC CHIP 470PF 5% 50V
C809 1-128-551-11 ELECT 22uF 20% 25V
C901 1-1 5-319-11 CERAMIC CHIP 0.1uF 50V
C902 1-1 5-319-11 CERAMIC CHIP 0.1uF 50V
C903 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C904 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C909 1-10 -343-00 MYLAR 1000PF 5% 200V
C910 1-128-551-11 ELECT 22uF 20% 25V
C911 1-12 -933-11 ELECT 100uF 20% 10V
C912 1-12 -933-11 ELECT 100uF 20% 1 V
C913 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C914 1-1 3-141-00 CERAMIC CHIP 0.001uF 5% 50V
C915 1-13 -173-00 FILM 0.47uF 5% 50V
C91 1-10 -383-00 MYLAR 0.047uF 5% 200V
C917 1-111-044-11 ELECT 2200uF 20% 1 V
C918 1-111-044-11 ELECT 2200uF 20% 1 V
C919 1-111-044-11 ELECT 2200uF 20% 1 V
C920 1-12 -052-11 ELECT 100uF 20% 50V
C921 1-12 -052-11 ELECT 100uF 20% 50V
C922 1-104-999-11 MYLAR 0.1uF 10% 200V
C923 1-104-999-11 MYLAR 0.1uF 10% 200V
AMPLIFIER

– 17 –
C924 1-126-052-11 ELECT 100uF 20% 35V
C925 1-126-052-11 ELECT 100uF 20% 35V
C926 1-119-761-11 ELECT 4700uF 20% 50V
C927 1-119-761-11 ELECT 4700uF 20% 50V
C928 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C929 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C930 1-126-009-11 ELECT 100uF 20% 16V
C931 1-126-009-11 ELECT 100uF 20% 16V
C932 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C933 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C934 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C935 1-126-157-11 ELECT 10uF 20% 16V
C936 1-126-157-11 ELECT 10uF 20% 16V
C937 1-164-232-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN801 1-537-477-21 TERMINAL BOARD (3P) (REMOTE, +12V, GND)
CN802 1-537-478-21 TERMINAL BOARD (4P) (SPEAKER OUT)
CN803 1-784-904-11 CONNECTOR 4P (HI LEVEL INPUT)
CN804 1-537-479-11 TERMINAL
CN805 1-537-479-11 TERMINAL
< JACK >
CNJ801 1-779-078-51 JACK, PIN 4P (OUTPUT THROUGH, INPUT)
< DIODE >
D801 8-719-025-34 DIODE 02CZ6.8-TE85L
D802 8-719-801-78 DIODE 1SS184
D803 8-719-801-78 DIODE 1SS184
D804 8-719-801-78 DIODE 1SS184
D805 8-719-801-78 DIODE 1SS184
D807 8-719-801-78 DIODE 1SS184
D808 8-719-070-01 LED SEC2764C (OVER CURRENT)
D809 8-719-070-01 LED SEC2764C (OFFSET)
D810 8-719-070-01 LED SEC2764C (TERMINAL)
D811 8-719-070-01 LED SEC2764C (MODE HI-VOLTAGE)
D812 8-719-070-01 LED SEC2764C (MODE HI-CURRENT)
D901 8-719-025-34 DIODE 02CZ6.8-TE85L
D902 8-719-025-50 DIODE 02CZ16-TE85L
D903 8-719-987-67 DIODE 11EFS2
D904 8-719-987-67 DIODE 11EFS2
D905 8-719-054-55 DIODE 1SS306(TE85L)
D906 8-719-054-55 DIODE 1SS306(TE85L)
D907 8-719-210-30 DIODE F10P20F(R)
D908 8-719-210-30 DIODE F10P20F(R)
D909 8-719-210-30 DIODE F10P20F(R)
D910 8-719-210-30 DIODE F10P20F(R)
D911 8-719-801-78 DIODE 1SS184
D912 8-719-801-78 DIODE 1SS184
D913 8-719-025-49 DIODE 02CZ15-TE85L
D914 8-719-025-49 DIODE 02CZ15-TE85L
D915 8-719-025-49 DIODE 02CZ15-TE85L
D916 8-719-025-49 DIODE 02CZ15-TE85L
D917 8-719-987-67 DIODE 11EFS2
D918 8-719-987-67 DIODE 11EFS2
< IC >
IC801 8-759-711-82 IC NJM4580E
IC802 8-759-711-82 IC NJM4580E
IC803 8-759-711-82 IC NJM4580E
IC804 8-759-711-82 IC NJM4580E
IC805 8-759-711-82 IC NJM4580E
IC806 8-759-711-82 IC NJM4580E
IC807 8-719-156-72 PHOTO COUPLER PS2501-1KA
IC901 8-759-144-88 IC UPC494GS
IC902 8-719-156-72 PHOTO COUPLER PS2501-1KA
< JUMPER RESISTOR >
JR1 1-216-296-00 CONDUCTOR, CHIP
JR2 1-216-295-00 CONDUCTOR, CHIP
JR3 1-216-295-00 CONDUCTOR, CHIP
< COIL >
L901 1-419-851-11 INDUCTOR 50uH
L902 1-410-396-71 INDUCTOR 0.45uH
< PILOT LAMP >
PL801 1-518-540-00 LAMP , PILOT
< TRANSISTOR >
Q101 8-729-422-29 TRANSISTOR 2SD601A-S
Q102 8-729-203-48 TRANSISTOR 2SC3327-A
Q103 8-729-184-53 TRANSISTOR 2SC1845-EA
Q104 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q105 8-729-184-53 TRANSISTOR 2SC1845-EA
Q106 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q107 8-729-209-18 TRANSISTOR 2SA1360-Y
Q108 8-729-203-45 TRANSISTOR 2SC3423-O
Q109 8-729-038-52 TRANSISTOR IRF540(H)
Q110 8-729-038-01 TRANSISTOR IRF9540(H)
Q111 8-729-954-51 TRANSISTOR 2SC1545
Q112 8-729-216-21 TRANSISTOR 2SA1162-Y
Q113 8-729-216-21 TRANSISTOR 2SA1162-Y
Q201 8-729-422-29 TRANSISTOR 2SD601A-S
Q202 8-729-203-48 TRANSISTOR 2SC3327-A
Q203 8-729-184-53 TRANSISTOR 2SC1845-EA
Q204 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q205 8-729-184-53 TRANSISTOR 2SC1845-EA
Q206 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q207 8-729-209-18 TRANSISTOR 2SA1360-Y
Q208 8-729-203-45 TRANSISTOR 2SC3423-O
Q209 8-729-038-52 TRANSISTOR IRF540(H)
Q210 8-729-038-01 TRANSISTOR IRF9540(H)
Q211 8-729-954-51 TRANSISTOR 2SC1545
Q212 8-729-216-21 TRANSISTOR 2SA1162-Y
Q213 8-729-216-21 TRANSISTOR 2SA1162-Y
Q801 8-729-216-21 TRANSISTOR 2SA1162-Y
Q802 8-729-230-49 TRANSISTOR 2SC2712-YG
Q803 8-729-230-49 TRANSISTOR 2SC2712-YG
Q804 8-729-216-21 TRANSISTOR 2SA1162-Y
Q805 8-729-230-49 TRANSISTOR 2SC2712-YG
Q806 8-729-230-49 TRANSISTOR 2SC2712-YG
Q807 8-729-230-49 TRANSISTOR 2SC2712-YG
Q808 8-729-230-49 TRANSISTOR 2SC2712-YG
Q809 8-729-230-49 TRANSISTOR 2SC2712-YG
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER
Ver 1.1

– 18 –
Q810 8-729-230-49 TRANSISTOR 2SC2712-YG
Q811 8-729-216-21 TRANSISTOR 2SA1162-Y
Q812 8-729-230-49 TRANSISTOR 2SC2712-YG
Q813 8-729-216-21 TRANSISTOR 2SA1162-Y
Q901 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q902 8-729-216-21 TRANSISTOR 2SA1162-Y
Q903 8-729-230-49 TRANSISTOR 2SC2712-YG
Q904 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q905 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q906 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q907 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q908 8-729-230-49 TRANSISTOR 2SC2712-YG
Q909 8-729-230-49 TRANSISTOR 2SC2712-YG
Q910 8-729-209-15 TRANSISTOR 2SD2012
Q911 8-729-141-83 TRANSISTOR 2SB1094-LK
Q912 8-729-119-78 TRANSISTOR 2SC403SP-51
Q913 8-729-173-38 TRANSISTOR 2SA733-K
< RESISTOR >
R101 1-208-518-11 RES,CHIP 22K 2% 1/10W
R102 1-208-518-11 RES,CHIP 22K 2% 1/10W
R103 1-208-526-11 RES,CHIP 47K 2% 1/10W
R104 1-208-526-11 RES,CHIP 47K 2% 1/10W
R105 1-208-518-11 RES,CHIP 22K 2% 1/10W
R106 1-208-518-11 RES,CHIP 22K 2% 1/10W
R107 1-208-462-11 RES,CHIP 10K 2% 1/10W
R108 1-208-518-11 RES,CHIP 22K 2% 1/10W
R109 1-208-462-11 RES,CHIP 10K 2% 1/10W
R110 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R111 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R112 1-208-462-11 RES,CHIP 10K 2% 1/10W
R113 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R114 1-208-534-11 RES,CHIP 100K 2% 1/10W
R115 1-208-534-11 RES,CHIP 100K 2% 1/10W
R116 1-208-534-11 RES,CHIP 100K 2% 1/10W
R117 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R118 1-208-534-11 RES,CHIP 100K 2% 1/10W
R119 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R120 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R121 1-208-518-11 RES,CHIP 22K 2% 1/10W
R122 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R123 1-208-462-11 RES,CHIP 10K 2% 1/10W
R124 1-208-760-11 RES,CHIP 120 2% 1/10W
R125 1-216-471-11 METAL OXIDE 27 5% 3W F
R126 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R127 1-208-510-11 RES,CHIP 10K 2% 1/8W
R128 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R129 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R130 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R131 1-208-810-11 RES,CHIP 15K 2% 1/10W
R132 1-208-810-11 RES,CHIP 15K 2% 1/10W
R133 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R134 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R135 1-208-401-11 RES,CHIP 33 2% 1/8W
R136 1-208-401-11 RES,CHIP 33 2% 1/8W
R137 1-208-534-11 RES,CHIP 100K 2% 1/10W
R138 1-208-534-11 RES,CHIP 100K 2% 1/10W
R139 1-249-419-11 CARBON 1.5K 5% 1/4W
R140 1-249-424-11 CARBON 3.9K 5% 1/4W
R141 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R142 1-208-462-11 RES,CHIP 10K 2% 1/10W
R143 1-240-179-11 METAL PLATE 0.03X2 5W
R144 1-208-810-11 RES,CHIP 15K 2% 1/10W
R145 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R146 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R147 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R148 1-208-510-11 RES,CHIP 10K 2% 1/8W
R149 1-208-510-11 RES,CHIP 10K 2% 1/8W
R150 1-208-550-11 RES,CHIP 470K 2% 1/10W
R151 1-215-857-11 METAL OXIDE 10 5% 1W
R152 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R201 1-208-518-11 RES,CHIP 22K 2% 1/10W
R202 1-208-518-11 RES,CHIP 22K 2% 1/10W
R203 1-208-526-11 RES,CHIP 47K 2% 1/10W
R204 1-208-526-11 RES,CHIP 47K 2% 1/10W
R205 1-208-518-11 RES,CHIP 22K 2% 1/10W
R206 1-208-518-11 RES,CHIP 22K 2% 1/10W
R207 1-208-462-11 RES,CHIP 10K 2% 1/10W
R208 1-208-518-11 RES,CHIP 22K 2% 1/10W
R209 1-208-462-11 RES,CHIP 10K 2% 1/10W
R210 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R211 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R212 1-208-462-11 RES,CHIP 10K 2% 1/10W
R213 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R214 1-208-534-11 RES,CHIP 100K 2% 1/10W
R215 1-208-534-11 RES,CHIP 100K 2% 1/10W
R216 1-208-534-11 RES,CHIP 100K 2% 1/10W
R217 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R218 1-208-534-11 RES,CHIP 100K 2% 1/10W
R219 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R220 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R221 1-208-518-11 RES,CHIP 22K 2% 1/10W
R222 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R223 1-208-462-11 RES,CHIP 10K 2% 1/10W
R224 1-208-760-11 RES,CHIP 120 2% 1/10W
R225 1-216-471-11 METAL OXIDE 27 5% 3W F
R226 1-208-437-11 RES,CHIP 1K 2% 1/10W
R227 1-208-510-11 RES,CHIP 10K 2% 1/8W
R228 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R229 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R230 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R231 1-208-810-11 RES,CHIP 15K 2% 1/10W
R232 1-208-810-11 RES,CHIP 15K 2% 1/10W
R233 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R234 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R235 1-208-401-11 RES,CHIP 33 2% 1/8W
R236 1-208-401-11 RES,CHIP 33 2% 1/8W
R237 1-208-534-11 RES,CHIP 100K 2% 1/10W
R238 1-208-534-11 RES,CHIP 100K 2% 1/10W
R239 1-249-419-11 CARBON 1.5K 5% 1/4W
R240 1-249-424-11 CARBON 3.9K 5% 1/4W
R241 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R242 1-208-462-11 RES,CHIP 10K 2% 1/10W
R243 1-240-179-11 METAL PLATE 0.03X2 5W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER

– 19 –
R244 1-208-810-11 RES,CHIP 15K 2% 1/10W
R245 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R246 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R247 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R248 1-208-510-11 RES,CHIP 10K 2% 1/8W
R249 1-208-510-11 RES,CHIP 10K 2% 1/8W
R250 1-208-550-11 RES,CHIP 470K 2% 1/10W
R251 1-215-857-11 METAL OXIDE 10 5% 1W
R252 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R801 1-208-558-11 RES,CHIP 1M 2% 1/10W
R802 1-208-437-11 RES,CHIP 1K 2% 1/10W
R803 1-208-510-11 RES,CHIP 10K 2% 1/8W
R804 1-216-698-11 METAL CHIP 91K 0.5% 1/10W
R805 1-208-522-11 RES,CHIP 33K 2% 1/10W
R806 1-208-462-11 RES,CHIP 10K 2% 1/10W
R807 1-208-462-11 RES,CHIP 10K 2% 1/10W
R808 1-208-462-11 RES,CHIP 10K 2% 1/10W
R809 1-208-462-11 RES,CHIP 10K 2% 1/10W
R810 1-208-558-11 RES,CHIP 1M 2% 1/10W
R811 1-208-494-11 RES,CHIP 2.2K 2% 1/8W
R812 1-208-486-11 RES,CHIP 1K 2% 1/8W
R813 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R814 1-208-486-11 RES,CHIP 1K 2% 1/8W
R815 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R816 1-208-486-11 RES,CHIP 1K 2% 1/8W
R817 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R818 1-208-462-11 RES,CHIP 10K 2% 1/10W
R819 1-208-462-11 RES,CHIP 10K 2% 1/10W
R820 1-208-462-11 RES,CHIP 10K 2% 1/10W
R821 1-208-462-11 RES,CHIP 10K 2% 1/10W
R822 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R823 1-208-462-11 RES,CHIP 10K 2% 1/10W
R824 1-216-238-00 RES,CHIP 47K 2% 1/8W
R825 1-208-462-11 RES,CHIP 10K 2% 1/10W
R826 1-208-462-11 RES,CHIP 10K 2% 1/10W
R827 1-208-462-11 RES,CHIP 10K 2% 1/10W
R828 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R829 1-208-510-11 RES,CHIP 10K 2% 1/8W
R830 1-208-462-11 RES,CHIP 10K 2% 1/10W
R832 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R833 1-208-522-11 RES,CHIP 33K 2% 1/10W
R834 1-208-522-11 RES,CHIP 33K 2% 1/10W
R835 1-208-526-11 RES,CHIP 47K 2% 1/10W
R836 1-208-526-11 RES,CHIP 47K 2% 1/10W
R837 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R838 1-208-772-11 RES,CHIP 390 2% 1/10W
R839 1-208-558-11 RES,CHIP 1M 2% 1/10W
R840 1-208-486-11 RES,CHIP 1K 2% 1/8W
R841 1-208-486-11 RES,CHIP 1K 2% 1/8W
R850 1-208-462-11 RES,CHIP 10K 2% 1/10W
R901 1-208-462-11 RES,CHIP 10K 2% 1/10W
R902 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R903 1-208-518-11 RES,CHIP 22K 2% 1/10W
R904 1-208-810-11 RES,CHIP 15K 2% 1/10W
R905 1-216-103-00 METAL CHIP 180K 5% 1/10W
R906 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R907 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R908 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R909 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R910 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R911 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-208-474-11 RES,CHIP 330 2% 1/8W
R913 1-208-478-11 RES,CHIP 470 2% 1/8W
R914 1-208-478-11 RES,CHIP 470 2% 1/8W
R915 1-208-405-11 RES,CHIP 47 2% 1/8W
R916 1-216-150-00 RES,CHIP 10 2% 1/8W
R917 1-208-437-11 RES,CHIP 1K 2% 1/10W
R918 1-208-437-11 RES,CHIP 1K 2% 1/10W
R919 1-208-405-11 RES,CHIP 47 2% 1/8W
R920 1-216-150-00 RES,CHIP 10 2% 1/8W
R921 1-216-150-00 RES,CHIP 10 2% 1/8W
R922 1-216-150-00 RES,CHIP 10 2% 1/8W
R923 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R924 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R925 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R926 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
< VARIABLE RESISTOR >
RV104 1-241-761-11 RES, ADJ, CARBON 1K (BIAS)
RV204 1-241-761-11 RES, ADJ, CARBON 1K (BIAS)
RV801 1-225-647-11 RES, VAR 20K/20K/20K/20K (FILTER)
RV802 1-225-648-11 RES, VAR 5K/5K (LOW BOOST)
RV803 1-225-648-11 RES, VAR 5K/5K (LEVEL)
< SWITCH >
S801 1-572-185-11 SWITCH, SLIDE (FILTER)
S901 1-771-387-11 SWITCH, TOGGLE (HI-CURRENT/HI-VOLTAGE)
< TRANSFORMER >
T901 1-431-882-11 TRANSFORMER, DC-DC CONVERTER
< TRANSFORMER >
TH801 1-808-877-11 THERMISTOR
THP802 1-809-664-51 THERMISTOR, POSITIVE
THP803 1-809-664-51 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
**************
CN804 1-537-479-11 TERMINAL
CN805 1-537-479-11 TERMINAL
D907 8-719-210-30 DIODE F10P20F(R)
D908 8-719-210-30 DIODE F10P20F(R)
D909 8-719-210-30 DIODE F10P20F(R)
D910 8-719-210-30 DIODE F10P20F(R)
F901 1-532-947-11 FUSE (BLADE TYPE) (AUTO FUSE) (30A)
Q109 8-729-038-52 TRANSISTOR IRF540(H)
Q110 8-729-038-01 TRANSISTOR IRF9540(H)
Q209 8-729-038-52 TRANSISTOR IRF540(H)
Q210 8-729-038-01 TRANSISTOR IRF9540(H)
Q904 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q905 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q906 8-729-030-73 TRANSISTOR MTAJ30N06HD
Q907 8-729-030-73 TRANSISTOR MTAJ30N06HD
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER

– 20 –
THP802 1-809-664-51 THERMISTOR, POSITIVE
THP803 1-809-664-51 THERMISTOR, POSITIVE
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-013-264-01
3-367-410-01
3-701-639-00
3-862-334-11
3-862-334-21
3-862-334-31
3-862-334-41
COVER, 3P TERMINAL TABLE
SCREW (DIA. 5X15), TAPPING
BAG, POLYETHYLENE
MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(AEP,UK,E)
MANUAL, INSTRUCTION (GERMAN, ITALIAN)
(AEP,UK,G,E)
MANUAL, INSTRUCTION (SPANISH,
PORTUGUESE) (AEP,UK,E)
MANUAL, INSTRUCTION (DUTCH, SWEDISH)
(AEP,UK,E)
3-862-334-51
3-862-334-61
MANUAL, INSTRUCTION (RUSSIAN,GREEK)
(AEP,UK,E)
MANUAL, INSTRUCTION (ENGLISH,FRENCH)
(US,Canadian)
************************************************************
#1
#2
#3
#4
#5
#6
#7
#8
#9
**************
HARDWARE LIST
**************
7-685-544-14
7-685-546-19
7-685-646-79
7-685-649-79
7-685-144-11
7-682-949-01
7-685-660-79
7-685-645-79
3-912-431-11
SCREW +BTP 3X5 TYPE2 N-S
SCREW +BTP 3X8 TYPE2 N-S
SCREW +P 3X8 TYPE2 N-S
SCREW +P 3X14 TYPE2 N-S
SCREW +P 3X5 TYPE2 N-S
SCREW +PSW 3X10
SCREW +P 4X10 TYPE2 N-S
SCREW +P 3X6 TYPE2 N-S
SCREW M 4X8 (P)
Ref. No. Part No. Description Remark
XM-1002HX
Ver 1.1
