Signal-to-noise ratio 90 dB
Frequency response 10 20,000 Hz
Wow and lutter Below measurable limit
General
Design and Speci ications subject to change without notice.
CD Player Section
FM
Tuning range 87.5 107.9 MHz
Antenna terminal External antenna connector
Intermediate requency 10.7 MHz/450 kHz
Usable sensitivity 8 dB
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 66 dB (stereo), 72 dB (mono)
Harmonic distortion at 1 kHz 0.6% (stereo), 0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 15,000 Hz
AM
Tuning range 530 1,710 kHz
Antenna terminal External antenna connector
Intermediate requency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs
Speaker impedance 4 8 ohms
Maximum power output 52 W × 4 (at 4 ohms)
Outputs Audio outputs ( ront /rear)
Power antenna relay control terminal
Power ampli ier control terminal
Inputs Telephone ATT control terminal
Illumination control terminal
BUS control input terminal
BUS audio input terminal
Remote controller input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 62 Hz
Treble ±10 dB at 16 kHz
Loudness +8 dB at 100 Hz
+2 dB at 10 kHz
Power requirements 12 V DC car battery (negative ground)
Dimensions Approx. 178 × 50 × 178 mm
(7 1/8 × 2 × 7 1/8 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 162 mm
(7 1/4 × 2 1/8 × 6 1/2 in.) (w/h/d)
Mass Approx. 1.2 kg (2 lb. 10 oz.)
Supplied accessories Parts or installation and connections (1 set)
Front panel case (1)
Card remote commander (1)
This unit cannot be connected to a digital preampli ier or an equalizer.
CDX-CA720X
FM/AM Compact Disc Player
Power Amplifier Section
Note
2002 SONY MOBILE
PRODUCT GUIDE
Tuner Section
5.5 volt F/R Preouts
Flip-down, Detachable Face
CD TEXT®
13-segment, blue LCD
8 s,1-Bit D/A Converter
Active Servo Control
60 Degree Install
CD-RW Playback
Xplod® Power: 52W x 4
Active Display w/Demo Mode
Supplied Wireless Remote (RM-X118)
Optional Wired Rotary Remote (RM-X4S)
CD/MD Control w/Custom File memory
XM Ready
DSO
EQ7
SSIR-EXA Tuner
18FM + 12AM memory presets
-
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven rom 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
Audio Power Specifications
Plug shown with wires acing viewer.
Pin Number Wire Color Description
1 White Le t ront +
2 Green Le t rear +
3 Purple Right rear +
4 Gray Right ront +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Le t ront -
10 Green/black Le t rear -
11 Purple/black Right rear -
12 Gray/black Right ront -
13 Sky blue ATT
14 Illumination
15
16 Yellow Battery
Harness Plug Configuration
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
