Sony CDX-GT63UIW - Fm/am Compact Disc Player User manual

The Sony Xplōd® CDX-GT63UIW is a versatile and smart car audio solution
that lets you listen to music several ways with superior sound quality.
Connect, charge, and control your iPod®2, Walkman® player, or other
digital music players with USB5 1-Wire, an innovative feature that also
displays song title, artist, track and more.
USB5 1 Wire for iPod®2
Now, one single head unit can access and control your iPod®2, Walkman® player, numerous
digital music players, USB5 enabled Thumb Drives and memory devices.
Quick-BrowZer®
Quick BrowZer® lets you quickly search for and select songs while driving.
Jump Mode
Jump Mode let's you quickly nd that sepcial song, by jumping through your collection.
Passenger Control
Let your co-pilot take control. Passenger Control lets your passengers play DJ while you drive.
Zappin™
Plays music clips by scanning your music collection. Find your favorites quickly and easily by a
simple touch of the Zappin™ control.
MP3/WMA Playback1
Play CDs, CD-Rs, and CD-RWs, including discs loaded with MP3s and WMA les1
DM+ Digital Music Plus
This Sony® original codec enhancer brings your compressed music les back to life!
DRIVE-S Chassis
Sony® Drive-S technology provides the ultimate audio platform upon which to build a system
that caters to demanding ears!
Detachable Faceplate with Front Aux Input
One little cable is all it takes to listen to your iPod®, portable music player, or portable DVD player
through your Sony Xplod® system.
3x Preouts with HPF/LPF Filter
The Sony Xplod® CDX-GT63UIW includes three preouts so you can boost your car's sound system
with minimal eort and maximum exibility.
Sat Radio3 / HD Radio®4 adaptor ready
The CDX-GT63WUI integrates seamlessly with satellite radio3 and HD Radio®4 so you can receive
digital radio broadcasts.
Specications
Amplier Section
Speaker Impedance 4-8 Ohms
Audio
Audio Format BTM
Band AM / FM
CD Playback Wow and utter-Below measurable limit
Digital-to-Analog Converter 24bit
Frequency Response 10-20,000Hz
Output Impedance 4-8 Ohms
CDX-GT63UIW CD Receiver MP3/WMA/AAC Player

Preout Voltage 2 volt
S/N Ratio CEA2006 S/N 82 dB
Sensitivity (db) FM:Usable sensitivity (75)(dBf): 9
Signal-to-Noise Ratio (dB) CD: 120dB
Station Preset(s) FM18/AM12
Tone Control(s)
Low: +/-10 dB at 60Hz (XPLOD)
Mid: +/-10dB at 1kHz (XPLOD)
High: +/-10dB at 10kHz (XPLOD)
Tuner Frequency Range FM:Tuner Frequency Range(MHz): 87.5-107.9, AM:Tuner Frequency Range(kHz): 530-1710
Tuner Type SSIR-EXA
Volume Control Tel/Nav Attenuation
Wow and Flutter Below Measurable Limit
Audio Features
Level Control -8dB ~ +18dB
Convenience
Menu Options Auto Title Scroll
Tilt Range 45°
Convenience Features
CD Text Display Yes
Illumination Blue, Green
On-Screen Clock 12H
General
Color Black
Inputs and Outputs
12V Trigger Output(s) Power antenna
Amplier turn on
Analog Audio Input(s) (Total) Front Aux-In
Antenna Terminal(s) Aerial Input Terminal
Audio Out (Variable/Fixed) Speaker outputs (sure seal connectors)
Digital Audio Input(s)
- Ability to use all forms of USB devices may vary as not all devices are compatible.
This unit can be connected to the following iPods. Update your iPod to the latest
soware before you use it.
-iPod Nano 1st generation*
-iPod Nano 2nd generation (aluminum)
-iPod Nano 3rd generation (video)
-iPod 5th generation (video)*
-iPod Classic
-iPod Touch
-iPhone
* When you connect iPod Nano1st generation or iPod 5th generation, Passenger
Control is not available.
-This unit is compliant with MSC (Mass Storage Class) and MTP (Media Transfer Protocol)
type USB devices compliant with the USB standard.
-This unit cannot recognize USB devices via a USB hub.
For customers in the USA, please visit the following site for further information:
http://www.xplodsony.com
If you have any questions or problems concerning your unit that are not covered in this
manual, consult your nearest Sony dealer.
Infrared Port Remote Controller Input Terminal
Input(s)
BUS audio input terminal,
Front USB5,
Front Aux In

1. Not all MP3, WMA, AAC les may playback due to le variations. Copyright protected
ACC-LC les cannot be played back.
2. Ability to use all generations of iPod products may vary as not all products are
compatible.
3. Satellite radio service requires a satellite radio tuner and service subscription, sold
separately.
4. HD Radio® capability requires an optional HD Radio tuner (XT-100HD).
5. Ability to use all forms of USB devices may vary as not all devices are compatible.
© 2009 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony, Memory Stick, nav-u, Quick-BrowZer, Walkman,
Xplod, ZAPPIN, and the Sony, nav-u and Xplod logos are trademarks of Sony. iPhone and
iPod are trademarks of Apple Inc., registered in the U.S. and other countries. Bluetooth is
a trademark of Bluetooth SIG, Inc. NAVTEQ Maps & Trac is a trademark of NAVTEQ. All
other trademarks are trademarks of their respective owners. Features and specications
are subject to change without notice. Non-metric weights and measures are approximate.
/Updated: December 15, 2011
Remote Jack Optional Wired Rotary Remote input
USB Port(s) USB Full-Speed
Power
Input Power 12 V DC car battery (negative ground (earth))
Output Power 52W x4 High Power - 17 watts per channel minimum continuous average power into
4 Ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5% total harmonic
distortion.
Power Consumption (in Operation) 45W
Tape Player
Frequency response CD: 10-20,000Hz
Tuner
FM Usable Sensitivity 10 dBf
Frequency Response 20 - 15,000 Hz
S/N Ratio 70 dB
Selectivity 75 dB at 400 kHz
Stereo Separation 40 dB at 1 kHz
Video Features
Display Technology LCD
Weights and Measurements
Dimensions (Approx.) 178 x 50 x 182mm
Weight (Approx.) 1.2 kg
Supplied Accessories
Supplied Accessories Parts for installation and connections (1 set)
Card remote commander: RM-X151
Optional Accessories
Optional Accessories
CD changer (10 discs): CDX-M757MX
CD changer (6 discs): CDX-T69
Source selector: XA-C40
Aux-in selector: XA-300
HD Radio® tuner: XT-100HD
USB Connection Cable for iPod: RC-100IP
