Sony GT620U - CDX Radio / CD User manual

SONY:
3-275-494-71 (1)
FM/AM
Compact Disc Player
Operating Instructions ---JB
Manual de instrucciones •
Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number
in the space provided below.
Refer
to these numbers whenever you call upon your Sony dealer regarding this product.
Model No. CDX-GT620U Serial No. _
To cancel the demonstration (DEMO) display, see page 12.
Para cancelar la pantalla de demostraci6n (DEMO), consulte la pagina 12.
rnJO§@
DIGITAL AUDIO
ITEXT I
AtracAD
AUDIO DEVICE
CDX-GT620U
© 2008 Sony Corporation

_. _Pla";,,YS_--I
_.
Windows
TM Media™
•
2
For installation and connections, see the
supplied installation/connections manual.
Warning
This equipment has been tested and found to
comply with the limits for aClass Bdigital
device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and,
if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in aparticular installation.
If this
equipment does cause harmful interference
to
radio or television reception, which can be
determined by turning the equipment
off and on,
the user is encouraged to try to correct the
interference by one or more
of the following
measures:
-Reorient
or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
CAUTION
The use of optical instruments with this product
will increase eye hazard.
For the state of california, USA only
Perchlorate Material- special handling may apply,
See www.dtsc.ca.govlhazardouswaste/perchlorate
Perchlorate Material: Lithium battery contains
perchlorate
"ATRAC", "ATRAC AD", SonicStage and their
logos are trademarks
of Sony Corporation.
"WALKMAN" and "WALKMAN" logo are
registered trademarks
of Sony Corporation.
Microsoft, Windows Media,
and the Windows logo are
trademarks or registered
trademarks
of Microsoft
Corporation
in the United States and/or other
countries.
Warning if your car's ignition has no
ACC position
Be sure to set the Auto Offfunction (page 12).
The unit will shut offcompletely and
automatically in the set time after the unit is
turned off, which prevents battery drain.
If you do not set the Auto Offfunction, press
and hold
(OFF) until the display disappears
each time you turn the ignition off.

Table of Contents
Welcome! 4
Getting Started
Resetting the unit 4
Preparing the card remote commander 4
Setting the clock 4
Detaching the front panel 5
Attaching the front panel 5
Inserting the disc in the unit 5
Ejecting the disc 5
Location of controls and basic
operations
Main unit 6
Card remote commander RM-XI51 6
Searching for atrack
-Quick-BrowZer 8
CD
Display items 9
Repeat and shuffle play 9
Radio
Storing and receiving stations 9
Storing automatically -BTM 9
Storing manually 9
Receiving the stored stations 9
Tuning automatically 9
USB devices
USB device playback 10
Display items 10
Listening to music on aMass Storage
Class type audio device 10
Listening to music on a"Walkman"
(ATRAC Audio Device) 10
Other functions
Changing the sound settings 11
Adjusting the sound characteristics 11
Customizing the equalizer curve
-EQ3 12
Adjusting setup items -SET 12
Using optional equipment 13
Auxiliary audio equipment 13
Rotary commander RM-X4S 13
Additional Information
Precautions ......................... .. 14
Notes on discs 14
About USB devices 15
Playback order of MP3IWMAIAAC files
(CD-RlRW or Mass Storage Class) 15
About MP3 files. .................. .. 15
About WMA files 16
About AAC files 16
About ATRAC files 16
Maintenance . . . . . . . . . . . . . . . . . . . . . . . .
.. 16
Removing the unit. ................... .. 17
Specifications ....................... .. 17
Troubleshooting ..................... .. 19
Error displays/Messages 20 •
3

Setting the clock
Before using the card remote commander for the
first time, remove the insulation film.
Note
Pressing the RESETbutton will erase the clocksetting
and some storedcontents.
oil
RESET ~---40
button ~
Tip
For how to replace the battery, see "Replacing the
lithium battery
of the card remote commander" on
page
16.
Preparing the card remote
commander
Before operating the unit for the first time, or
after replacing the car battery or changing the
connections, you must reset the unit.
Detach the front panel and press the RESET
button with apointed object, such as aball-point
pen.
Getting Started
Resetting the unit
The clock uses a12-hour digital indication.
1Press and hold the select button.
The setup display appears.
2Press the select button repeatedly
until "CLOCK-ADJ" appears.
3Press (SEEK) +.
The hour indication flashes.
4Rotate the control dial to set the hour
and minute.
To move the digital indication, press (SEEK)
-/+.
5Press the select button.
The setup is complete and the clock starts.
To display the clock, press
(DSPL). Press
( DSPL) again to return to the previous display.
Type of discs Label
on the disc
CD-DA
[Q]D~@ [Q]D~@
DIGITAL AUDIO DIGITAL AUDIO
I jiM.iI.MIM
IReWritablel
[Q]D~@ [Q]D~@
MP3
DIGITAL AUDIO
DIGITAL AUDIO
Gtk·lt.iIM
IReWritablel
WMA
AAC
[Q]D~@
ffi]D~@
1if:N·U.f4ijM IReWritablel
Welcome!
Thank you for purchasing this Sony Compact
Disc Player.
You can enjoy your drive with the
following functions.
•CD playback
You can play CD-DA (also containing CD
TEXT) and CD-RlCD-RW (MP3IWMAJAAC
files (page 15)).
•Radio reception
- You can store up to 6stations per band (FM 1,
FM2, FM3, AM1and AM2).
-BTM (Best Tuning Memory): The unit selects
strong signal stations and stores them.
•Search function
Quick-BrowZer:
You can quickly and easily
search for atrack in aCD, or USB device
connected to this unit (page 8).
•Sound adjustment
-EQ3 stage2:
You can choose anyone of 7
preset equalizer curves.
-DSO (Dynamic Soundstage Organizer):
Creates amore ambient sound field, using
virtual speaker synthesis, to enhance the
sound
of speakers, even if they are installed
low in the door.
-Digital Music Plus (DM+): Improves
digitally compressed sound, such as MP3.
•Optional device operation
USB device: AMass Storage Class USB
device
or "Walkman" (ATRAC Audio Device)
can be connected to the front USB terminal.
For details on usable devices, please refer to
About USB devices (page 15) or the Sony
support website (page 21).
•Auxiliary equipment connection
An AUX input jack on the front of the unit
allows connection
of aportable audio device.
4
•

Detaching the front panel
You can detach the front panel of this unit to
prevent theft.
Caution alarm
If you tum the ignition switch to the OFF
position without detaching the front panel, the
caution alarm will sound for afew seconds.
The alarm will only sound
if the built-in
amplifier
is used.
1Press (OFF ).
The unit is turned off.
2Press (OPEN).
The front panel is flipped down.
3Slide the front panel to the right, then
gently pull out the left end of the front
panel.
Notes
•Do not drop or put excessive pressure on the front
panel
and display window.
•Do notsubject the front panel
to heat/high
temperature
or moisture. Avoidleaving it in aparked
car or on adashboard/rear tray.
•Do not detach the front panel during playback of the
USB device, otherwise USB data may
be damaged.
Attaching the front panel
Place the hole ® of the front panel onto the
spindle ®
on the unit, then lightly push the left
side in.
~~=-="'=--
Press (SOURCE) on the unit (or insert adisc) to
operate the unit.
Note
Do not put anything on the innersurface of the front
panel.
Inserting the disc in the unit
1Press (OPEN ).
2Insert the disc (label side up).
3Close the front panel.
Playback starts automatically.
Ejecting the disc
1Press (OPEN).
2 Press~.
The disc is ejected.
3Close the front panel. •
5

Location of controls and basic operations
Main unit
Front panel removed
56
.....,
·
·
·
·
·
••• 1
16 17 18
r
~
I))
.-
6
IRESETI gl
6
Card remote commander
RM-X151 This section contains instructions on the location
of controls and basic operations. For details, see
the respective pages.
For USB device operation, see 'USB devices" on
page
10.
The corresponding buttons on the card remote
commander control the same functions as those
on the unit.
ff] OFF button
To power off; stop the source.
[2J Q(BROWSE) button page 8
To enter the Quick-BrowZer mode.
~ Control diaVselect button page 8, 11
To adju tvolume (rotate); select items (pre s
and rotate).
@J SOURCE button
To power on; change the source (Radio/CD/
USB/AUX).
[ID Display window

[§] USB terminal page 10
To connect to the USB device.
[l] OPEN button page 5
[ID ~(BACK) button page 8
To return to the previous display.
rID Receptor for the card remote
commander
[1Q] SEEK -/+ buttons
CDIUSB:
To skip tracks (press); skip tracks
continuously (press, then press again within
about Isecond and hold); reverse/fast-
forward atrack (press and hold).
Radio:
To tune in stations automatically (press); find
astation manually (press and hold).
II1J MODE button page 9, 10
To select the radio band (FM/AM); select the
play mode
of ATRAC Audio Device.
[12] BTM button page 9
To start the BTM function.
~ Number buttons
CDIUSB:
(D/m: ALBUM -/+
To skip albums (press); skip albums
continuously (press and hold).
®: REP page 9
CD: SHUF page 9
®: DM+ page 4
To activate the DM+ function, set
"DM+-ON." To cancel, set "DM+-
OFF."
@:PAUSE
To pause playback. To cancel, press
agam.
Radio:
To receive stored stations (press); store
stations (press and hold).
lHl DSPL (display)/SCRL (scroll) button
page 9
To change display items (press); scroll the
display item (press and hold).
II§] AUX input jack page 13
To connect aportable audio device.
[1§] RESET button page 4
[f] ~ (eject) button page 5
To eject the disc.
[1§] Disc slot page 5
To insert the disc.
The following buttons on the card remote
commander have also different buttons/functions
from the unit. Remove the insulation film before
use (page 4).
1m .. (1+11 )/ .. (~) buttons
To control CD/radiolUSB, the same as
(SEEK) -/+ on the unit.
Setup, sound setting, etc., can be operated by
.....
~ DSPL (display) button
To change display items.
g) VOL (volume) +/- button
To adjust volume.
PlJ ATT (attenuate) button
To attenuate the sound. To cancel, press
agam.
fI] SEL (select) button
The same as the select button on the unit.
During the Quick-BrowZer mode,
(SEL)
(select) is inactive.
Rm t(+)/ ... (-) buttons
To control CD/USB, the same as (D/m
(ALBUM -/+) on the unit.
Setup, sound setting, etc., can be operated by
t ....
~ SCRL (scroll) button
To scroll the display item.
~ Number buttons
To receive stored stations (press); store
stations (press and hold).
Notes
•When ejecting/inserting adisc, keep any USB
devices disconnected
to avoid damage to the disc.
•Ifthe unit is turned off and the display disappears, it
cannot be operated with the card remote
commander unless (SOURCE) on the unit is
pressed, or adisc is inserted to activate the unit first.
.~ .,'
7

Searching for atrack -Quick-BrowZer
You can search for atrack in aCD or USB device ("Walkman"/Mass Storage Class) easily by category.
Q(BROWSE):
To enter/exit the Quick-BrowZer mode.
~ (BACK):
To return to the previous display.
1Press Q(BROWSE).
The unit enters the Quick-BrowZer mode, and the list of search categories appears.
Display items differ, depending on the type
of device or disc.
Control dial:
To select the item (rotate); confirm the item (press).
2Rotate the control dial to select the desired search category, then press it to confirm.
ECl3
3Repeat step 2until the desired track is selected.
Playback starts.
To return to the previous display
Press ~ (BACK).
To exit the Quick-BrowZer mode
Press Q(BROWSE).
Notes
•When entering the Quick-BrowZermode, the repeat/shuffle setting is canceled.
•Depending
on the USB device, display items may notappear correctly
•Depending on the USB device, no sound may output during the Quick-BrowZer mode.

Display items
"Source
oTrack number/Elapsed playing time, Disc/
artist name, Album number*, Album name,
Track name, Text information, Clock
*Album numberis displayed only when the album is
changed.
To change display items 0, press (DSPL).
Tip
Displayeditems will differ, depending on the disc type,
recording format andsettings. For details on
MP3/
WMAlAAC, see page 15.
Repeat and shuffle play
1During playback, press ®(REP) or
CD (SHUF) repeatedly until the
desired setting appears.
Radio
Storing and receiving slations
Caution
When tuning in stations while driving, use Best
Tuning Memory (BTM) to prevent an accident.
Storing automatically - 81M
1Press (SOURCE) repeatedly until
"TUNER" appears.
To change the band, press (MODE)
repeatedly. You can select from FM l, FM2,
FM3,
AMI or AM2.
2Press and hold (BTM) until "BTM"
flashes.
The unit stores stations in order of frequency
on the number buttons.
Abeep sounds when the setting is stored.
Storing manually
1While receiving the station that you
want to store, press and hold a
number button (CD to
®) until
"MEM" appears.
Note
If you try to store anotherstation on the same number
button, the previously storedstation will be replaced.
•
*When an MP3IWMAlAAC is played.
To return to normal play mode, select "e OFF"
or "SHUF OFF."
Select
c:; TRACK
c:; ALBUM*
SHUF ALBUM*
SHUF DISC
To play
track repeatedly.
album repeatedly.
album
in random order.
disc in random order.
Receiving the stored stations
1Select the band, then press anumber
button (CD to
®).
Tuning automatically
1Select the band, then press (SEEK) -/+
to search for the station.
Scanning stops when the unit receives a
station. Repeat this procedure until the
desired station is received.
Tip
If you know the frequency of the station you want to
listen to, press and hold ( SEEK) -/+ to locate the
approximate frequency, then press
(SEEK) -/+
repeatedly to fine adjust to the desired frequency
(manual tuning).
9

USB devices
USB device playback
1Open the USB cover.
To change display items 0, press (DSPL).
Tip
Displayed items will differ, depending on the recorded
format and settings. For details on MP3IWMAlAAC/
ATRAC, see page
15.
Note
The display differs depending on the Mass Storage
Class type USB device,
and ATRAC Audio Device.
Listening to music on aMass
Storage Class type audio device
Repeat and shuffle play
1During playback, press ®(REP) or 0
(SHUF) repeatedly until the desired setting
appears.
To return to normal play mode, select
"4 OFF"
or "SHUF OFF".
•
2 Connect the USB device to the USB
terminal.
Select
4TRACK
4ALBUM
SHUF ALBUM
SHUF DEVICE
To play
track repeatedly.
album repeatedly.
album in random order.
device in random order.
Playback starts.
If aUSB device is already connected, to start
playback, press
(SOURCE) repeatedly until
"USB" appears.
Press
(OFF) to stop playback.
Notes
•Before removing aUSB device, be sure to stop
playback first.
If you remove your USB device during
playback, data
in the USB device maybe damaged.
•Do
not use USB devices so large or heavy that they
may fall down due
to vibration, or cause aloose
connection.
•Do
not detach the front panelduring playback of the
USB device, otherwise USB data maybe damaged.
Listening to music on a"Walkman"
(ATRAC Audio Device)
1During playback, press (MODE)
repeatedly until the desired setting
appears.
The item changes as follows:
ALBUM --+ TRACK --+ GENRE --+
PLAYLIST --+ ARTIST
Repeat and shuffle play
1During playback, press ®(REP) or 0
(SHUF) repeatedly until the desired setting
appears.
10
Display items
oATRAC Audio Device: AAD
Mass Storage Class: USB
oTrack!Album!Artist/Playlist/Genre number,
Track!Album!Artist/Playlist/Genre name,
Elapsed playing time, Clock
Select
4TRACK
4ALBUM
4ARTIST
4PLAYLIST
4GENRE
SHUF ALBUM
SHUF ARTIST
SHUF PLAYLIST
To play
track repeatedly.
album repeatedly.
artist repeatedly.
playlist repeatedly.
genre repeatedly.
album in random order.
artist in random order.
playlist
in random order.

To return to normal play mode, select "e; OFF"
or "SHUF OFF. "
SHUF GENRE
SHUF DEVICE
genre in random order.
device in random order.
Other functions
Changing the sound settings
Adjusting the sound
characteristics
1Press the select button repeatedly
until the desired item appears.
2Rotate the control dial to adjust the
selected item.
After 3seconds, the setting is complete and
the display returns to normal play/reception
mode.
The following items can be set (follow the page
reference for details):
"e" indicates the default settings.
EQ3
To select an equalizer type: "XPLOD,"
"VOCAL," "EDGE," "CRUISE," "SPACE,"
II
"GRAVITY," "CUSTOM" or "OFF (e)."
DSO
To select the DSO mode: "1," "2," "3" or "OFF
(e)." The larger the number, the more enhanced
the effect.
LOW*1, MID*1, HI*' (page 12)
To customize the equalizer curve.
BAL (Balance) .
To adjust the balance between the right and left
speakers: "RIGHT-I0" -"CENTER"
(e)-
"LEFT-I0"
FAD (Fader)
To adjust the balance between the front and rear
speakers: "FRONT-lO" -"CENTER"
(e)-
"REAR-10"
SUB (Subwoofer volume)
To adjust the subwoofer volume: "+10 dB" -
"0 dB" (e) - "-10 dB"
("ATT" is displayed at the lowest setting.)
AUX*2 (AUX level)
To adjust the volume level for each connected
auxiliary equipment. This setting negates the
need to adjust the volume level between sources
(page 13).
Adjustable level: "+18 dB" -"0 dB"
(e)-
"-8 dB"
*IWhen E03 is activated.
*2 When AUXsource is activated.
11

•
12
Customizing the equalizer curve
-EQ3
"CUSTOM" of EQ3 allows you to make your
own equalizer settings.
1Select asource, then press the select
button repeatedly to select "EQ3."
2Rotate the control dial to select
"CUSTOM."
3Press the select button repeatedly
until "lOW," "MID" or "HI" appears.
4Rotate the control dial to adjust the
selected item.
The volume level is adjustable in I dB steps,
from
-10 dB to + 10 dB.
..... ......
i::::i c:::i .1:i
Repeat steps 3and 4to adjust the equalizer
curve.
To restore the factory-set equalizer curve,
press and hold the select button before the
setting
is complete.
After 3seconds, the setting is complete and
the display returns to normal play/reception
mode.
Tip
Otherequalizer types are also adjustable.
Adjusting setup items - SET
1Press and hold the select button.
The setup display appears.
2Press the select button repeatedly
until the desired item appears.
3Rotate the control dial to select the
setting (example "ON" or "OFF").
4Press and hold the select button.
The setup is complete and the display returns
to normal play/reception mode.
Note
Displayed items will differ, depending on the source
and setting.
The following items can be set (follow the page
reference for details):
"e" indicates the default settings.
ClOCK-ADJ (Clock Adjust) (page 4)
BEEP
To set "BEEP-ON" (e) or "BEEP-OFF."
AUX-A*1 (AUX Audio)
To tum the AUX source display "AUX-A-ON"
(e) or "AUX-A-OFF" (page 13).
A.OFF (Auto Off)
To shut off automatically after adesired time
when the unit
is turned off.
-"A.OFF-NO" (e), "A.OFF-30S (Seconds),"
"A. OFF-30M (Minutes)" or "A.OFF-60M
(Minutes
)."
DEMO (Demonstration)
To set "DEMO-ON" (e) or "DEMO-OFF."
DIMMER
To change the brightness of the display.
-"DIMMER-AT" (e): to dim the display
automatically when you turn lights on.
-"DIMMER-OFF":
to deactivate the dimmer.
-"DIMMER-ON": to dim the display.
M.DSPl (Motion Display)
To select the Motion Display mode.
-"M.DSPL-SA" (e): to show moving patterns
and spectrum analyzer.
-"M.DSPL-ON": to show moving patterns.
-"M.DSPL-OFF": to deactivate the Motion
Display.
A.SCRl (Auto Scroll)
To scroll long displayed item automatically
when the disc/album/track
is changed.
-"A.SCRL-ON" (e): to scroll.
-"A.SCRL-OFF":
to not scroll.
lOCAL (Local Seek Mode)
-"LOCAL-ON" :
to only tune into stations with
stronger signals.
-"LOCAL-OFF" (e): to tune normal reception.
MONO*2 (Monaural Mode)
To improve poor FM reception, select monaural
reception mode.
-"MONO-ON" :to hear stereo broadcast in
monaural.
-"MONO-OFF" (e): to hear stereo broadcast in
stereo.
lPF (Low Pass Filter)
To select the subwoofer cut-offfrequency: "LPF
OFF" (e), "LPF125Hz" or "LPF 78Hz."
lOUD (Loudness)
To allow you to listen clearly at low volume
levels.
-"LOUD-ON" :to reinforce bass and treble.
-"LOUD-OFF" (e):
to not reinforce bass and
treble.
BTM (page 9)
*1When the unit is turned off.
*2 When FM is received.

Using optional8guipmlnl
Auxiliary audio equipment
By connecting an optional portable audio device
to the AUX input
jack (stereo mini jack) on the
unit and then simply selecting the source, you
can listen on your car speakers. The volume level
is adjustable for any difference between the unit
and the portable audio device. Follow the
procedure below:
Connecting the portable audio
device
1Turn off the portable audio device.
2Turn down the volume on the unit.
3Connect to the unit.
Rotary commander RM-X4S
Attaching the label
Attach the indication label depending on how
you mount the rotary commander.
Location of controls
The corresponding buttons on the rotary
commander control the same functions as those
on this unit.
All
continue to next page --+
The following controls on the rotary commander
require adifferent operation from the unit.
•SEL (select) button
The same as the select button on the unit.
During the Quick-BrowZer mode,
(SEL)
(select) is inactive.
•PRESET/DISC control
CD/USB: The same as (DIm (ALBUM -1+)
on the unit (push in and rotate).
Radio: To receive stored stations (push in and
rotate).
•VOL (volume) control
The same as the control dial on the unit (rotate).
•SEEKIAMS control
The same as (SEEK) -1+ on the unit (rotate, or
rotate and hold).
•DSPL (display) button
To change display items.
II
MODE
DSPL '--( 0,)
SEEKIAMS OFF
VOL
SOURCE
Connecting cord*
(not supplied)
Adjust the volume level
*Be sure to use astraight type plug.
Be sure to adjust the volume for each connected
audio device before playback.
1Turn down the volume on the unit.
2Press
(SOURCE) repeatedly until "AUX"
appears.
"AUX FRONT IN" appears.
3Start playback
of the portable audio device at a
moderate volume.
4Set your usual listening volume on the unit.
5Adjust the input level (page
11).
13

•
14
Changing the operative direction
The operative direction of the controls is factory-
set as
shown below.
To increase
If you need to mount the rotary commander on
the right hand side of the steering column, you
can reverse the operative direction.
1
While pushing the VOL control, press and
hold (SEL).
Additional Information
Precautions
• If your car has been parked in direct sunlight,
allow the unit to cool
off before operating it.
•Power antenna (aerial) will extend automatically
while the unit
is operating.
Moisture condensation
On arainy day or in avery damp area, moisture
condensation may occur inside the lenses and
display
of the unit. Should this occur, the unit will
not operate properly.
In such acase, remove the disc
and wait for about an hour until the moisture has
evaporated.
To maintain high sound quality
Be careful not to splash juice or other soft drinks
onto the unit or discs.
Notes on discs
•To keep a disc clean, do not touch its surface.
Handle the disc by its edge.
•Keep your discs in their cases
or disc magazines
when not in use.
•
Do not subject discs to heat/high temperature.
Avoid leaving them in aparked car
or on a
dashboard/rear tray.
•Do not attach labels, or use discs with sticky ink!
residue. Such discs may stop spinning when used,
causing amalfunction, or may ruin the disc.
xX X
®@~
•Do not use any discs with labels or stickers
attached.
The following malfunctions may result from using
such discs:
-Inability to eject adisc (due to alabel
or sticker
peeling off and jamming the eject mechanism).
-Inability to read audio data correctly (e.g.,
playback skipping, or no playback) due to heat
shrinking
of asticker or label causing adisc to
warp.
•Discs with non-standard shapes (e.g., heart,
square, star) cannot be played on this unit.
Attempting to do so may damage the unit. Do not
use such discs.
•
You cannot play 8cm (3 1/-1 in) CDs.

•Before playing, clean the discs
with acommercially available
cleaning cloth. Wipe each disc
from the center out. Do not use
solvents such as benzine,
thinner, commercially available
cleaners, or antistatic spray
intended for analog discs.
Notes on CD-R/CD-RW discs
•Some CD-Rs/CD-RWs (depending on the
equipment used for its recording or the condition
of the disc) may not play on this unit.
• You cannot playa CD-RIa CD-RW that is not
finalized.
•The unit is compatible with the ISO 9660 level 1/
level 2format, Joliet/Romeo in the expansion
format, and Multi Session.
•The maximum number of:
-folders (albums): 150 (including root and empty
folders).
-files (tracks) and folders contained in adisc: 300
(ifafolder/file names contain many characters,
this number may become less than 300).
-displayable characters for afolder/file name is
32 (Joliet), or 64 (Romeo).
•When the disc is recorded in Multi Session, only
the first track of the first session format is
recognized and played (any other format is
skipped). The priority of the format is CD-DA and
MP3IWMAIAAC.
-When the first track is aCD-DA, only CD-DA of
the first session is played.
-When the first track is not aCD-DA, the MP3/
WMA/ AAC session is played. If the disc has no
data in any of these formats, "NO MUSIC" is
displayed.
Music discs encoded with copyright
protection technologies
This product is designed to play back discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed by
some record companies. Please be aware that among
those discs, there are some that do not conform to
the CD standard and may not be playable by this
product.
Note on DualDiscs
ADuaIDisc is atwo sided disc product which
mates DVD recorded material on one side with
digital audio material on the other side. However,
since the audio material side does not conform to
the Compact Disc (CD) standard, playback on this
product is not guaranteed.
About USB devices
•Mass Storage Class and ATRAC Audio Device
type USB devices compliant with the USB
standard can be used. However, this unit cannot
recognize USB devices via aUSB HUB. For
details on the compatibility of your USB device,
visit the Sony support website (page 21).
•Corresponding codec is different according to
device type.
-Mass Storage Class: MP3IWMA/AAC
-ATRAC Audio Device: ATRAC/MP3IWMAI
AAC
•DRM (Digital Rights Management) files other
than ATRAC may not be played.
•The maximum number of displayable data is as
follows.
Mass Storage Class:
-folders (albums): 128, files (tracks) per folder:
500
ATRAC Audio Device: ATRACIMP3IWMA/AAC
-albums/artists/playlists/genres: 65535, tracks:
65535
Notes
•When using acable, use the one supplied with the
USB device to connect.
•Do not use aUSB device that is so large
or heavy it
may interfere with driving operations.
•Do notleave aUSB device
in aparked car, as
malfunction may result.
• It may take time for playback to begin, depending on
the amount of recorded data.
•Backup
of data in aUSB device is recommended.
Playback order of MP3IWMAIAAC
files (CD-R/RW
or Mass Storage
Class)
CJ
Folder
(album)
IE] MP3IWMAJ
AAC file
(track)
About MP3 files
•MP3, which stands for MPEG-l Audio Layer-3, is
amusic file compression format standard. It
compresses audio CD data to approximately III 0
of its original size.
continue to next page ---+
•
15

Maintenance
If you have any questions or problems concerning
your unit that are not covered in this manual. consult
your nearest Sony dealer.
WARNING
Battery may explode if mistreated.
Do not recharge, disassemble, or dispose of
in fire.
+side up
~
~I
'~
Fuse (10 A)
Replacing the lithium battery of the
card remote commander
Under normal conditions, the battery will last
approximately 1year. (The service life may be
shorter, depending on the conditions of use.)
When the battery becomes weak, the range of the
card remote commander becomes shorter.
Replace the battery with anew CR2025 lithium
battery. Use of any other battery may present a
risk of fire or explosion.
Notes on the lithium battery
•Keep the lithium battery out
of the reach of children.
Should the batterybe swallowed, immediately
consult adoctor.
oWipe the battery with adry cloth to assure a good
contact.
oBe sure to observe the correctpolarity when
installing the battery
oDo nothold the battery with metallic tweezers,
otherwise ashort-circuit may occur.
Fuse replacement
When replacing the fuse, be
sure to use one matching the
amperage rating stated on the
original fuse. If the fuse blows,
check the powerconnection and
replace the fuse. If the fuse
blows again after replacement.
there may be an internal
malfunction. In such acase.
consult your nearest Sony
dealer.
About AAC files
•AAC, which stands for Advanced Audio Coding,
is amusic file compression format standard. It
compresses audio CD data to approximately 1/11 *
of its original size.
oAAC tag is 126 characters.
oWhen naming an AAC file, be sure to add the file
extension ".m4a" to the file name.
oDuring playback or fast-forward/reverse of aVBR
(variable bit rate) AAC file, elapsed playing time
may not display accurately.
*only for 128 kbps
Note
Playback
of the following AAC files is not supported.
-lossless compression
-copyright-protected
About ATRAC files
ATRAC3plus format
ATRAC3. which stands for Adaptive Transform
Acoustic Coding3, is audio compression
technology. It compresses audio CD data to
approximately 1110 of its original size.
ATRAC3plus. which is an extended format of
ATRAC3, compresses the audio CD data to
approximately 1/20 of its original size. The unit
accepts both ATRAC3 and ATRAC3plus format.
The characters for text information written by
SonicStage are displayed.
•ID3 tag versions 1.0, 1.1, 2.2, 2.3 and 2.4 apply to
MP3 only. ID3 tag is 15/30 characters (1.0 and
1.1), or 631126 characters (2.2, 2.3 and 2.4).
•When naming an MP3 file, be sure to add the file
extension ".mp3" to the file name.
•During playback or fast-forward/reverse of aVBR
(variable bit rate) MP3 file, elapsed playing time
may not display accurately.
Note
Ifyou playa high-bit-rate MP3, such as 320 kbps,
sound may be intermittent.
About WMA files
•WMA, which stands for Windows Media Audio,
is amusic file compression format standard. It
compresses audio CD data to approximately 1/22*
of its original size.
o WMA tag is 63 characters.
•When naming a WMA file, be sure to add the file
extension ".wma" to the file name.
oDuring playback or fast-forward/reverse of aVBR
(variable bit rate) WMA file, elapsed playing time
may not display accurately.
II *only for 64 kbps
Note
Playback
of alossless compression file is not
supported.
16

Notes
•For safety, turn off the ignition before cleaning the
connectors,
and remove the key from the ignition
switch.
•Nevertouch the connectors directly with
your fingers
or with any metal device.
Hook facing
inwards.
eSlide the unit out of the mounting.
e Pull the release keys to unseat the unit.
2Remove the unit.
oInsert both release keys simultaneously
until they click.
Back of the front
panel
Main
unit
Cleaning the connectors
The unit may not function properly ifthe connectors
between the unit and the front panel are not clean. In
order to prevent this, detach the front panel (page 5)
and clean the connectors with acotton swab. Do not
apply too much force. Otherwise, the connectors
may be damaged.
Removing the unit
1Remove the protection collar.
o Detach the front panel (page 5).
e Pinch both edges of the protection collar,
then pull it out.
Specifications
II
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION
23.2 watts per channel minimum continuous
average power into 4ohms, 4channels driven
from 20
Hz to 20 kHz with no more than 5% total
harmonic distortion.
CEA2006 Standard
Power Output: ]7 Watts RMS x4at
4Ohms < ]%THD+N
SN Ratio:
82 dBA
(reference: 1Watt into 4Ohms)
CD Player section
Signal-to-noise ratio: 120 dB
Frequency response: ]0 - 20,000 Hz
Wow
and flutter: Below measurable limit
Tuner section
FM
Thning range:
87.5 -107.9 MHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 10.7 MHz/450 kHz
Usable sensitivity: 9dBf
continue to next page -- 17

•
18
Selectivity: 75 dB at 400 kHz
Signal-to-noise ratio:
67 dB (stereo), 69 dB (mono)
Harmonic distortion at 1kHz: 0.5 o/c (stereo),
0.3 %(mono)
Separation:
35 dB at 1kHz
Frequency response: 30 -15,000 Hz
AM
'funing range:
530
-1,710 kHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 10.7 MHz/450 kHz
Sensitivity: 30llV
USB Player section
Interface: USB (Full-speed)
Maximum current: 500mA
Power amplifier section
Outputs: Speaker outputs (sure seal connectors)
Speaker impedance: 4 - 8 ohms
Maximum power output: 52 Wx4(at 4ohms)
General
Output:
Audio outputs terminal (front/rear)
Subwoofer output terminal (mono)
Power antenna (aerial) relay control terminal
Power amplifier control terminal
Inputs:
Telephone ATT control terminal
Remote controller input terminal
Antenna (aerial) input terminal
AUX input jack (stereo mini jack)
Tone controls:
Low:
±1O dB at 60 Hz (XPLOD)
Mid:
±1O dB at 1kHz (XPLOD)
High:
±1O dB at 10 kHz (XPLOD)
Power requirements: 12 V DC car battery
(negative ground (earth»
Dimensions: Approx.
178 x50 x 180 mm
(7 '/8 x 2 x 7 1/
8
in) (w/h/d)
Mounting dimensions: Approx. 182 x 53 x 162 mm
(7 1/4x 2 1/8x 6 Ih in) (w/h/d)
Mass: Approx.
1.2 kg (2 Ib 11 oz)
Supplied accessories:
Card remote commander: RM-XI51
Parts for installation and connections
(1 set)
Optional accessory:
Rotary commander: RM-X4S
Your dealer may not handle some
of the above listed
accessory. Please ask the dealer for detailed
information.
MPEG Layer-3 audio coding technology and
patents licensed from Fraunhofer lIS and Thomson.
This product is protected by certain intellectual
property rights
of Microsoft Corporation. Use or
distribution of such technology outside of this
product is prohibited without alicense from
Microsoft
or an authorized Microsoft subsidiary.
Content providers are using the digital rights
management technology for Windows Media
contained in this device
("WM-DRM") to protect
the integrity
of their content ("Secure Content") so
that their intellectual property, including copyright,
in such content is not misappropriated.
This device uses
WM-DRM software to play
Secure Content
("WM-DRM Software"). If the
security
of the WM-DRM Software in this device
has been compromised, owners
of Secure Content
("Secure Content Owners") may request that
Microsoft revoke the
WM-DRM Software's right
to acquire new licenses to copy, display and/or
play Secure Content. Revocation does not alter the
WM-DRM Software's ability to play unprotected
content. Alist
of revoked WM-DRM Software is
sent to your device whenever you download a
license for Secure Content from the Internet
or
from a Pc. Microsoft may, in conjunction with
such license, also download revocation lists
onto
your device on behalf of Secure Content Owners.
Design and specifications are subject to change
without notice.
•Halogenated flame retardants are not used
in the
certain printed wiring boards.
•Halogenated flame retardants are not used in
cabinets.
•Packaging cushions are made from paper.

Troubleshooting
The following checklist will help you remedy
problems you may encounter with your unit.
Before going through the checklist below, check the
connection and operating procedures.
General
No power is being supplied to the unit.
oCheck the connection. If everything is in order, check
the fuse.
o If the unit is turned off and the display disappears, it
cannot be operated with the remote commander.
-- Tum on the unit.
The power antenna (aerial) does not extend.
The power antenna (aerial) does not have arelay box.
No sound.
oThe volume is too low.
oThe ATT function is activated, or the Telephone ATT
function (when the interface cable of acar telephone
is connected to the ATT lead) is activated.
oThe position of the fader control "FAD" is not set for
a2-speaker system.
No beep sound.
•The beep sound is canceled (page 12).
o An optional power amplifier is connected and you are
not using the built-in amplifier.
The contents of the memory have been erased.
oThe RESET button has been pressed.
-- Store again into the memory.
oThe power supply lead or battery has been
disconnected.
oThe power supply lead is not connected properly.
Stored stations and correct time are erased.
The fuse has blown.
Makes noise when the position of the ignition
is switched.
The leads are not matched correctly with the car's
accessory power connector.
During playback or reception, demonstration
mode starts.
If no operation is performed for 5minutes with
"DEMO-ON" set, demonstration mode starts.
-- Set "DEMO-OFF" (page 12).
The display disappears from/does not appear
in the display window.
oThe dimmer is set "DIMMER-ON" (page 12).
oThe display disappears if you press and hold (OFF).
-- Press and hold (OFF) on the unit until the
display appears.
oThe connectors are dirty (page 17).
The Auto Off function does not operate.
The unit is turned on. The Auto Off function activates
after turning off the unit.
-- Tum off the unit.
Card remote commander operation is not
possible.
Make sure the insulation film has been removed
(page 4).
DSO does not function.
Depending on the type of car interior or type of music,
DSO may not have adesirable effect.
. CD playback
The disc cannot be loaded.
•Another disc is already loaded.
oThe disc has been forcibly inserted upside down or in
the wrong way.
The disc does not playback.
oDefective or dirty disc.
oThe CD-Rs/CD-RWs are not for audio use (page 15).
MP3IWMAlAAC files cannot be played back.
The disc is incompatible with the MP3IWMAIAAC
format and version (page 15).
MP3IWMAlAAC files take longer to play back
than others.
The following discs take alonger time to start
playback.
- a disc recorded with acomplicated tree structure.
- a disc recorded in Multi Session.
- a disc to which data can be added.
The display items do not scroll. II
oFor discs with very many characters, those may not
scroll.
o"A.SCRL" is set to "OFF".
-- Set "A.SCRL-ON" (page 12).
-- Press and hold (DSPL) (SCRL).
The sound skips.
oInstallation is not correct.
-- Install the unit at an angle of less than 45° in a
sturdy part of the car.
oDefective or dirty disc.
The operation buttons do not function.
The disc will not eject.
Press the RESET button (page 4).
continue to next page --+
19

•
20
Radio reception
The stations cannot be received.
The sound is hampered by noises.
oConnect apower antenna (aerial) control lead (blue)
or accessory power supply lead (red) to the power
supply lead of acar's antenna (aerial) booster (only
when your car has built-in FM/AM antenna (aerial)
in the rear/side glass).
oCheck the connection of the car antenna (aerial).
oThe auto antenna (aerial) will not go up.
-Check the connection
of the power antenna
(aerial) control lead.
oCheck the frequency.
oWhen the DSO mode is on, the sound is sometimes
hampered by noises.
-Set the DSO mode to "OFF" (page 11).
Preset tuning is not possible.
oStore the correct frequency in the memory.
oThe broadcast signal is too weak.
Automatic tuning is not possible.
oSetting of the local seek mode is not correct.
-Tuning stops too frequently:
Set "LOCAL-ON" (page 12).
-Tuning does not stop at astation:
Set "MONO-ON" (page 12).
oThe broadcast signal is too weak.
-Perform manual tuning.
During FM reception, the "ST" indication
flashes.
oTune in the frequency accurately.
oThe broadcast signal is too weak.
-Set "MONO-ON" (page 12).
An FM program broadcast in stereo is heard in
monaural.
The unit is in monaural reception mode.
-Set "MONO-OFF" (page 12).
You cannot play back items via aUSB HUB.
This unit cannot recognize USB devices via aUSB
HUB.
Cannot play back items.
AUSB device does not work.
-+ Reconnect it.
The USB device takes longer to play back.
The USB device contains files with acomplicated tree
structure.
Abeep sounds.
During playback, the USB device has been
disconnected.
-+ Before disconnecting aUSB device, make sure to
stop playback first for data protection.
The sound is intermittent.
The sound may be intermittent at ahigh-bit-rate of
more than 320 kbps.
Error displays/Messages
CHECKING
The unit is confirming the connection of aUSB device.
-Wait until confirming the connection
is finished.
ERROR
oThe disc is dirty or inserted upside down.
-Clean or insert the disc correctly.
oAblank disc has been inserted.
oThe disc cannot play due to aproblem.
-Insert another disc.
oUSB device was not automatically recognized.
-Reconnect it again.
oPress ~ to remove the disc.
FAILURE
The connection of speakers/amplifiers is incorrect.
-See the installation/connections manual
of this
model to check the connection.
HUB NO SUPRT
USB HUB is not supported on this unit.
L. SEEK +/-
The local seek mode is on during automatic tuning.
NO DEV (No Device)
(SOURCE) is selected without a USB device
connected. AUSB device or aUSB cable has been
disconnected during playback.
-Be sure
to connect aUSB device and USB cable.
NO INFO
Text information is not written in the MP3IWMAI
AAC file.
NO MUSIC
The disc/USB device does not contain amusic file.
-Insert amusic
CD in this unit.
-Connect aUSB device with amusic file
in it.
NO NAME
Adisc/album/track name is not written in the track.
NO TRACK
The selected item in the USB device does not contain
an album/track.
OFFSET
There may be an internal malfunction.
-Check the connection. If the error indication
remains on
in the display, consult your nearest
Sony dealer.
OVERLOAD
USB device is overloaded.
-Disconnect the USB device, then change the source
by pressing
(SOURCE).
-Indicates that the USB device is out of order, or an
unsupported device is connected.
READ
The unit is reading all track and album information on
the disc/USB device.
-Wait until reading is complete and playback starts
automatically. Depending on the disclUSB device
structure, it may take more than aminute.
RESET
The CD unit cannot be operated due to aproblem.
-Press the RESET button (page 4).
