Sony Xplod CDX-CA810X User manual

POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
Design and Specifications subject to change without notice.
Signal-to-noise ratio 90 dB
Frequency response 10 – 20,000 Hz
Wow and flutter Below measurable limit
General
CD Player Section
FM
Tuning range 87.5 – 107.9 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 67 dB (stereo), 69 dB (mono)
Harmonic distortion at 1 kHz 0.5% (stereo), 0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 – 15,000 Hz
AM
Tuning range 530 – 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs (sure seal connectors)
Speaker impedance 4 – 8 ohms
Maximum power output 52 W × 4 (at 4 ohms)
Outputs Audio outputs (front/rear)
Subwoofer output (mono)
Power antenna relay control terminal
Power amplifier control terminal
Inputs Telephone ATT control terminal
BUS control input terminal
BUS audio input terminal
Remote controller input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 62 Hz
Treble ±10 dB at 16 kHz
Loudness +8 dB at 100 Hz
+2 dB at 10 kHz
Power requirements 12 V DC car battery (negative ground)
Dimensions Approx. 178 × 50 × 180 mm
(7 1/8 × 2 × 7 1/8 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 161 mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg (2 lb. 10 oz.)
Supplied accessories Card remote commander RM-X118
Parts for installation and connections (1 set)
Front panel case (1)
This unit cannot be connected to a UniLink digital preamplifier or equalizer.
CDX-CA810X
FM/AM Compact Disc Player
Power Amplifier Section
Note
2003 SONY MOBILE
PRODUCT GUIDE
Tuner
•7-color, 13-segment LED Display
•F/R Preouts w/HPF
•Sub Preout w/LPF
• Flip-down Detachable Face
• 52W x 4 High Power
• 8fs, 1-Bit D/A Converter
• 18FM + 12AM memory presets
• CD Text (disc/track/title display)
• CD/MD Control w/Custom File™ memory
• Station Memo™, Disc Memo™, Memo List functions
• Supplied Wireless Card Remote (RM-X118)
• Optional Wired Rotary Remote (RM-X4S)
•Indicates step-up
• Active Servo Control
• XT-XM1 Control
• DSO, EQ7
• XM Ready, CD Text
• 60 Degree Install
• CD-R/RW Playback
• SSIR-EXA Tuner
Plug shown with wires facing viewer.
Pin Number Wire Color Description
1 White Left front +
2 Green Left rear +
3 Purple Right rear +
4 Gray Right front +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Left front -
10 Green/black Left rear -
11 Purple/black Right rear -
12 Gray/black Right front -
13 Sky blue ATT
14
15
16 Yellow Battery
Harness Plug Configuration
Audio Power Specifications
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15

178 mm (7”)
2003 SONY MOBILE
PRODUCT GUIDE
CDX-CA810X
FM/AM Compact Disc Player
50 mm (2”)
Fuse (10A)
From car antenna BUS Control IN
178 mm (7”)
160 mm (6 1/4”)
50 mm (2”)
Audio OUT Rear
BUS Audio IN
Audio OUT Front
Remote IN
88 mm (3 7/16”)
53 mm (2 1/16”)
47 mm (1 7/8”)
33 mm (1 5/16”)
27 mm (11/16”)
Design and Specifications subject to change without notice.
