Sony XR-C2600 User manual

Operating Instructions
Manual de instrucciones
®œ•Œª°©˙Æ—
2000 Sony Corporation
US
FM/AM Cassette
Car Stereo
XR-C2600
For installation and connections, see the supplied installation/connections
manual.
Para obtener información sobre la instalación y las conexiones, consulte el manual
de instalación/conexiones suministrado.
ˆ©Û•ªæ˜™¶wÀ§ŒuÙs±µ°A–—®£¥£®—™°ß¶wÀ°˛uÙs±µª°©˙Æ—°®°C
3-868-290-31 (1)
ES
CT

2
Precautions
• If your car was parked in direct sunlight
resulting in a considerable rise in temperature
inside the car, allow the unit to cool off before
operating it.
•If no power is being supplied to the unit,
check the connections first. If everything is in
order, check the fuse.
•If no sound comes from the speakers of a
two-speaker system, set the fader control to
the center position.
•When the tape is played back for a long
period, the cassette may become warm
because of the built-in power amplifier.
However, this is not a sign of malfunction.
If you have any questions or problems
concerning your unit that are not covered in
this manual, please consult your nearest Sony
dealer.
To maintain high quality sound
If you have drink holders near your audio
equipment, be careful not to splash juice or
other soft drinks onto the car audio. Sugary
residues on this unit or cassette tapes may
contaminate the playback heads, reduce the
sound quality, or prevent sound reproduction
altogether.
Cassette cleaning kits cannot remove sugar
from the tape heads.
Welcome !
Thank you for purchasing this Sony Cassette
Player.
In addition to the cassette playback and radio
operations, you can expand your system by
connecting an optional CD/MD unit*1.
When you operate this unit or a connected
optional CD unit with the CD TEXT function,
the CD TEXT information will appear in the
display when you play a CD TEXT disc*2.
*1You can connect a CD changer, an MD changer,
a CD player, or an MD player.
*2A CD TEXT disc is an audio CD that includes
information such as the disc name, artist name,
and track names.
This information is recorded on the disc.

3
Notes on Cassettes
Cassette care
•Do not touch the tape surface of a cassette, as
any dirt or dust will contaminate the heads.
•Keep cassettes away from equipment with
built-in magnets such as speakers and
amplifiers, as erasure or distortion on the
recorded tape could occur.
•Do not expose cassettes to direct sunlight,
extremely cold temperatures, or moisture.
•Slack in the tape may cause the tape to be
caught in the machine. Before you insert the
tape, use a pencil or a similar object to turn
the reel and take up any slack.
•Distorted cassettes and loose labels can cause
problems when inserting or ejecting tapes.
Remove or replace loose labels.
•The sound may become distorted while
playing the cassette. The cassette player head
should be cleaned after each 50 hours of use.
Slack
Cassettes longer than 90 minutes
The use of cassettes longer than 90 minutes is
not recommended except for long continuous
play. The tape used for these cassettes is very
thin and tends to stretch easily. Frequent
playing and stopping of these tapes may cause
them to become entangled in the cassette deck
mechanism.

4
Table of Contents
This Unit Only With Optional Equipment
Location of controls ................................................. 5
Getting Started
Resetting the unit ................................................ 6
Detaching the front panel .................................. 6
How to use the menu ......................................... 7
Setting the clock .................................................. 7
Cassette Player
Listening to a tape ............................................... 8
Radio Reception during Fast-forwarding or
Rewinding of a tape
—ATA (Automatic Tuner Activation) ........ 9
Radio
Memorizing stations automatically
—Best Tuning Memory (BTM) .................... 9
Memorizing only the desired stations ........... 10
Receiving the memorized stations.................. 10
Other Functions
Adjusting the sound characteristics ................ 11
Attenuating the sound ...................................... 11
Changing the sound and display settings ......11
Boosting the bass sound
—D-bass ....................................................... 12
CD/MD Unit
Playing a CD or MD ......................................... 12
Playing tracks repeatedly
—Repeat Play .............................................. 14
Playing tracks in random order
—Shuffle Play .............................................. 14
Additional Information
Maintenance ....................................................... 14
Dismounting the unit ....................................... 15
Specifications ..................................................... 16
Troubleshooting guide ..................................... 17

5
Location of controls
XR-C2600
D
I
S
C
+
P
R
S
T
+
-
D
I
S
C
–
P
R
S
T
-
-
MODE
DSPL
OFF
DIR D-BASS
ENTER
MENU
SOUND
RELEASE
1 2 3 4 56
SOURCE
- SEEK/AMS
REP SHUF
qd SEEK/AMS –/+ (cursor left/right) buttons
7, 9, 10, 11, 13
seek 10
Automatic Music Sensor 13
manual search 13
qf Reset button (located on the front side
of the unit behind the front panel) 6
qg ENTER button 7, 9, 10, 11, 13
qh Frequency select switch
(located on the bottom of the unit)
See “Frequency select switch”in the
Installation/Connections manual.
qj Number buttons
During radio reception
Preset number select 10
During CD/MD playback:
(1) REP 14
(2) SHUF 14
qk OFF button*6
*Warning when installing in a car
without ACC (accessory) position on
the ignition key switch
Be sure to press (OFF) on the unit for two
seconds to turn off the clock display after
turning off the engine.
When you press (OFF) momentarily, the
clock display does not turn off and this
causes battery wear.
Refer to the pages listed for details.
1MENU button 7, 9, 10, 11, 13
2Volume control dial
3SOURCE (TUNER/CD/MD) button
9, 10, 12
4PRST/DISC +/– (cursor up/down) buttons
7, 9, 10, 11, 13
During radio reception:
Preset stations select 10
During CD/MD playback:
Disc change 13
5DSPL (display mode change) button
8, 12, 13
6MODE button
During radio reception:
BAND select 9, 10
During CD or MD playback:
CD/MD unit select 12
7Z(eject) button 8
8Display window
9m/M(fast winding)/DIR (tape
transport direction change) buttons 8
0D-BASS button 12
qa SOUND button 11
qs RELEASE (front panel release) button
6, 15

6
Attaching the front panel
Attach part Aof the front panel to part Bof
the unit as illustrated and push the left side
into position until it clicks.
Notes
• Be sure not to attach the front panel upside
down.
•Do not press the front panel too hard against the
unit when attaching it.
•Do not press too hard or put excessive pressure
on the display window of the front panel.
•Do not expose the front panel to direct sunlight
or heat sources such as hot air ducts, and do not
leave it in a humid place. Never leave it on the
dashboard of a car parked in direct sunlight or
where there may be a considerable rise in
temperature.
Caution alarm
If you turn the car ignition off without
removing the front panel, the caution alarm
will beep for a few seconds.
If you connect an optional power amplifier and
do not use the built-in amplifier, the beep
sound will be deactivated.
Getting Started
Resetting the unit
Before operating the unit for the first time or
after replacing the car battery, you must reset
the unit.
Remove the front panel and press the reset
button with a pointed object, such as a ball-
point pen.
Note
Pressing the reset button will erase the clock
setting and some memorized functions.
Detaching the front panel
You can detach the front panel of this unit to
protect the unit from being stolen.
1Press (OFF).
2Press (RELEASE), then slide the front
panel a little to the left, and pull it off
towards you.
Notes
• Be sure not to drop the panel when detaching it
from the unit.
•If you detach the panel while the unit is still
turned on, the power will turn off automatically
to prevent the speakers from being damaged.
•When carrying the front panel with you, use the
supplied front panel case.
Reset button
(OFF)
(RELEASE)
A
B

7
How to use the menu
This unit is operated by selecting items from a
menu.
To select, first enter the menu mode and
choose up/down (+/–of (PRST/DISC)), or
choose left/right (–/+ of (SEEK/AMS)).
(PRST/DISC)
(+) : To select upwards
(–) : To select downwards
(SEEK/AMS)
Setting the clock
The clock uses a 12-hour digital indication.
Example: To set the clock to 10:08
1Press (MENU), then press either side of
(PRST/DISC) repeatedly until “CLOCK”
appears.
1Press (ENTER).
The hour indication flashes.
2Press either side of (PRST/DISC) to set
the hour.
3Press + side of (SEEK/AMS).
The minute indication flashes.
(–) : To select
leftwards
(+) : To select
rightwards
SOURCE
SOURCE
4Press either side of (PRST/DISC) to set
the minute.
2Press (ENTER).
The clock starts.
After the clock setting is complete, the
display returns to normal playback mode.

8
Fast-winding the tape
During playback, press mor M.
*The < > indicator will flash while fast-winding
the tape.
To start playback during fast-forwarding or
rewinding, press the other fast-winding button
partially until the locked button is released.
Changing the display item
Each time you press (DSPL), the item changes
as follows:
Tape playback yFrequency*
*While the ATA function is activated.
After you select the desired item, the display
will automatically change to the Motion
Display mode after a few seconds.
In the Motion Display mode, all the above
items are scrolled in the display one by one in
order.
Tip
The Motion Display mode can be turned off. (See
“Changing the sound and display settings” on
page 11).
Cassette Player
Listening to a tape
Insert a cassette.
Playback starts automatically.
The side facing up is played.
The side facing down is played.
Tip
To change the tape‘s playback direction, press m
and M.
To stop playback and eject the
cassette
Press Z.
Direction
indicator*
FWD
REV
To rewind
m
M
To advance
M
m

9
Radio Reception during
Fast-forwarding or
Rewinding of a tape
—ATA (Automatic Tuner Activation)
When fast-forwarding or rewinding with the
mor Mbutton, the tuner will turn on
automatically.
1During playback, press (MENU).
2Press either side of (PRST/DISC)
repeatedly until “ATA”appears.
3Press + side of (SEEK/AMS) to select
“ON.”
Play mode starts.
4Press (ENTER).
To return to normal playback mode, select
“OFF”in step 3 above.
Radio
Memorizing stations
automatically
— Best Tuning Memory (BTM)
The unit selects the stations with the strongest
signals and memorizes them in the order of
their frequencies. You can store up to 6 stations
on each band (FM1, FM2, FM3, AM1, and
AM2).
Caution
When tuning in stations while driving, use
Best Tuning Memory to prevent accidents.
1Press (SOURCE) repeatedly to select the
tuner.
Each time you press (SOURCE), the source
changes as follows:
BTUNER BCD*
MD*b
*If the corresponding optional equipment is
not connected, this item will not appear.
2Press (MODE) repeatedly to select the
band.
Each time you press (MODE), the band
changes as follows:
BFM1 BFM2 BFM3
AM2 bAM1 b
3Press (MENU), then press either side of
(PRST/DISC) repeatedly until “BTM”
appears.
4Press (ENTER).
The unit stores stations in the order of their
frequencies on the number buttons.
A beep sounds when the setting is stored.
Notes
•The unit does not store stations with weak
signals. If only a few stations can be received,
some number buttons will retain their former
setting.
•When a number is indicated in the display, the
unit starts storing stations from the one currently
displayed.

10
Memorizing only the
desired stations
You can preset up to 18 FM stations (6 each for
FM1, 2, and 3) and up to 12 AM stations (6
each for AM1 and 2) in the order of your
choice.
1Press (SOURCE) repeatedly to select the
tuner.
2Press (MODE) repeatedly to select the
band.
3Press either side of (SEEK/AMS) to tune
in the station that you want to store on
the number button.
4Press and hold the desired number
button ((1) to (6)) until “MEM”appears.
The number button indication appears in
the display.
Note
If you try to store another station on the same
number button, the previously stored station will
be erased.
Receiving the memorized
stations
1Press (SOURCE) repeatedly to select the
tuner.
2Press (MODE) repeatedly to select the
band.
3Press the number button ((1) to (6)) on
which the desired station is stored.
Tip
Press either side of (PRST/DISC) to receive the
stations in the order they are stored in the
memory (Preset Search Function).
If you cannot tune in a preset
station
Press either side of (SEEK/AMS) to search
for the station (automatic tuning).
Scanning stops when the unit receives a
station. Press either side of (SEEK/AMS)
repeatedly until the desired station is
received.
Note
If the automatic tuning stops too frequently, press
(MENU), then press either side of (PRST/DISC)
repeatedly until “LOCAL” (local seek mode) is
displayed. Then press + side of (SEEK/AMS) to
select “LOCAL-ON.” Press (ENTER).
Only the stations with relatively strong signals will
be tuned in.
Tip
If you know the frequency of the station you want
to listen to, press and hold either side of
(SEEK/AMS) until the desired frequency appears
(manual tuning).
If FM stereo reception is poor
— Monaural Mode
1During radio reception, press (MENU),
then press either side of (PRST/DISC)
repeatedly until “MONO”appears.
2Press + side of (SEEK/AMS) until “MONO-
ON“appears.
The sound improves, but becomes
monaural (“ST”disappears).
3Press (ENTER).
To return to normal mode, select “MONO-
OFF”in step 2 above.

11
Other Functions
Adjusting the sound
characteristics
You can adjust the bass, treble, balance, and
fader.
You can store the bass and treble levels
independently for each source.
1Select the item you want to adjust by
pressing (SOUND) repeatedly.
BAS (bass) tTRE (treble) t
BAL (left-right) tFAD (front-rear)
2Adjust the selected item by pressing
either side of (SEEK/AMS).
Adjust within three seconds after selecting
the item.
Attenuating the sound
When the interface cable of a car telephone is
connected to the ATT lead, the unit decreases
the volume automatically when a telephone
call comes in (Telephone ATT function).
Changing the sound and
display settings
The following items can be set:
•CLOCK (page 7).
•BEEP –to turn the beep sound on or off.
•A.SCRL (Auto Scroll)*(page 13).
•D.INFO (Dual Information) to display the
clock and the play mode at the same time
(ON) or to display the information
alternately (OFF).
•M.DSPL –to turn the Motion Display on or
off.
1Press (MENU).
2Press either side of (PRST/DISC)
repeatedly until the desired item
appears.
Each time you press (–) side of
(PRST/DISC), the item changes as follows:
CLOCK tBEEP tA.SCRL* tD.INFO t
M.DSPL
*When the radio is off, or when no tape, CD,
or MD is playing, this item will not appear.
3Press (+) side of (SEEK/AMS) to select the
desired setting (Example: ON or OFF).
4Press (ENTER).
After the mode setting is complete, the
display returns to normal playback mode.

12
0dB
D.BASS-3
D.BASS-2
D.BASS-1 D.BASS-3
D.BASS-2
D.BASS-1
Boosting the bass sound
—D-bass
You can enjoy a clear and powerful bass
sound. The D-bass function boosts the low
frequency and high frequency signal with a
sharper curve than conventional bass boost.
You can hear the bass line more clearly even
while the vocal volume remains the same. You
can emphasize and adjust the bass sound
easily with the D-BASS control.
Adjusting the bass curve
Press (D-BASS) repeatedly to select the
desired bass curve.
As the D-BASS number increases so does
the effect.
D.BASS-1 tD.BASS-2 tD.BASS-3 t
D.BASS-OFF
Note
The bass sound may distort at same volume. If the
bass sound distorts, select less effective bass curve.
Level
Frequency (Hz)
With Optional Equipment
CD/MD Unit
This unit can control a maximum of ten
external CD/MD units in this configuration:
CD unit –maximum of five
MD unit –maximum of five
Any combination up to ten will work.
If you connect an optional CD unit with the
CD TEXT function, the CD TEXT information
will appear in the display when you play a CD
TEXT disc.
Playing a CD or MD
1Press (SOURCE) repeatedly to select CD
or MD.
2Press (MODE) until the desired unit
appears.
CD/MD playback starts.
When a CD/MD unit is connected, all the
tracks play from the beginning.
Changing the display item
Each time you press (DSPL) during CD, CD
TEXT, or MD playback, the item changes as
follows:
V
Elapsed playback time
V
Disc name*1/Artist name*2
V
Track name*3
*1If you have not labeled the disc or if there is no
disc name prerecorded on the MD, “NO NAME”
appears in the display.
*2If you play a CD TEXT disc, the artist name
appears in the display after the disc name.
(Only for CD TEXT discs with the artist name.)
*3If the track name of a CD TEXT disc or MD is not
prerecorded, “NO NAME”appears in the
display.

13
Locating a specific track
—Automatic Music Sensor (AMS)
During playback, press either side of
(SEEK/AMS) momentarily for each track
you want to skip.
Locating a specific point in a track
—Manual Search
During playback, press and hold either
side of (SEEK/AMS). Release when you
have found the desired point.
Changing Discs
During playback, press either side of
(PRST/DISC) momentarily.
The desired disc in the current unit begins
playback.
To locate
succeeding
tracks
To locate
preceding
tracks
To search
forward
To search
backward
After you select the desired item, the display
will automatically change to the Motion
Display mode after a few seconds.
In the Motion Display mode, all the above
items are scrolled in the display one by one in
order.
Tip
The Motion Display mode can be turned off. (See
“Changing the sound and display settings”on
page 11).
Automatically scrolling a disc name
—Auto Scroll
If the disc name, artist name, or track name on
a CD TEXT disc or MD exceeds 8 characters
and the Auto Scroll function is on, information
automatically scrolls across the display as
follows:
•The disc name appears when the disc has
changed (if the disc name is selected).
•The track name appears when the track has
changed (if the track name is selected).
If you press (DSPL) to change the display
item, the disc or track name of the MD or CD
TEXT disc is scrolled automatically whether
you set the function on or off.
1During playback, press (MENU).
2Press either side of (PRST/DISC)
repeatedly until “A.SCRL”appears.
3Press + side of (SEEK/AMS) to select
“A.SCRL-ON.”
4Press (ENTER).
To cancel Auto Scroll, select “A.SCRL-OFF”in
step 3 above.
Note
For some discs with very many characters, the
following cases may happen:
—Some of the characters are not displayed
—Auto Scroll does not work.
SOURCE
SOURCE
For preceding discs
For succeeding discs
Disc number
Track number
SOURCE

14
Additional
Information
Maintenance
Fuse Replacement
When replacing the fuse, be sure to use one
matching the amperage rating stated on the
original fuse. If the fuse blows, check the
power connection and replace the fuse. If the
fuse blows again after replacement, there may
be an internal malfunction. In such a case,
consult your nearest Sony dealer.
Warning
Never use a fuse with an amperage rating
exceeding the one supplied with the unit as
this could damage the unit.
Playing tracks repeatedly
—Repeat Play
You can select:
•REP-1 –to repeat a track.
•REP-2 –to repeat a disc.
During playback, press (1) (REP)
repeatedly until the desired setting
appears.
BREP-1 BREP-2
REP-OFF b
Repeat Play starts.
To return to normal playback mode, select
“REP-OFF”in step above.
Playing tracks in random
order —Shuffle Play
You can select:
•SHUF-1 –to play the tracks on the current
disc in random order.
•SHUF-2 –to play the tracks in the current
unit in random order.
•SHUF-ALL –to play all the tracks in all the
units in random order.
During playback, press (2) (SHUF)
repeatedly until the desired setting
appears.
BSHUF-1 BSHUF-2
SHUF-OFF bSHUF-ALL b
Shuffle Play starts.
To return to normal playback mode, select
“SHUF-OFF”in step above.
Fuse (10 A)

15
Cleaning the Connectors
The unit may not function properly if the
connectors between the unit and the front
panel are not clean. In order to prevent this,
open the front panel by pressing (RELEASE),
then detach it and clean the connectors with a
cotton swab dipped in alcohol. Do not apply
too much force. Otherwise, the connectors may
be damaged.
Notes
•For safety, turn off the engine before cleaning
the connectors and remove the key from the
ignition switch.
•Never touch the connectors directly with your
fingers or with any metal device.
Main unit
Back of the front panel
Dismounting the unit
1
2
3
4
Release key (supplied)

16
Specifications
Cassette player section
Tape track 4-track 2-channel stereo
Wow and flutter 0.13 % (WRMS)
Frequency response 30 –15,000 Hz
Signal-to-noise ratio 55 dB
Tuner section
FM
Tuning range FM tuning interval:
50 kHz/200 kHz
switchable
87.5 –108.0 MHz
(at 50 kHz step)
87.5 –107.9 MHz
(at 200 kHz step)
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 65 dB (stereo),
68 dB (mono)
Harmonic distortion at 1 kHz
0.7 % (stereo),
0.4 % (mono)
Separation 35 dB at 1 kHz
Frequency response 30 –15,000 Hz
AM
Tuning range AM tuning interval:
9 kHz/10 kHz switchable
531 –1,602 kHz
(at 9 kHz step)
530 –1,710 kHz
(at 10 kHz step)
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 –8 ohms
Maximum power output 45 W ×4 (at 4 ohms)
General
Outputs Audio output
Power antenna relay
control lead
Power amplifier control
lead
Telephone ATT control
lead
Tone controls Bass ±8 dB at 100 Hz
Treble ±8 dB at 10 kHz
Power requirements 12 V DC car battery
(negative ground)
Dimensions Approx. 188 ×58 ×182 mm
(w/h/d)
Mounting dimensions Approx. 182 ×53 ×163 mm
(w/h/d)
Mass Approx. 1.2 kg
Supplied accessories Parts for installation and
connections (1 set)
Front panel case (1)
Optional accessories BUS cable (supplied with
an RCA pin cord)
RC-61 (1 m), RC-62 (2 m)
Optional equipment CD changer (10 discs)
CDX-838, CDX-828,
CDX-737, CDX-636
MD changer (6 discs)
MDX-65
Other CD/MD changers
with the Sony-BUS system
Source selector
XA-C30
Design and specifications are subject to change
without notice.

17
Troubleshooting guide
Problem
No sound.
The contents of the memory
have been erased.
Indications do not appear in the
display.
Cause/Solution
•Set the fader control to the center position for two-speaker
systems.
•Rotate the dial clockwise to adjust the volume.
•The power cord or battery has been disconnected.
•The reset button was pressed.
tStore again into the memory.
Remove the front panel and clean the connectors. See
“Cleaning the connectors”(page 15) for details.
The following checklist will help you remedy the problems you may encounter with your unit.
Before going through the checklist below, check the connections and operating procedures.
General
Tape playback
Problem
The sound is distorted.
Cause/Solution
The tape head is contaminated.
tClean the head with a commercially available dry-type
cleaning cassette.
Radio reception
Problem
Preset tuning is not possible.
Automatic tuning is not
possible.
The stations cannot be
received.
The sound is hampered by
noises.
The “ST”indication flashes.
Cause/Solution
•Memorize the correct frequency.
•The broadcast signal is too weak.
The broadcast signal is too weak.
tUse manual tuning.
Connect an power antenna control lead (blue) or accessory
power supply lead (red) to the power supply lead of a car’s
antenna booster. (When your car has built-in FM/AM antenna
in the rear/side glass only.)
•Tune in the frequency accurately.
•The broadcast signal is too weak.
tSet to MONO mode (page 10).
Problem
The sound skips.
Cause/Solution
A dirty or defective disc.
CD/MD playback

18
Solution
Insert the disc magazine in the CD/
MD unit.
Insert discs in the CD/MD unit.
Insert another CD/MD.
Clean or insert the CD correctly.
Insert another MD.
Play an MD with tracks recorded on
it.
Press the reset button of the unit.
Close the lid or insert the MDs
properly.
Wait until the temperature goes
down below 50°C.
Display
NO MAG
NO DISC
NG DISCS
ERROR
BLANK
RESET
NO READY
HI TEMP
Cause
The disc magazine is not inserted in
the CD/MD unit.
No disc is inserted in the CD/MD unit.
A CD/MD cannot play because of
some problem.
A CD is dirty or inserted upside
down.*2
An MD does not play because of some
problem.*2
No tracks have been recorded on an
MD.*2
The CD/MD unit cannot be operated
because of some problem.
The lid of the MD unit is open or MDs
are not inserted properly.
The ambient temperature is more than
50°C.
*1
*1
Error displays (when an optional CD/MD unit is connected)
The following indications will flash for about five seconds, and an alarm sound will be heard.
*1When an error occurs during playback of a CD or MD, the disc number of the CD or MD does not appear
in the display.
*2The disc number of the disc causing the error appears in the display.
If the above-mentioned solutions do not help improve the situation, consult your nearest Sony
dealer.

19

2
Gracias por adquirir este reproductor de
cassettes de Sony.
Además de las operaciones de reproducción de
cassettes y de la radio, es posible ampliar el
sistema mediante la conexión de una unidad*1
de CD/MD opcional.
Si utiliza esta unidad o conecta una unidad de
CD opcional con la función CD TEXT, el visor
mostrarála información CD TEXT al
reproducir discos CD TEXT*2.
*1Es posible conectar un cambiador de CD, un
cambiador de MD, un reproductor de CD o un
reproductor de MD.
*2Un disco CD TEXT es un CD de audio que
contiene información, como el título del disco,
nombre del cantante y títulos de los temas.
Esta información estáregistrada en el disco.
¡Bienvenido! Precauciones
•Si aparca el automóvil bajo la luz solar
directa y se produce un considerable
aumento de temperatura en su interior, deje
que la unidad se enfríe antes de utilizarla.
•Si la unidad no recibe alimentación,
compruebe las conexiones en primer lugar. Si
todo estáen orden, examine el fusible.
•Si los altavoces no emiten sonido con un
sistema de dos altavoces, ajuste el control de
equilibrio en la posición central.
•Si reproduce la cinta durante mucho tiempo,
el cassette puede calentarse debido al
amplificador de potencia incorporado. No
obstante, esto es normal.
Si desea realizar alguna consulta o solucionar
algún problema referentes a la unidad que no
se mencionen en este manual, póngase en
contacto con el proveedor Sony más próximo.
Para mantener una alta calidad de
sonido
Si existen soportes para bebidas cerca del
equipo de audio, tenga cuidado de que no
salpiquen zumos u otras bebidas dulces sobre
el mismo, ya que la existencia de residuos
azucarados en la unidad o en las cintas de
cassette pueden ensuciar los cabezales de
reproducción, reducir la calidad del sonido o
eliminar el sonido de reproducción.
Los kits de limpieza para cassettes no eliminan
las sustancias azucaradas de los cabezales de
cinta.
