Sony CDX-M730 (XT-XM1) User manual

Design and Specifications subject to change without notice.
CDX-M730
FM/AM Compact Disc Player
2002 SONY MOBILE
PRODUCT GUIDE
-
 Detachable Active Black Panel (ABP)
 D/MD ontrol w/ ustom File memory
 Hi/Low Pass Filters, F/R/S Preouts
 Xplod® Power: 52W x 4
 Supplied Wireless Remote (RM-X110)
 Optional Wireless Rotary Remote (RM-X6S)
 8fs, 1-Bit D/A onverter
 Active Servo ontrol
 30 Degree Install
 D-RW Playback
 18FM + 12AM memory presets
 Dot Matrix, 5-color L D, clock
 Active Display w/Demo Mode
 Indicates step-up
 DSO, EQ7
 D TEXT®
 XM Ready
 SSIR-EXA Tuner
Signal-to-noise ratio 90 dB
Frequency response 10  20,000 Hz
Wow and flutter Below measurable limit
General
CD Player Section
FM
Tuning range 87.5  107.9 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 8 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 66 dB (stereo), 72 dB (mono)
Harmonic distortion at 1 kHz 0.6% (stereo), 0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30  15,000 Hz
AM
Tuning range 530  1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs
Speaker impedance 4  8 ohms
Maximum power output 52 W × 4 (at 4 ohms)
Outputs Audio outputs (front /rear)
Subwoofer output (mono)
Power antenna relay control terminal
Power amplifier control terminal
Inputs Telephone ATT control terminal
Illumination control terminal
BUS control input terminal
BUS audio input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 62 Hz
Treble ±10 dB at 16 kHz
Loudness +8 dB at 100 Hz
+2 dB at 10 kHz
Power requirements 12 V D car battery (negative ground)
Dimensions Approx. 178 × 50 × 182 mm
(7 1/8 × 2 × 7 1/4 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 160 mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Mass Approx. 1.5 kg (2 lb. 10 oz.)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
ard remote commander RM-X110
This unit cannot be connected to a digital preamplifier or an equalizer.
Power Amplifier Section
Note
Tuner Section
Plug shown with wires facing viewer.
Pin Number Wire olor Description
1 White Left front +
2 Green Left rear +
3 Purple Right rear +
4 Gray Right front +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Left front -
10 Green/black Left rear -
11 Purple/black Right rear -
12 Gray/black Right front -
13 Sky blue ATT
14 Illumination
15
16 Yellow Battery
Harness Plug Configuration
Audio Power Specifications
POWER OUTPUT AND TOTAL HARMONI DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15

178 mm (7)
2002 SONY MOBILE
PRODUCT GUIDE
CDX-M730
FM/AM Compact Disc Player
50 mm (2)
Fuse (10A)
160 mm (6 3/8)
50 mm (2)
Design and Specifications subject to change without notice.
Remote IN
Audio OUT Rear
BUS Audio IN/Aux IN
Audio OUT Front
BUS ontrol IN
180 mm (7 1/8)
47 mm (1 7/16)
53 mm ( 2 1/16)
88 mm (3 7/16)
33 mm (1 5/16)
27 mm (1 1/16)
SUB OUT
(mono)
From car antenna
