CXS-GT3516F
CXS-GT3516F Bundle
DETACH FACE WITH FRONT AUX INPUT
The easy - to - read single line LCD display shows clock, station ID and track
data when playing back your digital MP3/WMA files from CD or USB input.
Front auxiliary input lets you connect almost any portable audio device to
your car's sound system.
MP3/WMA/AAC MUSIC PLAYBACK
Play CDs, CD - Rs, and CD - RWs, including discs loaded with digital MP3, WMA
and AAC files .
50 FREE MUSIC DOWNLOADS
Receive 50 free music downloads from Sony Music when you purchase the
Sony CXS - GT3516F. Choose from thousands of the world’s greatest songs at
www.SonyMusicPass.com. To access your downloads, A Sony MusicPass
card with PIN is required and will ship with your order at no additional cost.
USB MASS STORAGE CONNECTIVITY
Connect and play music directly from your Mass Storage Class device or
USB equipped Walkman player.
INTUITIVE SEARCH FEATURES
Use Quick - BrowZer feature to find music by artist, album, genre, song or
playlist. Jump Mode allows you to fast forward through a category in 10%
increments while the ZAPPIN™feature can play a 6, 9, or 30 second intro
clip to help you find a specific song.
INTERNAL HIGH POWER
The CDX - GT35UW delivers 52 watts of peak power to all four speakers for
increased sound levels (208 watts total power). The 3 band EQ3 allows user
to customize the sound with +/ - 10 dB adjustments centered at 60 Hz, 1 kHz
and 10 kHz frequencies.
Xpl
ō d ™CDX - GT35UW car stereo by Sony lets you play MP3/WMA/AAC files
burned to CD using the front USB or a portable music player plugged in
via front aux input. Plus, experience great sound quality and powerful
sounds thanks to built in 52W x 4 high power output.
1
2
1
1
2
®
®
1
2

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/13/2011
CXS-GT3516F
CXS-GT3516F Bundle
Specifications
Convenience Features
CD Text Display: CD/MP3/WMA/AAC data
displayed
On - Screen Clock: 12H
DimmerAdjust: Manual - on/off
KeyIllumination: Red
General
DiscCapacity: 1
Material: HOP Cone / AL tweeter
Magnet: Ferrite
Color:
Radio Panel: Gun Metallic
Speakers: Silver and black
Audio
PreoutImpedance: 220 ohms
PreoutVoltage: 2 volt
S/NRatio: Audio Power: CEA2006 S/N 80
dBA
FrequencyResponse: CD: 10 - 20,000 Hz
Wow and Flutter: Below measurable limit
Impedance: 4 Ohms
StationPreset(s): 18 FM / 12 AM
Digital - to - AnalogConverter: 24 bit
Tuner Frequency Range:
FM:Tuner Frequency Range(MHz): 87.5 -
107.9
AM:Tuner Frequency Range(kHz): 530 -
1710
TunerType: SSIR - EXA
Band: AM / FM
Sensitivity(db): 90 dB/W/m
Signal - to - Noise Ratio (dB): CD: 120 dB
Format(s)Supported: MP3/WMA/AAC
files
Equalizer: EQ3: 3 band EQ
+/ - 10 dB at 60 Hz
+/ - 10 dB at 1 kHz
+/ - 10 dB at 10 kHz
Convenience
TiltRange: 0 - 45 ° mounting angle
Display
Technology: LCD
DisplayColor: Blue color / Negative
TextDisplayed: Source, artist, track,
playback time, menu and clock
TextLines: 1 line of information
Amplifier Section
SpeakerImpedance: 4 - 8 Ohms
Max power output: 52 watts x 4 at 4 ohms
Tuner
FM Usable Sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
S/NRatio: 70 dB (mono)
FrequencyResponse: FM: 20 - 15,000 Hz
StereoSeparation: 40 dB at 1 KHz
1
Power
OutputPower: 52W x4 Watts Max Power -
CEA2006 Standard Power Output: 17
Watts RMS per channel into 4 Ohms, 4
channels driven from 20 Hz to 20 kHz with
less than 1% THD+N.
CurrentDrain: 3 - 5 amps
Power Handling Capacity: 190 Watts
RatedInput: 40 watts
InputVoltage: 12 V DC car battery
(negative ground)
Inputs and Outputs
RCA Audio Output(s): Rear/Sub selectable
RCA pre - amp outputs
Digital Audio Input(s): Ability to use all
forms of USB devices may vary as not all
devices are compatible.
This unit is compliant with MSC (Mass
Storage Class) and MTP (Media Transfer
Protocol) type USB devices compliant
with the USB standard.
This unit cannot recognize USB devices
via a USB hub.
If you have any questions or problems
concerning your unit that are not
covered in the owners manual, consult
your nearest Sony dealer.
USBPort(s): Front USB
AntennaTerminal(s): AM/FM Antenna
Input Terminal
12V Trigger Output(s):
Power antenna
Amplifier turn on
AudioIn:
Front Aux with variable level: - 8dB
∼
+18dB
Front USB input
InfraredPort: Wireless remote
Dimensions
Weight: Radio: 1.3Kg
Speakers: 1.3Kg
Measurements:
Radio: 178 x 50 x 179mm
Speakers: 170 x 44 mm
Supplied Accessories
Parts for installation and connections (1
set)
RM - X151 wireless remote
Optional Accessories
Replacement remote: RM - X151
Color: , Radio Panel: Gun Metallic, ,
Speakers: Silver and black
UPC Code: 027242802636
1.NotallMP3,WMAorAACfilesmayplaybackduetofilevariations.
CopyrightprotectedACC - LC files cannot be played back.
2.USB playback of MSC (Mass StorageClass)andMTP(MediaTransfer
Protocol)type USB device compliantwithUSBstandard can be used.
©2010SonyElectronicsInc.Allrightsreserved.Reproductioninwholeor
inpart without written permissionisprohibited.Sony,Walkman, Xpl
ō d,
ZAPPIN,Quick - BrowZerandthe Sony and Xplod logosaretrademarksof
Sony.Allothertrademarksaretrademarksoftheirrespectiveowners.
Features and specifications are subject to change without notice. Non -
metricweights and measures areapproximateandmay vary.
