Sony XDP-MU110 User manual

4-299-669-11(1)
XDP-MU110
Digital Link
Sound System
Owner’s Record
The model and serial numbers are located on the bottom of the DSP
master unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer
regarding this product.
Model No. XDP-MU110 Serial No.
Operating Instructions US
Manual de instrucciones ES

2
Warning
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
For the State of California, USA only
Perchlorate Material – special handling
may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Perchlorate Material: Lithium battery
contains perchlorate
iPhone®, iPod®, iPod classic®,
iPod nano®, and iPod touch®are
trademarks of Apple Inc., registered in the
U.S. and other countries.
Warning if your car’s ignition has no
ACC position
To prevent battery drain, turn off the
system after use by pressing and holding
the SOURCE/OFF button on the remote
commander/cradle more than two
seconds. The LED indicators on the DSP
master unit and cradle turn off when the
system is off.
Note on the lithium battery
Do not expose the battery to excessive heat
such as direct sunlight, fire or the like.

3
Table of contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Resetting the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
DSP master unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RM-X251 Card remote commander . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Sound Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Optimized sound setting based on your vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the sound balance based on your listening preference . . . . . . . . . . . . . . . . . . . 9
Setting up the Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Arranging the cradle cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Attaching an iPod/iPhone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Setting up the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Enjoying an iPod/iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Playing from a car audio unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

4
Introduction
Thank you for purchasing the Digital Link Sound System (XDP-MU110).
This system allows you to digitally integrate an iPod/iPhone into your existing car audio unit.
You can enjoy exciting sound from your car audio unit and iPod/iPhone via this system, which
features sound settings optimized for your vehicle type by using Sony’s original digital sound
technology.
The DSP master unit makes a natural “front sound field” possible, so that you can feel bass as
though it comes from directly in front of the driver’s seat even though the subwoofer is located
at the rear of your car, e.g., in a cargo area.
There is also a digital connection for an iPod/iPhone so that you can enjoy high quality sound
in your car without noise/distortion.
Enjoy the new sound experience with this Digital Link Sound System.
Getting Started
Resetting the unit
Before operating the system for the first time, or after replacing the car battery or changing
connections, you should reset the system (page 5).
Press the RESET button of the DSP master unit.

5
The System Components
This section contains explanations on the location of controls and their basic operations.
DSP master unit
Sound setting switches page 8
Set each switch according to your car
type/interior.
SOURCE indicator
You can check the status of the DSP
master unit.
INPUT SELECT switch
Select either 2-channel or 4-channel
sound from the car audio unit. Select
“2ch” if you connect only the front car
speakers to the DSP master unit, with
High Level Input connection.
RESET
Press to reset the DSP master unit
settings.
Note
• Avoid touching the top of the DSP master unit
during use, as it becomes hot over time.
23 41
Indicator Status
Turns blue. A car audio unit is selected as
the source.
Turns red. An iPod/iPhone is selected as
the source.
Flashes blue. Diagnostic error. See
“Troubleshooting” (page 20).
Flashes red. Overload error when an
iPod/iPhone is selected as the
source. See
“Troubleshooting” (page 20).
Flashes blue
and red
alternately.
Temperature detection is
working. See
“Troubleshooting” (page 20).

6
Cradle
Suction cup
SEEK /buttons*1*2
Press to skip tracks.
Remote sensor
Indicator
You can check the status of the DSP
master unit.
VOLUME (VOL) +/–*2
SOURCE/OFF button
Press to turn on the power/change the
source between a car audio unit and an
iPod/iPhone.
Press and hold more than two seconds
to turn off the system. The indicator
() turns off.
Port for the cradle cable
Used for connecting the cradle cable.
Cover for the suction cup
PUSH RELEASE button
Push to stretch the arm.
LOCK/RELEASE lever
Turn to lock/release the suction cup.
PUSH button
Press hard to secure the cradle on the
dashboard.
Tab
Pull up to remove the cradle from the
dashboard.
*1 has a tactile dot.
*2 These buttons work only when an iPod/
iPhone is selected as the source and the music
player on an iPod/iPhone is activated.
Indicator Status
Turns blue. A car audio unit is selected as
the source.
Turns red. An iPod/iPhone is selected as
the source.
Flashes blue. Diagnostic error. See
“Troubleshooting” (page 20).
Flashes red. Overload error when an
iPod/iPhone is selected as the
source. See
“Troubleshooting” (page 20).
Flashes blue
and red
alternately.
Temperature detection is
working. See
“Troubleshooting” (page 20).

7
RM-X251 Card remote
commander
Remove the insulation film before use.
SOURCE/OFF button
Press to turn off the power/change the
source between a car audio unit and an
iPod/iPhone.
Press and hold more than two seconds
to turn off the system. The indicators on
the DSP master unit and the cradle turn
off.
FAD/BAL (FRONT/CNT/REAR)
buttons page 9
Press to adjust the balance between the
speakers.
VOL +/– buttons*1
LEFT/RIGHT buttons page 9
Press to adjust the speaker balance.
Press and hold the CNT button () to
return to the default setting.
BASS (–/CNT/+) buttons page 9
Press to adjust the bass level.
ALO (Automatic Level Optimizer)
button*1page 10
Adjust the playback volume level of an
iPod/iPhone to the optimum level:
“ON,” “OFF.”
/buttons*1
Press to skip tracks.
TREBLE (–/CNT/+) buttons page 9
Press these buttons to adjust the treble
level.
SUB VOL +/– button*2page 9
Press to adjust the subwoofer volume if
you connect a subwoofer to the system
and the SUBWOOFER switch on the
DSP master unit is set to “Y.”
*1 These buttons work only when an iPod/
iPhone is selected as the source and the music
player on an iPod/iPhone is activated.
*2 SUB VOL + has a tactile dot.
Note
• If the system is turned off and the indicators on
the cradle/DSP master unit are off, remote
commander operation is not possible. To
activate the system again, press the SOURCE/
OFF button on the cradle, and make sure that
the indicators on the cradle/DSP master unit
are lit.

8
Sound Settings
Optimized sound setting
based on your vehicle
This system provides well balanced sound,
which appears to come from in front of the
driver’s seat, optimized for the vehicle type
by setting the DSP master unit. 12 different
settings are available.
Warning
• Avoid touching the top of the DSP master unit
when setting the switches, as it becomes hot
during use.
Notes
• Set the sound of the car audio unit (BASS/
TREB/Loudness, etc.) to the flat position.
• Set the switches on the front panel of the DSP
master unit with your fingers. Do not use any
tools when setting these switches.
SW LOCATION switch
Select from one of three positions (FAR/
MID/NEAR) based on the distance between
the driver’s seat and where the subwoofer is.
This function only works when a subwoofer
is connected to the system and the
SUBWOOFER switch on the DSP master
unit is set to “Y.”
SUBWOOFER switch
Select “Y” (yes) or “N” (no) depending on
whether the subwoofer is connected to the
system. Select “Y” when the subwoofer is
connected.
VEHICLE SIZE switch
Select from one of three sizes (L/M/S) based
on the air volume of your car.
See the following examples.
Compact hatchback
Middle sized sedan
Pickup Truck
VEHICLE SIZE: S
SUBWOOFER: Y
SW LOCATION: MID
VEHICLE SIZE: M
SUBWOOFER: N
SW LOCATION: –
VEHICLE SIZE: S
SUBWOOFER: Y
SW LOCATION: NEAR

9
Full sized SUV
Tip for setting the SW LOCATION switch
If you are not sure about these sound
settings, set the VEHICLE SIZE switch first,
and then set the SW LOCATION switch to
where bass sound appears to come from in
front of the driver’s seat.
Setting the sound balance
based on your listening
preference
You can adjust the sound balance easily by
using the supplied remote commander
(page 7).
The system allows you to make separate
settings for each source (car audio unit,
iPod and iPhone)*. The setting you make
for a source is applied each time that source
is selected.
*The ALO button works only for an iPod/
iPhone selected as the source.
Tip
• Turn off the EQ of your iPod/iPhone before
adjusting the following sound settings.
Adjusting the speaker
balance
Press the FRONT/REAR/LEFT/RIGHT
buttons to adjust the balance between
the speakers.
An adjustment range of 7 steps is available
for each speaker setting. Press and hold the
CNT button to return to the default setting.
The default setting is CNT (center).
Adjusting the treble level
Press the TREBLE (–/CNT/+) button.
Available settings are -7 to +7, in 1-step
increments. Press and hold the CNT button
to return to the default setting. The default
setting is 0.
Adjusting the bass level
Press the BASS (–/CNT/+) button.
Available settings are -7 to +7, in 1-step
increments. Press and hold the CNT button
to return to the default setting. The default
setting is 0.
Adjusting the subwoofer
level
Press the SUB VOL +/– button.
Available settings are from -7 (no sound) to
+6, in 1-step increments. The default setting
is 0.
This function only works when a subwoofer
is connected to the system and the
SUBWOOFER switch on the DSP master
unit is set to “Y.”
VEHICLE SIZE: L
SUBWOOFER: Y
SW LOCATION: FAR
FAR
MIDNEAR

10
Adjusting the input volume
from the iPod/iPhone
Press the ALO button.
Adjust the playback volume level of an
iPod/iPhone to the optimum level.
Press the ALO button repeatedly to switch
between ON and OFF. The default setting is
ON. This function is available only when an
iPod/iPhone is selected as the source.
• ON: A high-pitched beep
• OFF: A low-pitched beep
Setting up the Cradle
Precautions
• Install the cradle on a dashboard properly so
that the unit will not interfere with normal
driving.
• Follow the instructions on this manual about
dealing with the suction cup to secure the
cradle on a dashboard. If you fail to do so,
the adhesive strength of the suction cup may
decrease, and the cradle may fall down.
• If the cradle becomes detached, a traffic
accident may result. To prevent this, use the
supplied strap.
• Keep the cradle out of the reach of children.
Should a small part of the cradle be
swallowed, immediately consult a doctor.
• Remove the cradle from the dashboard and
keep it out of direct sunlight after use.
Leaving it on a dashboard or in a car where it
will be exposed to high temperature may
cause malfunction, and it may also damage
the dashboard.
• An iPod/iPhone may not be charged if you
put it on the cradle when the temperature in
the car is extremely high/low.
• Be careful not to splash water on the cradle.
It may cause a malfunction.
• To disconnect the cradle cord, pull it out by
its connector, not the cord.
Parts List
Cradle
