Sony J10 User manual

Compact Videotape Players
J Series
J-10
J-10SDI
J-30
J-30SDI
NTSC/PAL

The Versatile All-round Players
Since their introduction in 2001, Sony J Series Compact Videotape Players
(consisting of the J-1, J-2, and J-3 models), have been accepted by
producers, journalists, and production staff around the world as ideal
desktop 1/2" standard-definition compact players. Their sophisticated
features, offered within an affordable price range, have opened new
opportunities in material viewing, logging, and source feeding to servers
or nonlinear editing systems.
Retaining the same design concept, affordability, and fundamental
features, Sony has revitalized the J Series by enhancing its interfacing
capabilities. The new J Series Compact Players - comprising four models,
the J-10, J-10SDI, J-30, and J-30SDI - now come equipped with an
i.LINK®* Videotape interface as standard, opening the door to the DV
world for Betacam®users.
Despite their compactness and affordability, the new J Series will surely
become one of the most powerful production assets today, and into the
future.
* i.LINK is a registered trademark of Sony used only to designate that a product contains
an IEEE1394 connection. The i.LINK connection may vary depending on the software
applications, operating system, and compatible i.LINK devices. All products with an
i.LINK connection may not communicate with each other. Please refer to the
documentation that comes with any device having an i.LINK connection for
information on compatibility, operating conditions, and proper connection.
INTRODUCTION

FEATURES
Ultimate Desktop Versatility
Compact Body Design fig 1
Sharing the same chassis design of their
predecessors, the new J Series Compact Players retain
a compact and lightweight design. At just 307 x 100
x 397 mm (12 1/8 x 4 x 15 3/4 inches) in size and in
weight 8.1 kg (17 lb 14 oz), they are equivalent in
size to a standard desktop PC.
They can be placed on the desks of busy producers,
journalists, and editors either horizontally or upright
in the supplied vertical stand - perfect for space-
constrained or awkward environments. In addition,
their new light-metallic coloring makes the J Series
Compact Players even more suitable for the office
environment.
Compatible with Small and Large Cassettes
Despite their very compact size, the J Series Compact
Players can play large-size as well as small-size
cassettes.
525/625 Versatility
The J Series Compact Players can be easily switched
between 525/60 and 625/50 playback modes,
enabling operation in international environments.
Powerful Playback Capability fig 2
The J-10 and J-10 SDI models have the capability to
play back Betacam SX®, Betacam SP®, and Betacam
tape recordings. The J-30 and J-30 SDI models add
playback capability for MPEG IMX®and Digital
Betacam®recordings. During cassette loading, each
format is automatically identified for playback, so no
menu settings or switching is necessary.
100
307
397
100
161 (mm)
321.5
J-10/J-10SDI
J-30/J-30SDI
1 Compact Body Design
2 Powerful Playback Capability

Enhanced Interfacing Capability
1i.LINK Interface - Opening the Door to
the DV World
The new J Series Compact Players come equipped
with an i.LINK interface as standard. This feature
makes them very unique, since 1/2" SD Betacam series
materials - including even 20-year-old archives - can be
converted to a 25 Mbps DV signal (video, audio*, and
time code are transferred) and sent to a compatible
DV device via a single i.LINK interface cable. In
addition, the industry-standard RS-422A Sony 9-pin
remote control interface allows editors to control the
J Series Compact Players remotely.
*2-ch or 4-ch selectable.
2Choice of Analog Component Output
and SDI Output
J Series Compact Players offer the choice of either
analog component output or SDI output depending on
application requirements. While the J-10 and J-30
offer one set of analog component outputs (BNC x 3)
as standard, the J-10 SDI and J-30 SDI offer two SDI
outputs (BNC x 2) - including one with superimposition
capability. Also, one time code output is provided on
the J-10 SDI and J-30 SDI models.
Two channels of analog audio output are
available either through the XLR connectors or RCA
pin jacks located on the rear panel of the J Series
Compact Players. A headphone jack is also provided
on the front panel. The audio channels to be output
to the analog outputs and headphone jack can be
selected from Ch 1/2, Ch 3/4, and Cue track. Audio
is automatically muted for off-speed playback and
non-data playback.
The J Series Compact Players incorporate an
infrared remote controller, which allows fundamental
operations to be controlled wirelessly. This feature
comes in handy for connection to conventional TV
monitors, as well as data projectors with composite
video or S-video input capability, making the J Series
Compact Players a useful machine for presentations
or demonstrations.
Operational Versatility
UMID and Essence Mark Readable
The J Series Compact Players can read UMID (Unique
Material Identifier), a type of metadata approved as
an SMPTE standard (SMPTE-330M) on MPEG IMX
and Digital Betacam tapes and output them through
the SDI interface*. The UMID consists of a globally
unique number and a material number, used for the
identification of recorded material. Essence Marks,
available on a variety of Sony camcorders, are also
useful metadata that can be manually or
automatically marked during shooting for easy
picture search in subsequent editing processes. The
J-30 SDI can read UMID and Essence Marks.
*Auto Event Detection is not supported.
Shot Mark Handling
The J Series Compact Players can scan tapes with
Shot Marks and automatically detect their position.
After scanning, a list of all marks can be displayed on
a video monitor, allowing easy cueing to any mark.
3Flexible Audio Outputs
4Ideal for Presentations
3 4 1 2 J-10SDI/J-30SDI
SDI/Time Code
Output
J-10/J-30 Rear Panel

Viewing Source Feeding to NLE
Presentation (Wireless Remote Control) Simple Dubbing
SYSTEM CONFIGURATION
VTR
Betacam/SP
Small Large
Betacam/SP
Betacam SXBetacam SX
Digital Betacam
(J-30/J-30SDI)
Digital Betacam
(J-30/J-30SDI)
MPEG IMX
(J-30/J30SDI)
MPEG IMX
(J-30/J30SDI)
Camcorder
Video Monitor J-10/J-10SDI/
J-30/J-30SDI
Video Monitor
i.LINK
RS-422
(9-pin simple
remote)
Video
• Component
(Y/R-Y/B-Y)
• SDI
• Composite
Audio
TC
DV-based NLE
Speakers
NLE
J-10/J-10SDI/
J-30/J-30SDI
J-10/J-10SDI/
J-30/J-30SDI
Composite Video
S-Video
J-10/J-10SDI/
J-30/J-30SDI
Remote
Controller
Projector
i.LINK (DVCAM Deck)
Component
SDI
J-10/J-10SDI/
J-30/J-30SDI
DVCAM
Betacam SX
Digital Betacam
(J-30/J-30SDI)
MPEG IMX
(J-30/J30SDI)
Betacam/SP
DVCAM Deck
Betacam SX Deck
Betacam/SP Deck
MPEG IMX Deck
(J-30/J30SDI)
Digital Betacam Deck
(J-30/J-30SDI)

SPECIFICATIONS
J-10 J-10SDI J-30 J-30SDI
General
Power requirements AC 100 V to 240 V, 50/60 Hz
Power consumption 55 W
Operating temperature +5 °C to +40 °C (+41 °F to + 104 °F)
Storage temperature -20 °C to +60 °C (-4 °F to + 140 °F)
Humidity 25% to 80% (relative humidity)
Weight 17 lb 14 oz (8.1 kg) 17 lb 14 oz (8.1 kg) 8.2 kg (18 lb 1 oz) 8.2 kg (18 lb 1 oz)
Dimensions (W x H x D) 12 1/8x 4 x 15 3/4inches (307 x 100 x 397 mm)
Tape speed
Digital Betacam – – 96.7 mm/s 96.7 mm/s
MPEG IMX – – 64.467 mm/s (525 mode), 64.467 mm/s (525 mode),
53.776 mm/s (625 mode) 53.776 mm/s (625 mode)
Betacam SX 59.515 mm (525 mode), 59.575 mm (625 mode)
Betacam/Betacam SP 118.6 mm/s (525 mode), 101.5 mm/s (625 mode)
Playback time
Digital Betacam – – Max. 124 min. with BCT-D124L Max. 124 min. with BCT-D124L
MPEG IMX – – Max. 184 min. (525 mode)/220 min. Max. 184 min. (525 mode)/220 min.
(625 mode) with BCT-184MXL (625 mode) with BCT-184MXL
Betacam SX Max. 194 min. with BCT-194SXLA
Betacam/Betacam SP Max. 90 min. (525 mode)/108 min. (625 mode) with BCT-90MLA
Fast forward/rewind time
Digital Betacam – – Approx. 5 min. with BCT-D124L Approx. 5 min. with BCT-D124L
MPEG IMX – – Approx. 5 min. with BCT-184MXL Approx. 5 min. with BCT-184MXL
Betacam SX Approx. 5 min. with BCT-184SXLA
Betacam/Betacam SP Approx. 5 min. with BCT-90MLA
Search speed range
Digital Betacam – – ±21 times normal playback speed ±21 times normal playback speed
MPEG IMX – – ±32 times normal playback speed ±32 times normal playback speed
Betacam SX ±35 times normal playback speed
Betacam/Betacam SP ±18 times (525 mode), ±20 times (625 mode) normal playback speed
Servo lock time 1.5 s or less (from standby on)
Load/unload time 7 s or less
Input signal
Ext. sync BNC (x 1), Frame lock
Output signals
Analog composite output BNC (x 1), Pin Jack (x 1), 1.0 Vp-p, 75 Ω
S-video output Mini DIN 4-pin (x 1), Y: 1.0 Vp-p, C: 0.286 Vp-p burst, 75 Ω
Analog component output BNC (x 3), Y: 1.0 Vp-p, – BNC (x 3), Y: 1.0 Vp-p, –
R-Y/B-Y: 0.7 Vp-p, 75 ΩR-Y/B-Y: 0.7 Vp-p, 75 Ω
SDI output – BNC (x 2), SMPTE 259M, – BNC (x 2), SMPTE 259M,
270 Mb/s, 0.8 Vp-p, 75 Ω270 Mb/s, 0.8 Vp-p, 75 Ω
i.LINK (DV) output 6-pin (x 1), IEEE 1394
Time Code output – BNC (x 1), 1.0 Vp-p, – BNC (x 1), 1.0 Vp-p,
75 Ω,unbalanced 75 Ω,unbalanced
Monitor output L/R Pin Jack (x 2): -10 dBu at 47 kΩload, unbalanced, XLR (male x 2): +4 dBm, 600 Ωload, low impedance, balanced
Headphone output JM-60 Stereo Phone Jack, -∞to -12 dBu at 8 Ωload, unbalanced
Remote Control
RS-422A D-sub 9-pin (female) (x 1), Sony 9-pin remote interface
RS-232C D-sub 9-pin (male) (x 1)
Wireless SIRCS
Supplied accessories
Operation manual (CD-ROM), Operation manual, vertical stand (x 2), Infra-red remote controller
© 2004 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony, Betacam, Betacam SP, Betacam SX, Digital Betacam, MPEG IMX, and i.LINK
are trademarks of Sony.
V-2215
MK10116V1 Printed in USA (5/04)
Sony Electronics Inc.
One Sony Drive
Park Ridge, NJ 07656
www.sony.com/professional
