Sony Pressman TCS-100DV User manual
SERVICE MANUAL
STEREO CASSETTE-CORDER
US Model
AEP Model
Tourist Model
SPECIFICATIONS
TCS-100DV
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type MT-TCS100-162
Recording system
4-track 2-channel stereo
Tape speed
4.8 cm/s or 2.4 cm/s
Frequency range
150 – 8,000 Hz using normal (T PE I) cassette (with REC TIME switch at “NORMAL”)
Speaker
Approx. 3.6 cm (1 ⁄ in.) dia.
716
Power output
Speaker:70 mW (at 10% harmonic distortion)
Head phones:3 mW + 3 mW (at 10% harmonic distortion)
Input
Microphone input jack (minijack) sensitivity 0.4 mV for 3 kilohms or lower
impedance microphone
Output
i (headphones) jack (minijack) for 8 – 300 ohms headphones
Variable range of the speed control
From +20% to –15% (with REC/TIME switch at “NORMAL”)
Power requirements
1.5V DC batteries size AAA (R03) × 2/External DC 1.5V power souces
Dimensions (w/h/d) incl. projecting parts and controls
Approx. 112 × 30 × 78 mm (4 ⁄ × 1 ⁄ × 3 ⁄ in.)
34316 18
Mass
Approx. 190 g (6.8 oz)
Supplied accessories
Carrying pouch (1)
Sony manganese batteries R03 (SB) (2) (Sony world model only)
Headphones with remote control (1)
Hand strap (1)
Design and specifications are subject to change without notice.
Ver 1.0 2000. 02
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
