Sony Xperia 1 User guide

4
1
7
5
6
2
3
1Charging/Notication light
2 NFC
3 Volume/Zoom key
4 Fingerprint sensor
5 Power key
6 Camera key
7USB Type-C™ port/Charger/Audio
adapter
To insert SIM and
memory cards
SIM2
microSD
SIM1
1Drag out the SIM card tray.
2Place the main SIM card securely in
position for SIM1.
3Place either the second SIM card
(SIM2) or the memory card securely in
the tray, in the correct orientation.
4Gently push the SIM card tray back
into the slot until it ts into place.
To turn on your device
1Long press the power key until the
device vibrates.
2Wait a moment for the device to start.
To activate the screen
•Briey press the power key.
Transferring content
For transferring content from an old
device to your new device, log in with
your Google account and sync your data
using services provided by Google. For
details visit support.google.com.
For more information
Visit support.sonymobile.com or tap to
launch the Support app.
The Support app is not available in all
countries and regions.

To view the CE marking and the FCC ID
1Drag out the SIM card tray.
2Drag out the label strip in the same way.
3To view the FCC ID, turn over your device. The FCC ID is
displayed on the other side of the label strip.
To view the regulatory compliance mark
•Open the phone dialer, then enter *#07#.
Warranty, SAR and usage guidelines
For information about warranty, SAR (Specic Absorption Rate) and safety
guidelines, please read the Important information provided under
Settings > System > About phone > Legal information on your device.
Supported frequency bands
Some frequency bands might be turned o in certain markets or by
certain operators.
You can nd your model number under Settings > System > About
phone.
J9110
UMTS HSPA+ (Bands 1, 2, 4, 5, 6, 8, 19) GSM GPRS/EDGE 850, 900, 1800,
1900 LTE (Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 19, 20, 25, 26, 28, 29, 32, 34, 38,
39, 40, 41, 46, 66) WLAN, 2.4G/5G, NFC
GSM 850/900 : 33dBm, DCS(1800)/PCS(1900) : 30dBm, UMTS : 24dBm,
LTE : 23dBm, 2.4GHz<100mW, 5.15-5.35GHz<200mW,
5.47-5.725GHz<200mW, 5.735-5.835GHz<25mW, NFC 13.56MHz
The 5150 – 5350MHz band is restricted to indoor use only.
Declaration of conformity
Hereby, Sony Mobile declares that the radio equipment type PM-1221-BV
(J9110) is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
http://www.compliance.sony.eu/
Loudness warning
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
FCC statement
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
For customers in the United States
Owner's record
The model and IMEI numbers are located on the box of the unit. Record
the IMEI number in the space provided below. Refer to them whenever
you call upon Sony Mobile Customer Support regarding this product.
Model No._______________
IMEI No. _______________
Legal information
This Startup guide is published by Sony Mobile Communications Inc. or its
local aliated company, without any warranty. Improvements and
changes to this Startup guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/or
equipment, may be made by Sony Mobile Communications Inc. at any
time and without notice. Such changes will, however, be incorporated
into new editions of this Startup guide. All illustrations are for illustration
only and may not accurately depict the actual device.
All product and company names mentioned herein are the trademarks or
registered trademarks of their respective owners. Any rights not expressly
granted herein are reserved. Visit https://www.sonymobile.com/global-
en/legal/ for more information.
Manufacturer: Sony Mobile Communications Inc., 4-12-3 Higashi-
Shinagawa, Shinagawa-ku, Tokyo 140-0002, Japan. For EU product
compliance: Sony Belgium, bijkantoor van Sony Europe B.V., Da Vincilaan
7-D1, 1930 Zaventem, Belgium.
Note: Sony Mobile advises users to backup their personal data and
information.
Some services are network- or subscription-dependent. Please contact
your network operator or our call centre for details.
©2019 Sony Mobile Communications Inc.
Startup guide
Xperia 1
J9110
Printed in XXX (Printers logotype)
