Sony FCB-EV7100 User manual

FCB-EV Series
Color Block Cameras
FCB-EV5500
FCB-EV7500
FCB-EV7100

Key Features
Capture crisp, clear Full HD (1080/60p) images*2
The high-performance 1/2.8-type Exmor™ CMOS image
sensor achieves superb Full HD (1920 x 1080) picture
quality, even in low-light environments. Progressive scanning
assures smoother pictures with reduced blur – ideal for
capturing the detail in moving images.
*2 The FCB-EV5500 achieves crisp HD 720 picture quality.
Fast, bright lens with rapid 30x optical zoom*3
The high quality lens offers a bright F1.6 maximum aperture
and 30x optical zoom range. Fast zoom operation (from
wide end to tele) is ideal for smooth, rapid transitions from
wide area coverage to detailed close-ups in security and
surveillance applications.
*3 The FCB-EV7100 is equipped with a bright F1.8 maximum aperture and
10x optical zoom.
Get a steadier picture with image stabilizer*4
The camera’s built-in image stabilizer function counters the
effects of blurred, shaky images caused by low-frequency
vibration. It’s useful for outdoor surveillance and traffic
monitoring applications where the camera may be subject
to wind or mechanical vibration such as on a bridge or
mounting pole.
*4 Except FCB-EV7100.
StableZoom™
Image stabilizer and optical/digital zoom are combined
to enhance picture quality while maintaining the original
horizontal angle of view, ensuring no compromise in image
size and reduced blurring.
2D/3D Noise Reduction
Advanced noise reduction technology filters noise from the
image for clearer results, especially in low light conditions.
Noise reduction can be selected from five levels to suit a
wide range of operating environments.
See more clearly with Visibility Enhancer and De-fog
Picture quality is enhanced dynamically and adaptively
on a pixel-by-pixel basis while continuously adapting to
the scene within the given dynamic range. There’s also a
de-fog feature that allows clearer viewing in foggy or misty
scenes.
Wide dynamic range
Wide-D image processing technology gives the ability
to see clear detailed images in high-contrast or backlit
environments. For the FCB-EV5500, enhanced processing
now supports an exceptionally wide 120dB dynamic range
method (HD 720 resolution) for even greater clarity.
Clear vision round the clock with Day/Night
Benefit from optimized picture quality in changing light
conditions – a frequent challenge in round-the-clock
security operations. In high sensitivity mode the camera
can operate effectively in lighting levels as low as 0.35 lx
(ICR on).*5
*5 The FCB-EV5500 achieves 0.25lx.
Introduction
FCB-EV7500 FCB-EV7100 FCB-EV5500
Imager sensor 1/2.8-type CMOS 1/2.8-type CMOS 1/3-type CMOS
Lens 30x 10x 30x
Picture quality Full HD 1080/60p (1920 x 1080) Full HD 1080/60p (1920 x 1080) HD 720/60p (1280 x 720)
Minimum illumination* 1.4 lx (F1.6, 50%) 1.4 lx (F1.8, 50%) 1.0 lx (F1.6, 50%)
Digital zoom 12x (360x with optical zoom) 12x (120x with optical zoom) 12x (360x with optical zoom)
Mass 260 g (9.2 oz) 210 g (7.4 oz) 260 g (9.2 oz)
Dimensions 50 x 60 x 89.7 mm
(2 x 2 3/8 x 3 5/8 inches)
45.6 x 48.8 x 78 mm
(1 13/16 x 1 15/16 x 3 1/8 inches)
50 x 60 x 89.7 mm
(2 x 2 3/8 x 3 5/8 inches)
Defog
Wide-D (Wide dinamic range)
Image stabilizer
StableZoom
Auto ICR (Auto IR-cut Filter Removal)
Spherical privacy zone masking
Noise reduction
Slow AE response
* High sensitivity mode, ICR off.
In response to growing demand for the high-quality, high-resolution images, Sony is adding three new color
models to our camera block line-up.
The FCB-EV7500 employs 1/2.8-type Exmor™ CMOS image sensor with Full HD (1080/60p) performance, and
achieves excellent zooming performance with a 30x optical zoom lens. The FCB-EV7100 also delivers Full HD
(1080/60p) performance with a 10x optical zoom lens with very light compact design. The FCB-EV5500 is a
model with HD (720/60p) performance with 30x optical zoom lens.
All of these cameras inherit a multitude of features from Sony’s world-renowned FCB Series including Wide-D*1,
Auto ICR, and Spherical Privacy Zone Masking. These useful features are suitable for a variety of applications to
satisfy your needs.
*1 Wide dynamic range.

Dimensions Unit: mm (inches)
89.7 (3 5/8)
82.7 (3 3/8)4.3 (3/16)
9.4
(3/8)
7.55 (5/16)
11.8 (15/32)73 ±0.1 (2 7/8)
33 ±0.1 (1 5/16)
29 ±0.1
(1 3/16)
33.55 (1 3/8)
37.75 ±0.1 (1 1/2)
17.55 ±0.1
(23/32)
25.4 ±0.1
(1)
21 ±0.1 (27/32)
16 ±0.1 (21/32)
27 ±0.1 (1 1/8)
10 (13/32)
Ø41.7 (1 11/16)
Ø45.6 (1 13/16)
48.3 ±0.1 (1 15/16)
46.5° (1 7/8°)
72.9° (2 7/8°)
8 (11/32)
13.5 (9/16)
Front Top
Rear Left
Bottom
Right
Front Top
Rear Left
Bottom
Right
FCB-EV7500 / FCB-EV5500
FCB-EV7100
14 ±0.1 (9/16)
20 ±0.1
(13/16)
20 ±0.1
(13/16)
4.5 (3/16)
2-M2 Within a depth of 3 mm (1/8in.)
or less from the side
4-M2 Within a depth of 3 mm (1/8in.)
or less from the side
8-M2 Within a depth of 3 mm (1/8in.)
or less from the bottom surface
9-M2 Within a depth of 3 mm (1/8in.)
or less from the top surface
11
(7/16)
8
(11/32)
28 ±0.1
(1 1/8)
20 ±0.1
(13/16)
12.55 (1/2)
50 (2)
60 (2 3/8)
30 (1 3/16)
5 (7/32)
10 (13/32)
Analog I/O
Digital I/O
50 (2)
25 (1)
25 (1)
78 (3 1/8)
62.5 ±0.1 (2 1/2)
20.45
(13/16)
12.4 (1/2)
4-M2 Depth 3 mm (1/8in.) or less
4-M2 Depth 3 mm (1/8 in.) or less
5-M2
Depth 3 mm (1/8in.)
or less
28 ±0.1
(1 1/8)
40.7 (1 5/8)
20 ±0.1
(13/16)
23.7
(15/16)
10 (13/32)
45.6 (1 13/16)
8 (11/32)
11 (7/16)
29.6 (1 3/16)
7 (9/32)
10 (13/32)
23 (29/32)
16.95 (11/16)
45.6 (1 13/16)
48.8 (1 15/16)
21 ±0.1
(27/32)
5.5 ±0.1 (7/32)
29.5 ±0.1
(1 3/16)
13
(17/32)
4 (3/16)
11 (7/16)
Analog (24P)
Digital (30P)
Auto ICR (Auto IR-cut Filter Removal)
In low light conditions the camera automatically switches
from day to night mode, removing the IR-cut filter to boost
sensitivity for clear pictures in near-darkness.
Spherical privacy zone masking
Areas of view can be selectively masked for privacy.
Masked areas are automatically interlocked with the
camera’s pan/tilt/zoom movements.
Choice of HD and SD output modes
Video signal outputs are available in a range of HD (digital
and analog) and SD formats, reducing integration cost and
complexity by avoiding the need for additional analog/
digital converters. Video output modes can be changed
‘on the fly’ during normal operation, without a hardware
reboot of the camera.
One-cable connection for simpler integration
A single cable carries HD video signals plus VISCA
communication and power supply. Integration flexibility
is further supported by both 30-pin micro coaxial (digital
output) and 24-pin FFC (analog output) interfaces.
Wide range of features for versatile operation
Versatile operation is ensured by a wide range of functions
and adjustments, including: White Balance modes; Picture
effects (E-Flip, Nega Art, Black & White, Mirror Image, Color
Enhancement); Motion Detection/Alarm; Picture freeze;
Temperature readout; Slow AE response; Electronic shutter/
slow shutter;Title display/Camera mode display (English).

MK11047V1YIT13SEP
Distributed by ©2013 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for mass and dimensions are approximate.
“SONY”,“make.believe”,“Exmor” and “StableZoom” are
registered trademarks of Sony Corporation.
All other trademarks are the property of their respective owners.
SPECIFICATIONS PIN ASSIGNMENTS
CN401
Pin No. Name Level
1 TXOUT3+
2 TXOUT3-
3 TXCLKOUT+
4 TXCLKOUT-
5 TXOUT2+
6 TXOUT2-
7 TXOUT1+
8 TXOUT1-
9 TXOUT0+
10 TXOUT0-
11 GND
12 TxD CMOS 5 V (Low: Max.
0.1 V, High: Min. 4.4 V)
13 RxD CMOS 5 V (Low: Max.
1.0 V, High: Min. 2.3 V)
14 DC IN 6 to 12 V DC
15 DC IN 6 to 12 V DC
16 DC IN 6 to 12 V DC
17 DC IN 6 to 12 V DC
18 DC IN 6 to 12 V DC
19 GND
20 GND
21 TXOUT7+ Single out mode: open
22 TXOUT7- Single out mode: open
23 TXOUT6+ Single out mode: open
24 TXOUT6- Single out mode: open
25 NC
26 RESET Reset: Low (GND)
Normal: Open (1.8 V)
27 TXOUT5+ Single out mode: open
28 TXOUT5- Single out mode: open
29 TXOUT4+ Single out mode: open
30 TXOUT4- Single out mode: open
Connector: USL00-30L-C (KEL Co.)
CN501
Pin No. Name Level
1 GND
2 TxD CMOS 5 V (Low: Max.
0.1 V, High: Min. 4.4 V)
3 RxD CMOS 5 V (Low: Max.
1.0 V, High: Min. 2.3 V)
4 RESET Reset: Low (GND)
Normal: Open (1.8 V)
5 GND
6 NC
7 GND
8 NC
9 GND
10 VBS-OUT
11 GND
12 Y-OUT HD Analog Component
13 GND
14 Pb-OUT HD Analog Component
15 GND
16 Pr-OUT HD Analog Component
17 GND
18 DC IN 6 to 12 V DC
19 DC IN 6 to 12 V DC
20 DC IN 6 to 12 V DC
21 DC IN 6 to 12 V DC
22 GND
23 DC IN 6 to 12 V DC
24 GND
Connector: 046240024006800+ (Kyocera-elco)
FCB-EV7500 FCB-EV7100 FCB-EV5500
Image sensor 1/2.8-type Exmor CMOS
Image sensor
(Number of effective pixels) Approx. 2.38 Megapixels Approx. 1.37 Megapixels
Signal system 1080p/59.94, 1080p/50, 1080p/29.97, 1080p/25, 1080i/59.94, 1080i/50,
720p/59.94, 720p/50, 720p/29.97, 720p/25, NTSC*1, PAL*1
720p/59.94, 720p/50, 720p/29.97,
720p/25, NTSC*1, PAL*1
Minimum
illumination
(50%)
High sensitivity
mode Color: 0.35 lx (F1.6,AGC on,1/30 s) Color: 0.25 lx (F1.6,AGC on,1/30 s)
Normal mode Color: 1.4 lx (F1.6,AGC on,1/30 s) Color:1.4lx (F1.8,AGC on, 1/30 s) Color: 1.0 lx (F1.6,AGC on,1/30 s)
Recommended illumination 100 lx to 100,000 lx
S/N ratio More than 50 dB
Gain Auto/Manual (0 step to 28 step,+2 step/total 15 steps)
Max. Gain Limit (6 step to 28step, +2 step/total 12 steps)
Shutter speed 1/1 s to 1/10,000 s, 22 steps
Sync system Internal
Exposure control Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow AE
Backlight compensation Yes
Aperture control 16 steps
White balance Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto), One-push, Manual
Lens 30x optical zoom
f=4.3 mm (wide) to 129.0 mm (tele)
F1.6 to F4.7
10x optical zoom
f=3.8 mm (wide) to 38 mm (tele)
F1.8 to F3.4
30x optical zoom
f=4.3 mm (wide) to 129.0 mm (tele)
F1.6 to F4.7
Digital zoom 12x (360x with optical zoom) 12x (120x with optical zoom) 12x (360x with optical zoom)
Focusing system Auto (Sensitivity: normal, low), One-push AF, Manual, Interval AF, Zoom Trigger AF, Focus compensation in ICR on
Horizontal viewing angle 63.7° (wide end) to 2.3° (tele end) 67.0° (wide end) to 7.6°(tele end) 57.8° (wide end) to 2.1° (tele end)
Minimum object distance 10 mm (wide end) to 1200 mm
(tele end) (Default:300 mm)
10 mm (wide end) to 800 mm
(tele end) (Default:320 mm)
10 mm (wide end) to 1200 mm
(tele end) (Default:300 mm)
Auto ICR Yes
Wide-D*2Yes
Visibility enhancer Yes
Noise reduction Yes (6 steps)
Progressive scan mode Yes
Image stabilizer Yes No Yes
StableZoom Yes
Digital output Yes
Spherical privacy zone masking Yes
Motion detection Yes
Alarm No
Slow AE response Yes
Picture effects E-Flip, Nega Art, Black & White, Mirror image, Color enhancement
Picture freeze Yes
Slow shutter Yes
Temperature readout Yes
Title display 20 characters/line,max.11 lines
Camera mode display Yes
Key switch control No
Camera operation switch No
Video output HD Analog: Component (Y/Pb/Pr)
Digital:Y/Cb/Cr4:2:2 via LVDS
(Signal format conforms to SMPTE 274/SMPTE 296.)
Analog: Component (Y/Pb/Pr)
Digital:Y/Cb/Cr4:2:2 via LVDS
(Signal format conforms to SMPTE 296.)
SD VBS
Camera control interface VISCA (CMOS 5 V level)
Baud rate:9.6 Kbps,19.2 Kbps,38.4 Kbps,115.2 Kbps, Stop bit: 1 bit
Power requirements 6.0 V to 12.0 V DC 6.0 V to 12.0 V DC 6.0 V to 12.0 V DC
Power consumption 2.9 W (zoom/focus inactive)
3.7 W (zoom/focus active)
3.4 W (zoom/focus inactive)
3.7 W (zoom/focus active)
2.6 W (zoom/focus inactive)
3.5 W (zoom/focus active)
Operating temperature -5ºC to +60ºC (23°F to 140°F)
Storage temperature -20ºC to +60ºC (-4°F to 140°F)
Operating humidity 20% to 80%
Storage humidity 20% to 95%
Dimensions (W x H x D) 50.0 x 60.0 x 89.7 mm
(2 x 2 3/8 x 3 5/8 inches)
45.6 mm x 48.8 mm x 78.0 mm
(1 13/16 x 1 15/16 x 3 1/8 inches)
50.0 x 60.0 x 89.7 mm
(2 x 2 3/8 x 3 5/8 inches)
Mass 260 g (9.2 oz) 210 g (7.4 oz) 260 g (9.2 oz)
*1 Non-standard video format. *2 Wide dynamic range.
