Sony FD Mavica MVC-FD100 User manual

➤
1/2.7" 1.2 Mega Pixel Effective Super
HAD™ CCD, 1.3 Mega Pixel Gross
Captures professional looking still images
with excellent picture clarity and true-to-
life color reproduction. Reduced noise in
the imager improves signal-to-noise ratio,
particularly effective when shooting black
objects or in dark situations.
➤
SXGA, XGA, VGA Image Resolution:
Match the resolution you capture images to
your needs. Utilizing high quality CCD imagers,
Sony digital still cameras capture stunning
images in a variety of resolutions ideal for a
variety of applications from high-resolution
printing, screen shows, websites or e-mail.
➤
Dual Media Slots:
Dual Media slots allow
images to be stored on
inexpensive easy-to-use
floppy disks or in greater capacities
using Memory Stick®media. Only FD
Mavica can copy from one type of media
to another. So you don’t have to wait to
e-mail images to your friends, you can
give them the image on the spot copied
to an affordable 3.5"floppy disk. Memory
Stick media is a flash memory system
that holds data on a tiny, transportable
unit which can be used in digital
cameras, camcorders, computers,
printers and more. Choose between the
simplicity of floppies as well as
ultra-capacity storage of Memory Stick
media-up to 128 MB of memory.
3X Optical/ 6X Precision Digital Zoom:
Zoom helps you frame your
shots for better digital
pictures. Bring distant
subjects closer or pull back for wide
shots. Precision Digital zoom extends the
optical zoom range by 2X without the
jagged edges of other designs, resulting
smooth images.
➤
12-Bit DXP A/D Conversion:
12-bit Digital Extended
Processor (DXP) captures the
dynamic range between light
and dark areas of your subject, providing
an overall improvement, 4 times the level
of brightness of 10 bit systems, without
losing detail (highlights and shadow).
E-Mail Mode:
Stores a low-resolution 320 x
240 file in a separate folder
from the original image for
faster Internet uploads and downloads.
➤
Intelligent Flash with Red-Eye Reduction:
Provides the appropriate amount of flash
for optimum brightness and color
accuracy in virtually any lighting
condition. The Red-Eye Reduction
system uses a series of pre-flashes that
causes the subject’s pupils to contract,
reducing the possibility of reflection from
the back of the eye that causes the
red-eye problem.
➤
MPEG Movie Mode (No Audio)
Create small MPEG1 videos
clips that record 8.3 frames
per second. These clips are
great for emailing. Videos can be recorded
in the Presentation mode at 320 x 240
resolution for 5,10 or 15 seconds. Or
record up to 60 seconds using the E-mail
Mode at 160 x 112 resolution. These clips
are great for e-mailing.
➤
Light Metering
Capture the best possible images even in
difficult situations, like when your subject
is strongly backlit or in deep shadow.
Light metering provides better exposure
balance in your images. Choose from
Center-weighted Metering and Spot
Metering. Center-weighted metering
measures light in the entire frame, but
emphasizes the weight in the center of
the frame. Spot metering measures the
light at the center of the frame only.
➤
Clip Motion:
Animated function plays back
still images in succession in
1/2 second intervals. Clip
motion allows you to capture up to 10
frames in the GIF format and combines
them into a compact animated GIF file.
By varying time between shots you
can create a variety of entertaining
animations not possible with other
motion capture functions.
2.5" 123K Pixel LCD Display:
What you see is what you get! A large, full
color LCD display viewfinder lets you
preview or review your shots right on the
camera back, with great detail and clarity.
5-Mode Program AE:
Allows quick and easy setting of proper
exposure, shutter and depth-of-field for a
variety of shooting environments. A/E
modes include: Twilight, Twilight +,
Landscape, Pan Focus and Spot Meter.
➤
TEXT Mode (GIF):
Great for taking images of
documents. Text mode
captures images (GIF) with
much smaller file sizes without reducing
resolution.
➤
TIFF Mode:
Digital images can be stored
in an uncompressed file
format (TIFF–Tagged Image
File Format on the cameras Memory Stick
media only). Images are presented with all
the color information found in the original
shot with no compression, and are perfect
for use in graphic applications.
FEATURES
➤
STEP-UP FEATURE
MVC-FD100
FD Mavica®
Digital Still Camera

OPTIONAL ACCESSORIES
SPECIFICATIONS
Imaging Device: 1/2.7" 1.2 MP Effective Pixels, Super HAD™
CCD 1.3 MP Gross Pixels
Recording Media: 3.5" Floppy Disk/Memory Stick®Media
Zoom: 3X Optical/2X Digital/6X Total
Filter Diameter: 37mm
Focal Length: 6.4 –19.2mm
35mm Conversion: 41 –123mm
F: 3.8 –3.9
Focus: Auto, Preset
Macro: Auto (3cm)
Shutter Speed: Auto (2 sec. –1/800 sec.)
Manual Exposure: Yes, +/- 2.0 EV, 1/3 EV steps
Color LCD: 2.5", 123K Pixels
Flash Mode: Red-eye Reduction, On, Off, Auto
White Balance: Auto, Hold, Indoor, Outdoor
Picture Effects: Sepia, B&W, Negative Art, and Solarization
ISO: Yes (Auto, 100, 200, 400)
Program AE Modes: Spot Meter, Pan Focus, Landscape, Twilight
Self-Timer: Yes, 10 seconds
Audio/Video Out: Yes; Video Only
Accessory Terminal: No
Erase/Protect: Yes
Date/Time Stamp: Yes
Slide Show Mode: Yes
Media/Battery Indicator: Yes
File Formats: JPEG, GIF, TIFF*, MPEG1
Max File Resolution: 1280 x 960 (SXGA)
MPEG Movie Mode: Yes (w/o Audio), Presentation Mode 320 x
240, Email Mode 160 x 112
Clip Motion: Normal (160 x 120), Mobile (80 x 72)
Microphone/Speaker: No
USB Terminal: Yes
Software Supplied: Pixela Image Mixer Ver. 1.0
Compatible with Microsoft®Windows®98, 98SE, Me, 2000,
XP; Macintosh®8.5.1, 8.6, 9.0, 9.1
USB Drivers, Microsoft®Windows®98, 98SE, ME, 2000, XP;
Macintosh®8.5.1, 8.6, 9.0, 9.1, 10.0, 10.1
Supplied Accessories: NP-F330, AC Power Adapter, AC cable,
Video cable, USB cable
Dimensions (W/H/D): 5
3
/ 5 " x 4
1
/ 10 " x 3
1
/ 16 " (142mm x 104mm x 77mm)
Weight: 1.15 lbs. (520 grams)
©2002 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited.
All rights reserved. Sony, AccuPower, InfoLithium, Mavica, Memory Stick, and Super HAD are
trademarks of Sony.
Microsoft and Windows are trademarks of Microsoft Corporation.
Macintosh is a trademark of Apple Computer, Inc. All other trademarks are the property of their
respective owners. Features and specifications subject to change without notice.
Non-metric weights and measures are approximate.
AC-V700A AC Adapter/Charger
BC-V615 Battery Charger
BC-V500 Dual Battery Charger
NP-F550 InfoLithium®Battery
LCS-MVC4 Carrying Case
ACC-MVC2 Starter Kit
VCL-HG0737X Wide Angle Lens
VCL-0637H Wide Angle Lens
VCL-HG2037X Telephoto Lens
VCL-MHG07A High Grade Wide
Angle Lens
VCL-ES06A Wide Angle Lens
VCL-ES20A Telephoto Lens
VF-37CPKS, Polarizing Filter Kit
VF-R37K Neutral Density Kit
MSA-16A/32A/64A/128A Memory
Stick Media
MSAC-US5 Memory Stick
Reader/Writer Optical Mouse
MSAC-HGA8 Memory Stick Case
DSAC-MVC Eye Level View Finder
Sony Electronics Inc.
16765 West Bernardo Drive
San Diego, CA 92127
www.sony.com/di
MVC-FD100
ADDITIONAL FEATURES
USB Interface
Playback Zoom, Trim and Resize
White Balance (Auto/Indoor/Outdoor/Hold)
InfoLithium®Battery System with AccuPower™Meter
Rechargeable Battery with in Camera Charger/AC Adaptor Supplied
1280 x 960 1280 x 960 1024 x 768 640 x 480
(3:2)
Floppy Disk 6 6 10 30
8MB 10 10 20 45
16MB 20 20 40 95
32MB 50 50 80 195
64MB 100 100 165 390
128MB 200 200 335 785
JPEG Still Image Mode
Fine/Standard
Memory Stick Presentation Mode Video Mail Mode
Media (320 x 240) (160 x 112)
Up to 15 Sec Intervals Up to 60 Sec Intervals
Floppy Disk 15 sec 60 sec
8MB 1 min 20 sec 5 min 20 sec
16MB 2 min 40 sec 10 min 40 sec
32MB 5 min 20 sec 21 min 20 sec
64MB 10 min 40 sec 42 min 40 sec
128MB 21 min 20 sec 85 min 20 sec
MPEG MOVIE MODE
MAXIMUM STORAGE TIME
