Sony Mavica MVC-CD1000 Operating instructions

model name1[MVC-CD1000]
[3-062-474-11(1)]
masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\01COV-DirectC-
DUC\010cov.fm]
3-062-474-11(1)
DirectCD
™
Software Operating Instructions
©2000 Sony Corporation
MVC-CD1000
010cov.fm Page 1 Tuesday, May 23, 2000 4:27 PM

2
masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\02war.fm]
model name1[MVC-CD1000]
[3-062-474-11(1)]
Notice for users
Program © Copyright 1999 Adaptec,
Inc. All rights reserved./
Documentation ©2000 Sony
Corporation
All rights reserved. This manual or the
software described herein, in whole or
in part, may not be reproduced,
translated or reduced to any machine
readable form without prior written
approval from Sony Corporation.
IN NO EVENT SHALL SONY
CORPORATION BE LIABLE FOR
ANY INCIDENTAL,
CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON
TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR
IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE OR
OTHER INFORMATION
CONTAINED HEREIN OR THE USE
THEREOF.
Sony Corporation reserves the right to
make any modification to this manual
or the information contained herein at
any time without notice.
The software described herein may
also be governed by the terms of a
separate user license agreement.
Trademarks
•Adaptec is a registered trademark of
Adaptec, Inc.
•Easy CD Creator and DirectCD are
trademarks of Adaptec, Inc.
•Microsoft and Windows are
trademarksofMicrosoftCorporation,
registered in the U.S.A. and other
countries.
•Macintosh and Power PC are
trademarks of Apple Computer, Inc.
registered in the U.S.A. and other
countries.
•All other product names mentioned
herein may be the trademarks or
registered trademarks of their
respective companies. Furthermore,
“™” and “®” are not mentioned in
each case in this manual.
01cov.book Page 2 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\01covTOC.fm]
3
model name1[MVC-CD1000]
[3-062-474-11(1)]
Table of contents
Notice for users ...............................2
Introduction .....................................4
Installing DirectCD .........................5
Using DirectCD ...............................8
Removing the disc .........................12
Modifying data in a disc ................13
01cov.book Page 3 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
4
model name1[MVC-CD1000]
[3-062-474-11(1)]
Introduction
This manual describes how to install the application software, DirectCD supplied
with the MVC-CD1000, and how to use it. If explanations described in this manual
are different from the PDF file in the CD-ROM, follow explanations described in this
manual.
Note
You cannot install DirectCD into a Macintosh computer. To read the disc that has been
finalized, copy Adaptec UDF Volume Access included in the CD-ROM (SPVD-001) supplied
with the MVC-CD1000 to System folder of your personal computer and restart your personal
computer.
Once you install the USB driver into your personal computer (for details on
installation, refer tothe operating instructions of the MVC-CD1000), and connect the
MVC-CD1000 and your personal computer with the USB cable, you can do the
following operations:
•You can send images shot with the MVC-CD1000 to your personal computer and
play them back on your personal computer. (The finalization is not required.)
•You can write images that are captured by your personal computer onto a disc and
make the picture album.
•You can directly read and write images shot with the MVC-CD1000 in the CD-R/
CD-RW drive, without executing the finalization.
Recommended Windows environment for DirectCD
•MMX Pentium 166 MHz or greater (When using DirectCD with the MVC-
CD1000: MMX Pentium 200 MHz or greater)
•32 MB or more of RAM
•45 MB or more of free hard-disk space
•Monitor with 800×600-resolution and 256-color
•Microsoft Internet Explorer 4.01 or later
01cov.book Page 4 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
5
model name1[MVC-CD1000]
[3-062-474-11(1)]
Installing DirectCD
•When using a CD-ROM drive
DirectCD is not required to only view images on the finalized disc in a CD-ROM
drive. If you read or write images on the disc which is not finalized, you have to
connect the MVC-CD1000 to your personal computer with the USB cable and
install DirectCD into your personal computer. For details on USB connection, refer
to the operating instructions of the MVC-CD1000.
•When using a CD-R or CD-RW drive
Select one of the following ways according to the configuration of your personal
computer.
— When a writing software has not been installed into your personal computer, you
can install DirectCD into your personal computer.
— When DirectCD other than this version has been installed into your personal
computer, you can install DirectCD included in the supplied CD-ROM. You
cannot use any other versions of DirectCD with the MVC-CD1000. If you
install the supplied DirectCD, DirectCD that has been installed in your personal
computer will be upgraded to the new version.
— When a writing software other than DirectCD has been installed into your
personal computer, uninstall the writing software from your personal computer,
then install DirectCD. If you want to use the writing software, do not install
DirectCD. You cannot use the MVC-CD1000 with DirectCD.
Note
You may not be able to use DirectCD depending on your CD-R drive or CD-RW drive.
01cov.book Page 5 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
6
model name1[MVC-CD1000]
[3-062-474-11(1)]
For Windows 98 users
Follow these steps below to install DirectCD. English version illustrations are used in
this manual.
1Turn on your personal computer and insert the supplied CD-ROM
(SPVD-001) into the CD-ROM drive of your personal computer.
The following window appears on the screen.
If the window above is not displayed, start up “SETUP. EXE” in the CD-ROM.
2Select the language.
3Click [DirectCD].
The “Welcome” window appears on the screen.
4Click [Next].
5Read the text on the window carefully, and if you accept it, click
[Yes].
01cov.book Page 6 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
7
model name1[MVC-CD1000]
[3-062-474-11(1)]
DirectCD will be available after you restart your personal computer. Check the option
[Yes ...,] then click [Finish].
Notes on Easy CD Creator included in the supplied CD-ROM
•You cannot use Easy CD Creator with the MVC-CD1000 connected to your personal computer
with the USB cable.
•Be sure to install Easy CD Creator of the same version as included in the supplied CD-ROM,
with DirectCD. If one of other versions of Easy CD Creator is installed, DirectCD that is
installed from the supplied CD-ROM may not function.
6Check the directory in which DirectCD will be installed.
When you install DirectCD into another directory other than the default one,
click [Browse...], and select the directory.
7Click [Next].
The setup of the program starts. When the installation is complete, the screen
returns to the window displayed in step 1.
8Click [Exit].
The “Setup Complete” window appears on the screen.
01cov.book Page 7 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
8
model name1[MVC-CD1000]
[3-062-474-11(1)]
Using DirectCD
You have to install the USB driver into your personal computer to connect the MVC-
CD1000 to your personal computer with the USB cable. For details on the
installation of the USB driver and on the directory, refer to the operating instructions
of the MVC-CD1000.
When you use a new disc or record a new image onto the disc that was finalized, you
have to format the disc (page 9).
Note
When you write new data onto the disc, before removing
the disc from the MVC-CD1000, be sure to follow the
procedure for removing the disc (page 12). If you remove
the disc or disconnect the USB cable, without following
the procedure, data on the disc may be broken.
Starting DirectCD
1After starting up your computer, insert a disc into the MVC-
CD1000, and connect to your personal computer with the USB
cable.
2Turn on the MVC-CD1000 and your personal computer.
“DirectCD Disc Ready” appears on the screen.
If this screen does not appear, double-click the CD icon on the Windows
taskbar, in the lower corner of your screen.
to the USB connector
Personal computer USB cable
to the DIGITAL I/O jack
Push in until the
plug clicks into
place
01cov.book Page 8 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
9
model name1[MVC-CD1000]
[3-062-474-11(1)]
You have to format (initialize) a disc before recording images onto the disc.
If you format a new Sony Mavica disc, you can store about 156 MB data on it.
Formatting a disc
1Start DirectCD as described in the previous section.
After a few seconds, a screen should appear asking you to “Please select the
type of disc you wish to create.”
2Select the first option, [Click here to create a data disc that will be
accessible through a drive letter].
The Adaptec DirectCD Wizard starts.
Note
Do not select the other options. If you do, you cannot use the disc with the MVC-CD1000.
3Read the text in the “Welcome” window and click [Next].
The [Drive Information] window appears.
4Read the text in the “Recorder Information” window and click
[Next].
The “Format Disc” window appears.
01cov.book Page 9 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
10
model name1[MVC-CD1000]
[3-062-474-11(1)]
5In the “Format Disc” window, click [Next] to continue.
The “Name Your Disc” window appears.
6Type a disc name of up to 11 characters.
7Click [Finish].
Disc formatting begins. The “DirectCD Disc Ready” window appears when
the formatting is complete.
8Click [OK].
01cov.book Page 10 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
11
model name1[MVC-CD1000]
[3-062-474-11(1)]
Once your disc is formatted as a DirectCD disc, you can write data to it in several
different ways:
•To shoot images using the MVC-CD1000.
•To drag and drop files from Windows Explorer onto the disc drive icon.
•To select [Save As] from the File menu of a Windows application and select the
drive letter of the MVC-CD1000.
•To use the [Send To] command.
•To use MS-DOS command prompts from a DOS window in Windows.
Note
•If the file name format of images are not correspond to the following format,
DSC0ssss.JPG, you cannot play them back on the MVC-CD1000. For details, refer to the
operating instructions of the MVC-CD1000.
•If the file has too large size, this file may not be able to be played back on the MVC-CD1000.
Writing data to a disc
01cov.book Page 11 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
12
model name1[MVC-CD1000]
[3-062-474-11(1)]
Removing the disc
When you open the file in the disc with your application software, quit it before
starting the procedure below.
Note
When you write new data onto the disc, before removing
the disc from the MVC-CD1000, be sure to follow the
procedure below. If you remove the disc or disconnect the
USB cable, without following the procedure, data on the
disc may be broken.
1Right-click on the DirectCD icon on the taskbar and select
[Eject] from the drop-down list box.
The “Eject Disc” window appears.
2Check the appropriate option and click [Finish].
•If you do not execute the finalization, click the upper option on the window.
•If you execute the finalization to view images on a CD-ROM drive, click the
lower option on the window. When you will not add or modify data on the
disc any more, also, check the “Protect disc so it cannot be written to again”
option.
3Check that the ACCESS lamp is not lit, then open the disc cover
and remove the disc.
01cov.book Page 12 Tuesday, May 23, 2000 4:28 PM

masterpage:Right
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
13
model name1[MVC-CD1000]
[3-062-474-11(1)]
Modifying data in a disc
After you have formatted a blank disc for DirectCD use, you can keep adding data to
the disc until it is full. To do so, follow these steps:
If you “delete” files from a disc, the files become invisible to the file system (that is,
they cannot be seen in Windows Explorer) but the space they occupy is not available
for other files.
Thus, “deleting” files from a disc does not increase the available free space on the
disc. To delete the contents on a disc, follow these steps:
Writing more data to a disc
1Insert the disc into the MVC-CD1000 and connect the MVC-CD1000
to your personal computer with the USB cable.
2After the “DirectCD Disc Ready” window appears, click [OK], then
write data to the disc.
Deleting a file from a disc
1While in Windows Explorer, select the file(s) you want to delete.
2Select [Delete] from the File menu, or press the Delete key.
3Click [Yes] to confirm that you want to delete the files from the
disc.
The selected files will be deleted.
Writing More Data to a finalized disc
1Insert the disc that was previously finalized to read on a
standard CD-ROM drive into the MVC-CD1000.
2Start DirectCD.
3Click [Next] on each window until you see the “Make Disc
Writable” window.
4Type the name you want to call your disc in the “Name Your
Disc” window, using up to 11 characters.
01cov.book Page 13 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-
DirectCDUC\03pre.fm]
14
model name1[MVC-CD1000]
[3-062-474-11(1)]
5Click [Finish].
The “DirectCD Disc Ready” window will be displayed and writing data is
completed.
You can now copy more files to the disc using Windows Explorer or any
Windows application.
01cov.book Page 14 Tuesday, May 23, 2000 4:28 PM

01cov.book Page 15 Tuesday, May 23, 2000 4:28 PM

masterpage:Left
filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\03BCO-
DirectCDUC\01covIX.fm]
Sony Corporation Printed in Japan
01covIX.fm Page 16 Tuesday, May 23, 2000 4:29 PM
