Personal Audio
Docking System
4-400-213-33(1)
©2012 Sony Corporation Printed in China
Reference Guide GB
Note
In the Reference Guide, “iPod” is used as a general
reference to functions on an iPod, iPhone or iPad, unless
otherwise specified by the text or illustrations.
If you have any questions or problems concerning your
unit, please consult your nearest Sony dealer.
General information
Specifications
iPod
DC out: 5 V
MAX: 2.1 A
Radio
Frequency range
Band Frequency Frequency step
FM 87.5 MHz - 108 MHz 0.05 MHz
Bluetooth
Output
Bluetooth Specification Power Class 2
Maximum communication range
Line of sight approx. 10 m*1
Frequency band
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
Communication System
Bluetooth Specification Version 2.1 + EDR (Enhanced
Data Rate)
Compatible Bluetooth Profiles*2
A2DP (Advanced Audio Distribution Profile)
AVRCP*3(Audio/Video Remote Control Profile)
Supported codec*4
SBC (Subband Codec)
*1The actual range will vary depending on factors such as obstacles
between devices, magnetic fields around a microwave oven,
static electricity, reception sensitivity, aerial performance,
operating system, application software, etc.
*2Bluetooth standard profiles provide the specifications for
Bluetooth communication between devices.
*3Some operations may not be available for some models of iPod.
*4Codec: Audio signal compression and conversion format
General
Speaker
Woofer: Approx. 76 mm dia. × 2
Tweeter: Approx. 25 mm dia. × 2
Input
AUDIO IN jack (ø 3.5 mm stereo minijack)
Impedance: 50 kΩ
Average input level: 245 mV
Power output
20 W + 20 W (at 1% harmonic distortion) (with AC
adaptor)
7 W + 7 W (at 1% harmonic distortion) (with rechargeable
battery)
Power source
Rated external power source: DC IN 20 V (with supplied
AC adaptor (AC 100 V - 240 V, 50 Hz/60 Hz) or
rechargeable battery pack NH-300RDP)
Battery life*:
Approx. 7 hours (playback of iPod)
Approx. 7 hours (FM reception)
Approx. 6.5 hours (Bluetooth playback)
Dimensions
Approx. 356.0 mm × 168.1 mm × 121.7 mm (w/h/d)
(incl. projecting parts and controls)
Mass
Approx. 2.6 kg
Supplied accessories
Remote control (with a lithium battery) (1)
AC adaptor (1)
AC power cord (1)
Reference Guide (this document) (1)
Cushion for small-size iPod (1)
*Measured by Sony standards. The actual battery life may vary
depending on the circumstance of the unit.
Compatible iPod/iPhone/iPad
models
The compatible iPod/iPhone/iPad models are as follows.
Update the software of the iPod/iPhone/iPad to the latest
version before using it with this unit.
Dock Connector compatible models
iPod touch (4th generation)
iPod touch (3rd generation)
iPod touch (2nd generation)
iPod nano (6th generation)*
iPod nano (5th generation)
iPod nano (4th generation)
iPod nano (3rd generation)
iPod classic 160GB (2009)
iPhone 4S
iPhone 4
iPhone 3GS
iPhone 3G
iPad 2
iPad
Wireless music streaming compatible models
iPod touch (4th generation)
iPod touch (3rd generation)
iPod touch (2nd generation)
iPhone 4S
iPhone 4
iPhone 3GS
iPhone 3G
iPad 2
iPad
RDP-XF300iP
WARNING
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
To reduce the risk of fire, do not cover the ventilation of
the apparatus with newspapers, tablecloths, curtains, etc.
And do not place lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do not expose
this apparatus to dripping or splashing, and do not place
objects filled with liquids, such as vases, on the apparatus.
Do not install the appliance in a confined space, such as a
bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries
installed) to excessive heat such as sunshine, fire or the like
for a long time.
As the main plug is used to disconnect the unit from the
mains, connect the unit to an easily accessible AC outlet.
Should you notice an abnormality in the unit, disconnect
the main plug from the AC outlet immediately.
The unit is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet, even if
the unit itself has been turned off.
The nameplate and important information concerning
safety are located on the bottom exterior of the main unit
and on the surface of the AC adaptor.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same type.
Notice for customers: the following information is
only applicable to equipment sold in countries
applying EU directives
The manufacturer of this product is Sony Corporation, 1-
7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan. The
Authorized Representative for EMC and product safety is
Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Germany. For any service or guarantee matters,
please refer to the addresses given in separate service or
guarantee documents.
Hereby, Sony Corp., declares that this equipment is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. For details,
please access the following URL:
http://www.compliance.sony.de/
Use of the RLAN network is governed:
— with respect to private use, by the Legislative Decree of
1.8.2003, no. 259 (“Code of Electronic
Communications”). In particular Article 104 indicates
when the prior obtainment of a general authorization is
required and Art. 105 indicates when free use is
permitted;
*The iPod nano (6th generation) cannot be controlled by the
remote when the command of “MENU,” “,” “,” and “ENTER”
is pressed.
Design and specifications are subject to change without
notice.
Troubleshooting
General
The power does not turn on when the AC adaptor is
connected.
Make sure the AC adaptor is connected to the wall outlet
firmly.
The rechargeable battery is depleted.
Connect the AC adaptor to charge the battery.
There is no sound.
Adjust VOLUME +/− (VOL +/− on the remote).
Noise is heard.
Ensure that the unit is not near in-use portable phones,
etc.
The power will not turn on when the AC adaptor is
disconnected.
The Power Off Hold function may be set. In this case,
cancel the Power Off Hold function. (See “Power Off
Hold function.”)
The rechargeable battery may be depleted. In this case,
connect the AC adaptor to charge the battery. (See “To
use the AC adaptor.”)
“ERROR” appears in the display and the unit turns off
automatically.
If this symptom occurs frequently, consult your nearest
Sony dealer.
When using an iPod on the Dock
There is no sound.
Make sure the iPod is connected firmly.
Make sure that the function for iPod is activated.
Operation is not performed.
Make sure the iPod is connected firmly.
Check that the iPod is compatible with this unit. (See
“Dock Connector compatible models.”)
The iPod does not charge.
Make sure the iPod is connected firmly.
Make sure the AC adaptor is connected firmly.
Check that the iPod is compatible with this unit. (See
“Dock Connector compatible models.”)
When using the Bluetooth connection
There is no sound.
Ensure that this unit is not too far from the iPod, or this
unit is not receiving interference from a wireless LAN,
other 2.4 GHz wireless device, or microwave oven.
Check that the Bluetooth connection is made properly
between this unit and the iPod.
Pair this unit and the iPod again.
Keep away from metal objects or surfaces.
Make sure that the Bluetooth function is activated.
Sound skips or the correspondence distance is short.
If a device that generates electromagnetic radiation, such
as a wireless LAN, other Bluetooth device(s), or a
microwave oven is nearby, move away from such
sources.
Remove any obstacle between this unit and the iPod or
move away from the obstacle.
Locate this unit and the iPod as close to each other as
possible.
Re-position this unit.
Re-position the iPod.
Connecting cannot be done.
Perform pairing again. (See “To pair with an iPod.”)
Check that the iPod is compatible with this unit. (See
“Wireless music streaming compatible models.”)
Pairing cannot be done.
Bring this unit and the iPod closer together.
Delete the unit from the iPod and perform pairing again.
Check that the iPod is compatible with this unit. (See
“Wireless music streaming compatible models.”)
Radio
Reception is poor.
Extend the aerial to its full length, and orientate for best
FM reception.
The sound is weak or is of poor quality.
If the unit is close to a TV, move it away from the TV.
The TV picture is unstable.
If you are listening to an FM program near a TV with an
indoor aerial, move the unit away from the TV.
Audio-in
There is no sound.
Make sure the audio connecting cable is connected
firmly.
Make sure that the connected optional component is in
playback mode.
Make sure that the Audio-in function is activated.
The sound is low.
Check the volume of the connected optional component.
— with respect to the supply to the public of the RLAN
access to telecom networks and services, by the
Ministerial Decree 28.5.2003, as amended, and Art.
25 (general authorization for electronic communications
networks and services) of the Code of electronic
communications.
On Copyrights and Licenses
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license. Other trademarks and trade
names are those of their respective owners.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other
countries. iPad is a trademark of Apple Inc.
“Made for iPod,” “Made for iPhone,” and “Made for iPad”
mean that an electronic accessory has been designed to
connect specifically to iPod, iPhone, or iPad, respectively, and
has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and
regulatory standards. Please note that the use of this accessory
with iPod, iPhone, or iPad may affect wireless performance.
Use of this radio equipment is not allowed in the
geographical area within a radius 20km from the centre of
Ny-Alesund, Svalbard in Norway.
Precautions
To disconnect AC power, grasp the plug itself, not the
cord.
Since a strong magnet is used for the speaker, keep credit
cards using magnetic coding or spring-wound watches,
CRT-based TVs, or projectors, etc., away from the unit
to prevent possible damage from the magnet.
Do not leave the unit in a location near a heat source
such as a radiator or airduct, or in a place subject to
direct sunlight, excessive dust, mechanical vibration, or
shock.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on a surface (a rug, a
blanket, etc.) or near materials (a curtain) which might
block the ventilation holes.
Should any solid object or liquid fall into the unit,
unplug the unit and have it checked by qualified
personnel before operating it any further.
During a thunderstorm, do not touch the antenna
(aerial) and plug.
Do not touch the unit with wet hands.
Do not place the unit anywhere near water.
NOTES ON LITHIUM BATTERY
Wipe the battery with a dry cloth to assure a good
contact.
Be sure to observe the correct polarity when installing
the battery.
Do not hold the battery with metallic tweezers,
otherwise a short-circuit may occur.
Disposal of Old Electrical & Electronic
Equipment (Applicable in the European
Union and other European countries with
separate collection systems)
This symbol on the product or on its packaging indicates
that this product shall not be treated as household waste.
Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative
consequences for the environment and human health,
which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed
information about recycling of this product, please contact
your local Civic Office, your household waste disposal
service or the shop where you purchased the product.
Applicable accessory: Remote control.
Disposal of waste batteries (applicable
in the European Union and other
European countries with separate
collection systems)
This symbol on the battery or on the packaging indicates
that the battery provided with this product shall not be
treated as household waste.
On certain batteries this symbol might be used in
combination with a chemical symbol. The chemical
symbols for mercury (Hg) or lead (Pb) are added if the
battery contains more than 0.0005% mercury or 0.004%
lead.
By ensuring these batteries are disposed of correctly, you
will help prevent potentially negative consequences for the
environment and human health which could otherwise be
caused by inappropriate waste handling of the battery. The
recycling of the materials will help to conserve natural
resources.
In case of products that for safety, performance or data
integrity reasons require a permanent connection with an
incorporated battery, this battery should be replaced by
qualified service staff only.
To ensure that the battery will be treated properly, hand
over the product at end-of-life to the applicable collection
point for the recycling of electrical and electronic
equipment.
For all other batteries, please view the section on how to
remove the battery from the product safely. Hand the
battery over to the applicable collection point for the
recycling of waste batteries.
For more detailed information about recycling of this
product or battery, please contact your local Civic Office,
your household waste disposal service or the shop where
you purchased the product.
On Bluetooth communication
Bluetooth wireless technology operates within a range of
about 10 meters.
Maximum communication range may vary depending
on obstacles (human body, metal, wall, etc.) or
electromagnetic environment.
Steel cabinet
Limited performance
Optimal performance
The unit
The following conditions may affect the sensitivity of
Bluetooth communication.
— There is an obstacle such as a person, metal, or wall
between this unit and iPod.
— A device using 2.4 GHz frequency, such as a wireless
LAN device, cordless telephone, or microwave oven,
is in use near the unit.
— The unit is installed on a shelf made of steel.
Because Bluetooth devices and wireless LAN
(IEEE802.11b/g/n) use the same frequency, microwave
interference may occur and resulting in communication
speed deterioration, noise, or invalid connection if this
unit is used near a wireless LAN device. In such a case,
perform the following.
— Use this unit at least 10 m away from any wireless
LAN device.
— If this unit is used within 10 m of a wireless LAN
device, turn off the wireless LAN device.
— Install this unit and iPod as near to each other as
possible.
Microwaves emitting from a Bluetooth device may affect
the operation of electronic medical devices. Turn off this
unit and iPod in the following locations, as it may cause
an accident.
— where inflammable gas is present, in a hospital, train,
airplane, or a petrol station
— near automatic doors or a fire alarm
This unit supports security capabilities that comply with
the Bluetooth standard to provide a secure connection
when the Bluetooth wireless technology is used, but
security may be insufficient, depending on the setting.
Be careful when communicating using Bluetooth
wireless technology.
We do not take any responsibility for leakage of
information during Bluetooth communication.
Connection with all Bluetooth devices cannot be
guaranteed.
— A device featuring Bluetooth function is required to
conform to the Bluetooth standard specified by
Bluetooth SIG, Inc. and be authenticated.
— Even if the connected device conforms to the above
mentioned Bluetooth standard, some devices may not
be connected or work correctly, depending on the
features or specifications of the device.
Depending on the device to be connected, it may require
some time to start communication.
Remote control
The remote does not function.
The unit cannot be turned on with the remote when the
AC adaptor is disconnected. In this case, press on
the unit to turn it on.
Replace the battery in the remote with a new one if it is
weak.
Make sure that you are pointing the remote at the remote
sensor on the unit.
Do not cover or place any objects directly in front of the
(Remote sensor) receiver.
Remove any obstacles in the path of the remote and the
unit.
Make sure the remote sensor is not exposed to strong
light such as direct sunlight or fluorescent lamp light.
If the problem persists, consult your nearest Sony dealer.
Preparations
Power source
Auto power off
After playback of the music (from an iPod on the Dock,
Bluetooth connection, or optional component connected
to the AUDIO IN jack) has finished, and if no operation is
performed for about 20 minutes, the unit will
automatically turn off.
Notes
While the unit is turned on, if no operation is performed
for more than about 30 seconds, the display turns off. In
this case, press SOUND to turn on the display again.
The unit cannot be turned on with the remote when the
AC adaptor is disconnected.
To use the AC adaptor
1Connect the supplied AC power cord to the AC
adaptor.
2Connect the AC adaptor to the DC IN 20V jack
on the back of this unit firmly and plug it into a
wall outlet.
Note on the AC adaptor
Use the supplied Sony AC adaptor only. The polarity of
the plugs of other manufacturers may be different.
Failure to use the supplied AC adaptor may cause the
unit to malfunction.
3Confirm that charging has started.
When charging starts, the battery indicator appears.
While charging, the charging indicator animation
loops.
When the unit is turned off
When charging completes, the full battery indicator
appears for a while, and then disappears.
Notes
If you connect the AC adaptor when the battery is fully
charged, the full battery indicator appears for a while,
and then disappears.
If you connect the AC adaptor when the battery power is
low, charging starts and the low battery and charging
indicator animation loops.
The unit cannot be operated without the AC adaptor while
the low battery indicator appears.
When the unit is turned on
When charging completes, the full battery indicator
appears.
Note
It will take approximately 6 hours to fully charge the
battery.
To use the rechargeable battery
You can operate the unit with the rechargeable battery
instead of the AC adaptor.
Note
The maximum output volume will be lower when the
AC adaptor is disconnected.
To check the remaining power of the battery
The remaining power of the battery will be indicated when
the unit is turned on. As the remaining battery power
depletes, the battery indicator decreases.
Level 1 Level 2 Level 3 Level 4
When the battery becomes almost fully depleted, “LOW
BATT” flashes and the unit will turn off. To charge the
battery, connect the AC adaptor. (See “To use the AC
adaptor.”)
Notes
The remaining battery power will not be indicated when
the unit is turned off.
The unit requires at least 30 minutes to charge the
battery if “LOW BATT” appears.
The battery indicator shows approximate remaining
battery power.
Operating conditions will affect the rate of battery
depletion.
When to replace the rechargeable battery
Repeated recharging causes the duration of the battery
power to decrease over time. Replace the battery pack
when its duration becomes half the usual period, even after
charging it fully.
Note
The rechargeable battery pack is not a commercially
available product. To purchase rechargeable battery pack
(NH-300RDP), consult your nearest Sony dealer.
To replace the rechargeable
battery
1Remove the screw of the battery compartment at
the bottom of the unit, and open the lid.
2Disconnect the connector of the battery pack and
pull it out.
3Insert a new battery pack and connect its
connector to the jack.
4Replace the battery compartment lid and tighten
the screw.
Notes
When replacing the battery pack, place a soft cloth etc.,
under the unit.
Turn off the unit and disconnect the AC adaptor before
removing the old battery pack.
Charge a new battery pack before use. For details, see
“To use the AC adaptor.”
Remote control
Before using the supplied remote for the first time, remove
the insulation film.
Aim the remote at the (Remote sensor) of the unit.
When to replace the battery
With normal use, the battery (CR2025) should last for
about 6 months. When the remote can no longer operate
the unit, replace the battery with a new one.
side facing up
Note
If you are not going to use the remote for a long time,
remove the battery to avoid any damage that may be caused
by leakage or corrosion.
Continued on the reverse side
