Sony DAV-LF1 User manual

Platinum DVD Dream® System
• Wireless Front To Rear- DIAT Digital Infrared Audio Transmission
• 600 Total System Power- 86 x 5(F,C,R) + 170 x 1 Subwoofer
• DVD/SACD/CD Player with Progressive Scan Output
• Dolby® Digital, dts®, and Dolby® Pro Logic® II Decoding
• Front/Rear Flat Panel matching Floor Standing Speakers (Optional Wall mounts sold seperately)
• CD-R/RW, Super Audio CD (Multi), MP3 Playback*
• S-Master™ Full Digital Amplifier
• Digital Direct Drive Subwoofer (Dual 85Watt Amps)
• Touch Panel Control
DIAT Wireless Audio System Advantage - Wireless transmission of Audio signals from the front of a room to the rear of a room.
Benefit - No more wires running from your receiver across your living room floor to the back of the room.
Demonstration - Stand in front of the rear speakers and point out the lack of wires running from the rear speakers to the receiver and then
Play a SA-CD or a 5.1 DVD. The DIAT (Digital Infrared Audio Transmission) system was developed by Sony to transmit the audio signals of
the most advanced high-bandwidth media (such as DVD, HDTV, and SA-CD) using infrared light. Unlike conventional wireless
transmission systems biased on radio frequencies, DIAT's signals are not pre-compressed, and the original signal integrity is maintained
without distortion, even in the presence of noise and radio interference. Wireless never sounded this good.
S-Master Full digital Amplifier Advantage - Sony's revolutionary S-Master full digital amplifiers are ushering in a new era of high
performance amplifiers with authentic reproduction of sound anywhere!
Benefit - Unlike conventional analogue amplifier designs, the S-Master processes 1-Bit audio signals (similar to that of Super Audio CD)
entirely through digital circuitry, the S-Master preserves the purity of that signal from source right up to output. This simplifies the signal
path, minimizes distortion and reduces the generation of heat. Other than allowing the digital amplifier to be made smaller and sleeker, this
enables the S-Master to reproduce music of the utmost fidelity to the original source. Pristine, clear and sparkling.
DAV-LF1

Platinum DVD Dream® System
For more information:
http://www.sony.com
DAV-LF1
Features
Audio
• Bass Enhancement Function
• Digital Cinema Sound™ System
• Total Power Output 600W Front
Speaker: 86W x 2; Center Speaker:
86W x 1; Rear Speaker: 86W x 2;
Subwoofer: 170W x 1 (Dual 85W
Amps)
• CD/SACD Text
• Play Modes (Shuffle, Program,
Repeat)
General
• Single Disc DVD/SACD/CD
Changer with Progressive Scan
Output
• CD-R/RW, Super Audio CD (Multi),
MP3 Playback*
• JPEG Playback with Slide Show
• Dolby® Digital, dts®, and Dolby®
Pro Logic® II Decoding
• S-Master™; Full Digital Amplifier
• 6 Speaker System, Front/Rear
Floor Standing Speakers, Center
Channel and Active Powered
Subwoofer
• Front and Rear Floor Standing
Speakers
• Tuner with 20 FM + 10 AM Station
Presets
• Progressive Scan Output (480P)
• Input Function DVD, (SACD, CD,
Video, Sat, Tuner AM/FM)
Inputs and Outputs
• Component Video and S-Video
Outputs
• Digital Input for Satellite TV, etc.
• 2 Analog A/V Inputs, 1 Analog A/V
Output
• Headphone Jack 3.5mm Mini Pin
• Digital Audio Input x 1
• Video Signal Inputs x 2
• Video Signal Outputs x 4 (2
Composite,1 Component,1
S-Video Output)
Convenience
• Color Coded Speaker Connections
With color coded connections, a
user simply has to match green
with green, etc. to finish
connecting a full 5.1 channel
surround system.
• Pre-Programmed Luminous A/V
Remote Commander® Remote
Control
• On Screen Display (OSD)
• Power Save Mode
FAB
• DIAT Wireless Audio System
• S-Master Full digital Amplifier
• MP3 Graphic User Interface
• JPEG Picture Playback
• Dolby® Pro Logic® II
Key Technologies
• Color Coded Speaker Connections
• Digital Input
• Progressive Scan
Specifications
DVD/CD/SACD Changer
• Video DA Converter 10 bit
• Audio DA Converter 1 bit
Tuner
• FM Tuning Range 87.5 - 108 MHz
• AM Tuning Range 530 - 1710 kHz
Front/Rear Speaker
• Tweeter Unit Dimension Approx.
1" (2.5cm)
• Woofer Unit Dimension Approx. 3
15/16" (10cm)
• Speaker System 2 way type
Center Speaker
• Tweeter Unit Dimension Approx.
1" (2.5cm)
• Woofer Unit Dimension Approx. 3
15/16" (10cm)
• Speaker System 2 way type
Subwoofer
• Woofer Unit Dimension Approx. 7
1/12" (18cm)
Weights and Measurements
• Front/Rear Dimensions Approx. 5
10/11" x 27 9/16" x 1" (150x 70x
50.5mm) Without Speaker Stands
• Front/Rear Weights Approx. 12lbs.
13 oz. (5.8kg) Without Speaker
Stands
• Center Dimensions 18 1/2" x 5
10/11" x 1" (470 x 150 x
50.5mm)Without Speaker Stand
• Center Weights Approx. 5.5 lbs.
(2.5kg)
• Subwoofer Dimensions Approx. 9
1/2" x 23 6/7" x 9 1/2"
(241x606x241mm)
• Subwoofer Weight Approx. 30 lbs.
14 oz.(9.5 kg)
Supplied Accessories
• Instruction Manual
• Remote Commander® Remote
Control RM-SP320
• Color Coded Speaker Cable
Optional Accessories
• WS-DAVLFM (Wall mount to hang
the main unit of the DAV-LF1 on
the wall.)
• WS-DAVLFS (Wall mount to hang 1
DAV-LF1 Speaker on the wall.)
Weights & Measures
• Approx. 10 lbs 6oz (4.7Kg) Plus
Speakers
• Approx 22 4/11" x 7 7/8" x 4 8/11"
(568 x 200 x 120mm) plus
speakers
UPC Codes
• 0272426516850
©2004 Sony Electronics Inc. All rights reserved.
Features and specifications are subject to
change without notice. All trademarks
referenced herein are trademarks of Sony or
their respective owners. *CD-R/RW playback
may not be compatible with all discs,
depending on recording conditions.
Sony Electronics Inc.
16765 West Bernardo Drive
San Diego, CA 92127
