Sony POP-FMPA1 User manual

Operation Instructions
Sony 4K Content Generator
POP-FMPA1

2
WARNING
To reduce the risk of fire or electric
shock, do not expose this appliance
to dripping or splashing, and do not
place objects
filled with liquids, such as vases, on
the appliance.
To reduce the risk of fire, do not cover
the ventilation opening of the
appliance with newspapers,
tablecloths, curtains, etc.
Do not expose the appliance to naked
flame sources (for example, lighted
candles).
To avoid electric shock, do not open
the cabinet. Refer servicing to
qualified personnel only.
Do not expose batteries or appliances
with battery installed to excessive
heat, such as sunshine and fire.
Notice for customers in the United
Kingdom and Republic of Ireland
A molded plug complying with
BS1363 is fitted to this equipment for
your safety and convenience.
Should the fuse in the plug supplied
need to be replaced, a fuse of the
same rating as the supplied one and
approved by A or BSI to BS1362,
(i.e., marked with or mark)
must be used.
If the plug supplied with this
equipment has a detachable fuse
cover, be sure to attach the fuse
cover after you change the fuse.
Never use the plug without the fuse
cover. If you should lose the fuse
cover, please contact your nearest
Sony service station.
Notice for the customers in Europe

3
Disposal of Old Electrical &
Electronic
Equipment (Applicable in the
European Union and other
European countries with separate
collection systems)
This symbol on the product or on its
packaging indicates that this product
shall not be treated as household
waste. Instead it shall be handed over
to the applicable collection point for
the recycling of electrical and
electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential
negative consequences for the
environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. The recycling of materials
will help to conserve natural
resources. For more detailed
information about recycling of this
product, please contact your local
Civic Office, your household waste
disposal service or the shop where
you purchased the product.
Installing
• Do not install this player in a
confined space, such as a bookshelf
or similar unit.
Notice for customers:
The following information is only
applicable to equipment sold in
countries applying EU directives.
The manufacturer of this product is
Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japan.
The Authorized Representative for
EMC and product safety is Sony
Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart,
Germany. For any service or
guarantee matters please refer to the
addresses given in separate service
or guarantee documents.
Precautions
• The player is not disconnected from
the AC power source (mains) as
long as it is connected to the wall
outlet, even if the player itself has
been turned off.
• Install this unit so that the AC power
cord (mains lead) can be unplugged
from the wall socket immediately in
the event of trouble.
Notice for the customers in Europe

4
Bulgarian Производител: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075
Япония
За съответствие на продукти от EC: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Германия
Czech Výrobce: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japonsko
Pro technické požadavky dle směrnic EU: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, SRN
Danish Producent: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
Overensstemmelse med EU lovgivning: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Tyskland
Dutch Producent: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
Voor EU-product conformiteit: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Duitsland
English Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
For EU product compliance: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Germany
Estonian Tootja: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Jaapanis
EL toote vastavus: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Saksamaal
Finnish Valmistaja: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075, Japani
EU vaatimusten mukaisuus: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Saksa
French Fabricant: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japon
Pour toute question relative à la conformité des produits dans l’UE: Sony
Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Allemagne
German Hersteller: Sony Corporation, 1-7-1 Konan Minato-ku Tokio, 108-0075 Japan
Für EU Produktkonformität: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Deutschland
Greek Κατασκευαστής: Sony Corporation, 1-7-1 Konan Minato-ku Τόκυο , 108-0075
Ιαπωνία
Συμμόρφωση Προϊόντος με νομοθεσία Ε.Ε.: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Γερμανία
Hungarian Gyártó: Sony Corporation, 1-7-1 Konan Minato-ku Tokió, 108-0075 Japán
Európai uniós termékbiztonság: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Németország
Notice for the customers in Europe

5
Italian Produttore: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Giappone
Per la conformità del prodotto in ambito UE: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Germania
Latvian Ražotājs: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japānā
Par ES produktu atbilstību: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Vācijā
Lithuanian Gamintojas: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japonija
Dėl ES gaminių atitikties: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Vokietija
Norwegian Produsent: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
EU produkt samsvar: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Tyskland
Polish Producent: Sony Corporation, 1-7-1 Konan Minato-ku Tokio, 108-0075 Japonia
Informacje o zgodności produktu z wymaganiami UE: Sony Deutschland GmbH,
Hedelfinger Strasse 61, 70327 Stuttgart, Niemcy
Portuguese Fabricante: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japão
Para a conformidade dos produtos na EU: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Alemanha
Romanian Producător: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japonia
Pentru conformitatea UE a aparatului: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Germania
Slovak Výrobca: Sony Corporation, 1-7-1 Konan Minato-ku, Tokyo, 108-0075 Japonsko
Zhoda podľa legislatívy EU: Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Nemecko
Slovenian Proizvajalec: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japonska
Skladnost izdelkov za EU: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Nemčija
Spanish Fabricante: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japón
Para la conformidad del producto en la UE: Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Alemania
Swedish Tillverkare: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
För EU:s produktöverensstämmelse: Sony Deutschland GmbH, Hedelfinger Strasse
61, 70327 Stuttgart, Tyskland
Notice for the customers in Europe

6
Precautions
On placement
• Place the player in a location with
adequate ventilation to prevent heat
build-up in the player.
• Do not place the player on a soft
surface such as a rug that might
block the ventilation holes.
• Do not place the player in a location
near heat sources, or in a place
subject to direct sunlight, excessive
dust, or mechanical shock.
• Do not place the player outdoors, in
vehicles, on ships, or on other
vessels.
• If the player is brought directly from
a cold to a warm location, or is
placed in a very damp room,
moisture may form on the outer
surface and on interior of the player.
Should this occur, the player may
not operate properly. In this case,
leave the player turned on for about
half an hour until the moisture
evaporates.
• Do not install the player in an
inclined position. It is designed to be
operated in a horizontal position
only.
On power sources
• Disconnect the player from the wall
outlet if you are not going to use the
player for a long time. To disconnect
the AC power cord, grasp the plug
itself; never pull the cord.
• Observe following points to prevent
the AC power cord being damaged.
Do not use the AC power cord if it is
damaged, as doing so may result in
an electric shock or fire.
– Do not pinch the AC power cord
between the player and wall, shelf,
etc.
– Do not put anything heavy on the
AC power cord or pull on the AC
power cord itself.
On AC adaptor
• Use the supplied AC adaptor for this
player, as other adaptors may cause
a malfunction.
• Do not disassemble or reverse-
engineer.
• Do not confine the AC adaptor in a
closed place such as a bookshelf or
an AV cabinet.
• Do not connect the AC adaptor to a
traveler’s electric transformer, which
may generate heat and cause a
malfunction.
• Do not drop or apply shock.
On replacement of parts
In the events that this player is
repaired, repaired parts may be
collected for reuse or recycling
purposes.

7
On cleaning
Clean the cabinet, panel, and controls
with a soft cloth. Do not use any type
of abrasive pad, scouring powder or
solvent such as alcohol or benzine.
On connecting to the "AUIDIO
VIDEO OUT" jack.
Observe the following as improper
handling may damage the jack and
the connector.
• Carefully align the jack on the rear
of the player and the connector by
checking their shapes. Make sure
the connector is not upside down or
tilted.
• Hold the connector straight when
connecting or disconnecting the
HDMI cable. Do not twist or force
the connector into the jack.
• Be sure to disconnect the HDMI
cable when moving the player.
On adjusting volume
Do not turn up the volume while
listening to a section with very low
level inputs or no audio signals. If
you do, your ears and the
speakers may be damaged when
a peak level section is played.
IMPORTANT NOTICE
Caution: This player is capable of
holding a still video image or on-
screen display image on your
television screen indefinitely. If you
leave the still video image or on-
screen display image displayed on
your TV for an extended period of
time, you risk permanent damage to
your television screen.
Plasma display panel televisions and
projection televisions are susceptible
to this.

8
1.Installation
In-store installation of the 4K Content Generator
1. Do not leave the remote controller at the shop front. Use it only when
necessary.
2. Use Antitheft slot to prevent the 4K Content Generator from being stolen.
Important technical knowledge and Sonyʼs original content is inside the 4K
Content Generator.
3. Ensure adequate ventilation for heat from the player. Do not install the
player in a fully sealed cabinet.
4. Leave at 10cm of open space in front of the player and behind it, for air
intake and exhaust. In addition, the ideal from of the rear cabinet is
unclosed.
5. Maintain an optimal distance between the player and the power outlet and
TV.
6. When using the remote controller, operate in adequate distance with no
obstacles in between. The remote controller emits IR signal.
7. If you need to hide the 4K Content Generator behind the wall or in a box,
use the IR Extender supplied with the 4K Content Generator.
8. Do not placed upside down or sideways.
Intake
exhaust
Antitheft slot

9
1.Installation
HDMI Terminal
HDMI cable
Sony 4K TV
4K
Content
Generator
front
rear
EXT IR
IR
Extender
(Supplied)
Option:
When locating the 4K Content
Generator apart from the 4K
TV, use the IR Extender.
Remote
(Supplied)
for 4K AUDIO
VIDEO OUT 1
Note:
Connect to “for AUDIO VIDEO OUT 1” in case of
single TV connection. If connecting a single TV to
other terminal than “ for AUDIO VIDEO OUT 1”, no
signal will output to the TV.
Basic setting：Connecting to a single 4K TV
Remote
(Supplied)

10
1.Installation
HDMI Terminal
HDMI cable
Sony 4K TV
4K
Content
Generator
Advanced setting：Connecting to multiple 4K TVs
for 4K AUDIO VIDEO OUT 1
Notes:
- Up to three 4K TVs can be connected to one 4K Content Generator. Same
signals from “for Audio VIDEO OUT 1” will output to the other terminal(s).
- If you want to connect two 4K TVs, connect them to “for AUDIO VIDEO
OUT 1” and “ for AUDIO VIDEO OUT 2”. If you connect to “for AUDIO
VIDEO OUT 2” and “for AUDIO VIDEO 3”, no signals will output to the TVs.
for 4K AUDIO VIDEO OUT 2
for 4K AUDIO VIDEO OUT 3
Sony 4K TV
Sony 4K TV
HDMI cable
HDMI cable
HDMI Terminal
HDMI Terminal
Mandatory
