Sony Bravia KDL-19M4000 User manual

LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL RX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-775-07
KDL-19M4000 RM-YD025 US
KDL-19M4000 RM-YD025W US
KDL-19M4000 RM-YD025 CANADA
KDL-19M4000 RM-YD025W CANADA
KDL-19M4000 RM-YD025 MEXICO
KDL-19M4000 RM-YD025W MEXICO
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 3/2008
☛
:UPDATED ITEM
REVISION DATE SUBJECT
3/2008 No revisions or updates are applicable at this time.
4/2008 Reissue entire manual to include PWBs for G Board (Power Supply)
Added Line Art illustration for Wire Dressing
Added PNs for Colored Bezels to Exploded View section.
5/2008 Corrected instructions for 2-1. Resetting to Factory Defaults After Board Replacement.
Replaced page 17.
5/2008 Corrected PNs for White and Black Front Bezel Assemblies. Replaced page 43.
10/2008 Removed Self Diagnosis logo from Front Cover and Self Diagnostic Function page.
Replaced pages 2 and 10.
12/2008 Corrected H2 Board and H3 Board information. Replaced pages 13, 15, 16, 18, 21, & 38-39.
8/2009 Corrected H2 Board and H3 Board information. Replaced pages 3, 13, 15, 16, 18, 21, 38, 39, & 43.

LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL RX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-775-07
KDL-19M4000 RM-YD025 US
KDL-19M4000 RM-YD025W US
KDL-19M4000 RM-YD025 CANADA
KDL-19M4000 RM-YD025W CANADA
KDL-19M4000 RM-YD025 MEXICO
KDL-19M4000 RM-YD025W MEXICO
KDL-19M4000 RM-YD025

3
KDL-19M4000
KDL-19M4000
TABLE OF CONTENTS
Specifications ................................................................................. 4
Warnings and Cautions .................................................................. 6
Safety-Related Component Warning .............................................. 7
Safety Check-Out ........................................................................... 9
Self-Diagnostic Function............................................................... 10
SECTION 1: DISASSEMBLY................................................................11
1-1. Stand Removal......................................................................11
1-2. Handle Removal....................................................................11
1-3. Rear Cover Removal............................................................ 12
1-4. Function Key Removal ......................................................... 12
1-5. H3 Board Removal............................................................... 13
1-6. A Board and G Board Removal............................................ 13
1-7. Hinge Removal..................................................................... 14
1-8. LCD Panel and Main Bracket Removal................................ 14
1-9. Speakers Removal............................................................... 15
1-10.H2 Board and LED Lens Removal ....................................... 15
Wire Dressing ............................................................................... 16
Overall View ......................................................................... 16
SECTION 2: SERVICE ADJUSTMENTS............................................. 17
2-1. Resetting to Factory Defaults after Board Replacement...... 17
SECTION 3: DIAGRAMS..................................................................... 18
3-1. Circuit Boards Location ........................................................ 18
3-2. Printed Wiring Boards
and Schematic Diagrams Information .................................. 18
3-3. Block Diagram...................................................................... 20
3-4. Connector Diagram .............................................................. 21
3-5. Schematics and Supporting Information .............................. 22
A Board Schematic Diagram (1 of 15).................................. 22
A Board Schematic Diagram (2 of 15).................................. 23
A Board Schematic Diagram (3 of 15).................................. 24
A Board Schematic Diagram (4 of 15).................................. 25
A Board Schematic Diagram (5 of 15).................................. 26
A Board Schematic Diagram (6 of 15).................................. 27
A Board Schematic Diagram (7 of 15).................................. 28
A Board Schematic Diagram (8 of 15).................................. 29
A Board Schematic Diagram (9 of 15).................................. 30
A Board Schematic Diagram (10 of 15)................................ 31
A Board Schematic Diagram (11 of 15)................................ 32
A Board Schematic Diagram (12 of 15)................................ 33
A Board Schematic Diagram (13 of 15)................................ 34
A Board Schematic Diagram (14 of 15)................................ 35
A Board Schematic Diagram (15 of 15)................................ 36
H1 Board Schematic Diagram.............................................. 37
H2 Board Schematic Diagram.............................................. 38
H3 Board Schematic Diagram.............................................. 39
G Board Schematic Diagram ............................................... 40
SECTION 4: EXPLODED VIEWS........................................................ 42
4-1. Rear Cover Assembly and Stand Assembly ........................ 42
4-2. Chassis ................................................................................ 43
APPENDIX A: ENCRYPTION KEY COMPONENTS..........................A-1
SECTION TITLE PAGE SECTION TITLE PAGE
☛
☛

4
KDL-19M4000
KDL-19M4000
SPECIFICATIONS
Design and specifications are subject to change without notice.
120V - 240V AC, 50/60Hz
VIDEO (IN) 1/2
S Video (4-Pin Mini DIN) (Video 2 only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Video
1.0 Vp-p, 75 ohms unbalanced, sync negative
Audio
500 mVrms (100% modulation)
Impedance:47 kilohms
COMPONENT IN:
YPBPR(Component Video)
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative
P
B:0.7 Vp-p, 75 ohms
P
R:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p
Audio
500 mVrms (100% modulation)
Impedance: 47 kilohms
Power Requirements HDMI IN:
HDMI
Video: 480i, 480p, 720p, 1080i
Audio: Two channel linear PCM 32, 44.1
and 48 kHz, 16 bits
Audio
500 mVrms (100% modulation)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (100% modulation)
PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
PC AUDIO IN:
Stereo mini jack, 500mVrms, 47 kilohms
HEADPHONES:
Stereo mini jack
Impedance: 16 ohms
Trademark Information
Macintosh is a trademark of Apple Inc., registered in the U.S. and other
countries.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.
Blu-ray Disc is a trademark.
“BRAVIA”, and are trademarks of Sony Corporation.

5
KDL-19M4000
KDL-19M4000
Television system
NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC Compliant 8VSB
QAM on cable ANSI/SCTE 07 2000
Channel coverage
Analog Digital
Terrestrial 2-69 2-69
Cable 1-135 1-135
Antenna
75-ohm external terminal for VHF/UHF
Panel System
LCD (Liquid Crystal Display) Panel
Display Resolution (horizontal x vertical):
1440 dots x 900 lines
Screen Size (measured diagonally)
approx. 19 inches
Supplied Accessories
Remote Commander RM-YD025 or RM-YD025W
Size AA Batteries (2)
AC Power Cord
Cable Band
Operating Instructions
Quick Setup Guide
Warranty Card
Online Registration Card (USA only)
Optional Accessories
Headphones Plug Adapter
Connecting Cables
Wall-Mount Bracket
SU-WL100
KDL-19M4000
in use 53W
in standby Less than 1.0 W
3W + 3W
mm 40 x 100 mm
in 15/8 x 4 in
with stand and handle
mm 485 x 165 x 400 mm
in 191/8 x 61/2 x 153/4 in
without stand and handle
mm 485 x 85 x 401 mm
in 191/8 x 33/8 x 157/8 in
Mass
with stand and handle
kg 7.8 kg
lbs 17 lbs 2 oz
without stand and handle
kg 6.9 kg
lbs 15 lbs 2 oz
Dimensions (W x H x D)
Power Consumption
Speaker Output (W)
Dimensions (W x H x D)
All measurements are approximations.

6
KDL-19M4000
KDL-19M4000
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.
CARRYING THE TV
Carry the TV in the specified manner
To avoid dropping the TV and causing serious injury, be sure to follow
these guidelines:
Before carrying the TV, disconnect all cables.
When you carry the TV without handle, place your hand as
illustrated and hold it securely. Do not put stress on the LCD panel.
When carrying the TV, do not subject it to shocks or vibration,
or excessive force.
Without handle
With handle
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the ac power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace
these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that
are critical for safe operation are identified in this manual. Follow these procedures whenever critical components are replaced or improper operation is
suspected.
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifié seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifié faire ainsi.
POUR TRANSPORTER LE TÉLÉVISEUR
Avec poignee de transport
Transport du téléviseur de la manière précisée
Assurez-vous de suivre ces consignes pour éviter de laisser tomber le
téléviseur et de provoquer des blessures graves :
Débranchez tous les câbles avant de transporter le
téléviseur.
Transportez le téléviseur en plaçant les mains tel
qu’illustré et le tenir solidement. N’appliquez pas de
pression sur l’écran ACL.
Lorsque vous transportez le téléviseur, ne le soumettez
pas à des chocs ou vibrations, ni à une force excessive.
Sans poignee de transport
Afin d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le
chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
!ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une
importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le
present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement
sont identifies dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants critiques, ou lorsqu’un mauvais
fonctionnement suspecte.

7
KDL-19M4000
KDL-19M4000
SAFETY-RELATED COMPONENT WARNING
There are critical components used in LCD color TVs that are important for safety. These components are identified with shading and
!
mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number
specified in the electrical parts list to prevent electric shock, fire, or other hazard.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
 do not press on the panel or frame edge to avoid the risk of electric shock.
do not scratch or press on the panel with any sharp objects.
do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
do not expose the LCD panel to direct sunlight.
avoid contact with water. It may cause a short circuit within the module.
disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
always clean the LCD panel with a soft cloth material.
use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT

8
KDL-19M4000
KDL-19M4000
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
example 1
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.
For more information on the use of Lead Free Solder, please refer to
http://www.sony-training.com
rebmuntraP retemaiD skrameR
91-500-046-7mm3.0gK52.0
02-500-046-7mm4.0gK05.0
12-500-046-7mm5.0gK05.0
22-500-046-7mm6.0gK52.0
32-500-046-7mm8.0gK00.1
42-500-046-7mm0.1gK00.1
52-500-046-7mm2.1gK00.1
62-500-046-7mm6.1gK00.1

9
KDL-19M4000
KDL-19M4000
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 μF
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

10
KDL-19M4000
KDL-19M4000
SELF-DIAGNOSTIC FUNCTION
IMPORTANT:
The unit in this manual DOES NOT contain a self-diagnostic function. If an error occurs, the TV will not stay on. It is our recommendation that if a
repair is required for this set, the technician should bring both the A Board and the G Board to the customer location.
Control Buttons
TIMER STANDBY POWER
Description of LED Indictors
The unit in this manual DOES NOT contain a self-diagnostic function.

11
KDL-19M4000
KDL-19M4000
SECTION 1: DISASSEMBLY
1-1. STAND REMOVAL
1-2. HANDLE
REMOVAL
1Remove 4 screws Handle and Rear Cover, +PSW M4X12
Stand Assembly
2
1
3
1
Rear Cover
Handle
1Place the TV set face down onto the soft cloth
2Remove 2 screws, +PSW M4X16
3Hold both sides of the stand firmly, and pull out the stand from hinge housing

12
KDL-19M4000
KDL-19M4000
1-3. REAR COVER REMOVAL
1-4. FUNCTION KEY REMOVAL
1Remove 6 screws, +BVTP 4X25
2Remove 3 screws from Terminal positions, +BVTP 3X10
3Remove 2 screws from both sides of Hinge positions, +BVTP 4X12
4Remove 3 screws from bottom of Rear Cover, +BVTP 3X10
1Remove 1 screw and release ground wire, +PSW M3X6
2Disconnect one connector from H1 Board
3Release hooks
1
2
3
4
Rear Cover
Bezel
3
2
1
Bezel
Function
Touch-Key
H1 Board
Ground Wire

13
KDL-19M4000
KDL-19M4000
1-5. H3 BOARD REMOVAL
1Remove 1 screw and release ground wire, +PSW M3X6
2Disconnect one connector from H3 Board
3Remove 2 screws, +BVTP 3X10
1-6. A BOARD AND G BOARD REMOVAL
1Remove 8 screws and release ground wire, +PSW M3X6
2Remove 4 screws from bottom of Main Shield, +FH 4X5
3Remove 1 screw, +FH 3X4
4Remove 2 screws, UNC (HEX)
5Remove 5 screws, +PSW M3X6
6Disconnect 8 connectors
7Remove 1 Nut and 1 screw (+FH3X4) from Tuner
8Disconnect 5 connectors
9Remove 6 screws, +PSW M3X6
10 Slide out AC inlet with G Board from Main Bracket
1
Ground Wire
Side Jack Bracket
H3 Board
3
2
1
2
4
3
5
67
Main Shield
A Board
Main Shield
8
9
10
G Board
☛

14
KDL-19M4000
KDL-19M4000
1-7. HINGE REMOVAL
1Remove 2 screws, +BVTP 4X21
2Remove 2 screws, +PSW M4X16
3Release Ground Wire
4Unhook Bottom and Top Hinge Covers
1-8. LCD PANEL AND MAIN BRACKET REMOVAL
1Remove 7 screws, +BVTP 3X10
2Remove 4 screws, +PSW M3X6
2
1
4
Hinge
Hinge Cover (Bottom)
Hinge Cover (Top)
3
Ground Wire
2
1
LCD Bracket
Bezel
LCD Panel

15
KDL-19M4000
KDL-19M4000
1-9. SPEAKERS REMOVAL
1Remove 6 screws from Speakers, +BVTP 3X10
1-10. H2 BOARD AND LED LENS REMOVAL
1Remove 2 screws, +BVTP 3X10
2Disconnect 1 connector
1
1
Speaker (R)
Speaker (L)
1
2
Bezel
H2 Board
LED Indicator
☛

16
KDL-19M4000
KDL-19M4000
WIRE DRESSING
OVERALL VIEW
☛
G Board A Board H3
H2

17
KDL-19M4000
KDL-19M4000
2-1. RESETTING TO FACTORY DEFAULTS AFTER BOARD REPLACEMENT
Traditional Service Mode is not available in this chassis. The only option for service technicians is to reset all of the settings to the Factory Default from
the Self Diagnostic screen.
CAUTION: Resetting the TV to the Factory Defaults will over-write all customer settings including Parental Lock setting.Before performing this reset,
contact the customer to determine what adjustments they have made.
1. Turn on the TV.
2. While holding down the button on the remote control, on the TV press and hold the MENU button until “reset” displays at the bottom left corner of
the screen.
The TV turns itself off, then turns back on again.
The Initial Setup screen displays.
3. Use the Initial Setup screen options to reset the TV to the factory settings.
RM-YD025
SECTION 2: SERVICE ADJUSTMENTS
Button
☛

18
KDL-19M4000
KDL-19M4000
SECTION 3: DIAGRAMS
3-1. CIRCUIT BOARDS LOCATION
3-2. PRINTED
WIRING BOARDS AND
SCHEMATIC DIAGRAMS INFORMATION
All capacitors are in μF unless otherwise noted. pF : μμF 50WV or
less are not indicated except for electrolytics and tantalums.
All electrolytics are in 50V unless otherwise specified.
All resistors are in ohms. kΩ=1000Ω, MΩ=1000kΩ
Indication of resistance, which does not have one for rating
electrical power, is as follows: Pitch : 5mm
Rating electrical power :
1/4 W
1/4 W in resistance, 1/10 W and 1/16 W in chip resistance.
: nonflammable resistor
: fusible resistor
: internal component
: panel designation and adjustment for repair
: earth ground
: earth-chassis
All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
Readings are taken with a color-bar signal input.
Readings are taken with a 10MΩdigital multimeter.
Voltages are DC with respect to ground unless otherwise noted.
Voltage variations may be noted due to normal production
tolerances.
All voltages are in V.
S : Measurement impossibility.
: B+line.
: B-line. (Actual measured value may be different).
: signal path. (RF)
Circled numbers are waveform references.
The components identified by shading and
!
symbol are critical for safety. Replace
only with part number specified.
The symbol indicates a fast operating fuse and is displayed on the component
side of the board. Replace only with fuse of the same rating as marked.
Les composants identifies per un trame et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une piece portant le numero specifie.
Le symbole indique une fusible a action rapide. Doit etre remplace par une
fusible de meme yaleur, comme maque.
NOTE: The components identified by a red outline and a mark contain confidential
information. Specific instructions must be adhered to whenever these components
are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
H1
H2
A
G
H3
☛

19
KDL-19M4000
KDL-19M4000
G
D
S
B1 E1
C2
B2 C1E2
2
3
4
5
6
7
8
9
10
11
12
14
16
17
18
–
1
G
D
S
B2 E2
C1
B1 C2
E1
B2 E2
C1
B1 C2E1
B2 E2
C1
B1 C2E1
19
B1 E1
E2
C1(B2)
C2
20
B1
E2
C1
C2
22
23
(B2)
E1
(B2)
E1
E2
B1
C2
C1
21
B1
E1
C2
B2
C1
E2
G
SS
D
G
D
B1
E1
C2
B2
C1
E2
B1
E2
C2C1(B2)
E2
B1
C1
C2E1(B2)
C2
B1
C1
E2E1(B2)
C2
B1
C1
E2
B2
E1
C2
Ver.1.6
Transistor
(FET)
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Discrete semiconductor
(Chip semiconductors that are not actually used are included.)
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Source
Source
Anode Anode
(NC)
(NC)
Cathode
Anode
Cathode
Common
Cathode Cathode
Common
Cathode Cathode
Common
Common
Common
Common
Cathode
Anode
Base Emitter
Collector
Base Emitter
Collector
Drain
Gate
Gate
Drain
Device Printed symbol Terminal name Circuit
Terminal name of semiconductors in silk screen
printed circuit ( )
Anode
Anode
Anode Cathode
Anode Anode
Cathode
13
Transistor
(FET)
Transistor
(FET)
15
Emitter
Collector
Base
Transistor
Source
Gate
Drain
Cathode
Anode
Anode Cathode
Anode
Anode
*
REFERENCE INFORMATION
RESISTOR
: RN METAL FILM
: RC SOLID
: FPRD NONFLAMMABLE CARBON
: FUSE NONFLAMMABLE FUSIBLE
: RW NONFLAMMABLE WIREWOUND
: RS NONFLAMMABLE METAL OXIDE
: RB NONFLAMMABLE CEMENT
: ADJUSTMENT RESISTOR
COIL
: LF-8L MICRO INDUCTOR
CAPACITOR
: TA TANTALUM
: PS STYROL
: PP POLYPROPYLENE
: PT MYLAR
: MPS METALIZED POLYESTER
: MPP METALIZED POLYPROPYLENE
: ALB BIPOLAR
: ALT HIGH TEMPERATURE
: ALR HIGH RIPPLE

20
KDL-19M4000
KDL-19M4000
3-3. BLOCK DIAGRAM
RF in
Main board
Ir
Rx
Micro
processor
Reg. ICs
Line Out
19"
(1440 x 900)
LCD Panel
LIPS
Power
Speaker
8Ohm/10W*2
Remote
Controller
YPrPb
EEPROM
512Kb
Analog Front End
Digital Video
Processor
Digital
Front End
Headphone
AC in
HDMI
PC
AV1
I2S
Control
VOL + CH +
Enter/
Input VOL- CH-
Power
Menu
EEP
ROM
TosLink
HDMI
LVDS
Demodulator
Inverter(19") )
Micro
Processor
(R8C Tiny)
IR
I/F
(DTV-C4US)
(HYB18T256x2) (S29GL064)
(Audio Switch)
NJM2750
Audio
Processor
USB
HOST
(M66596FP)
EEP
ROM
HDCP
KEY
DDR2
16x16Mb
NOR Flash
64Mbit
ADC Audio
Processor
DAC
Audio Processor
(MSP-4440K)
Power
AMP
(YDA-138)
Line
out
Driver
*DIF1
DIF2
I/O
(M24512)
NJM-4558
AV2
SPDIF
SW
(SN74CB3T3
253DBQR)
USB
CVBS
