ISSUED
A
B
C
D
E
F
G
H
I
J
K
L
23456789
10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
I
J
K
L
SCALE
(E)
(J)
UNIT
ANGLE
SHEET
6
1
2
3
4
5
TOLERANCE
FAMILY
RANK
X
X
X
X
X
X
HISTORY
X COUNT
SUFFIX
REPL. REVISION
SIGN.
DRAWN BY
PLANNED BY CHECKED BY
APPROVED BY
TENTATIVE
MODEL
PART NO.
PART NO.
MATERIAL(COLOR)
FINISH(COLOR)
ORIGINAL
MODEL
USED 0N
mm
SONY STANDARD DRAWING
TITLE/DESCRIPTION
F spec - D12
1
1
'09.4
A1
DATE
ECN-NO.
1
CONFIDENTIAL
THISDOCUMENT IS THE PROPRIETARY PRO PERTYOF SONY. ITS USE IS AUTHORIZED ONLYFOR RESPONDING TO A REQUEST FO R QUOTATION,OR FOR THE PERFORMANCE O FWORK FOR SONY. ALL QUESTIONS MUST BE REFERRED TO
ISPROHIBITED. OFFENDERS WILL BE HEL DLIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THEGRANT OF A PATENT, UTILITY MODE L OR DESIGN.COPYRIGHT RESERVED.
THELOCAL PURCHASING DEPARTMENT OF S ONY. THE REPRODUCTION, DISTRIBUTION ANDUTILIZATION OF THIS DOCUMENT AS WELLAS THE COMMUNICATION OF ITS CON TENTS TO OTHERS WITHOUT EXPRESS AUTH ORIZATION
( 135)
( 288) ( 566)
( 281)
( 88)
( 357)
( 58) ( 277)
1865
( 73 1/2 inch)
1925.6 (1926:SPEC)
( 75 7/8 inch)
2136.33 (2137:SPEC)
( 84 1/4 inch:SPEC)
1051
( 41 1/2 inch)
525.5
( 20 3/4 inch)
1510.8 (1511:SPEC)
( 59 1/2 inch:SPEC)
1206(1206:SPEC)
( 47 1/2 inch:SPEC) 566.4 (567:SPEC)
( 22 3/8 inch:SPEC)
201.9
( 8 inch)
400(400:SPEC)
( 15 3/4 :inch)
400(400:SPEC)
( 15 3/4 :inch)
200
( 7 7/8 :inch)
320 (320;SPEC)
(12 5/8 inch:SPEC)
171
( 6 3/4 :inch)
750.7 (751:SPEC)
( 29 5/8inch:SPEC)
129.3 (130:SPEC)
( 5 1/8 inch:SPEC)
579.7 (580:SPEC)
( 22 7/8 inch)
1135.5 (1136:SPEC)
( 44 3/4 inch:SPEC)
( 720)
( 348) ( 665) ( 197) ( 207)
90 (90:SPEC)
( 3 5/8 inch:SPEC)
78.7 (79:SPEC)
( 3 1/8 inch:SPEC)
1208.5 (1209:SPEC)
( 47 5/8 inch:SPEC)
SU-WL500
TABLE TOP STAND
M6x(8 to 12+T) (T:VESA PLATE THICKNESS)
or +PSW6x16 (for SONY wall mount)
Header Value (JP) Value (UC2) Value(LA1,LA6) Value (CEI) Value (AF1, AU5, HK, TW) Value (CN8)
Model Name KD-84X9000 XBR-84X900 XBR-84X900,XBR-84X905 KD-84X9005 KD-84X9000 KD-84X9000
SV No. SV-22919 SV-22909 SV-22910 etc SV-22917 SV-22916 etc SV-22915
D
I
M
E
N
S
I
O
N
TV only (WxHxD) 213.7x113.6x9.0 cm 2137x1136x90 mm / 84 1/4x44 3/4x3 5/8 inch 2137x1136x90 mm Approx. 213.7x113.6x9.0 cm Approx. 2137x1136x90 mm Approx. 2137x1136x90 mm
TV with Stand (WxHxD) 213.7x151.1(120.9)x56.7 cm 2137x1511(1209)x567 mm / 84 1/4x59 1/2(47 1/2)x22 3/8 inch 2137x1511(1209)x567 mm Approx. 213.7x151.1(120.9)x56.7 cm Approx. 2137x1511(1209)x567 mm Approx. 2137x1511(1209)x567 mm
Media Receiver (WxHxD) - - --- -
Monitor only (WxHxD) 192.6x113.6x7.9 cm 1926x1136x79 mm / 75 7/8x44 3/4x3 1/8 inch 1926x1136x79 mm Approx. 192.6x113.6x7.9 cm Approx. 1926x1136x79 mm Approx. 1926x1136x79 mm
Monitor with Stand (WxHxD) 192.6x151.1x56.7 cm 1926x1511x567 mm / 75 7/8x59 1/2x22 3/8 inch 1926x1511x567 mm Approx. 192.6x151.1x56.7 cm Approx. 1926x1511x567 mm Approx. 1926x1511x567 mm
Media Receiver with Stand (WxHxD) - - --- -
Satellite Speaker (WxHxD) - - - -- -
Stand Width 120.6 cm 1206 mm / 47 1/2inch 1206 mm Approx. 120.6 cm Approx. 1206 mm Approx. 1206 mm
VESA Hole Pitch 40.0x40.0 cm 400x400 mm / 15 3/4x15 3/4 inch 400x400 mm 40.0x40.0 cm Approx. 400x400 mm Approx. 400x400 mm
W
E
I
G
H
T
TV Only 80.0 Kg 80.0 Kg / 176.3 lb. 80.0 Kg Approx. 80.0 Kg Approx. 80.0 Kg Approx. 80.0 Kg
TV With Stand 97.9 Kg/ Table Top 95.2 kg 97.9 Kg(Table Top 95.2 kg) / 215.7 lb.(Table Top 209.7 lb.) 97.9 Kg/ Table Top 95.2 kg 97.9 Kg/ Table Top 95.2 kg Approx. 97.9 Kg/ Table Top 95.2 kg Approx. 97.9 Kg/ Table Top 95.2 kg
Media Receiver (WxHxD) - - - - - -
Monitor Only 72.7 Kg 72.7 Kg / 160.2 lb. 72.7 Kg Approx. 72.7 Kg Approx. 72.7 Kg Approx. 72.7 Kg
Monitor With Stand 90.5 Kg/ Table Top 87.8 kg 90.5 Kg(Table Top 87.8 kg) / 199.4 lb.(Table Top 193.4 lb.) 90.5 Kg/ Table Top 87.8 kg Approx. 90.5 Kg/ Table Top 87.8 kg Approx. 90.5 Kg/ Table Top 87.8 kg Approx. 90.5 Kg/ Table Top 87.8 kg
Media Receiver with Stand - - --- -
Satellite Speaker - - - -- -
Remarks
1:10
ATOM
Pro/E
0° -
-
- -
84(X9000) EXTERIOR VIEW
84(X9000) EXTERIOR VIEW
- -
LCD TV LCD TV
- -
2012.07.13 2012.07.13 - -
NEZU NEZU - -
2012.07.13
-
-
