SERVICE / TRAINING MANUAL
LCD Digital Color TV
AZ2-F Chassis
Segment: 2b-2
9-888-418-01
Version Date Subject
1.0 3/29/2011 No revisions or updates are applicable at this time.
ORIGINAL MANUAL ISSUE DATE: 3/2011
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE / TRAINING MANUAL
LCD Digital Color TV
AZ2-F Chassis
Segment: 2b-2
9-888-418-01
Self Diagnosis
Supported model
KDL-46HX820

MODEL LIST
MODEL COMMANDER DESTINATION MODEL COMMANDER DESTINATION
KDL-46HX820 RM-YD057 US/CND KDL-55HX820 RM-YD067 LA/MX
KDL-55HX820 RM-YD057 US/CND
9-888-418-01

KDL-46HX820/55HX820 i
TABLE OF CONTENTS
Section 1 - Safety and Features.................................................1
Warnings and Cautions - English...............................................1
Handling the LVDS FFC Connector ...........................................3
Special Handling Instructions When
Replacing the LCD Panel Assembly.....................................4
Warnings and Cautions - French................................................5
Safety-Related Warnings ...........................................................7
Safety Check-Out.......................................................................9
Self Diagnosis Function ...........................................................12
Overview ..................................................................................13
Features...................................................................................13
See It All in 3D........................................................................... 13
Dynamic Edge LED Backlight ................................................... 13
Sleek design.............................................................................. 13
OptiContrast™ Panel ................................................................ 13
X-Reality™ PRO Engine ........................................................... 14
Motionow ™ XR 480 ............................................................... 14
Internet Streaming & Connectivity............................................. 14
Intelligent Presence Sensor ...................................................... 14
Ambient Sensor......................................................................... 14
Navigation Made Easy .............................................................. 15
Energy Saving Switch ............................................................... 15
Faster Start-Up.......................................................................... 15
USB Photos, Videos & Music.................................................... 15
BRAVIA® Sync™ Compatible ................................................... 15
Specications ...........................................................................16
Section 2 - Software Requirements.........................................19
Overview ..................................................................................19
Software Updates for Customers.............................................19
Software Updates for Servicers ...............................................20
Software Update Responsibility ................................................ 21
Checking the Software Version ................................................. 21
Examples of Software Correctable Symptoms.......................... 21
Section 3 - Chassis Overview..................................................22
Overview ..................................................................................22
Overall Circuit Description........................................................24
Main Board...............................................................................24
Tuner ......................................................................................... 24
X-Reality Processor................................................................... 24
Audio Amplier .......................................................................... 24
Temperature Sensor.................................................................. 24
Power Supply...........................................................................25
Power Supply for Backlight System .......................................... 25
3D IR Emitter............................................................................25
Wireless LAN Card...................................................................25
Switch Unit ...............................................................................25
Camera Module........................................................................25
IR Board...................................................................................26
LCD Panel Assembly ...............................................................26
TCON Board.............................................................................. 26

KDL-46HX820/55HX820 ii
TABLE OF CONTENTS
Diagrams..................................................................................27
Block Diagrams ......................................................................... 27
Connector Diagrams ................................................................. 29
Section 4 - Troubleshooting.....................................................33
Overview ..................................................................................33
Updating the Software............................................................... 33
Triage Chart .............................................................................34
Protection Shutdown................................................................35
Standby LED Flash Count......................................................... 35
Diagnostic Code Descriptions..................................................37
Viewing the Self Check Diagnostic History ............................... 38
Section 5 - Flow Charts and Diagrams ...................................39
Overview ..................................................................................39
No Power................................................................................... 40
Standby LED Blinking................................................................ 43
No Picture.................................................................................. 44
No 3D Viewing........................................................................... 46
Section 6 - Disassembly/Part Number Information ...............47
Table-Top Stand Assembly Removal........................................47
Rear Cover and AC Cover Removal ........................................48
Switch Unit, HEM2 Board, Camera Module, and
Wireless LAN Card Removal..............................................49
BATL (Main) Board and G5/G6/G7
(Power Supply) Board Removal .........................................50
Center Cabinet, HLT2 Board and LCD Panel Removal ...........51
Cleaning the LCD Panel............................................................ 51
Screws .....................................................................................52
Connectors...............................................................................53
KDL-46HX820 Only................................................................... 53
KDL-55HX820 Only................................................................... 53
Accessories and Packaging.....................................................54
Miscellaneous ..........................................................................54
Remote Commander................................................................54
Wire Dressing...........................................................................55
KDL-46HX820 Only................................................................... 55
KDL-55HX820 Only................................................................... 55
Section 7 - Service Adjustments .............................................56
Overview ..................................................................................56
Updating the Software..............................................................56
Accessing Service Adjustment Mode .......................................56
Viewing or Changing Service Data............................................ 57
Verifying Service Adjustments..................................................58
Verifying the Segment Code...................................................... 58
Verifying the Destination............................................................ 58
Verifying the Model Name ......................................................... 59
Optional Adjustments ...............................................................59
Setting White Balance Adjustments .......................................... 59
Resetting the TV to Factory Condition .....................................60
Resetting the TV to Factory Condition Using Service Mode ..... 60

KDL-46HX820/55HX820 iii
TABLE OF CONTENTS
Appendix A - Removing the Rear Cover ...............................A-1
Removing the Power Cord from the Rear Cover ................... A-1
Appendix B - Rear Cover Caution .........................................B-1
KDL-46HX820 Only................................................................ B-1
KDL-55HX820 Only................................................................ B-2
Appendix C - Triage Sheets ...................................................C-1
KDL-46HX820 Only................................................................C-1
KDL-55HX820 Only................................................................C-2
Appendix D - Setup Guide......................................................D-1

KDL-46HX820/55HX820 1
WARNINGS AND CAUTIONS - ENGLISH
CAUTION
These servicing instructions are for use by qualied service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualied to do so.
CARRYING THE TV
•Carry the TV with the adequate number of people; larger size TVs require two or more people.
•Correct hand placement while carrying the TV is very important for safety and to avoid damage.
•Disconnect all cables when carrying the TV.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the AC power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identied by shading and ! mark on the exploded views are critical for safe operation.
Replace all components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. It is essential
that all critical parts be replaced only with the part number specied in this manual to prevent electric shock, re, or other hazard.
Circuit adjustments that are critical for safe operation are identied in this manual.
Follow these procedures whenever critical components are replaced or improper operation is suspected.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and labor
guarantee.
SECTION 1 - SAFETY AND FEATURES

KDL-46HX820/55HX820 2
SECTION 1 - SAFETY AND FEATURES
CAUTION
WDo Not use paper towels, any type of abrasive pad, rags, rubber or vinyl materials to clean the screen. Using these materials could easily
scratch the screen which may result in permanent damage.
WDo Not use any cleaning product containing alkaline/acid cleaner, scouring powder, or volatile solvent, such as alcohol, ammonia,
benzene, thinner or insecticide. Using any of these harsh cleaners may result in permanent damage to the screen.
WDo Not spray water or detergent directly onto the TV screen . If liquid drips into the bottom of the screen it may cause a failure.
CLEANING THE LCD PANEL
CAUTION: When cleaning the TV, be sure to unplug the power cord to avoid any chance of electric shock.
Clean the cabinet of the TV with a dry soft cloth.
Wipe the LCD screen gently with a soft cloth.
RStubborn stains may be removed with a cloth slightly moistened with a solution of mild soap and warm water.
RIf using a chemically pretreated cloth, please follow the instruction provided on the package.
RNever use strong solvents such as a thinner, alcohol or benzine for cleaning.
RPeriodic vacuuming of the ventilation openings is recommended to ensure to proper ventilation.

KDL-46HX820/55HX820 3
SECTION 1 - SAFETY AND FEATURES
HANDLING THE LVDS FFC CONNECTOR
Use caution when you connecting or removing the LVDS FFC Connector.
DO NOT remove the connector by the reinforcement tab only.
1. Holding onto the entire LVDS FFC Connector,
insert the LVDS FFC Connectorinto the connector slot.
1. Gently press down on the release tabs of the connector slot.
2. Holding onto the entire LVDS FFC Connector,
pull out the connector while continuing to hold down
the release tabs of the connector slot.
(See caution below.)
Insert
connector.
2
Press down
Press down
Main Board
Main Board
CAUTION: The LVDS FFC Connector can be inserted into the Main Board upside down.
If it is inserted upside down, the pins on the LVDS FFC Connector
will short-circuit and damage the board.
Remove
connector.
Inserted Correctly Inserted Incorrectly
Correct Incorrect
DISCONNECTING THE LVDS FFC CONNECTOR CONNECTING THE LVDS FFC CONNECTOR

KDL-46HX820/55HX820 4
SECTION 1 - SAFETY AND FEATURES
SPECIAL HANDLING INSTRUCTIONS WHEN REPLACING THE LCD PANEL ASSEMBLY
Use the following precautionary guidelines when handling the LCD Panel Assembly to avoid material degradation or screen coating degradation,
and ensure that dust, dirt, or ngerprints are not left between the glass and the LCD Panel Assembly.
1. After removing the boards and connectors, note where the frame is on the panel. (Figure 1)
2. Lift the LCD Panel Assembly by holding the top and bottom of the panel approximately 200mm from the edge with your palms
on the back of the panel. (Figure 2)
CAUTION: Lifting or holding the panel at the corners may damage the panel.
3. Use the same method when taking the replacement panel out of the carton. (Figure 3)
Figure 1 Figure 2 Figure 3
CAUTION: DO NOT lift the LCD Panel by holding the short side of the panel or by placing your palms on the front glass. (Figures 4 & 5)
Figure 4 Figure 5

KDL-46HX820/55HX820 5
SECTION 1 - SAFETY AND FEATURES
WARNINGS AND CAUTIONS - FRENCH
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualié seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualié faire ainsi.
POUR TRANSPORTER LE TÉLÉVISEUR
•Transportez le téléviseur avec le nombre de personnes approprié ; un téléviseur de grande
taille doit être transporté par au moins deux personnes.
• Lors du transport du téléviseur , l’emplacement des mains est très important pour votre
sécurité, ainsi que pour éviter de causer des dommages.
ALERTE!!
An d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage.
Le chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont
d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est
indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite
du fonctionnement sont identies dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants critiques, ou
lorsqu’un mauvais fonctionnement suspecte.

KDL-46HX820/55HX820 6
SECTION 1 - SAFETY AND FEATURES
AVERTISSEMENT
WN’utilisez pas de serviettes en papier, tout type de tampons ou chiffons abrasifs, ou matériaux en caoutchouc ou en vinyle pour nettoyer
l’écran. Ces types de matériaux peuvent facilement rayer l’écran, entraînant ainsi un dommage permanent.
WN’utilisez pas de produit de nettoyage contenant un nettoyant alcalin/acide, poudre abrasive ou solvant volatil, comme de l’alcool ou de
l’ammoniaque, du benzène, un diluant ou un insecticide. L’usage de ces types de nettoyants peut causer des dommages permanents à
l’écran.
WNe vaporisez pas d’eau ou de détergent directement sur l’écran du téléviseur. Si du liquide s’insère dans le bas de l’écran, cela peut causer
une panne.
NETTOYER L’ÉCRAN ACL
AVERTISSEMENT : Au moment de nettoyer le téléviseur, assurez-vous de débrancher le cordon d’alimentation an d’éviter tout risque
de choc électrique.
Nettoyez le caisson du téléviseur avec un chiffon doux et sec.
Essuyez l’écran ACL doucement avec un chiffon doux.
R Les taches tenaces peuvent être enlevées avec un chiffon légèrement humecté d’une solution de savon doux et d’eau tiède.
R Si vous utilisez un chiffon chimique prétraité, suivez les directives gurant à l’emballage.
RN’utilisez jamais de solvants puissants comme un diluant, de l’alcool ou du benzène pour nettoyer.
R Nous recommandons de passer l’aspirateur de façon périodique sur les ouvertures de ventilation an d’assurer une ventilation appropriée.

KDL-46HX820/55HX820 7
SECTION 1 - SAFETY AND FEATURES
SAFETY-RELATED WARNINGS
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
1. Do not press on the panel or frame edge to avoid the risk of electric shock.
2. Do not scratch or press on the panel with any sharp objects.
3. Do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
4. Do not expose the LCD panel to direct sunlight.
5. Avoid contact with water. It may cause a short circuit within the module.
6. Disconnect the AC power when replacing the backlight or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
7. Always clean the LCD panel with a soft cloth material.
8. Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
9. Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
10. During the repair, DO NOT leave the Power On for more than 1 hour while the TV is face down on a cloth.

KDL-46HX820/55HX820 8
SECTION 1 - SAFETY AND FEATURES
AVERTISSEMENTS DE SÉCURITÉ
FAITES ATTENTION LORS DE LA MANIPULATION DE L’ÉCRAN ACL
Au moment de réparer l’écran ACL, assurez-vous d’être mis à la terre à l’aide d’un bracelet à cet effet.
Au moment d’installer le panneau ACL sur un mur, il doit être maintenant en place à l’aide des 4 orices de xation présents au
couvercle arrière.
1. N’appuyez par sur le bord du panneau ou du cadre an d’éviter le risque de choc électrique.
2. Ne rayez pas ou n’appuyez pas sur le panneau avec des objets pointus.
3. Ne laissez pas le module exposé à des températures élevées ou dans des secteurs à haut niveau d’humidité pour une
période prolongée.
4. N’exposez pas le panneau ACL à l’ensoleillement direct.
5. Évitez le contact avec l’eau, car elle peut causer un court-circuit dans le module.
6. Déconnectez l’alimentation c.a. au moment de remplacer le rétroéclairage ou le circuit inverseur (Un voltage élevé se produit
dans le circuit inverseur à 650Vrms).
7. Nettoyez toujours le panneau ACL avec un chiffon doux.
8. Faites attention lors de la manipulation des ls ou connecteurs du circuit inverseur. Le fait d’endommager les lms peut
causer un court-circuit.
9. Protégez le panneau des décharges électrostatiques an d’éviter d’endommager le circuit électronique (C-MOS).
10. Pendant la réparation, NE LAISSEZ PAS l’alimentation en fonction pendant plus de 1 heure pendant que l’écran du téléviseur
repose sur un tissu.

KDL-46HX820/55HX820 9
SECTION 1 - SAFETY AND FEATURES
SAFETY CHECK-OUT
After correcting the original service problem, perform the following safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder
splashes and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and mounting hardware have been replaced. Be absolutely
certain that you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out
to the customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and
recommend their replacement.
6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.

KDL-46HX820/55HX820 10
SECTION 1 - SAFETY AND FEATURES
VÉRIFICATION DE SÉCURITÉ
Après avoir corrigé le problème de service original, effectuez les vérications de sécurité suivantes avant de remettre le
téléviseur au client :
1. Vériez le secteur de votre réparation an de vous assurer qu’il ne reste aucune connexion non soudée ou mal soudée.
Vériez toute la surface du circuit pour la présence d‘éclaboussures ou de ponts de soudure.
2. Vériez le lage inter-modules an de vous assurer qu’aucun l n’est « pincé » ou soit en contact avec des résistances à
wattage élevé.
3. Assurez-vous que tous les boutons de contrôle, écrans, couvercles, courroies de mise à la terre et équipement de xation
ont été remplacés. Soyez absolument certain d’avoir remplacé tous les isolateurs.
4. Recherchez la présence de pièces de remplacement non autorisées, surtout au niveau des transistors, qui auraient été
installés lors d’une réparation antérieure. Faites-en la remarque au client et recommandez leur remplacement.
5. Recherchez toute pièce qui, quoique fonctionnelle, fait montre de signez évidents de détérioration. Faites-en la remarque au
client et recommandez leur remplacement.
6. Vériez la présence de ssures et d’abrasions sur les cordons. Recommandez le remplacement de ces cordons au client.
7. Vériez les terminaux d’antenne, les garnitures en métal, les boutons « métallisés », les vis et autres pièces en métal
exposées pour toute fuite de courant. Vériez les fuites de la façon décrite ci-dessous.

KDL-46HX820/55HX820 11
SECTION 1 - SAFETY AND FEATURES
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and from all exposed
metal parts to any exposed metal part having a return to chassis, must not exceed
0.5 mA(500 microamperes). Leakage current can be measured by any one of three
methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245 digital
multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so
analog meters must have an accurate low voltage scale.
4. The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
HOW TO FIND A GOOD EARTH GROUND
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw on
most AC outlet boxes is also at earth ground.
If the retaining screw is to be used as your earth ground, verify that it is at ground
by measuring the resistance between it and a cold-water pipe with an ohmmeter.
The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60-to 100-watt trouble-light (not a
neon lamp) between the hot side of the receptacle and the retaining screw. Try both
slots, if necessary, to locate the hot side on the line; the lamp should light at normal
brilliance if the screw is at ground potential (see Figure B).
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure B. Checking for earth ground.
To Exposed Metal
Parts on Set
0.15 µF
Earth Ground
AC
Voltmete
r
(0.75V)
Figure A. Using an AC voltmeter to check AC leakage.

KDL-46HX820/55HX820 12
SECTION 1 - SAFETY AND FEATURES
SELF DIAGNOSIS FUNCTION
The TVs in this manual contain a self-diagnostic function. If an error occurs, the standby LED will automatically begin to ash. The number of
times the LED ashes translates to a probable source of the problem. A denition of the standby LED ash indicator is listed in the Operating
Instruction manual for the user’s reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal
past problems and how often these problems occur.
For complete information, refer to “Section 4 - Troubleshooting” on page 33.
Self Diagnosis
Supported model

KDL-46HX820/55HX820 13
SECTION 1 - SAFETY AND FEATURES
OVERVIEW
The AZ2-F chassis is one of several designs for the 2011 model line
of Sony Bravia® LCD televisions. This manual covers the following
models:
KDL-46HX820
KDL-55HX820
FEATURES
Several new features are introduced in this chassis model lineup
along with some carryovers from the previous year.
SEE IT ALL IN 3D
Enjoy incredible depth and a sharp, Full HD 1080p picture from
the leader in 3D technology. Plus easy set up with built-in 3D sync
transmitter. (3D Active Glasses required, sold separately).
DYNAMIC EDGE LED BACKLIGHT
Experience enhanced picture quality and contrast with local
dimming technology. It sharpens image contrast giving an amazingly
crisp picture you can see. The backlight system allows for a more
environmentally friendly television than traditional CCFL-tube TVs.
SLEEK DESIGN
Sony’s monolithic design consists of an elegant sheet of glass
stretching from edge-to-edge. It looks just as good when it’s off as it
does when it’s on.
OPTICONTRAST™ PANEL
Sony’s exclusive panel technology boosts contrast and brightness,
making for an enhanced viewing experience.

KDL-46HX820/55HX820 14
SECTION 1 - SAFETY AND FEATURES
X-REALITY™ PRO ENGINE
Enjoy Sony’s best picture experience no matter what you’re watching.
Sony’s X-Reality PRO engine brings out incredible detail through
multi-frame, pixel-by-pixel analysis of each scene. You will see
optimal color, contrast and sharpness including in low resolution web
videos.
MOTIONFLOW ™ XR 480
Experience motion clarity from the combination of LED backlighting
and high frame-rate technology. See smooth motion during fast
action movies and sports. Sony’s Motionow XR 480 technology
reduces blur caused by quick camera movements, enhances image
sharpness, and overall creates a clearer picture.
INTERNET STREAMING & CONNECTIVITY
“Internet Streaming & Widgets: Internet favorites now streaming
on your television. In addition to Qriocity™, watch hit movies with
Netix®, popular TV shows on Hulu Plus™ or user-generated video on
YouTube™. You can even listen to personalized music on Pandora®.
Enjoy the widest selection of internet content at your ngertips. And
with Internet Widgets, you can access news headlines, weather
updates, or play games while you watch TV.1
Skype™ Ready: Easily connect to family and friends live on your
HDTV wherever they are with Skype! Enjoy free high denition
Skype-to–Skype video calls from the comfort of your living room.
Simply attach the Sony® compact microphone/camera (required,
sold separately) and see your friends on the big screen – it’s unlike
any experience you could get on a PC.2
Integrated Wi-Fi®:Conveniently stream entertainment straight from
the Internet and from your home network using the built-in Wi-Fi®.1
DLNA® Streaming: Access and share photos, videos and music on
your TV by streaming them from compatible DLNA® device like your
PC or Playstation®3 system.3”
INTELLIGENT PRESENCE SENSOR
Enjoy an incredibly customized picture and sound experience every
time. Sony’s Intelligent Presence Sensor uses built-in Face Detection
technology to turn itself off if no one is watching, warns children when
they’re too close to the screen and adjusts picture and sound based
on where people are sitting in the room.
AMBIENT SENSOR
Incredible picture in any lighting. The built-in Ambient Sensor
automatically adjusts the TV’s color and brightness based on the
room’s lighting conditions giving you a natural looking picture.
1. Broadband speed of at least 2.5 Mbps recommended (10 Mbps for HD content). Video quality
varies. Content provided is subject to change. Premium content may require additional
fees or a subscription. Wireless connectivity requires an 802.11 home network (802.11n
recommended).
2. Broadband speed of at least 2.5 Mbps recommended (10 Mbps for HD content). Video quality
varies. Content provided is subject to change. Premium content may require additional
fees or a subscription. Wireless connectivity requires an 802.11 home network (802.11n
recommended). Skype requires rmware update and is subject to Skype’s terms and
conditions, which Skype has the ability to change at any time
3. Requires all devices to be connected to the same home network.
