LMD-2450W
LMD-2050W
Professional LCD Monitors
In response to the rapid spread of High Definition
(HD) content creation, Sony has added two high-
grade HD monitors to its LMD Series of LCD monitors.
One is the LMD-2450W, featuring a 24-inch*1panel
with true HD resolution of 1920 x 1080 pixels, the
other is the LMD-2050W, with a 20-inch*2panel of
1680 x 1050 resolution.
Using the market-proven Sony ChromaTRU™techno-
logy, these monitors achieve accurate colour
matching between panels with colour reproduction
equivalent to Sony CRT displays. They are also
designed to offer the high functionality and ope-
rability for which Sony professional video monitors
are renowned.
The LMD-2450W and LMD-2050W accept a variety
of signals in both analogue and digital and HD
and SD formats. Analogue interfaces include
composite NTSC and PAL, Y/C, RGB and HD/SD
component, all of which are offered as standard,
while digital interfaces are provided in HD-SDI and
SD-SDI as options.
In addition, analogue HD-15 and DVI-D interfaces
are equipped as standard to accept PC signals
ranging from VGA to WUXGA.
A closed caption decoder and backlight control
function are also offered on both models, together
with many other professional video monitor
functions such as parallel remote control, markers,
tally and external sync input.
The LMD-2450W and LMD-2050W, residing at the
top of the LMD Series, are the best-suited LCD
monitors in their class for picture monitoring in
broadcast and post-production applications.
*124-inch viewable area, measured diagonally.
*220.1-inch viewable area, measured diagonally.
The monitors of choice for broadcast
and post-production picture monitoring

Input Versatility
Multi-format Signal Support
The LMD-2450W and LMD-2050W both accept almost any SD or HD
video format, in both analogue and digital. These include compos-
ite NTSC and PAL, component 480/60i and 575/50i, progressive
480/60P and 576/50P and high-definition 1080/60i, 1080/50i, 720/60P,
1080/24P, 1080/25P and 1080/30P. They also accept 1080/24PsF and
1080/25PsF. Standard interfaces include analogue composite
(NTSC/PAL), SD/HD analogue component and RGB and Y/C.
Additional analogue inputs are available using option boards.
Digital interfaces including HD-SDI and SD-SDI are also offered as
optional boards to meet budgetary and user needs. Furthermore,
the LMD-2450W and LMD-2050W accept various types of analogue
and digital computer signals via their standard HD-15 and DVI-D
interfaces, respectively. Finally, with their high-performance scan
converters, these monitors can display PC signals ranging from VGA
to WUXGA*.
* The LMD-2050W cannot display 1920 x 1200 WUXGA images. Images ranging from WSXGA+
(1680 x 1050) to 1920 x 1080 are down-converted for display on the LMD-2050W.
Preset Computer Input Frequencies
The LMD-2450W and LMD-2050W are factory preset to accept
32 and 25 typical computer input signal frequencies, respectively.
Superb Picture Performance
High-purity Colour Filters
The LMD-2450W and LMD-2050W use precisely manufactured RGB
colour filters, allowing the reproduction of colours with stunning
depth and saturation to create highly natural images.
Accurate Gamma and Stable White Balance –
ChromaTRU Colour Processing
For an extra level of colour reproduction accuracy, every LCD panel
used in the LMD-2450W and LMD-2050W is precisely colour calibrat-
ed at the factory, providing characteristics consistent with those of
CRT displays. The colorimetry of an LCD display, by nature, can
exhibit inaccurate R, G, B colour coordinates and unbalanced R, G,
B gamma curves, which can make precise colour matching
between multiple monitors a challenge. These are also the primary
reasons why LCD colour tone can slightly differ from CRT tone.
The LMD-2450W and LMD-2050W solve this problem by precisely cal-
ibrating each LCD panel's light output so that the R, G, B colour
coordinates are virtually the same as those of a CRT monitor.
A second calibration is further applied so that white balance is
maintained at a consistent colour temperature throughout all
grayscale levels. The result of these precise calibrations is colour
reproduction equivalent to Sony CRT displays.
Input Signals/Input Adaptors
LMD-2450W / LMD-2050W Connector Panel
575/50i (PAL) 625 575 16:9/4:3 25 O O O O O O
480/60i*(NTSC) 525 483 16:9/4:3 30 O O O O O O
576/50P 625 576 16:9/4:3 50 — O —— — O
480/60P 525 483 16:9/4:3 60 — O —— — O
1080/24PsF 1125 1080 16:9 24 — O*2 — O — O*2
1080/25PsF 1125 1080 16:9 25 — O*2 — O — O*2
1080/24P 1125 1080 16:9 24 — O*2 — O — O*2
1080/25P 1125 1080 16:9 25 — O*2 — O — O*2
1080/30P 1125 1080 16:9 30 — O*2 — O — O*2
1080/50i 1125 1080 16:9 25 — O — O — O
1080/60i*1125 1080 16:9 30 — O — O — O
720/50P 750 720 16:9 50 — O*2 — O — O*2
720/60P 750 720 16:9 60 — O — O — O
Video
Signal
Formats Total
Line
Active
Line
Aspect
Ratio
Frame
rate*3
Input Signal Interface
Composite/
Y/C
RGB/
Component
SD-SDI
HD-SDI
SDI
4:2:2
Composite/
Y/C
RGB/
Component
Standard
Optional
BKM-220D
Optional
BKM-243HS
Optional
BKM-277W
Optional
BKM-229X
*2For component *3Compatible with 1/1.001
N=Negative P=Positive *down-converted to display
640 x 480 @60Hz 800 640 525 480 25.175 31.469 59.940 N N OO
800 x 600 @56Hz 1024 800 625 600 36.000 31.156 56.250 P P OO
800 x 600 @60Hz 1056 800 628 600 40.000 37.879 60.317 P P OO
800 x 600 @72Hz 1040 800 666 600 50.000 48.077 72.188 P P OO
800 x 600 @75Hz 1056 800 625 600 49.500 46.875 75.000 P P OO
800 x 600 @85Hz 1048 800 631 600 56.250 53.674 85.061 P P OO
1024 x 768 @60Hz 1344 1024 806 768 65.000 48.363 60.004 N N OO
1024 x 768 @70Hz 1328 1024 806 768 75.000 56.476 70.069 N N OO
1024 x 768 @75Hz 1312 1024 800 768 78.750 60.023 75.029 P P OO
1024 x 768 @85Hz 1376 1024 808 768 94.500 68.677 84.997 P P OO
1152 x 864 @75Hz 1600 1152 900 864 108.000 67.500 75.000 P P OO
1280 x 960 @60Hz 1800 1280 1000 960 108.000 60.000 60.000 P P OO
1280 x 1024 @60Hz 1688 1280 1066 1024 108.000 63.981 60.020 P P OO
1600 x 1200 @60Hz 2160 1600 1250 1200 162.000 75.000 60.000 P P O —
640 x 480 @60Hz 800 640 494 480 23.625 29.531 59.780 P N OO
800 x 600 @60Hz 960 800 618 600 35.500 36.979 59.837 P N OO
1024 x 768 @60Hz 1184 1024 790 768 56.000 47.297 59.870 P N OO
1280 x 960 @60Hz 1440 1280 988 960 85.250 59.201 59.920 P N O —
1600 x 1200 @50Hz 2144 1600 1235 1200 132.375 61.742 49.994 N P O —
1600 x 1200 @60Hz 1760 1600 1235 1200 130.375 74.077 59.981 P N O —
1360 x 768 @50Hz 1760 1360 791 768 69.500 39.489 49.922 N P OO
1360 x 768 @60Hz 1776 1360 768 768 84.625 47.649 59.936 N P OO
1360 x 768 @60Hz 1520 1360 790 768 72.000 47.368 59.960 P N OO
1920 x 1080 @50Hz 2544 1920 1112 1080 141.375 55.572 49.975 N P OO*
1920 x 1080 @60Hz 2080 1920 1111 1080 138.625 66.647 59.988 P N OO*
1920 x 1200 @50Hz 2560 1920 1235 1200 158.000 61.719 49.975 N P O —
1920 x 1200 @60Hz 2080 1920 1235 1200 154.125 74.099 59.999 P N O —
1280 x 768 @60Hz 1680 1280 795 768 80.125 47.693 59.992 N P OO
1280 x 768 @75Hz 1712 1280 802 768 102.875 60.091 74.926 N P OO
1280 x 768 @60Hz 1440 1280 790 768 68.250 47.396 59.995 P N OO
720 x 400 @70Hz 900 720 449 400 28.322 31.469 70.087 N P OO
1280 x 800 @60Hz 68.900 48.935 59.969 N N OO
1920 x 1200 @60Hz 2120 1920 1212 1200 154.000 74.642 59.935 P P O —
Vertical LMD-2450W LMD-2050WHorizontal
Resolution H
Total
H
Addr.
V
Total
V
Addr.
Dot Clock
[MHz]
fH
[kHz]
fV
[Hz]
Sync. polarity
HD15 Input Signal Format
2
Main Features

3
Parallel Remote Control
The LMD-2450W and LMD-2050W can be controlled remotely via
a parallel remote connector. There are 38 functions in the remote
menu, such as the ability to switch input signals, of which eight
can be allocated to the connector.
Stereo Audio Monitoring
The LMD-2450W and LMD-2050W are equipped with stereo speakers
(0.5 W + 0.5 W), which enable the operator to monitor audio.
Protected Controls
The key-inhibit function of the LMD-2450W and LMD-2050W monitors
helps prevent inadvertent operation from the control panel.
Closed-Caption Decoder
The LMD-2450W and LMD-2050W are equipped with a closed cap-
tion decoder. The closed caption information embedded in the
analogue composite and component inputs can be decoded for
display.
Mounting Flexibility (VESA, 19-inch EIA Standard Rack)
Complying with VESA (Video Electronics Standard Association)
standards, both the LMD-2450W and LMD-2050W can easily be
mounted (100 x 100 mm pitch) on a wall or ceiling. The LMD-2050W
(8U high) can also be rack-mounted in a 19-inch EIA standard rack
using the optional MB-529 Mounting Bracket, even though the
monitor itself is wider than 19 inches.
Sophisticated I/P Conversion
The LMD-2450W and LMD-2050W use a motion-adaptive
I/P-conversion process to achieve conversion results that are
optimised to the picture content, whether it is static or dynamic.
Highly accurate I/P conversion is provided regardless of signal
resolution, for example, whether the input is HD or SD.
Excellent Brightness and Contrast
The LMD-2450W and LMD-2050W provide high-brightness,
high-contrast images by utilising super-wide aperture LCD panels.
Extremely Wide Viewing Angle
The LMD-2450W and LMD-2050W offer the most stable images
within the LMD Series when viewed from various angles. They both
offer a wide viewing angle of 178 degrees, horizontally and vertical-
ly, with virtually no reduction in picture contrast, colour saturation
and hue shift. This allows precise images to be clearly viewed from
various positions and angles – a critical requirement in professional
video monitoring.
Operational Convenience
Advanced Marker Settings
These monitors can display various area markers, including a centre
marker, aspect markers and a safety zone marker. The brightness of
these markers can be selected from three different levels: white,
gray and dark gray. Users can also select either a black or gray
matte to fill the outer area of the aspect markers. These flexible
marker controls, together with the choice of many different aspect
markers, make the LMD-2450W and LMD-2050W extremely conven-
ient display devices for a variety of shooting scenarios – from stan-
dard video acquisition to digital cinematography.
Colour Temperature Selection
The colour temperature of both the LMD-2450W and LMD-2050W
monitors can be selected from 9300k, 6500k and a user-defined
preset.
Selectable Scan Size
The scan size of the LMD-2450W and LMD-2050W monitors can be
selected between 5% overscan and 0% scan modes. The aspect
ratio can be switched between 16:9 and 4:3 according to the input
signal.
Three-colour Tally
The LMD-2450W and LMD-2050W come equipped with a tally lamp
that can be lit via a parallel remote connector. The status of the
signal displayed on the monitor can be identified by the tally colour
- red, green, or amber.
Smart APA (Auto Pixel Alignment) for Computer Input
The image size of the LMD-2450W and LMD-2050W monitors can be
automatically adjusted to its optimal setting with the one-touch APA key.
Marker Variation
16:9 Mode 4:3 Mode
Aspect Marker 4:3, 15:9, 14:9, 13:9, 1.85:1, 16:9
2.35:1, 1.85:1 & 4:3
Centre marker OO
Safety Area 80%, 85%, 88%, 90%, 93% 80%, 85%, 88%, 90%, 93%
CRT
LCD
Green
Yellow green Yellow
Orange yellow
Orange
Red
Moderate red
Dark skin
Light skin
Whlite
Foliage
Bluish green
Magenta
Blue flower
Blue sky
Cyan
Purple
Purplish blue
Blue
The CIE u' v' chart is used to evaluate the light output of display
devices. In this diagram, the raw light output of a Sony LCD panel
is compared with that of a Sony CRT. The triangular areas show
their different colour reproduction capabilities (Colour Space).
The green and red dots indicate the colour of light output from
a Sony LCD panel and from a Sony CRT for certain RGB input
signals. Note that the same light colour is not obtained for the
same video input. The ChromaTRU process, on the other hand,
reproduces consistent light output extremely close to that of a CRT.
0.55
0.50
0.45
0.40
0.35
0.30
0.25
0.20
0.15
0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50
CRT (Sony CRT) LCD (Sony LCD Panel) Sony LCD Panel
Sony CRTChromaTRU
CIE Colour Coordinates
v'
u'

www.sonybiz.net/lmd
BKM-220D
SD-SDI 4:2:2 Input Adaptor
BKM-243HS
HD-SDI/SD-SDI Input Adaptor
BKM-227W
NTSC/PAL Input Adaptor
BKM-229X
Analogue Component Adaptor
© 2007 Sony Corporation. All rights reserved. Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice. All non-metric weights and measurements are approximate.
Images on monitors are simulated. Sony and ChromaTRU are trademarks of Sony Corporation.
VESA is a trademark of the Video Electronics Standards Association.
CA LMD-2450W/2050W/GB- / /2007
Optional Accessories
Dimensions Unit: mm (inches)
Other Features
• WFM and Audio* Level Meter Windows
* Only embedded audio is supported.
• Picture by Picture mode
• H/V Delay Function
• ACC Off
• DC Operation
• Setup Level for Analogue Component
and NTSC signals
• Sub Control buttons for adjusting Contrast,
Chroma, Phase and Brightness
• Blue-Only Mode
• Monochrome Mode
• Auto Chroma/Phase Setup
• Remote (Ethernet, RS-232C, Parallel Remote)
• DVI-D Input
• Power-saving Function (computer input only)
• DCC-2B
LMD-2450W LMD-2050W
Picture Performance
Type A-Si TFT Active Matrix LCD A-Si TFT Active Matrix LCD
Resolution 1920 x1200 pixels (WUXGA) 1680 x1050 pixels (WSXGA+)
Picture Size (H x W) Approx. 518.4 x 324.0 mm Approx. 433.5 x 272.9 mm
(Viewable area) (Approx. 20 1/2x 12 1/8inches) (Approx. 17 1/8x 10 3/4inches)
(Diagonal) Approx. 613.2 mm (24.1 inches) Approx. 511.1 mm (20.1 inches)
Aspect 16:10
Colours Approx 16,700,000 colours (8bits)
Viewing Angle 89°/89°/89°/89° (typical) (up/down/left/right contrast>10:1)
Input
Standard Composite BNC x 1, 1.0 VP-p ±3dB sync negative
4pin Mini DIN x 1 Y: 1.0 Vp-p ±3dB sync negative,
Y/C C: 0.286 Vp-p ±3dB (NTSC burst signal level),
0.3 Vp-p ±3dB (PAL burst signal level)
BNC x 3
RGB, Component RGB: 0.7 Vp-p ±3dB (Sync On Green, 0.3 Vp-p sync negative)
Component: 0.7 Vp-p ±3dB (75% chrominance standard colour bar signal)
External Sync BNC x 1 0.3 to 4.0 Vp-p ±bipolarity ternary or negative polarity binary
Audio RCA pin x 2 (L, R) -5 dBu 47 kΩor higher
D-sub 15 pin x 1,
HD15 R/G/B: 0.7 Vp-p sync positive (Sync On Green, 0.3 Vp-p sync negative)
Sync: Total level (polarity free, H/V separate and composite sync)
Plug & Play function: corresponds to DDC-2B
DVI TMDS signal link
Parallel remote Modular connector 8 pin x 1 (pin assignment at users' allocation)
Serial remote (LAN) D-sub 9-pin (RS232C) x 1,
RJ-45 modular connector (ETHERNET) x 1 (10BASE-T/100BASE-TX)
DVI TMDS signal link
DC in XLR type 4pin x 1 DC24V (output impedance 0.005Ωor less)
Optional Option input slot 2 slots (for HD-SDI, SDI capability and extra analogue I/O's)
Output
Standard Composite BNC x 1, Loop-though, with 75Ωautomatic termination
Y/C 4pin mini DIN x 1 Loop-though, with 75Ωautomatic termination
RGB, Component BNC x 3, Loop-though, with with 75Ωautomatic termination
External Sync BNC x 1, Loop-though, with 75Ωautomatic termination
Audo monitor out RCA pin type x 2 (L, R)
Speaker (Built-in) 1 W + 1 W (stereo)
General
Power Requirement AC100V to 240V AC100V to 240V
50/60Hz 0.6A to 1.1A, DC24V 4.6A 50/60Hz 0.4A to 0.8A, DC24V 3.3A
Power Consumption Maximum Approx. 115 W Maximum Approx. 95 W
(with 2 x BKM-229X) (with 2 x BKM-229X)
Operating Temparature 0 to 35 °C (recommended operation temperature 20 to 30 °C)
Operating Humidity 30 to 85 % (No condensation)
Storage & Transport Temperature -20 to 60 °C
Storage & Transport Humidity 0 to 90 %
Operating/Storage/Trans. Pressure 700 to 1060 hPa
Dimensions (W x H x D)
Dimension 602.4 x 497.9 x 269.9 mm 518.5 x 468.4 x 269.9 mm
(23 3/4x 19 5/8x 10 3/4inches)(
20 1/2x 18 1/2x 10 3/4inches)
Dimension 602.4 x 386.2 x 110.0 mm 518.5 x 328.7 x 104.7 mm
without stand (23 3/4x 15 1/4x 4 3/8inches)(
20 1/2x 13 x 4 1/8inches)
Display Stand (W x H x D) 320.0 x 361.5 x 269.9 mm (12 5/8x 14 1/4x 10 3/4inches)
Mass With two Approx. 11.4 kg ( 25 lb 2 oz) Approx. 10.5 kg ( 23 lb 2 oz)
option boards with BKM-229X x 2 with BKM-229X x 2
Without option boards Approx. 11.0 kg ( 24 lb 4 oz) Approx. 10.1 kg ( 22 lb 4 oz)
LMD-2450W LMD-2050W
Specifications
602.4 (23 3⁄4) 110.0 (4 3⁄8)
518.5 (20 1⁄2)104.7 (4 1⁄8)
320.0 (12 5⁄8) 269.9 (10 3⁄4)
269.9 (10 3⁄4)
COMPOSITE
COMPONENT
Y/C
RGB
A-1
A-2
B-1
B-2
DVI
F1
F2
F3
F4
HD-15
CONTROL
VOLUME
CONTRAST
PHASE
CHROMA
BRIGHT
MENU
ENTER
ñ
+
ñ
+
ñ
+
ñ
+
ñ
+
ñ
+
RETURN
ñ
+
ñ
+
ñ
+
ñ
+
ñ
+
ñ
+
386.2 (15 1⁄4)
497.9 (19 5⁄8)
361.5 (14 1⁄4)
361.5 (14 1⁄4)
328.7 (13)
468.4 (181⁄2)
320.0 (12 5⁄8)
