PFM-32C1
Flat Panel Display
•32-inch*, 16:9 widescreen flat panel display
•Real Digital System for true image reproduction
•High-definition flat panel provides clear pictures
•Slim, sleek styling
* Viewable area, measured diagonally

© 2001 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
838
97
110.5
521
4545
4545
ON
STANDBY
INPUT1
RGB/YUV
AUDIO
INPUT2
CONTROLS
REMOTE
RGB/YUV
AUDIO
IN OUT COMPOSITE
IN OUT Y/CIN AUDIOIN
VIDEO
Versatile And Stylish
With a simple yet sophisticated appearance, the PFM-32C1 offers outstanding
installation flexibility. This slim, lightweight display provides large, superb quality
images in minimal space.
Multiple Inputs With High-Performance Scan Converter
The PFM-32C1 accepts a wide variety of signal sources, including Composite,
S-video, Component, HDTV, DTV and RGB computer signals. A built-in
high-performance scan converter offers optimum image quality whatever the
signal format, providing accurate pixel-by-pixel image reproduction.
Other Features
•High-quality digital audio amplifier and an optional speaker system
•Picture Mode function – three user presets and two fixed sets of parameters
•Selectable Aspect ratios of Wide Zoom, Letter Box Zoom, Restore, Subtitle or
Normal 4:3 selectable
•Size control and Shift control
•Picture Zoom
•24 hour on/off timer and sleep function
•Power saving function
•Screen saver functions –
Picture Orbiting and Picture Inversion
•Worldwide power supply range
Specifications
Brilliant Picture Quality
■Real Digital System
The PFM32C1 incorporates Sony’s unique digital signal processing technology –
Real Digital System. All signals are both input and processed digitally to give true
image reproduction. A new bi-pixel I/P conversion circuit, developed exclusively
for Sony flat panel displays, converts interlace signals to progressive images of
effectively higher definition.
■High-Definition Flat Panel
The PFM-32C1 uses a high-definition flat panel with 1024 x 852 pixels that,
together with the Real Digital System, provides high quality, smooth images across
the screen. The anti-reflection coating on the glass panel reduces light reflection
to maintain picture contrast.
Picture Performance
Panel Resolution 1024 x 852 pixels
Pixel pitch 0.84 x 0.39 mm
Active area (W/H) 715.68 x 399.36 mm
Viewable picture area 32-inch/820 mm (diagonal)
Driver 8-bit RGB
Colors 16.8 million colors simultaneously
Type AC-type Plasma Display Panel with anti-reflection screen
Color system NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL 60
Sampling rate 13.5 to 140 MHz
Input/Output
INPUT1/INPUT2 D-sub 15-pin
RGB 0.714 Vp-p/non-composite, 1.0 Vp-p/composite, 75 Ω
YUV 0.7 Vp-p/non-composite (U/V), 1.0 Vp-p/composite (Y), 75 Ω
AUDIO Stereo mini jack, 500 mV rms, high impedance
VIDEO COMPOSITE IN BNC, 1.0 Vp-p ±2 dB sync negative, 75 Ωautomatic termination
Y/C IN Mini DIN 4-pin
Y 1.0 Vp-p ±2 dB sync negative, 75 Ω
C 0.286 Vp-p ±2 dB sync negative (NTSC), 75 Ω
0.3 Vp-p ±2 dB sync negative (PAL), 75 z
AUDIO IN Stereo mini jack, 500 mV rms, high impedance
COMPOSITE OUT Loop-through BNC
CONTROL S IN/OUT Stereo mini jack, 5.0 Vp-p
REMOTE (RS-232C) D-sub 9-pin
SPEAKER OUT (L/R) 7 W + 7 W (impedance: 6 Ω)
General
Power requirements AC 100 to 240 V, 50/60 Hz, 3.2 to 1.6 A
Power consumption 270 W
Operating temperature 0 to 35 °C (32 to 95 °F)
Storage temperature -10 to 40 °C (14 to 104 °F)
Humidity 20 to 90 %, no condensation
Dimensions* (W/H/D) 838 x 521 x 97 mm (33 x 20 5/8 x 3 7/8 inches)
Mass 22 kg (48 lb 8 oz)
Supplied Accessories
AC Power Cord, AC Plug Holder (2), Remote Commander RM-971,
AA size Battery (2), Cable Holder A (2), Cable Holder B (4),
Operating Instructions
Optional Accessories
Adjustable Mounting Bracket: MB32ADJ
Flat Mounting Bracket: MB32FLAT
Display Stand SU-P32C, Speaker System SS-SP10A
Regulation Compliance
UL1950, CSA No.950 (c-UL), CE LVD (EN60950), Dentori Otsu,
FCC Class B, IC Class B, VCCI Class B, CE EMC (EN55022 Class-B,
EN55024, EN61000-3-2, EN61000-3-3),
C-Tick (AS/NZS 3548/95, AS/NZS 4252.1), CCIB, JEIDA, CB, KIL, MIC
*
Excluding protruding parts
INPUT 1
RGB /YUV AUDIO
INPUT 2 CONTROLS REMOTE
RGB /YUV AUDIO IN OUT COMPOSITE
IN OUT Y/C IN AUDIO IN
VIDEO
Connector Panel
PFM-32C1
Dimensions
Unit: mm
Superior quality, style and flexibility Sony PFM-32C1
Digital Signal
Analog Signal
Real Digital System
Bi-pixel IP
Conversion Scaling
(Resolution
conversion)
Video Signal
Processing
Video
Decoder
Video
Signal
PC
Signal
PFM-32C1/
32C1E
Panel Drive
