Professional Monitor Pocket Guide
www.sonybiz.net

MULTIFORMAT BROADCAST CRT MONITORS
BVM-A SERIES
■32-inch Flat 16:9 HR Trinitron,
EBU Phosphors, 1000 TV lines
■Multi format signal support
■Dual link HD-SDI
■Auto white balance
■Digital uniformity & convergence
■Optional input boards
■Separate control unit with
Memory Stick slot
■Ethernet based remote control
■SNMP remote maintenance
BVM-A32E1WM
■20-inch HR Trinitron, EBU
Phosphors, 900 TV lines
■Multi format signal support
■Dual link HD-SDI
■Auto white balance
■Digital uniformity
■Optional input boards
■Separate control unit with Memory
Stick slot
■Ethernet based remote control
■SNMP remote maintenance
BVM-A20F1M
■14-inch HR Trinitron, EBU
Phosphors, 800 TV lines
■Multi format signal support
■Dual link HD-SDI
■Auto white balance
■Digital uniformity
■Optional input boards
■Separate control unit with
Memory Stick slot
■Ethernet based remote control
■SNMP remote maintenance
BVM-A14F5M

MULTIFORMAT VIEW
LMD SERIES (2-PIECE)
■32-inch WXGA wide screen
LCD panel
■Separate LCD panel and video
processor
■Versatile video and computer
inputs
■Multi format SD/HD video inputs
■Compact, slim and lightweight
LCD panel
■X-Algorithm & ChromaTru
processing
■Low power consumption
■Parallel remote function
LMD-322W + MEU-WX2
■23-inch WXGA wide screen
LCD panel
■Separate LCD panel and video
processor
■Versatile video and computer inputs
■Multi format SD/HD video inputs
■Compact, slim and lightweight
LCD panel
■X-Algorithm & ChromaTru processing
■Low power consumption
■Parallel remote function
LMD-232W + MEU-WX2
WS
WS
LMD-322W with SU-559

ING LCD MONITORS
LMD-212 + MEU-WX2
■21-inch XGA LCD panel
■Separate LCD panel and video
processor
■Versatile video and computer inputs
■Multi format SD/HD video inputs
■Compact, slim and lightweight LCD
panel
■X-Algorithm & ChromaTru processing
■Low power consumption
■Parallel remote function
■17-inch WXGA wide screen
LCD panel
■Separate LCD panel and video
processor
■Versatile video and computer inputs
■Multi format SD/HD video inputs
■Compact, slim and lightweight
LCD panel
■X-Algorithm & ChromaTru processing
■Low power consumption
■Parallel remote function
LMD-172W + MEU-WX2
■15-inch XGA LCD panel
■Separate LCD panel and video
processor
■Versatile video and computer inputs
■Multi format SD/HD video inputs
■Compact, slim and lightweight LCD panel
■X-Algorithm & ChromaTru processing
■Low power consumption
■Parallel remote function
LMD-152 + MEU-WX2
WS

VIEWING LCD
LMD SERIES (1-PIECE)
■20-inch VGA LCD panel
■Wide viewing angle 170 degrees
■PAL/NTSC, Y/C,
component/RGB inputs
■Optional SDI input decoder
■Selectable 16:9 and 4:3
aspect ratio
■Enhanced production features
■Parallel remote function
■Optional Rack Mount kit
LMD-2020
■14-inch VGA LCD panel
■Wide viewing angle 170 degrees
■PAL/NTSC, Y/C, component/RGB
inputs
■Optional SDI input decoder
■Selectable 16:9 and 4:3 aspect ratio
■Enhanced production features
■Parallel remote function
■Optional Rack Mount kit
LMD-1420

MONITORS
■20-inch VGA LCD panel
■Wide viewing angle 170 degrees
■PAL/NTSC, Y/C,
component/RGB inputs
■Selectable 16:9 and 4:3
aspect ratio
■Entry level production features
■Parallel remote function
■Optional Rack Mount kit
LMD-2010
■14-inch VGA LCD panel
■Wide viewing angle 170 degrees
■PAL/NTSC, Y/C, component/RGB
inputs
■Selectable 16:9 and 4:3 aspect ratio
■Entry level production features
■Parallel remote function
■Optional Rack Mount kit
LMD-1410

FIELD LCD MONITORS
LMD SERIES (1-PIECE)
LMD-9050
■8.4-inch XGA LCD panel
■Multi format SD/HD video inputs
■Analogue & HD/SD-SDI input standard
■AC/DC and battery operation
■Enhanced production features
■Optional ENG kit
■Optional dual LCD Rack Mount kit
■8.4-inch VGA LCD panel
■Analogue & SD-SDI input standard
■Analogue HD component input
■AC/DC and battery operation
■Enhanced production features
■Optional ENG kit
■Optional dual LCD Rack Mount kit
LMD-9030
■8.4-inch VGA LCD panel
■Verstatile analogue input
■Analogue HD component input
■AC/DC and battery operation
■Enhanced production features
■Optional ENG kit
■Optional dual LCD Rack Mount kit
LMD-9020
NEW
NEW

MULTIPLE LCD MONITORS
LMD SERIES
LMD-7220W
■2x7-inch WS LCD panel
■Selectable aspect ratio 16:9/4:3
■PAL/NTSC input
■Optional SDI video decoder
■Parallel remote function
■Rack mount capability
■3x5.6-inch LCD panel
■PAL/NTSC input
■Optional SDI video decoder
■Parallel remote function
■Rack mount capability
LMD-5320
■4x4-inch LCD panel
■PAL/NTSC input
■Optional SDI video decoder
■Parallel remote function
■Rack mount capability
LMD-4420

ACCESSORIES
BVM ACCESSORIES
OPTIONAL PLUG-IN DECODER BOARDS
BKM-61D SDI/Analogue multi input adaptor
BKM-62HS HD/SD SDI input adaptor
BKM-68X Analogue component input adaptor
ACCESSORIES
BKM-15R Monitor control unit
BKM-14L Auto Set-up probe
BKM-35H Monitor control unit attachment kit
for BVM-A20F1M
SMF-700 Monitor interface cable
RACK MOUNT KITS
BKM-30E14 Rack mount kit for BVM-A14F5M
BKM-30E20 Rack mount kit for BVM-A20F1M
MB-510 Rack mount kit for BKM-15R

LMD ACCESSORIES
OPTIONAL PLUG-IN DECODER BOARDS
BKM-220D SDI decoder board for MEU-WX2
2x digital inputs
BKM-243HS HD/SD SDI decoder board for MEU-WX2
2x digital inputs
BKM-255DV DV signal decoder board for MEU-WX2
2x digital inputs
BKM-320D SDI decoder board for LMD-2020/1420/
7220W/5320/4420
1x digital input
ACCESSORIES
SMF-600 10 m Display interface cable
for LMD-322W/232W/172W/212/152
SU-558 Stand foot for LMD-232W/172W/212/152
SU-559 Floor stand for LMD-322W
VF-509 ENG kit for LMD-9050/9030/9020
BP-GL95/ Rechargeable Li-ion battery pack
BP-GL65/
BP-IL75
BP-M50/ Rechargeable Nickel Metal Hybrid battery pack
BP-M100
BC-M50/ Ni-Mh and Li-ion battery charger
BC-M150
RACK MOUNT KITS
MB-522A Rack mount for LMD172W
MB-523 Rack mount for LMD-212
MB-524 Rack mount for LMD-152
MB-525 Rack mount for LMD-9050/9030/9020
MB-526 Rack mount for LMD-1420/1410
MB-527 Rack mount for LMD-2020/2010
MB-528 Mounting panel for MB-525

5 additional reasons to choose LMD Series
2 Years Support
The Silver Support Pack is included as standard with all
LMD Series models and extends the support period from
the standard 1-year warranty to two years. Not only that,
but extra features and services are also included.
Operational Phone Call Centre
Operational phone support is provided to give advice
and help so that the user can get the most out of their
equipment and maximise its performance. Our telephone
support is available from Monday to Friday and in 5 lan-
guages: English, French, German, Italian and Spanish.
Collection Anywhere
In the event of equipment failure, Sony will arrange
collection of the faulty unit directly from, and delivery
of the repaired unit directly to the customer’s location -
anywhere in mainland EU, Norway or Switzerland. That
makes it simpler, quicker and even more convenient for
the customer.
Repair within 7 days
Sony will collect, repair and return the unit to the
customer’s preferred location within 7 working days. So,
minimum downtime, increased confidence and the ability
to plan your business are guaranteed.
Loan
If the faulty equipment cannot be repaired in time, the
hotline will contact the customer and arrange to have a
loan unit delivered. Arrangements will be made to collect
the loan unit as soon as confirmation is received that the
repair has been carried out satisfactorily.

STANDARD DEFINITION CONFIGURATION
BVM-A32E1WM/A20F1M/A14F5M
BKM-61D SDI/Analogue multi input adaptor
BKM-68X Analogue component/RGB adaptor
BKM-15R (for BVM-A32E1WM/A20F1M)
BKM-35H (Attachment kit for BVM-A20F1M)
MULTI FORMAT CONFIGURATION
BVM-A32E1WM/A20F1M/A14F5M
BKM-62HS HD/SD SDI input adaptor
BKM-68X Analogue component/RGB adaptor
BKM-15R (for BVM-A32E1WM/A20F1M)
BKM-35H (Attachment kit for BVM-A20F1M)
BVM-A Series Configuration
BKM-35H Control Unit attached to BVM-A20F1M

MULTIFORMATSPECIFICATIONS
BVM-A32E1WM
PICTURE SIZE 32-inch
PICTURE RESOLUTION 1000 TV lines
PHOSPHORS EBU
PITCH SIZE 0.32 mm~0.36 mm
16:9 CAPABILITY Yes
COLOUR TEMPERATURE D65/D93/User
COLOUR SYSTEM PAL/NTSC/SECAM
AUTO WHITE BALANCE BKM-14L
COMPUTER INPUT N/A
COMPOSITE VIDEO INPUT 3x (BKM-61D)
COMPONENT/RGB INPUT 1x (BKM-68X)
Y/C VIDEO INPUT 1x (BKM-61D)
HD ANALOGUE COMPONENTS 1x (BKM-68X)
HD-SDI VIDEO INPUT 2x (BKM-62HS)
DUAL LINK HD-SDI 1x (BKM-62HS)
SDI VIDEO INPUT 2x (BKM-61D)
I.LINK VIDEO INPUT N/A
EXTERNAL SYNC Yes
AUDIO INPUT N/A
BUILT-IN SPEAKER N/A
UNDERSCAN Yes
BLUE ONLY Yes
H/V DELAY Yes
TALLY LAMP Yes
REMOTE CONTROL Ethernet/parallel
RACK MOUNT N/A
POWER REQUIREMENTS AC 100 to 240V
(50/60Hz)
POWER CONSUMPTION Approx 235W max
BATTERY OPERATION N/A
DIMENSIONS (W/H/D) MM 794 x 555.4 x 694
MASS approx 96 kg
HEIGHT N/A

BROADCAST CRT MONITORS – BVM-A SERIES
BVM-A20F1M BVM-A14F5M LMD-322W
20-inch 14-inch 32-inch WS
900 TV lines 800 TV lines 1280 x 768 dots
EBU EBU N/A
0.30 mm 0.25 mm N/A
Yes Yes Yes
D65/D93/User D65/D93/User D65/D93/User
PAL/NTSC/SECAM PAL/NTSC/SECAM PAL/NTSC
BKM-14L BKM-14L N/A
N/A N/A VGA ~ SXGA
3x (BKM-61D) 3x (BKM-61D) 1x
1x (BKM-68X) 1x (BKM-68X) 1x
1x (BKM-61D) 1x (BKM-61D) 1x
1x (BKM-68X) 1x (BKM-68X) Yes
2x (BKM-62HS) 2x (BKM-62HS) 2x (BKM-243HS)
1x (BKM-62HS) 1x (BKM-62HS) N/A
2x (BKM-61D) 2x (BKM-61D) 2x (BKM-220D)
N/A N/A 2x (BKM-255DV)
Yes Yes Yes
N/A N/A Yes
N/A N/A Yes
Yes Yes Zero scan
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Ethernet/parallel Ethernet/parallel Parallel
BKM-30E20 BKM-30E14 N/A
AC 100 to 240V AC 100 to 240V AC 100 to 240V
(50/60Hz) (50/60Hz) (50/60Hz)
Approx 200W max Approx 170W max 120 W (LMD)
26W (MEU)
N/A N/A N/A
444 x 414 x 570 482 x 280 x 571 790 x 512 x 94 (LMD)
434 x 44 x 305 (MEU)
approx 40 kg approx 26 kg approx 17.6kg (LMD)
approx 4.5 kg (MEU)
9U 6U N/A

MULTIFORMAT VIEWING LCD MONITORS – LMD SERIES
LMD-232W LMD-172W LMD-212
23-inch WS 17-inch WS 21-inch
1280 x 768 dots 1280 x 768 dots 1024 x 768 dots
N/A N/A N/A
N/A N/A N/A
Yes Yes Yes
D65/D93/User D65/D93/User D65/D93/User
PAL/NTSC PAL/NTSC PAL/NTSC
N/A N/A N/A
VGA ~ SXGA VGA ~ SXGA VGA ~ SXGA
1x 1x 1x
1x 1x 1x
1x 1x 1x
Yes Yes Yes
2x (BKM-243HS) 2x (BKM-243HS) 2x (BKM-243HS)
N/A N/A N/A
2x (BKM-220D) 2x (BKM-220D) 2x (BKM-220D)
2x (BKM-255DV) 2x (BKM-255DV) 2x (BKM-255DV)
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Zero scan Zero scan Zero scan
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Parallel Parallel Parallel
N/A MB-522A MB-523
DC 12V, AC 100 DC 12V, AC 100 DC 12V, AC 100
to 240V (50/60Hz) to 240V (50/60Hz) to 240 V (50/60Hz)
65W (LMD) 53W (LMD) 84 W (LMD)
26W (MEU) 26W (MEU) 26W (MEU)
N/A N/A N/A
563 x 372 x 78 (LMD) 441 x 294 x 67 (LMD) 515 x 409 x 81
434 x 44 x 305 (MEU) 434 x 44 x 305 (MEU) 434 x 44 x 305 (MEU)
approx 6.4 kg (LMD) approx 4.8 kg (LMD) approx. 6.7 Kg (LMD)
approx 4.5 kg (MEU) approx 4.5 kg (MEU) approx 4.5 kg (MEU)
N/A 7U with MB-522A 10U with MB-523

VIEWING LCD MON
LMD-152 LMD-2020 LMD-2010
15-inch 20-inch 20-inch
1024 x 768 dots 640 x 480 dots 640 x 480 dots
N/A N/A N/A
N/A N/A N/A
Yes Yes Yes
D65/D93/User D65/D93/User D65/D93/User
PAL/NTSC PAL/NTSC PAL/NTSC
N/A N/A N/A
VGA ~ SXGA N/A N/A
1x 2x 2x
1x 1x 1x
1x 1x 1x
Yes N/A N/A
2x (BKM-243HS) N/A N/A
N/A N/A N/A
2x (BKM-220D) 1x (BKM-320D) N/A
2x (BKM-255DV) N/A N/A
Yes Yes N/A
Yes Yes Yes
Yes Yes Yes
Zero scan Yes Yes
Yes Yes N/A
Yes N/A N/A
Yes Yes N/A
Parallel Parallel Parallel
MB-524 MB-527 MB-527
DC 12V, AC 100 AC 100 to 240V AC 100 to 240V
(50/60Hz) (50/60Hz) (50/60Hz)
29W (LMD) 87W 84W
26W (MEU)
N/A N/A N/A
379 x 297 x 70 470 x 394 x 87 470 x 394 x 87
434 x 44 x 305 (MEU)
approx.4 Kg (LMD) approx 9.2kg (with stand) approx 8.7kg (with stand)
approx 4.5 kg (MEU) approx 7.5kg (w/o stand) approx 7.0kg (w/o stand)
7U with MB-524 10U with MB-527 10U with MB-527

NITORS – LMD SERIES FIE
LMD-1420 LMD-1410 LMD-9050
14-inch 14-inch 8.4-inch
640 x 480 dots 640 x 480 dots 1024 x 768 dots
N/A N/A N/A
N/A N/A N/A
Yes Yes Yes
D65/D93/User D65/D93/User D65/D93/User
PAL/NTSC PAL/NTSC PAL/NTSC
N/A N/A N/A
N/A N/A N/A
2x 2x 2x
1x 1x 1x
1x 1x 1x
N/A N/A Yes
N/A N/A 2x
N/A N/A N/A
1x (BKM-320D) N/A 2x
N/A N/A N/A
Yes N/A Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes N/A Yes
N/A N/A N/A
Yes N/A Yes
Parallel Parallel Parallel
MB-526 MB-526 MB-525 (Dual LMD)
AC 100 to 240V AC 100 to 240V AC 100 to 240V
(50/60Hz) (50/60Hz) (50/60Hz)
51W 48W approx 28W
N/A N/A Yes
343 x 304 x 87 343 x 304 x 87 216 x 206 x 136.1
approx 6.8kg (with stand) approx 6.5kg (with stand) 3.9kg with AC adaptor
approx 5.1kg (w/o stand) approx 4.8kg (w/o stand) 3kg w/o accessories
7U with MB-526 7U with MB-526 5U with MB-525

LD LCD MONITORS – LMD SERIES MULT
LMD-9030 LMD-9020 LMD-7220W
8.4-inch 8.4-inch 2x7-inch WS
640 x 480 dots 640 x 480 dots 480 x 234 dots
N/A N/A N/A
N/A N/A N/A
Yes Yes Yes
D65/D93/User D65/D93/User N/A
PAL/NTSC PAL/NTSC PAL/NTSC
N/A N/A N/A
N/A N/A N/A
2x 2x 1x per screen
1x 1x N/A
1x 1x N/A
Yes Yes N/A
N/A N/A N/A
N/A N/A N/A
2x N/A 1x per screen (BKM-320D)
N/A N/A N/A
Yes Yes N/A
Yes Yes N/A
Yes Yes N/A
Yes Yes N/A
Yes Yes N/A
N/A N/A N/A
Yes Yes Yes
Parallel Parallel Parallel
MB-525 (Dual LMD) MB-525 (Dual LMD) Yes
AC 100 to 240V AC 100 to 240V AC 100 to 240V
(50/60Hz) (50/60Hz) (50/60Hz)
approx 22W approx 20W 23W (26W max)
Yes Yes N/A
216 x 206 x 136.1 216 x 206 x 136.1 482 x 133 x 47
3.8kg with AC adaptor 3.7kg with AC adaptor Approx 2.3kg
2.9kg w/o accessories 2.8kg w/o accessories
5U with MB-525 5U with MB-525 3U

TIPLE LCD MONITORS – LMD SERIES
LMD-5320 LMD-4420
3x5.6-inch 4x4-inch
320 x 240 dots 480 x 234 dots
N/A N/A
N/A N/A
N/A N/A
N/A N/A
PAL/NTSC PAL/NTSC
N/A N/A
N/A N/A
1x per screen 1x per screen
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
1x per screen (BKM-320D) 1x per screen (BKM-320D)
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
Yes Yes
Parallel Parallel
Yes Yes
AC 100 to 240V AC 100 to 240V
(50/60Hz) (50/60Hz)
22W (28W max) 18W (26W max)
N/A N/A
482 x 131 x 47 482 x 88.1 x 47
Approx 2.3kg Approx 1.9 kg
3U 2U

© 2005 Sony Corporation.
Sony is a registered trademark of the Sony
Corporation, Japan. Sony Trinitron, HR Trinitron,
ChromaTRU and Silver Support are trademarks of
Sony Corporation. Features and specifications are
subject to change without notice.
CA Monitor Pocket Guide/GB- / /2005
