SDM-HS94/HS94P
US Model
Canadian Model
AEP Model
TFT LCD COLOR COMPUTER DISPLAY
SERVICE MANUAL

– 2 –
SDM-HS94/HS94P (E)
1. LCD CHARACTERISTICS
Type
[HS94]
: TFT Color LCD Module
Active Display Area : 19 inch(376.32(H) x 301.056(V))
Size : 404.2(W) x 330(H) x 20(D)
Pixel Pitch : 0.294 (Per one triad) x 0.294
Color Depth : 16,777,216 colors
Electrical Interface : LVDS
Operating Mode : Normally White
Backlight Unit : 4-CCFL (Cold Cathode
Fluorescent Lamp)
Type
[HS74P]
: TFT Color LCD Module
Active Display Area : 19 inch(376.32(H) x 301.056(V))
Size : 396(W) x 324(H) x 18(D)
Pixel Pitch : 0.294 (Per one triad) x 0.294
Color Depth : 262K colors
Electrical Interface : LVDS
Operating Mode : Normally White
Backlight Unit : 4-CCFL (Cold Cathode
Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : -85°[HS94]
[HS94P]
min Right : +85°min
Top :+85°min Bottom : -85°min
Left : -65°min Right : +65°min
Top :+65°min Bottom : -65°min
2-2. Luminance
[HS94] : 200(min), 250(Typ)
[HS94P] : 350(min), 400(Typ)
[HS94] : 400(min), 700(Typ)
[HS94P] : 250(min), 450(Typ)
2-3. Contrast Ratio
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
• Type : Separate Sync
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.70 V( 5%)
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.35 Vp-p
c) Color 15, 0 : 0.7 Vp-p
3) Input Impedance : 75Ω
3-3. Operating Frequency
Horizontal : 28 ~ 80kHz
Vertical : 48 ~ 75Hz
4
. Max. Resolution
Analog : 1280 x 1024 / 75Hz
Digital : 1280 x 1024 / 60Hz
5. POWER SUPPLY
5-1. Power
: AC 100~240V, 50/60Hz , 1.0A
5-2. Power Consumption
6. ENVIRONMENT
6-1. Operating Temperature: 5°C~35°C (41°F~95°F)
(Ambient)
6-2. Relative Humidity : 10%~80%
(Non-condensing)
6-3. MTBF : 50,000 Hours(Typ)
30,000 Hours(Min)
7. DIMENSIONS (with TILT/SWIVEL)
Width : 480 mm (18.9'')
Depth : 260 mm (10.2'')
Height : 440mm (17.3'')
8. WEIGHT (with TILT/SWIVEL)
Net. Weight : 7.1 kg (15.65 lbs)
Gross Weight : 9.4 kg (20.72 lbs)
CONTENTS
SPECIFICATIONS
SPECIFICATIONS ................................................... 2
SIGNAL CONNECTOR PIN ASSIGNMENT ........... 3
PRECAUTION
TIMING CHART
......................................................... 4
....................................................... 5
OPERATING INSTRUCTIONS ................................ 6
WIRING DIAGRAM ................................................. 7
BLOCK DIAGRAM .................................................. 8
DESCRIPTION OF BLOCK DIAGRAM ................ 9
LIPS BOARD BLOCK DIAGRAM ......................... 10
ADJUSTMENT ....................................................... 11
SERVICE OSD EXPLODED VIEW.........................12
EXPLODED VIEW...................................................13
EXPLODED VIEW PARTS LIST ............................14
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPMS OFF
POWER S/W OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
POWER CONSUMPTION
less than 50 W
less than 1 W
less than 1 W
less than 1 W
LED COLOR
GREEN
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-
less than 1 W

– 3 –
SDM-HS94/HS94P (E)
Signal Connector Pin Assignment
Pin Signal (DVI-D)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
T. M. D. S. Data2-
T. M. D. S. Data2+
T. M. D. S. Data2/4 Shield
T. M. D. S. Data4-
T. M. D. S. Data4+
DDC Clock
DDC Data
Analog Vertical Sync.
T. M. D. S. Data1-
T. M. D. S. Data1+
T. M. D. S. Data1/3 Shield
T. M. D. S. Data3-
T. M. D. S. Data3+
+5V Power
Ground
(return for +5V,
H. Sync. and V. Sync.)
Pin Signal (DVI-D)
18
9
17 24
16
16
17
18
19
20
21
22
23
24
Hot Plug Detect
T. M. D. S. Data0-
T. M. D. S. Data0+
T. M. D. S. Data0/5 Shield
T. M. D. S. Data5-
T. M. D. S. Data5+
T. M. D. S. Clock Shield
T. M. D. S. Clock+
T. M. D. S. Clock-
T. M. D. S. (Transition Minimized Differential Signaling)
• DVI-D Connector

– 4 –
SDM-HS94/HS94P (E)
WARNING FOR THE SAFETY-RELATED COMPONENT.
•There are some special components used in LCD
monitor that are important for safety.
These parts are
marked on the schematic diagram and the
replacement parts list.
It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
•Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
•Must mount the module using mounting holes arranged
in four corners.
•Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
•Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
•Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
•Make certain that treatment person’s body are
grounded through wrist band.
•Do not leave the module in high temperature and in
areas of high humidity for a long time.
• The module not be exposed to the direct sunlight.
•Avoid contact with water as it may a short circuit within
the module.
•If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
•If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
•Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

– 5 –
SDM-HS94/HS94P (E)
Mode H/V
Sort
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
720x400
70Hz
H– 35.00 864 640 64 64 96 224
V– 66.667Hz 525 480 3 3 39 45
640x480
60Hz
H– 37.50 840 640 16 64 120 200
V– 75.0Hz 500 480 1 3 16 20
640x480
65Hz
H– 31.500 900 720 18 108 54 180
V+ 70.156Hz 449 400 12 3 34 49
640x480
75Hz
H– 35.162 896 720 34 40 102 176
V– 59.901Hz 587 480 12 2 93 107
720x480
60Hz
H+- 35.156 1024 800 24 72 128 224
V+ 56.250Hz 625 600 1 2 22 25
800x600
56Hz
H+ 37.879 1056 800 40 128 88 256
V+ 60.317Hz 628 600 1 4 23 28
800x600
60Hz
H+ 48.077 1040 800 56 120 64 240
V+ 72.188Hz 666 600 37 6 23 66
800x600
72Hz
H+ 46.875 1056 800 16 80 160 256
V+ 75.0Hz 625 600 1 3 21 25
800x600
75Hz
H– 49.727 1152 832 32 64 224 320
V– 74.553Hz 667 624 3 3 37 43
832x624
(MAC16”)
75Hz
H– 48.363 1344 1024 24 136 160 320
V– 60.004Hz 806 768 3 6 29 38
1024x768
60Hz
H– 56.476 1328 1024 24 136 144 304
V– 70.069Hz 806 768 3 6 29 38
1024x768
70Hz
H+ 60.023 1312 1024 16 96 176 288
V+ 75.029Hz 800 768 1 3 28 32
1024x768
75Hz
H– 60.241 1328 1024 32 96 176 304
V– 74.927Hz 804 768 3 3 30 36
1024x768
(MAC19)
75Hz
H+ 67.500 1600 1152 64 128 256 448
V+ 75.000Hz 900 864 1 3 32 36
1152x864
75Hz
H– 68.681 1456 1152 32 128 144 304
V– 75.062Hz 915 870 3 3 39 45
1152x870
(MAC21)
75Hz
H– 61.795 1504 1152 30 128 194 352
V– 65.950Hz 937 900 2 4 31 37
1152x900
66Hz
H– 71.732 1472 1152 16 96 208 320
V– 76.068Hz 943 900 2 8 33 43
1152x900
75Hz
H+ 31.216 1480 1170 37 129 144 310
V+ 50.026Hz 624 584 3 3 34 40
1170x584
50Hz
H+ 60.000 1800 1280 96 112 312 520
V+ 60.000Hz 1000 960 1 3 36 40
1280x960
60Hz
H+ 63.981 1688 1280 48 112 248 408
V+ 60.020Hz 1066 1024 1 3 38 42
1280x1024
60Hz
H+ 79.976 1688 1280 16 144 248 408
V+ 75.025Hz 1066 1024 1 3 38 42
1280x1024
75Hz
Sync
Polarity Frequency
Dot
Clock
Back Porch
(F)
Blanking time
(B)
Resolution
28.350
25.175
30.240
31.500
31.505
36.000
40.000
50.000
49.500
57.285
65.000
75.000
78.750
80.000
108.000
100.000
92.940
105.590
46.200
108.000
108.000
135.000
TIMING CHART
<< Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >>
H– 31.469 800 640 16 96 48 160
V– 59.940Hz 525 480 10 2 33 45
Sync Duration
(D)
Front Porch
(C)
Video Active Time
(A)
Total Period
(E)

– 6 –
SDM-HS94/HS94P (E)
TIMING CHART
VIDEO
SYNC
B
C
E
A
D
OPERATING INSTRUCTIONS
1. (Power) switch and indicator
To turn the display on or off, press the (power) switch
upward.
The power indicator lights up in green when the display
is turned on, and lights up in orange when the monitor is
in power saving mode.
2. MENU button
This button displays or closes the main menu.
3. buttons
These buttons function as the buttons when
INPUT
selecting the menu items and making adjustments.
4. OK button
This button selects the item or executes the settings in
the menu.
5. button
This button is used to change the brightness of the
screen.
6. AC IN connector
Connect the power cord (supplied).
7. DVI-D input connector (digital RGB)
This connector inputs digital RGB video signals that
comply with DVI Rev.1.0.
8. HD15 (RGB) input connector (analog RGB)
9. Input Select
This connector inputs analog RGB video signals (0.7
Vp-p, positive) and SYNC signals. DDC (Display Data
Channel) is a standard of VESA.

– 7 –
SDM-HS94/HS94P (E)
WIRING DIAGRAM
Connector Ass’y
P/N: 6631T11016W
Connector Ass’y
P/N: 6631T20023L

– 8 –
SDM-HS94/HS94P (E)
ADC
DVI(TMDS)
Inverter
Output
(4Lamp)
EEPROM
(EDID)
EEPROM
(System)
LVDS
Panel
Vcc
Regulator Regulator
KEY
DVI-D D-Sub X1
Filter
EEPROM*1
(EDID)
MST9131B
3.3V
3.3V
2.5V
2.5V
5V
5V
MTV412PLCC
12V
DVI Rx
LAMP Connector
LIPS
OSD
Scaling Pre-Amp PLL
LVDS
Tx
+
BLOCK DIAGRAM

– 9 –
SDM-HS94/HS94P (E)
DESCRIPTION OF BLOCK DIAGRAM
1. Video Controller Part & Display Data Transmitter Part.
This part amplifies the level of video signal for the digital conversion and converts from the analog video signal to the
digital video signal using a pixel clock.
The pixel clock for each mode is generated by the PLL.
The range of the pixel clock is from 25MHz to 135MHz.
This part consists of the Scaler, LVDS Tx, TMDS Rx, Reset IC.
The Scaler gets the video signals which were converted analog to digital, interpolates input to 1280 x 1024
resolution signal and outputs 8-bit R, G, B signal to transmitter.
Especially pre-amp / ADC / Video controller/ Transmitter are merged to one chip ‘MST9131A’ by MST.
This part transmit digital signal from the Scaler to the receiver of module.
2. Power Part
This part consists of the one 3.3V and one 2.5 regulators to convert power which is provided 5V by LIPS Board.
In particular, 5V is provided for LCD Panel. There is also 12V which is for Audio power.
Also, 5V is converted 3.3V and 2.5V by regulator. Converted power is provided for IC in the main board.
3. System Controller (Microprocessor) Circuit
1) Microprocessor (U501) distinguishes polarity and frequency by calculating horizontal and vertical sync input from
signal source.
2) Microprocessor (U501) carries out power control by sending power-down trigger signal to each IC.
3) Microprocessor (U501) communicates with EEPROM (704), and MST9131A (U201) through IIC or 8 bit bus line.
It is enable to control and communicate each devices.
4) Microprocessor (U501) let User adjust screen by OSD function.

– 10 –
SDM-HS94/HS94P (E)
EMI
COMPONENTS
LINE
100 ~ 240V
INPUT RECTIFIER
AND FILTER
ENERGY
TRANSFER
OUTPUT RECTIFIER
AND FILTER
12V
5V
GND
SIGNAL
COLLECTI
ON
PHOTO-
COUPLER
ISOLATION
PWM
CONTROL
CIRCUIT
HVDC 100KHz
PRIMARY SECONDARY
50 ~ 60Hz
Operation description_LIPS
LIPS Board Block Diagram
1. EMI components.
This part contains of EMI components to comply with global marketing EMI standards like FCC, VCCI CISPR, the
circuit included a line-filter, across line capacitor and of course the primary protection fuse.
2. Input rectifier and filter.
This part function is for transfer the input AC voltage to a DC voltage through a bridge rectifier and a bulk capacitor.
3. Energy Transfer.
This part function is transfer the primary energy to secondary through a power transformer.
4. Output rectifier and filter.
This part function is to make a pulse width modulation control and to provide the driver signal to power switch, to
adjust the duty cycle during different AC input and output loading condition to achive the dc output stablize, and also
the over power protection is also monitor by this part.
5. Photo-Coupler isolation.
This part function is to feed back the dc output changing status through a photo transistor to primary controller to
achieve the stabilized dc output voltage.
6. Signal collection.
This part function is to collect the any change from the dc output and feed back to the primary through photo
transistor.

– 11 –
SDM-HS94/HS94P (E)
ADJUSTMENT
Windows EDID V1.0 User Manual
Operating System: MS Windows 98, 2000, XP
Port Setup: Windows 98 => Doesn’t need setup
Windows 2000, XP => Need to Port Setup.
This program is available for LCD Monitor only.
1. Port Setup
a) Copy “UserPort.sys” file to
“c:\WINNT\system32\drivers” folder
b) Run Userport.exe
c) Remove all default number
d) Add 300-3FF
e) Click Start button.
f) Click Exit button.
2. EDID Read & Write
1) Run WinEDID.exe
2) Edit Week of Manufacture, Year of Manufacture,
Serial Number
a) Input User Info Data
b) Click “Update” button
c) Click “ Write” button

– 12 –
SDM-HS94/HS94P (E)
Figure 1. Cable Connection
220
IBM
Compatible PC
PARALLEL PORT
Power inlet (required)
Power LED
ST Switch
Power Select Switch
(110V/220V)
Control Line
Not used
RS232C
PARALLEL
V-SYNCPOWER
ST
VGS MONITOR
E
E
V-Sync On/Off Switch
(Switch must be ON.)
F
F
A
A
B
B
C
C
15
10
5
5
69
1
1
1
14
13
25
6
5V
5V
5V
4.7K
4.7K
4.7K
74LS06
74LS06
OFF ON
OFF
ON
11
Video Signal
Generator
SERVICE OSD
1) Turn off the power switch button.
2) Press DOWN, POWER key.
3) Shows the service OSD menu. That menu is located in down side of main menu.
4) The service OSD menu contains additional menus as described below.
a) COLOR TEMP : Adjust R/G/B color values of contrast and brightness in 9300K, 6500K, user color mode.
b) INITIAL EEPROM : Initialize the EEPROM values(24C08).
c) CLEAR ETI : Initialize the used time of monitor.
d) AGING : Select aging mode.(On/Off)
e) WHITE BALANCE
AUTO : Allows you to set the R/G/B offset and gain value automatically.
MANUAL : Allows you to set the R/G/B offset and gain value manually.
f) DEFAULT TIMING : Se lect the resolution timing of the signal. Sub menus are 1152x864(VESA standard
timing) and 1152x870(MAC computer timing).
g) MODULE : Select the LCD module attached to this monitor.

– 13 –
SDM-HS94/HS94P (E)
12
4
6
SONY
1
2
5
12
3
9
11
8
7
GENS
10
EXPLODED VIEW

– 14 –
SDM-HS94/HS94P (E)
EXPLODED VIEW PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
X-2022-696-1 BEZEL ASSY (HS94, Black)
X-2022-718-1 BEZEL ASSY (HS94, Blue)
X-2022-698-1 BEZEL ASSY (HS94P, Black)
X-2022-719-1 BEZEL ASSY (HS94P, Silver)
1-805-347-21 LCD PANEL (Fujitsu) (HS94)
1-805-644-11 LCD PANEL (AU) (HS94)
1-805-751-11 LCD PANEL (AU) (HS94P)
X-2022-697-1 BACK CABINET ASSY (HS94, HS94P, Black)
X-2022-721-1 BACK CABINET ASSY (HS94, Blue)
X-4041-491-1 CENTER CABINET ASSY (HS94)
X-2022-700-1 CENTER CABINET ASSY (HS94P)
4-094-676-01 HINGE COVER (HS94)
4-094-676-31 HINGE COVER (HS94P)
X-4041-492-1 STAND ASSY (HS94)
X-2022-701-1 STAND ASSY (HS94P)
A-1066-954-A H MOUNT (HS94/HS94P)
4-094-671-31 BOTTOM VENT COVER (HS94, HS94P, Black)
4-094-671-21 BOTTOM VENT COVER (HS94, Blue)
1-900-275-71 CONNECTOR ASSY (HS94/HS94P)
A-1070-059-A G MOUNT (for Fujitsu) (HS94)
A-1070-062-A G MOUNT (for AU) (HS94)
A-1070-062-A G MOUNT (for AU) (HS94P)
A-1070-060-A A MOUNT (for Fujitsu) (HS94)
A-1070-063-A A MOUNT (for AU) (HS94)
A-1070-077-A A MOUNT (HS94P)
2-149-425-01 REAR COVER (HS94, Black)
2-149-425-31 REAR COVER (HS94, Blue)
2-149-425-11 REAR COVER (HS94P, Black)
2-149-425-41 REAR COVER (HS94P, Silver)
1-827-110-21 D-SUB CABLE (HS94)
1-827-757-11 D-SUB CABLE (HS94P)
1-829-852-11 DVI CABLE (HS94)
1-827-758-11 DVI CABLE (HS94P)
1-827-120-21 POWER-SUPPLY CORD SET (AEP) (HS94)
1-827-122-21 POWER-SUPPLY CORD SET (CH) (HS94)
1-827-118-11 POWER-SUPPLY CORD SET (U/C) (HS94P)
1-827-120-11 POWER-SUPPLY CORD SET (AEP) (HS94P)
1-827-122-11 POWER-SUPPLY CORD SET (CH) (HS94P)
2-103-460-01 QUICK SETUP GUIDE (AEP) (HS94/HS94P)
4-094-401-01 PROTECTION BAG (HS94/HS94P)
2-149-428-01 CUSHION (HS94/HS94P)
2-148-719-01 INDIVIDUAL CARTON (HS94)
2-148-721-01 INDIVIDUAL CARTON (HS94P)
2-148-303-01 CD-ROM (HS94/HS94P)
2-103-460-11 QUICK SETUP GUIDE (U/C, CH) (HS94/HS94P)
Description
Part No.
Ref. No.
ACCESSORIES & PACKING MATERIALS
9-878-265-01
English
2004IR02-1
Made in Japan
© 2004.9
Sony EMCS Corporation
Ichinomiya Tec
