About this Help Guide
This is the Vlog Monitor XQZ-IV01 Help Guide.
Note
System and application updates can present the features in your device in another way than described in this Help Guide.
Notes on use
Please be sure to read the supplied "Important Information".
Overview of this unit
Attach this unit to the rear side of Xperia and combine it with a tripod, etc. to shoot selfies with the main camera of
Xperia.
The Xperia model compatible with this unit is as follows.
- Sony Smartphone Xperia PRO-I (DC5.0V / 0.4A)
F-754-100-11(1) Copyright 2021 Sony Corporation
3

Help Guide
Vlog Monitor
XQZ-IV01
Identifying the parts
Monitor
Holder
LCD screen (size: 3.5-inch / resolution: 1280 × 720)1.
ON/OFF (Screen ON/OFF) switch2.
FLIP (Screen flip) button3.
(Brightness control) button4.
Microphone jack5.
POWER (Charging) port6.
INPUT (Input) port7.
Tripod socket hole8.
Holder attaching area9.
Magnet for attaching monitor1.
Tripod socket hole2.
Accessory shoe3.
4

Connection cable
F-754-100-11(1) Copyright 2021 Sony Corporation
5

Help Guide
Vlog Monitor
XQZ-IV01
Attaching a grip
Attach a grip with a camera mounting screw.
Note
Use a tripod with a screw shorter than 5.5 mm. The holder cannot be fixed firmly to a tripod with a screw that is 5.5 mm or longer,
causing damage to this unit.
F-754-100-11(1) Copyright 2021 Sony Corporation
Insert the camera mounting screw of the grip into the tripod socket hole of the holder.
1
Turn the camera mounting wheel of the grip to secure the holder.
2
6

Help Guide
Vlog Monitor
XQZ-IV01
Attaching a smartphone
Note
Be careful not to pinch your finger between the holder and the smartphone. It may cause bodily injury.
Position the holder between the camera key (a) and the power key (b) of the smartphone.
1
Put the smartphone on the top of the holder.
2
Fit the smartphone to the bottom of the holder.
Firmly set the smartphone so there are no gaps between the holder and the smartphone.
3
7

Carefully attach the smartphone to avoid making scratches.
F-754-100-11(1) Copyright 2021 Sony Corporation
8

Help Guide
Vlog Monitor
XQZ-IV01
Attaching the monitor
Note
Attaching the monitor improperly may cause the monitor to drop, resulting in bodily injury or malfunction of this unit.
F-754-100-11(1) Copyright 2021 Sony Corporation
Combine the magnet of the holder (a) and the holder attaching area of the monitor (b) to attach the monitor
in a well-fitting manner.
1
Adjust the monitor position.
Check that the monitor does not cover the smartphone camera.
Do not let the left side of the monitor stick out of the smartphone. It may cause communication disturbance.
2
9

Help Guide
Vlog Monitor
XQZ-IV01
Connecting a smartphone
Note
If you disconnect the connection cable when shooting, shooting will be stopped. At this time, a message may appear on the
smartphone for reconnecting of this unit. Follow the instructions.
We cannot guarantee the performance if you use a cable other than the connection cable supplied with this unit. Always use the
supplied connection cable.
When the connection cable is connected, the monitor flashes for a moment due to energization. It is not malfunction.
F-754-100-11(1) Copyright 2021 Sony Corporation
Connect one end of the connection cable supplied to this unit to the smartphone.
1
Connect the other end of the connection cable to the INPUT (Input) port of the monitor.
2
