Sony MP-CL1A User guide

MP-CL1A 3- MPA- 011-01 MP-CL1A 3-M PA- 011-01
AR
© 2016 Sony Corporation
Printed in Korea
3-M PA- 011-01
Startup Guide EN
Guía de inicio ES
Guia Rápido PT
KR
TH
CT
MP-CL1A MP-CL1A
Mobile ProjectorMobile Projector

MP-CL1A 3-MP0-xxx-01 MP-CL1A 3-MP0-xxx-01
TableofContents
Checking the Bundled Items...................................4
Parts and Controls................................................... 5
About the status of lamp....................................................................6
Getting Started ....................................................... 7
Charging the projector........................................................................7
Turning the power on..........................................................................8
Using the lens cover stand..................................................................8
Connecting your Device.........................................10
Projecting the Contents or Screen of the Connecting
Device.................................................................... 11
Connecting via screen mirroring .......................................................11
Connecting via HDMI or MHL cable ................................................. 12
Connecting to External Speakers or Headphones ..14
Connecting via Bluetooth® connection............................................. 14
Connecting using a cable.................................................................. 16
Troubleshooting.....................................................17
Specifications.........................................................18
Notes on Use..........................................................19
Trademarks........................................................... 22
WARNING.............................................................. 22
2EN 2AR
تﺎﯾﻮﺘﺤﻤﻟالوﺪﺟ
4......................................................................ﺔﻘﻓﺮﻤﻟاﺮﺻﺎﻨﻌﻟاﻦﻣ ﻖﻘﺤﺘﻟا
5.............................................................................ﻢﻜﺤﺘﻟاﺢﯿﺗﺎﻔﻣوءاﺰﺟﻷا
6 ...................................................................................................................ﺔﺒﻤﻠﻟاﺔﻟﺎﺣلﻮﺣ
7.........................................................................................ماﺪﺨﺘﺳﻻاءﺪﺑ
7................................................................................................................. ضﺮﻌﻟازﺎﻬﺟﻦﺤﺷ
8 .......................................................................................................................ﺔﻗﺎﻄﻟاﻞﻴﻐﺸﺗ
8 ................................................................................................ﺔﺳﺪﻌﻟاءﺎﻄﻏ ةﺪﻋﺎﻗماﺪﺨﺘﺳا
10........................................................................................زﺎﮭﺠﻟاﻞﯿﺻﻮﺗ
11...................................................ﻞﯿﺻﻮﺘﻟازﺎﮭﺟ ﺔﺷﺎﺷ وأتﺎﯾﻮﺘﺤﻤﻟاضﺮﻋ
11......................................................................... ﺔﺷﺎﺸﻟاسﺎﻜﻌﻧاﺔﻴﺻﺎﺧﻖﻳﺮﻃ ﻦﻋ ﻞﻴﺻﻮﺘﻟا
12.................................................................................... MHL و ٔاHDMI ﻞﺒﻛ ﺮﺒﻋﻞﻴﺻﻮﺘﻟا
14.................................................سأرتﺎﻋﺎﻤﺳ وأﺔﯿﺟرﺎﺧ تﺎﻋﺎﻤﺳ ﻞﯿﺻﻮﺗ
14......................................................................................Bluetooth® لﺎﺼﺗاﺮﺒﻋﻞﻴﺻﻮﺘﻟا
16........................................................................................................ ﻞﺒﻛ ماﺪﺨﺘﺳﺎﺑ ﻞﻴﺻﻮﺘﻟا
17.............................................................................ﮫﺣﻼﺻإو ﻞﻠﺨﻟايﺮﺤﺗ
18............................................................................................تﺎﻔﺻاﻮﻤﻟا
19.......................................................................لﺎﻤﻌﺘﺳﻻالﻮﺣتﺎﻈﺣﻼﻣ
21..................................................................................ﺔﯾرﺎﺠﺘﻟاتﺎﻣﻼﻌﻟا
22...................................................................................................ﺮﯾﺬﺤﺗ

MP-CL1A 3-MPA-011-01
More information
Refer to “Help Guide”in the menu for details about how to use
the projector.
[ Information] [Help guide]
“Help Guide”is also available on the Internet.
http://www.sony.net/SonyInfo/Support/

MP-CL1A 3-MPA-011-01
4EN
Please read the following instructions carefully before using the
projector, and retain this manual for future reference.
CAUTION
•Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation expo
sure.
•Do not point the laser light directly at eyes or people, nor look into it.
Doing so may cause serious injuries such as loss of eyesight.
Checkingthe BundledItems
•Projector (1)
•Lens cover stand (1) (see pages 8 to 9)
•USB cable (1)
•Carrying pouch (1)
•Startup Guide (this manual, 1)

MP-CL1A 3-MPA-011-01
5EN
Parts and Controls
Micro USB jack
(only for charging the
projector)
(power) button
Jog lever (−/ENTER/+)
Use this lever to select a
menu item.
Speaker
HDMI/MHL IN jack
AUDIO OUT jack
USB OUT jack
(for power supply)
Ventilation holes
(charge) lamp (red/
orange/green)
(power) lamp (white
)
Lens
Laser radiates from this
aperture.

MP-CL1A 3-MPA-011-01
* When connected with the AC Adaptor
6EN
About the status of lamp
The (power) lamp and the f
ollowing projector conditions.
White 
(charge) lamp indicate the
* The luminance of the screen may become low with the rising of the projector
body'stemperature.
Orange
* The (power) lamp (white) blinks at the same time.
Green
Status of lamp Projector condition
Power on
Power off
– Eco mode*
Status of lamp Projector condition
Charging
– Finished charging / Disconnected
Status of lamp Battery remaining
70% to 100% remaining
30% to 70% remaining
0% to 30% remaining
Empty*
Status of lamp Projector condition
Supplying power*
Low battery

MP-CL1A 3-MPA-011-01
7EN
Micro USB jack
Red
Getting Started
Charging the projector
1 Connect the projector to a wall outlet with the USB cable (
supplied) and an AC adaptor (sold separately).
The (charge) lamp lights in amber while charging.
AC adaptor
USB cable
Status of lamp Projector condition
Malfunction

MP-CL1A 3-MPA-011-01
8EN
Turning the power on
1 Press and hold the (power) button for longer than one second.
The (power) lamp lights.
To turn off the projector, press and hold the (power) button for
longer than one second.
Using the lens cover stand
When protecting the projector's lens
Attach the lens cover stand by sliding from left to right.
1 2
When projecting on a wall or in front
Attach the lens cover stand by sliding from left to right, then rotate
the stand and adjust the tilt of the projector to set the projection p
osition.
1 2

MP-CL1A 3-MPA-011-01
9EN
When projecting on the ceiling
Attach the lens cover stand by sliding it from the bottom to the
top, then rotate the stand.
1 2
Note
When taking out the projector from the carrying pouch, hold its body
tightly.

MP-CL1A 3-MPA-011-01
10EN
ConnectingyourDevice
•Android device page 11 or page 12
You can connect your device by using screen mirroring or an MHL
connection if your device is compatible.
Screen mirroring
(see page 11)
MHL connection
(see page 12)
MHL cable (sold separately)
•iOS device page 12
You can connect your device by using an HDMI connection. For the
HDMI connection, an Apple Digital AV adapter is required.
Apple Digital AV adapter HDMI cable (sold
separately) (sold separately)
•HDMI device (PC, game, and so on) page 12
You can connect your device by using an HDMI connection.
HDMI cable (sold separately)
