Sony Superbright VPL-PX40 User manual

Projector Lamp
LMP-P260
(for replacement)
Suspension Support
PSS-610
LMP-P260
Specifications Input Signal Preset Data
Optional Accessories
Dimensions
VPL-PX40
Projection system 3 LCD panels, 1 lens projection system
LCD panel
Projection lens
0.99-inchp-Si TFT Sony LCD panel with Micro Lens Array
2,359,296 pixels (786,432 pixels x 3)
Approx. 1.3 times zoom lens, F1.7 to 2.3, f37.6 to 48.8 mm
Lamp 265 W UHP Lamp
Screen coverage 40 to 300 inches (viewable area, measured diagonally)
Light output 3500 ANSI lumens*1
Color system BTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N (automatically/manually selected)
Resolution Video: 750 TV lines, RGB: 1024 x 768 pixels
Acceptable signals
Cabinet color
RGB (fH 19 to 92 kHz, fV: 48 to 92 Hz (up to UXGA), 15 kHz RGB Component
50/60 Hz,Progressive component 50/60 Hz, DTV (480/60i,575/50i,480/60p, 540/60p,
575/50p, 720/60p,720/50p, 1080/60i, 1080/50i) Composite video, Y/C video
White
Speaker Stereo speakers system 40 x 70 mm (1 5/8 x 2 7/8 inches) Max. 2W x 2
Power requirements 100 to 240 V, 50/60 Hz
Power consumption Max. 365 W, Standby 6 W
Operating temperature 0 to 35˚C (32 to 95˚F)
Operating humidity 35 to 85%
Dimensions 420 (W) x 115 (H) x 316 (D) mm (16 5/8 x 4 5/8 x 12 1/2 inches)
Mass Approx. 7.5 kg (16 lb 10 oz)
Heat dissipation 1246 BTU
Composite
VIDEO IN
INPUT A
INPUT B
INPUT C
INPUT D
USB
OUTPUT
REMOTE
CONTROL S IN/
PLUG IN POWER
Phono type, 1.0 Vp-p ±2 dB sync negative, 75 Ω
Y/C IN Mini DIN 4-pin
Y1.0Vp-p ±2 dB sync negative, 75Ω
CBurst 0.286 Vp-p ±2 dB (NTSC), 75Ωor 0.3 Vp-p ±2 dB (PAL), 75Ω
HD D-sub 15-pin (female)
Analog RGB HD D-sub 15-pin (female)
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Analog RGB HD D-sub 15-pin (female)
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
Digital RGB DVI-D (TMDS)
Analog RGB/Component
R/R-Y 0.7 Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
5 BNC (Female)
G with Sync/Y 1.0 Vp-p ±2 dB sync negative, 75 Ω
B/B-Y 0.7 Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Up (female) x 1 (Shared by INPUT A/B/C/D)
MONITOR OUT*2
HD D-sub 15-pin (female) R/R-Y, G/Y, B/B-Y: Gain Unity, 75ΩSYNC/HD, VD: 4.0 Vp-p (open), 1.0 Vp-p (75 Ω)
RS-232C D-sub 9-pin (female)
AUDIO OUT (Variable out)
Stereo mini jack, max. 1 V rms, when the input siginal is 500 mV rms, impedance less than 5 kΩ
ETHERNET port RJ-45: 10 BASE-T/100 BASE-TX
Stereo mini jack
5.0 Vp-p, plug in power, DC 5V
UL, cUL, DHHS, FCC Class A, IC Class A, NEMKO, CE (LVD), CE (EMC), C-Tick, CCC, VCCI class B, JEITA
Laser type Class II
Wavelength
Output
Remote commander, Monitor Cable (2 m): HD D-sub 15-pin to HD D-sub 15-pin, USB Cable A type to B type (2 m),
AA size Battery (x 2), Lens Cap, Air Filter, Operating Manual, Installation Manual for dealers
645 nm
1 mW
Model
Optica
Signals
General
Inputs/Outputs
Safety regulations
Laser beam
Supplied
accessories
No.
1
2
3
4
5
6*
7*
8*
9*
10*
11*
12*
13*
14*
15*
16*
17*
18*
19*
20*
21*
22*
23*
24*
25*
26*
27*
28
29
30*
31
32*
33
34*
35
36*
37
38
39
43
44
45
47
48
50
52
Preset Signal
VIDEO/60 60Hz 15.734 59.940
15.625 50.000
15.734 59.940
SonG/Y
15.625 50.000 or
33.750 60.000
Composite
31.469 70.086 P/N
37.861 85.080 P/N
24.823 56.416 N/N
31.469 70.086 N/P
37.861 85.080 N/P
31.469 59.940 N/N
35.000 66.667 N/N
37.861 72.809 N/N
37.500 75.000 N/N
43.269 85.008 N/N
35.156 56.250 P/P
37.879 60.317 P/P
48.077 72.188 P/P
46.875 75.000 P/P
53.674 85.061 P/P
49.724 74.550 N/N
35.524 86.958 P/P
48.363 60.004 N/N
56.476 69.955 N/N
60.023 75.029 P/P
68.677 84.997 P/P
63.995 70.019 P/P
67.500 75.000 P/P
77.487 85.057 P/P
61.795 65.960 N/N
71.713 76.047
Cneg(N/P)
60.000 60.000 P/P
75.000 75.000 P/P
46.433 86.872 P/P
53.316 50.062
SonG(P/P)
63.974 60.013 P/P
79.976 75.025 P/P
91.146 85.024 P/P
75.000 60.000 P/P
31.470 60.000 SonG
31.250 50.000 SonG
28.130 50.000
45.000 60.000
37.500 50.000
33.750 60.000
63.981 60.020 N/N
VIDEO/50 50Hz
480/60i
575/50i
HDTV 1035/60i, 1080/60i
640x350
640x400
640x480
800x600
832x624
1024x768
1152x864
1152x900
1280x960
1280x1024
1600x1200
VGA-1
(VGA350)
VESA 85(VGA350)
NEC PC98
VGA-2(TEXT)/VESA70
VESA 85(VGA400)
VESA 60
Mac 13
VESA 72
VESA 75(IBM M3)
VESA 85(IBM M4)
VESA 56
VESA 60
VESA 72
VESA 75(IBM M5)
VESA 85
Mac 16
VESA 43(8514)
VESA 60
VESA 70
VESA 75
VESA 85
VESA 70
VESA 75
VESA 85
SUN LO
SUN HI
VESA 60
VESA 75
VESA 43
SGI-5
VESA 60
SXGA VESA75
SXGA VESA85
UXGA VESA60
480/60p
(double frequency of NTSC)
575/50p (double frequency of PAL)
1080/50i
720/60p
720/50p
540/60p
1400x1050 SXGA+
fH
(kHz) fV (Hz) H/V
When the signal other than ones in "Preset Signals" are input,
the picture may not display correctly. When the aspect ratio of
an input signal is other than 4:3, a part of the screen is
displayed in black. The UXGA signal can be projected only
when user set the frequency of a computer 60Hz. The digital
input complies with the signals marked with asterisks(*) on the
table. When the digital signal output from a computer is a
signal other than the signals marked with asterisks(*) among
the memory numbers 6 to 39, it is automatically output
according to the specifications of the projector. The memory
numbers 22 and 34 are the interlace signals.
Signal Cables
SMF-400
(HD D-sub 15-pin to 5 BNC, for
RGB signal)
SMF-410
(HD D-sub 15-pin to HD D-sub
15-pin, for RGB signal)
Optional Lenses
VPLL-FM22
(Fixed short-focus lens)
VPLL-ZM102
(Long-focus zoom lens)
*1ANSI lumens is a measuring method of the American National Standards Instisute IT7. 228. Since there is no uniform method of measuring
brightness, specifications will vary among manufactures. *2DIGITAL RGB and Component signals are not output from the MONITOR OUT
terminal. *3Not available in some areas. For details, please contact your nearest Sony office.
©2002 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
Mac is registered trademark of Apple Computer, Inc.
Printed in Japan on recycled paper.MK07852V1FRT02NOV
Distributed by
420(16 5/8)
145(5 3/4)
87(3 1/2)
316(12 1/2)
115(4 5/8)
Power consumption during standby 6.0W or less.
Halogenated flame retardant is not used in cabinets.
Lead-free solder is used for soldering.
Polystyrene form for cushioning has been eliminated
and corrugated paper is used as buffer materials.
Unit:mm (inches)

For Powerful Presentations
…the VPL-PX40
The Key to Smart Presentations
…the Sony VPL-PX40 Projector
Leave a lasting impression. With its brightness of
3500 ANSI lumens* and a high contrast level, the
VPL-PX40 is the easy and effective way to view
presentations in any environment or lighting
condition. Its 3D Gamma Correction and 3D Digital
Comb Filter features, plus an RGB Enhancer for
RGB and DDE for video, combine to make pictures
always look their best.
*ANSI lumens is a measurement unit defined by the American
National Standards Institute IT7.228. Since there is no uniform
method of measuring brightness, specifications may vary
among manufacturers.
High Brightness and Contrast
With a new optical system incorporating Sony LCD
panels and a 265 W UHP lamp,the VPL-PX40 offers
an outstanding brightness of 3500 ANSI lumens.
High-quality images can be projected even in high
ambient-light conditions, producing an extremely
highcontrast ratio.
High Resolution
By utilizing three 0.99-inch XGA
LCD panels, the VPL-PX40 provides
a clean and detailed reproduction
of all images.
Digital Signal Processing
The VPL-PX40 achieves high picture quality with
Sony original Digital Signal Processing technology.
The VPL-PX40 provides digital signal processing by
adopting a newly developed driver for the LCD
panel that directly accepts digital signals; thus the
projector is capable of projecting images with high
accuracy.
Smart APA
Dot phase and image size or shift can be
automatically adjusted to their optimal settings
according to input signals.
3D Gamma Correction
The 3D Digital Gamma Correction circuit
simultaneously provides superb grayscale
reproduction and helps to improve overall picture
uniformity.
Dynamic Detail Enhancer (DDE)
This unique Sony technology generates high
quality images through the Interlace/Progressive
conversion processor. Signals of film-originated
sources converted through 2-3 and 2-2 pull down
process are detected, resulting in extremely
accurate image reproduction.
RGB Enhancer
For a crisper RGB image, the VPL-PX40 is equipped
with an RGB Enhancer function. A simple
adjustment provides heightened image quality to
match any image source – whether text, photos, or
graphics.
The Benefits of Networking
The VPL-PX40 can even be controlled via a TCP/IP-based
network connection, which also enables users to
receive maintenance information. This functionality is
ideal for offices and schools equipped with a Local Area
Network (LAN).
Back-to-Front Tilt
The VPL-PX40 can be tilted upwards or
downwards by 90 degrees. This flexibility
greatly expands the projector’s
application possibilities.
Digital Keystone Adjustment
Keystone distortion, caused when the projection angle is
not properly calibrated, can be easily corrected within a
wide adjustment range of +/- 20 degrees. The necessary
adjustments can be easily made via the On-Screen Display.
On-Screen Display (OSD)
The OSD, which provides
easy projector control, is
available in a choice of nine
languages: English, French,
Spanish, German, Italian,
Japanese, Chinese,
Portuguese, or Korean.
Direct Power On and Off
With this function, standby mode can be skipped over
to activate the VPL-PX40 immediately. And thanks to a
cooling fan with drive circuitry that works even after the
power has been cut, the projector can be turned on or
off using a circuit-breaker switch on a switchboard.
Password-Authentication System
This function restricts unauthorized use of the projector.
Once a password has been set, the VPL-PX40 cannot be
used without it.
Optional Lenses
Two optional lenses are available, giving users the
ability to customize the VPL-PX40 to perfectly suit any
projection environment.
Throwing Distance
VPLL-FM22
❚Fixed short-focus lens
❚Throw ratio*: 0.9:1
*Throw ratio is the distance between the center of the projector lens and
the screen, divided by the screen width.
Multiple Inputs
Using a built-in high-performance scan converter,
the VPL-PX40 accepts a wide range of input signals:
composite video, S-Video, Y/R-Y/B-Y, Y/PB/PR and
RGB video, as well as analog and digital computer
signals. A variety of DTV signals
(480/60i,575/50i,540/60p,480/60p,575/50p,720/60p,
720/50p, 1080/60i, and 1080/50i) are also fully
supported, extending its potential even further.
DVI interface
The VPL-PX40 accepts digital signals directly thanks
to its DVI interface.
4-times Digital Zoom
To help convey a clear message, the 4-times Digital
Zoom function allows users to zoom in on any part
of the projected image during a presentation.
Stereo Sound
Users can improve the impact and effectiveness of
presentations with stereo audio output from the
built-in stereo-speaker system.
Useful Remote-Control Unit
The supplied remote-control unit is
equipped with keys to control
various projector functions, for
smooth, persuasive presentations
every time. It has an integrated
mouse function for point-and-click
control of a USB-connected
computer, and it can work as a laser
pointer to direct the audience’s
attention and guide them through
the presentation.
Complete the experience. An integrated stereo-
speaker system delivers audio to support the
presentation visuals for even greater impact.
A laser-pointer, mouse function and 4-times Digital
Zoom – all included on the supplied remote-
control unit – help to make presentations run
smoothly and keep the audience enthralled. The
projector itself – the main presentation tool – goes
virtually unnoticed, because of near-silent
operation.
The broad installation capabilities of the VPL-PX40
enable the projector to be mounted on the ceiling
or floor, or installed in a rear-projection system.
Installation flexibility is further enhanced by the
choice of two optional lenses. With the Direct
Power-On function, the projector can be turned on
or off quickly using a circuit-breaker switch on a
switchboard, and, for added security, the VPL-
PX40 incorporates a password-authentication
system.
Visuals
Audio
Presentation Tools
Flexibility
Picture Quality
Presentation Effectiveness
Input Versatility
Flexibility
Screen Size
*80 100 120 150 180 200 250 300
Minimum
a'
3350 4130 4900 6070 7230 8000 9940 11880
132 1/8 162 5/8 193 1/8 238 7/8 284 5/8 315 1/8 391 3/8 467 5/8
4140 5110 6080 7530 8990 9960 12380 14810
163 201 1/4 239 3/8 296 3/4 354 392 1/4 487 3/4 583 1/4
Maximum
b+693 b+846 b+998 b+1227 b+1455 b+1608 b+1989 b+2370
b+27 3/8 b+33 3/8 b+39 3/8 b+48 3/8 b+57 3/8 b+63 3/8 b+78 3/8 b+93 3/8
150/175/200/250/275/300mm (6, 7, 7 7/8, 9 7/8, 10 7/8, 11 7/8 inches) adjustable when using PSS-610
x
b
Screen Size
*40 80 100 150 180 200 250 300
Minimum
a
1490 3040 3820 5750 6920 7690 9630 11570
58 7/8 119 7/8 150 3/8 226 5/8 272 3/8 302 7/8 379 1/8 455 1/2
1890 3830 4800 7220 8680 9650 12070 14500
74 3/8 150 3/4 189 284 1/2 341 3/4 380 475 1/2 571
Maximum
x-305 x-610 x-762 x-1143 x-1372 x-1524 x-1905 x-2286
x-12 x-24 x-30 x-45 x-54 x-60 x-75 1/8 x-90 1/8
x-392 x-697 x-849 x-1230 x-1459 x-1611 x-1992 x-2373
x-15 1/2 x-27 1/2 x-33 1/2 x-48 1/2 x-57 1/2 x-63 1/2 x-78 1/2 x-93 1/2
b
c
Floor Installation
Floor installation (Standard Lens)
Ceiling Installation
Ceiling installation using the PSS-610
Projector Suspension Support (Standard Lens)
a: distance between the screen to the center of the lens
b: distance between the floor and the center of the lens
c: distance between the floor and the bottom of the adjusters of the projector
x: free
*: Viewable area,measured diagonally
a': distance from the center of the upper ceiling mount bracket hole (rear) to the screen
b: distance between the ceiling and the surface of the mounting bracket
x: distance between the ceiling and the center of the screen
*: Viewable area,measured diagonally
PSS-610 Projector Suspension Support (not supplied)
a
x
b
c
a'
x
b
VPLL-ZM102
❚1.5-times zoom long-focus lens
❚Throw ratio*: 3.35-4.9:1

Projector Lamp
LMP-P260
(for replacement)
Suspension Support
PSS-610
LMP-P260
Specifications Input Signal Preset Data
Optional Accessories
Dimensions
VPL-PX40
Projection system 3 LCD panels, 1 lens projection system
LCD panel
Projection lens
0.99-inchp-Si TFT Sony LCD panel with Micro Lens Array
2,359,296 pixels (786,432 pixels x 3)
Approx. 1.3 times zoom lens, F1.7 to 2.3, f37.6 to 48.8 mm
Lamp 265 W UHP Lamp
Screen coverage 40 to 300 inches (viewable area, measured diagonally)
Light output 3500 ANSI lumens*1
Color system BTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N (automatically/manually selected)
Resolution Video: 750 TV lines, RGB: 1024 x 768 pixels
Acceptable signals
Cabinet color
RGB (fH 19 to 92 kHz, fV: 48 to 92 Hz (up to UXGA), 15 kHz RGB Component
50/60 Hz,Progressive component 50/60 Hz, DTV (480/60i,575/50i,480/60p, 540/60p,
575/50p, 720/60p,720/50p, 1080/60i, 1080/50i) Composite video, Y/C video
White
Speaker Stereo speakers system 40 x 70 mm (1 5/8 x 2 7/8 inches) Max. 2W x 2
Power requirements 100 to 240 V, 50/60 Hz
Power consumption Max. 365 W, Standby 6 W
Operating temperature 0 to 35˚C (32 to 95˚F)
Operating humidity 35 to 85%
Dimensions 420 (W) x 115 (H) x 316 (D) mm (16 5/8 x 4 5/8 x 12 1/2 inches)
Mass Approx. 7.5 kg (16 lb 10 oz)
Heat dissipation 1246 BTU
Composite
VIDEO IN
INPUT A
INPUT B
INPUT C
INPUT D
USB
OUTPUT
REMOTE
CONTROL S IN/
PLUG IN POWER
Phono type, 1.0 Vp-p ±2 dB sync negative, 75 Ω
Y/C IN Mini DIN 4-pin
Y1.0Vp-p ±2 dB sync negative, 75Ω
CBurst 0.286 Vp-p ±2 dB (NTSC), 75Ωor 0.3 Vp-p ±2 dB (PAL), 75Ω
HD D-sub 15-pin (female)
Analog RGB HD D-sub 15-pin (female)
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Analog RGB HD D-sub 15-pin (female)
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
Digital RGB DVI-D (TMDS)
Analog RGB/Component
R/R-Y 0.7 Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
5 BNC (Female)
G with Sync/Y 1.0 Vp-p ±2 dB sync negative, 75 Ω
B/B-Y 0.7 Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Up (female) x 1 (Shared by INPUT A/B/C/D)
MONITOR OUT*2
HD D-sub 15-pin (female) R/R-Y, G/Y, B/B-Y: Gain Unity, 75ΩSYNC/HD, VD: 4.0 Vp-p (open), 1.0 Vp-p (75 Ω)
RS-232C D-sub 9-pin (female)
AUDIO OUT (Variable out)
Stereo mini jack, max. 1 V rms, when the input siginal is 500 mV rms, impedance less than 5 kΩ
ETHERNET port RJ-45: 10 BASE-T/100 BASE-TX
Stereo mini jack
5.0 Vp-p, plug in power, DC 5V
UL, cUL, DHHS, FCC Class A, IC Class A, NEMKO, CE (LVD), CE (EMC), C-Tick, CCC, VCCI class B, JEITA
Laser type Class II
Wavelength
Output
Remote commander, Monitor Cable (2 m): HD D-sub 15-pin to HD D-sub 15-pin, USB Cable A type to B type (2 m),
AA size Battery (x 2), Lens Cap, Air Filter, Operating Manual, Installation Manual for dealers
645 nm
1 mW
Model
Optica
Signals
General
Inputs/Outputs
Safety regulations
Laser beam
Supplied
accessories
No.
1
2
3
4
5
6*
7*
8*
9*
10*
11*
12*
13*
14*
15*
16*
17*
18*
19*
20*
21*
22*
23*
24*
25*
26*
27*
28
29
30*
31
32*
33
34*
35
36*
37
38
39
43
44
45
47
48
50
52
Preset Signal
VIDEO/60 60Hz 15.734 59.940
15.625 50.000
15.734 59.940
SonG/Y
15.625 50.000 or
33.750 60.000
Composite
31.469 70.086 P/N
37.861 85.080 P/N
24.823 56.416 N/N
31.469 70.086 N/P
37.861 85.080 N/P
31.469 59.940 N/N
35.000 66.667 N/N
37.861 72.809 N/N
37.500 75.000 N/N
43.269 85.008 N/N
35.156 56.250 P/P
37.879 60.317 P/P
48.077 72.188 P/P
46.875 75.000 P/P
53.674 85.061 P/P
49.724 74.550 N/N
35.524 86.958 P/P
48.363 60.004 N/N
56.476 69.955 N/N
60.023 75.029 P/P
68.677 84.997 P/P
63.995 70.019 P/P
67.500 75.000 P/P
77.487 85.057 P/P
61.795 65.960 N/N
71.713 76.047
Cneg(N/P)
60.000 60.000 P/P
75.000 75.000 P/P
46.433 86.872 P/P
53.316 50.062
SonG(P/P)
63.974 60.013 P/P
79.976 75.025 P/P
91.146 85.024 P/P
75.000 60.000 P/P
31.470 60.000 SonG
31.250 50.000 SonG
28.130 50.000
45.000 60.000
37.500 50.000
33.750 60.000
63.981 60.020 N/N
VIDEO/50 50Hz
480/60i
575/50i
HDTV 1035/60i, 1080/60i
640x350
640x400
640x480
800x600
832x624
1024x768
1152x864
1152x900
1280x960
1280x1024
1600x1200
VGA-1
(VGA350)
VESA 85(VGA350)
NEC PC98
VGA-2(TEXT)/VESA70
VESA 85(VGA400)
VESA 60
Mac 13
VESA 72
VESA 75(IBM M3)
VESA 85(IBM M4)
VESA 56
VESA 60
VESA 72
VESA 75(IBM M5)
VESA 85
Mac 16
VESA 43(8514)
VESA 60
VESA 70
VESA 75
VESA 85
VESA 70
VESA 75
VESA 85
SUN LO
SUN HI
VESA 60
VESA 75
VESA 43
SGI-5
VESA 60
SXGA VESA75
SXGA VESA85
UXGA VESA60
480/60p
(double frequency of NTSC)
575/50p (double frequency of PAL)
1080/50i
720/60p
720/50p
540/60p
1400x1050 SXGA+
fH
(kHz) fV (Hz) H/V
When the signal other than ones in "Preset Signals" are input,
the picture may not display correctly. When the aspect ratio of
an input signal is other than 4:3, a part of the screen is
displayed in black. The UXGA signal can be projected only
when user set the frequency of a computer 60Hz. The digital
input complies with the signals marked with asterisks(*) on the
table. When the digital signal output from a computer is a
signal other than the signals marked with asterisks(*) among
the memory numbers 6 to 39, it is automatically output
according to the specifications of the projector. The memory
numbers 22 and 34 are the interlace signals.
Signal Cables
SMF-400
(HD D-sub 15-pin to 5 BNC, for
RGB signal)
SMF-410
(HD D-sub 15-pin to HD D-sub
15-pin, for RGB signal)
Optional Lenses
VPLL-FM22
(Fixed short-focus lens)
VPLL-ZM102
(Long-focus zoom lens)
*1ANSI lumens is a measuring method of the American National Standards Instisute IT7. 228. Since there is no uniform method of measuring
brightness, specifications will vary among manufactures. *2DIGITAL RGB and Component signals are not output from the MONITOR OUT
terminal. *3Not available in some areas. For details, please contact your nearest Sony office.
©2002 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
Mac is registered trademark of Apple Computer, Inc.
Printed in Japan on recycled paper.MK07852V1FRT02NOV
Distributed by
420(16 5/8)
145(5 3/4)
87(3 1/2)
316(12 1/2)
115(4 5/8)
Power consumption during standby 6.0W or less.
Halogenated flame retardant is not used in cabinets.
Lead-free solder is used for soldering.
Polystyrene form for cushioning has been eliminated
and corrugated paper is used as buffer materials.
Unit:mm (inches)

For Powerful Presentations
…the VPL-PX40
The Key to Smart Presentations
…the Sony VPL-PX40 Projector
Leave a lasting impression. With its brightness of
3500 ANSI lumens* and a high contrast level, the
VPL-PX40 is the easy and effective way to view
presentations in any environment or lighting
condition. Its 3D Gamma Correction and 3D Digital
Comb Filter features, plus an RGB Enhancer for
RGB and DDE for video, combine to make pictures
always look their best.
*ANSI lumens is a measurement unit defined by the American
National Standards Institute IT7.228. Since there is no uniform
method of measuring brightness, specifications may vary
among manufacturers.
High Brightness and Contrast
With a new optical system incorporating Sony LCD
panels and a 265 W UHP lamp,the VPL-PX40 offers
an outstanding brightness of 3500 ANSI lumens.
High-quality images can be projected even in high
ambient-light conditions, producing an extremely
highcontrast ratio.
High Resolution
By utilizing three 0.99-inch XGA
LCD panels, the VPL-PX40 provides
a clean and detailed reproduction
of all images.
Digital Signal Processing
The VPL-PX40 achieves high picture quality with
Sony original Digital Signal Processing technology.
The VPL-PX40 provides digital signal processing by
adopting a newly developed driver for the LCD
panel that directly accepts digital signals; thus the
projector is capable of projecting images with high
accuracy.
Smart APA
Dot phase and image size or shift can be
automatically adjusted to their optimal settings
according to input signals.
3D Gamma Correction
The 3D Digital Gamma Correction circuit
simultaneously provides superb grayscale
reproduction and helps to improve overall picture
uniformity.
Dynamic Detail Enhancer (DDE)
This unique Sony technology generates high
quality images through the Interlace/Progressive
conversion processor. Signals of film-originated
sources converted through 2-3 and 2-2 pull down
process are detected, resulting in extremely
accurate image reproduction.
RGB Enhancer
For a crisper RGB image, the VPL-PX40 is equipped
with an RGB Enhancer function. A simple
adjustment provides heightened image quality to
match any image source – whether text, photos, or
graphics.
The Benefits of Networking
The VPL-PX40 can even be controlled via a TCP/IP-based
network connection, which also enables users to
receive maintenance information. This functionality is
ideal for offices and schools equipped with a Local Area
Network (LAN).
Back-to-Front Tilt
The VPL-PX40 can be tilted upwards or
downwards by 90 degrees. This flexibility
greatly expands the projector’s
application possibilities.
Digital Keystone Adjustment
Keystone distortion, caused when the projection angle is
not properly calibrated, can be easily corrected within a
wide adjustment range of +/- 20 degrees. The necessary
adjustments can be easily made via the On-Screen Display.
On-Screen Display (OSD)
The OSD, which provides
easy projector control, is
available in a choice of nine
languages: English, French,
Spanish, German, Italian,
Japanese, Chinese,
Portuguese, or Korean.
Direct Power On and Off
With this function, standby mode can be skipped over
to activate the VPL-PX40 immediately. And thanks to a
cooling fan with drive circuitry that works even after the
power has been cut, the projector can be turned on or
off using a circuit-breaker switch on a switchboard.
Password-Authentication System
This function restricts unauthorized use of the projector.
Once a password has been set, the VPL-PX40 cannot be
used without it.
Optional Lenses
Two optional lenses are available, giving users the
ability to customize the VPL-PX40 to perfectly suit any
projection environment.
Throwing Distance
VPLL-FM22
❚Fixed short-focus lens
❚Throw ratio*: 0.9:1
*Throw ratio is the distance between the center of the projector lens and
the screen, divided by the screen width.
Multiple Inputs
Using a built-in high-performance scan converter,
the VPL-PX40 accepts a wide range of input signals:
composite video, S-Video, Y/R-Y/B-Y, Y/PB/PR and
RGB video, as well as analog and digital computer
signals. A variety of DTV signals
(480/60i,575/50i,540/60p,480/60p,575/50p,720/60p,
720/50p, 1080/60i, and 1080/50i) are also fully
supported, extending its potential even further.
DVI interface
The VPL-PX40 accepts digital signals directly thanks
to its DVI interface.
4-times Digital Zoom
To help convey a clear message, the 4-times Digital
Zoom function allows users to zoom in on any part
of the projected image during a presentation.
Stereo Sound
Users can improve the impact and effectiveness of
presentations with stereo audio output from the
built-in stereo-speaker system.
Useful Remote-Control Unit
The supplied remote-control unit is
equipped with keys to control
various projector functions, for
smooth, persuasive presentations
every time. It has an integrated
mouse function for point-and-click
control of a USB-connected
computer, and it can work as a laser
pointer to direct the audience’s
attention and guide them through
the presentation.
Complete the experience. An integrated stereo-
speaker system delivers audio to support the
presentation visuals for even greater impact.
A laser-pointer, mouse function and 4-times Digital
Zoom – all included on the supplied remote-
control unit – help to make presentations run
smoothly and keep the audience enthralled. The
projector itself – the main presentation tool – goes
virtually unnoticed, because of near-silent
operation.
The broad installation capabilities of the VPL-PX40
enable the projector to be mounted on the ceiling
or floor, or installed in a rear-projection system.
Installation flexibility is further enhanced by the
choice of two optional lenses. With the Direct
Power-On function, the projector can be turned on
or off quickly using a circuit-breaker switch on a
switchboard, and, for added security, the VPL-
PX40 incorporates a password-authentication
system.
Visuals
Audio
Presentation Tools
Flexibility
Picture Quality
Presentation Effectiveness
Input Versatility
Flexibility
Screen Size
*80 100 120 150 180 200 250 300
Minimum
a'
3350 4130 4900 6070 7230 8000 9940 11880
132 1/8 162 5/8 193 1/8 238 7/8 284 5/8 315 1/8 391 3/8 467 5/8
4140 5110 6080 7530 8990 9960 12380 14810
163 201 1/4 239 3/8 296 3/4 354 392 1/4 487 3/4 583 1/4
Maximum
b+693 b+846 b+998 b+1227 b+1455 b+1608 b+1989 b+2370
b+27 3/8 b+33 3/8 b+39 3/8 b+48 3/8 b+57 3/8 b+63 3/8 b+78 3/8 b+93 3/8
150/175/200/250/275/300mm (6, 7, 7 7/8, 9 7/8, 10 7/8, 11 7/8 inches) adjustable when using PSS-610
x
b
Screen Size
*40 80 100 150 180 200 250 300
Minimum
a
1490 3040 3820 5750 6920 7690 9630 11570
58 7/8 119 7/8 150 3/8 226 5/8 272 3/8 302 7/8 379 1/8 455 1/2
1890 3830 4800 7220 8680 9650 12070 14500
74 3/8 150 3/4 189 284 1/2 341 3/4 380 475 1/2 571
Maximum
x-305 x-610 x-762 x-1143 x-1372 x-1524 x-1905 x-2286
x-12 x-24 x-30 x-45 x-54 x-60 x-75 1/8 x-90 1/8
x-392 x-697 x-849 x-1230 x-1459 x-1611 x-1992 x-2373
x-15 1/2 x-27 1/2 x-33 1/2 x-48 1/2 x-57 1/2 x-63 1/2 x-78 1/2 x-93 1/2
b
c
Floor Installation
Floor installation (Standard Lens)
Ceiling Installation
Ceiling installation using the PSS-610
Projector Suspension Support (Standard Lens)
a: distance between the screen to the center of the lens
b: distance between the floor and the center of the lens
c: distance between the floor and the bottom of the adjusters of the projector
x: free
*: Viewable area,measured diagonally
a': distance from the center of the upper ceiling mount bracket hole (rear) to the screen
b: distance between the ceiling and the surface of the mounting bracket
x: distance between the ceiling and the center of the screen
*: Viewable area,measured diagonally
PSS-610 Projector Suspension Support (not supplied)
a
x
b
c
a'
x
b
VPLL-ZM102
❚1.5-times zoom long-focus lens
❚Throw ratio*: 3.35-4.9:1

For Powerful Presentations
…the VPL-PX40
The Key to Smart Presentations
…the Sony VPL-PX40 Projector
Leave a lasting impression. With its brightness of
3500 ANSI lumens* and a high contrast level, the
VPL-PX40 is the easy and effective way to view
presentations in any environment or lighting
condition. Its 3D Gamma Correction and 3D Digital
Comb Filter features, plus an RGB Enhancer for
RGB and DDE for video, combine to make pictures
always look their best.
*ANSI lumens is a measurement unit defined by the American
National Standards Institute IT7.228. Since there is no uniform
method of measuring brightness, specifications may vary
among manufacturers.
High Brightness and Contrast
With a new optical system incorporating Sony LCD
panels and a 265 W UHP lamp,the VPL-PX40 offers
an outstanding brightness of 3500 ANSI lumens.
High-quality images can be projected even in high
ambient-light conditions, producing an extremely
highcontrast ratio.
High Resolution
By utilizing three 0.99-inch XGA
LCD panels, the VPL-PX40 provides
a clean and detailed reproduction
of all images.
Digital Signal Processing
The VPL-PX40 achieves high picture quality with
Sony original Digital Signal Processing technology.
The VPL-PX40 provides digital signal processing by
adopting a newly developed driver for the LCD
panel that directly accepts digital signals; thus the
projector is capable of projecting images with high
accuracy.
Smart APA
Dot phase and image size or shift can be
automatically adjusted to their optimal settings
according to input signals.
3D Gamma Correction
The 3D Digital Gamma Correction circuit
simultaneously provides superb grayscale
reproduction and helps to improve overall picture
uniformity.
Dynamic Detail Enhancer (DDE)
This unique Sony technology generates high
quality images through the Interlace/Progressive
conversion processor. Signals of film-originated
sources converted through 2-3 and 2-2 pull down
process are detected, resulting in extremely
accurate image reproduction.
RGB Enhancer
For a crisper RGB image, the VPL-PX40 is equipped
with an RGB Enhancer function. A simple
adjustment provides heightened image quality to
match any image source – whether text, photos, or
graphics.
The Benefits of Networking
The VPL-PX40 can even be controlled via a TCP/IP-based
network connection, which also enables users to
receive maintenance information. This functionality is
ideal for offices and schools equipped with a Local Area
Network (LAN).
Back-to-Front Tilt
The VPL-PX40 can be tilted upwards or
downwards by 90 degrees. This flexibility
greatly expands the projector’s
application possibilities.
Digital Keystone Adjustment
Keystone distortion, caused when the projection angle is
not properly calibrated, can be easily corrected within a
wide adjustment range of +/- 20 degrees. The necessary
adjustments can be easily made via the On-Screen Display.
On-Screen Display (OSD)
The OSD, which provides
easy projector control, is
available in a choice of nine
languages: English, French,
Spanish, German, Italian,
Japanese, Chinese,
Portuguese, or Korean.
Direct Power On and Off
With this function, standby mode can be skipped over
to activate the VPL-PX40 immediately. And thanks to a
cooling fan with drive circuitry that works even after the
power has been cut, the projector can be turned on or
off using a circuit-breaker switch on a switchboard.
Password-Authentication System
This function restricts unauthorized use of the projector.
Once a password has been set, the VPL-PX40 cannot be
used without it.
Optional Lenses
Two optional lenses are available, giving users the
ability to customize the VPL-PX40 to perfectly suit any
projection environment.
Throwing Distance
VPLL-FM22
❚Fixed short-focus lens
❚Throw ratio*: 0.9:1
*Throw ratio is the distance between the center of the projector lens and
the screen, divided by the screen width.
Multiple Inputs
Using a built-in high-performance scan converter,
the VPL-PX40 accepts a wide range of input signals:
composite video, S-Video, Y/R-Y/B-Y, Y/PB/PR and
RGB video, as well as analog and digital computer
signals. A variety of DTV signals
(480/60i,575/50i,540/60p,480/60p,575/50p,720/60p,
720/50p, 1080/60i, and 1080/50i) are also fully
supported, extending its potential even further.
DVI interface
The VPL-PX40 accepts digital signals directly thanks
to its DVI interface.
4-times Digital Zoom
To help convey a clear message, the 4-times Digital
Zoom function allows users to zoom in on any part
of the projected image during a presentation.
Stereo Sound
Users can improve the impact and effectiveness of
presentations with stereo audio output from the
built-in stereo-speaker system.
Useful Remote-Control Unit
The supplied remote-control unit is
equipped with keys to control
various projector functions, for
smooth, persuasive presentations
every time. It has an integrated
mouse function for point-and-click
control of a USB-connected
computer, and it can work as a laser
pointer to direct the audience’s
attention and guide them through
the presentation.
Complete the experience. An integrated stereo-
speaker system delivers audio to support the
presentation visuals for even greater impact.
A laser-pointer, mouse function and 4-times Digital
Zoom – all included on the supplied remote-
control unit – help to make presentations run
smoothly and keep the audience enthralled. The
projector itself – the main presentation tool – goes
virtually unnoticed, because of near-silent
operation.
The broad installation capabilities of the VPL-PX40
enable the projector to be mounted on the ceiling
or floor, or installed in a rear-projection system.
Installation flexibility is further enhanced by the
choice of two optional lenses. With the Direct
Power-On function, the projector can be turned on
or off quickly using a circuit-breaker switch on a
switchboard, and, for added security, the VPL-
PX40 incorporates a password-authentication
system.
Visuals
Audio
Presentation Tools
Flexibility
Picture Quality
Presentation Effectiveness
Input Versatility
Flexibility
Screen Size
*80 100 120 150 180 200 250 300
Minimum
a'
3350 4130 4900 6070 7230 8000 9940 11880
132 1/8 162 5/8 193 1/8 238 7/8 284 5/8 315 1/8 391 3/8 467 5/8
4140 5110 6080 7530 8990 9960 12380 14810
163 201 1/4 239 3/8 296 3/4 354 392 1/4 487 3/4 583 1/4
Maximum
b+693 b+846 b+998 b+1227 b+1455 b+1608 b+1989 b+2370
b+27 3/8 b+33 3/8 b+39 3/8 b+48 3/8 b+57 3/8 b+63 3/8 b+78 3/8 b+93 3/8
150/175/200/250/275/300mm (6, 7, 7 7/8, 9 7/8, 10 7/8, 11 7/8 inches) adjustable when using PSS-610
x
b
Screen Size
*40 80 100 150 180 200 250 300
Minimum
a
1490 3040 3820 5750 6920 7690 9630 11570
58 7/8 119 7/8 150 3/8 226 5/8 272 3/8 302 7/8 379 1/8 455 1/2
1890 3830 4800 7220 8680 9650 12070 14500
74 3/8 150 3/4 189 284 1/2 341 3/4 380 475 1/2 571
Maximum
x-305 x-610 x-762 x-1143 x-1372 x-1524 x-1905 x-2286
x-12 x-24 x-30 x-45 x-54 x-60 x-75 1/8 x-90 1/8
x-392 x-697 x-849 x-1230 x-1459 x-1611 x-1992 x-2373
x-15 1/2 x-27 1/2 x-33 1/2 x-48 1/2 x-57 1/2 x-63 1/2 x-78 1/2 x-93 1/2
b
c
Floor Installation
Floor installation (Standard Lens)
Ceiling Installation
Ceiling installation using the PSS-610
Projector Suspension Support (Standard Lens)
a: distance between the screen to the center of the lens
b: distance between the floor and the center of the lens
c: distance between the floor and the bottom of the adjusters of the projector
x: free
*: Viewable area,measured diagonally
a': distance from the center of the upper ceiling mount bracket hole (rear) to the screen
b: distance between the ceiling and the surface of the mounting bracket
x: distance between the ceiling and the center of the screen
*: Viewable area,measured diagonally
PSS-610 Projector Suspension Support (not supplied)
a
x
b
c
a'
x
b
VPLL-ZM102
❚1.5-times zoom long-focus lens
❚Throw ratio*: 3.35-4.9:1

Projector Lamp
LMP-P260
(for replacement)
Suspension Support
PSS-610
LMP-P260
Specifications Input Signal Preset Data
Optional Accessories
Dimensions
VPL-PX40
Projection system 3 LCD panels, 1 lens projection system
LCD panel
Projection lens
0.99-inchp-Si TFT Sony LCD panel with Micro Lens Array
2,359,296 pixels (786,432 pixels x 3)
Approx. 1.3 times zoom lens, F1.7 to 2.3, f37.6 to 48.8 mm
Lamp 265 W UHP Lamp
Screen coverage 40 to 300 inches (viewable area, measured diagonally)
Light output 3500 ANSI lumens*1
Color system BTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N (automatically/manually selected)
Resolution Video: 750 TV lines, RGB: 1024 x 768 pixels
Acceptable signals
Cabinet color
RGB (fH 19 to 92 kHz, fV: 48 to 92 Hz (up to UXGA), 15 kHz RGB Component
50/60 Hz,Progressive component 50/60 Hz, DTV (480/60i,575/50i,480/60p, 540/60p,
575/50p, 720/60p,720/50p, 1080/60i, 1080/50i) Composite video, Y/C video
White
Speaker Stereo speakers system 40 x 70 mm (1 5/8 x 2 7/8 inches) Max. 2W x 2
Power requirements 100 to 240 V, 50/60 Hz
Power consumption Max. 365 W, Standby 6 W
Operating temperature 0 to 35˚C (32 to 95˚F)
Operating humidity 35 to 85%
Dimensions 420 (W) x 115 (H) x 316 (D) mm (16 5/8 x 4 5/8 x 12 1/2 inches)
Mass Approx. 7.5 kg (16 lb 10 oz)
Heat dissipation 1246 BTU
Composite
VIDEO IN
INPUT A
INPUT B
INPUT C
INPUT D
USB
OUTPUT
REMOTE
CONTROL S IN/
PLUG IN POWER
Phono type, 1.0 Vp-p ±2 dB sync negative, 75 Ω
Y/C IN Mini DIN 4-pin
Y1.0Vp-p ±2 dB sync negative, 75Ω
CBurst 0.286 Vp-p ±2 dB (NTSC), 75Ωor 0.3 Vp-p ±2 dB (PAL), 75Ω
HD D-sub 15-pin (female)Analog RGB
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Analog RGB HD D-sub 15-pin (female)
R0.7Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
G with Sync 1.0 Vp-p ±2dB sync negative, 75Ω
B0.7Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ(Shared by INPUT B/C)
Digital RGB DVI-D (TMDS)
Analog RGB/Component
R/R-Y 0.7 Vp-p ±2 dB positive, 75Ω
G0.7Vp-p ±2 dB positive, 75Ω
5 BNC (Female)
G with Sync/Y 1.0 Vp-p ±2 dB sync negative, 75 Ω
B/B-Y 0.7 Vp-p ±2 dB positive, 75Ω
SYNC/HD
Composite sync 1.0 to 5.0 Vp-p, high impedance positive/negative
Horizontal sync 1.0 to 5.0 Vp-p, high impedance positive/negative
VD
Vertical sync 1.0 to 5.0 Vp-p, high impedance positive/negative
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Up (female) x 1 (Shared by INPUT A/B/C/D)
MONITOR OUT*2
HD D-sub 15-pin (female) R/R-Y, G/Y, B/B-Y: Gain Unity, 75ΩSYNC/HD, VD: 4.0 Vp-p (open), 1.0 Vp-p (75 Ω)
RS-232C D-sub 9-pin (female)
AUDIO OUT (Variable out)
Stereo mini jack, max. 1 V rms, when the input siginal is 500 mV rms, impedance less than 5 kΩ
ETHERNET port RJ-45: 10 BASE-T/100 BASE-TX
Stereo mini jack
5.0 Vp-p, plug in power, DC 5V
UL, cUL, DHHS, FCC Class A, IC Class A, NEMKO, CE (LVD), CE (EMC), C-Tick, CCC, VCCI class B, JEITA
Laser type Class II
Wavelength
Output
Remote commander, Monitor Cable (2 m): HD D-sub 15-pin to HD D-sub 15-pin, USB Cable A type to B type (2 m),
AA size Battery (x 2), Lens Cap, Air Filter, Operating Manual, Installation Manual for dealers
645 nm
1 mW
Model
Optica
Signals
General
Inputs/Outputs
Safety regulations
Laser beam
Supplied
accessories
No.
1
2
3
4
5
6*
7*
8*
9*
10*
11*
12*
13*
14*
15*
16*
17*
18*
19*
20*
21*
22*
23*
24*
25*
26*
27*
28
29
30*
31
32*
33
34*
35
36*
37
38
39
43
44
45
47
48
50
52
Preset Signal
VIDEO/60 60Hz 15.734 59.940
15.625 50.000
15.734 59.940
SonG/Y
15.625 50.000 or
33.750 60.000
Composite
31.469 70.086 P/N
37.861 85.080 P/N
24.823 56.416 N/N
31.469 70.086 N/P
37.861 85.080 N/P
31.469 59.940 N/N
35.000 66.667 N/N
37.861 72.809 N/N
37.500 75.000 N/N
43.269 85.008 N/N
35.156 56.250 P/P
37.879 60.317 P/P
48.077 72.188 P/P
46.875 75.000 P/P
53.674 85.061 P/P
49.724 74.550 N/N
35.524 86.958 P/P
48.363 60.004 N/N
56.476 69.955 N/N
60.023 75.029 P/P
68.677 84.997 P/P
63.995 70.019 P/P
67.500 75.000 P/P
77.487 85.057 P/P
61.795 65.960 N/N
71.713 76.047
Cneg(N/P)
60.000 60.000 P/P
75.000 75.000 P/P
46.433 86.872 P/P
53.316 50.062
SonG(P/P)
63.974 60.013 P/P
79.976 75.025 P/P
91.146 85.024 P/P
75.000 60.000 P/P
31.470 60.000 SonG
31.250 50.000 SonG
28.130 50.000
45.000 60.000
37.500 50.000
33.750 60.000
63.981 60.020 N/N
VIDEO/50 50Hz
480/60i
575/50i
HDTV 1035/60i, 1080/60i
640x350
640x400
640x480
800x600
832x624
1024x768
1152x864
1152x900
1280x960
1280x1024
1600x1200
VGA-1
(VGA350)
VESA 85(VGA350)
NEC PC98
VGA-2(TEXT)/VESA70
VESA 85(VGA400)
VESA 60
Mac 13
VESA 72
VESA 75(IBM M3)
VESA 85(IBM M4)
VESA 56
VESA 60
VESA 72
VESA 75(IBM M5)
VESA 85
Mac 16
VESA 43(8514)
VESA 60
VESA 70
VESA 75
VESA 85
VESA 70
VESA 75
VESA 85
SUN LO
SUN HI
VESA 60
VESA 75
VESA 43
SGI-5
VESA 60
SXGA VESA75
SXGA VESA85
UXGA VESA60
480/60p
(double frequency of NTSC)
575/50p (double frequency of PAL)
1080/50i
720/60p
720/50p
540/60p
1400x1050 SXGA+
fH
(kHz) fV (Hz) H/V
When the signal other than ones in "Preset Signals" are input,
the picture may not display correctly. When the aspect ratio of
an input signal is other than 4:3, a part of the screen is
displayed in black. The UXGA signal can be projected only
when user set the frequency of a computer 60Hz. The digital
input complies with the signals marked with asterisks(*) on the
table. When the digital signal output from a computer is a
signal other than the signals marked with asterisks(*) among
the memory numbers 6 to 39, it is automatically output
according to the specifications of the projector. The memory
numbers 22 and 34 are the interlace signals.
Signal Cables
SMF-400
(HD D-sub 15-pin to 5 BNC, for
RGB signal)
SMF-410
(HD D-sub 15-pin to HD D-sub
15-pin, for RGB signal)
Optional Lenses
VPLL-FM22
(Fixed short-focus lens)
VPLL-ZM102
(Long-focus zoom lens)
*1ANSI lumens is a measuring method of the American National Standards Instisute IT7. 228. Since there is no uniform method of measuring
brightness, specifications will vary among manufactures. *2DIGITAL RGB and Component signals are not output from the MONITOR OUT terminal.
©2002 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
Mac is registered trademark of Apple Computer, Inc.
Printed in Japan on recycled paper.MK07852V1FRT02NOV
Distributed by
420(16 5/8)
145(5 3/4)
87(3 1/2)
316(12 1/2)
115(4 5/8)
Power consumption during standby 6.0W or less.
Halogenated flame retardant is not used in cabinets.
Lead-free solder is used for soldering.
Polystyrene form for cushioning has been eliminated
and corrugated paper is used as buffer materials.
Unit:mm (inches)
