ViewSonic PJ503D - DLP Projector User manual

PJ503D
LIGHT, BRIGHT PORTABLE
DLP PROJECTOR
WITH ADVANCED
5-SEGMENT COLOUR WHEEL
Flexible, solid and affordable
The ViewSonic PJ503D packs an impressive 1500 lumens in just 2.6kg.
This full-featured projector is light, bright and affordable without
compromising on quality. With its DLP technology, a contrast ratio of
2000:1 and native SVGA resolution (up to 1280 x 1024 compressed),
you’ll be impressed by the rich, saturated colours and crystal-clear
images. Support of worldwide video signal standards (PAL, SECAM
and NTSC) and HDTV (720p and 1080i) plus digital keystone
correction and various video inputs provide exceptional versatility.
The Eco-mode function even extends your lamp life and reduces the
noise output to just 27dB which makes it also perfect for home video
usage. The PJ503D is the perfect choice for professionals, classroom
applications and home users who have a tight budget and expect
a versatile and solid projector for data and also video applications.
OUTSTANDING MULTIMEDIA
PERFORMANCE WITH GREAT COLOURS
>Bright in virtually any setting with 1500 lumens
Packs 1500 ANSI lumens in just 2.6kg the PJ503D provides sufficient
brightness for most commercial or home environments.
>SVGA native resolution and up to SXGA compressed
Native SVGA 800 x 600 resolution, compressed SXGA 1280 x 1024.
>DLP
®
technology with 5-segment colour wheel
Stunning all-digital clarity with life-like colour, sharp graphics
and outstanding video. And the sophisticated 5-segment colour
(RGBWY) wheel provides even better colour accuracy than
standard DLP projectors with a 4-segment colour wheel.
>Easy set-up
The PJ503D comes with a fair selection of electronic features with
ease the setup process. Whether it is the electronic keystone
correction for maintaining a squared image or quickly selecting
one of the 7 preset modes for different environment usages or the
automatic signal detection - this projector will make your life easy.
>Supports HD signals including 720p and 1080i
Capable of displaying HDTV signals as well as other video and
data sources
1
.
>Solid product quality
Despite the low price the PJ503D is amazingly well designed
and manufactured. Experience the solid silver buttons, the robust
casing, the intuitive menu and other details.
>Eco mode extends lamp life
Extend the life of your lamp up to
3000 hours
2
while reducing to an almost
unnoticeable 27dbA.

PJ503D
LIGHT, BRIGHT PORTABLE DLP PROJECTOR
WITH ADVANCED 5-SEGMENT COLOUR WHEEL
DLP Type 0.55" DDR SVGA DMD DLP
Resolution 800 x 600 SVGA native, (max. 1280 x 1024 SXGA compressed)
Lens Digital zoom, manual focus
Zoom Factor 1.0 (F = 2.57/f = 22.2mm)
Digital Keystone Vertical ± 7º
DISPLAY Size 37.5"–150" (0.95m–3.81m) (Diagonal)
Throw Distance 1.5m–6.0m
Throw Ratio 2:1
Lamp 160W, 2000 hours (Eco mode 3000 hours2)
Brightness 1500 ANSI lumens
Contrast Ratio 2000:1
Aspect Ratio 4:3 (native), 16:9
INPUT SIGNAL Video RGB analogue, Video NTSC M, NTSC 4.43, PAL (B, D, G, H, I, M, N, 60),
SECAM, SDTV/EDTV (480i/p, 576i/p), HDTV (720p, 1080i)
Frequency Fh: 30–100kHz; Fv: 50–87Hz
COMPATIBILITY PC Analogue: VGA up to SXGA (scaled), 800 x 600 @ 60Hz preferred
Mac®3 Analogue: up to SXGA (scaled), 800 x 600 @ 60Hz preferred
CONNECTOR PC-VGA 1 x 15-pin mini D-sub
Composite Video 1 x RCA jack
S-Video 1 x 4-pin mini-DIN
Component Video 15-pin mini D-sub to 3 x RCA component video adapter1
Control 1 x 9-pin D-sub RS-232
USB 1 x USB Typ B (for service only)
POWER Voltage AC 100–120/200–240V, 50/60Hz (auto switch)
Consumption < 250W (typ.)
CONTROLS Basic Stand-by, menu, input
OSD4Picture Menu (preset mode, brightness, contrast, colour temperature,
colour, tint, sharpness), Pro-Picture Menu (Auto image adjust, aspect ratio,
V keystone correction, H/V position, phase, H size), Setting Menu (OSD
timeout, reset), Advanced Menu (projection [front, rear], bank screen timer,
auto source detection, language [Czech, Dutch, English, French, German,
Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish,
Simplified Chinese, Traditional Chinese], splash screen, high altitude mode,
auto off, Eco mode), Information Menu (source, resolution, system, present
mode, equivalent lamp hour)
OPERATING Temperature 0°C–40°C
CONDITIONS Humidity 10%–90% (non condensation)
NOISE LEVEL Normal 30dB (typ.)
Eco mode 27dB (typ.)
DIMENSIONS (W x H x D mm) 263 x 108 x 218 (physical)
370 x 297 x 186 (packaging)
WEIGHT Net 2.6kg
Gross 3.7kg
REGULATIONS CE, CB, TÜV/GS, GOST, UL/cUL, FCC-B, C-Tick, WEEE, RoHS
OTHER Vertical digital keystone correction, 7 Preset Modes for different environment
usages (PC input: Brightest, Presentation, Photo, Cinema; Video input:
Brightest, Standard, Cinema), Eco mode
PACKAGE DLP Projector, 1.8m power cables (Europe [Schuko]/UK), 1.8m VGA cable,
CONTENTS remote control, batteries, lens cap, Quick Start Guide (multi-language),
ViewSonic Wizard CD (User guide) (multi-language)
WARRANTY Please see: www.viewsoniceurope.com/UK/Support/warranty.htm
For more product information, visit us on the web at www.ViewSonicEurope.com
1Optional cables required. 2Running Eco mode exclusively can extend lamp life up to 3000 hours. 3May require optional Mac adapter. 4Some features may not available on all inputs.
Copyright © 2007 ViewSonic Corporation. All rights reserved. Specifications subject to change without notice. The DLP logo is a trademark of Texas Instruments. Corporate names and trademarks
stated herein are the property of their respective companies. VS PJ503D 03/07-UK
