Sony VPL-DX125 User manual

DATA PROJECTOR
VPL-DX125
VPL-DX145
VPL-DW125
VPL-EX221
VPL-EX225
VPL-EX241
VPL-EX245
VPL-EX271
VPL-EX275
VPL-EW225
VPL-EW245
VPL-EW275
PROTOCOL MANUAL
1st Edition (Revised 1)

VPL-EX225
!警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，
人身事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.

T-1 (E)
VPL-EX225
Table of Contents
1. Overview
1-1. Introduction .................................................................. 1 (E)
1-2. Glossary of Terms ........................................................ 1 (E)
1-3. Protocol Stack Structure............................................... 1 (E)
2. Common Commands
2-1. Sub Commands ............................................................ 3 (E)
2-1-1. ITEM List ........................................................... 3 (E)
2-1-2. Infrared Remote Command Code....................... 8 (E)
2-2. Reply ............................................................................ 9 (E)
3. RS-232C (Except for VPL-DX125/VPL-
DX145/VPL-DW125)
3-1. Connection ................................................................. 10 (E)
3-2. Communication Specifications................................... 10 (E)
3-3. Communication Procedure......................................... 11 (E)
3-3-1. Outline of Communication ............................... 11 (E)
3-4. Communication Rules................................................ 11 (E)
3-5. Approximate Return Waiting Times........................... 11 (E)
3-6. Command Block Format ............................................ 12 (E)
3-6-1. Simplified Command ........................................ 12 (E)
3-7. Packet Examples ........................................................ 13 (E)
3-7-1. Set ASPECT to “ZOOM” ................................. 13 (E)
3-8. AMX Device Discovery............................................. 13 (E)
4. Ethernet
4-1. Service........................................................................ 14 (E)
4-1-1. Advertisement................................................... 14 (E)
4-1-2. PJ Talk............................................................... 15 (E)
4-2. Communication Procedure......................................... 16 (E)
4-3. Protocols..................................................................... 17 (E)
4-3-1. SDAP ................................................................ 17 (E)
4-3-2. SDCP................................................................. 18 (E)
4-3-3. PJLink ............................................................... 27 (E)
4-3-4. DDDP................................................................ 34 (E)
4-3-5. CIP .................................................................... 34 (E)

1 (E)
VPL-EX225
1. Overview
1-1. Introduction
The projector is remotely controllable over RS-232C as well as Ethernet. It is useful for setting up the
projector away from the operator.
This protocol manual describes the specifications such as packet format and procedures for controlling the
projector.
In the following sections below, the term “CONTROLLER” is used as a device which controls the projec-
tor. CONTROLLER can be a PC or other specific device that is able to handle RS-232C or Ethernet.
Although most of commands are available for both RS-232C and Ethernet, some commands are dedicated
to Ethernet.
*Ethernet is a registered trademark of Xerox Corporation.
1-2. Glossary of Terms
Table 1-1 Glossary of Terms
Terms Abbreviated Description
CONTROLLER _Command initiator such as PCs.
PROJECTOR _Front projector. (device)
SDAP Simple Display Advertisement Protocol Protocol name for advertising the projector status over
Ethernet.
SDCP Simple Display Control Protocol Protocol name for controlling projector over Ethernet.
PJLink _Protocol name for controlling projector over Ethernet.
DDDP Dynamic Device Discovery Protocol AMX Device Discovery is the protocol name by AMX
to enable to configure the AMX control system and
other intended devices.
CIP Crestron Internet Protocol Protocol name used in Crestron RoomView and
control system by Crestron.
1-3. Protocol Stack Structure
The protocol stack structure diagram is shown below. Though the stack is drawn for RS-232C and Ether-
net separately, the following portions are common.
Table 1-2 Common Portions in Protocol Stack
Layer Name Description
Sub Command Value is assigned for projector’s functions. Refer to the section 2-1 for detail description.
Simplified Command Packet format for sending/receiving “Sub Command”. Refer to the section 3-6-1 for detail
description.

2 (E) VPL-EX225
(1) RS-232C
Fig. 1-1 RS-232C Protocol Stack
“RS-232C” layer is physical portion and “Asynchronous” is the traditional protocol layer as shown in the
section 3-2.
(2) Ethernet
Fig. 1-2 Ethernet Protocol Stack
Because of traditional portions for Ethernet general layer, “TCP/IP”, “UDP/IP”, and “HTTP” are out of
scope in this document.
SDCP specific command is described in the section 4-3-2.
SDAP and SDCP (PJ Talk) are SONY original protocol stack, which are described in the sections 4-3-1
and 4-3-3 respectively.
RS-232C
Simplified Command
Asynchronous
Sub Command
AMX Device
Discovery
SDCP Specific Command
UDP/IP
Ethernet
TCP/IP
SDCP (PJ Talk)
Sub
Command
Simplified
Command
SDAP DDDP
HTTP PJLinkCIP

3 (E)
VPL-EX225
2. Common Commands
2-1. Sub Commands
Sub Command is the value which is used by Simplified Command. Value is assigned for executing func-
tion. For example, if you want to change the picture mode, the appropriate value assigned for the desired
picture mode should be chosen.
2-1-1. ITEM List
Item lists are described below. Tables are shown per item name.
ITEM List For Picture
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Byte
PICTURE MODE 00h 02h DYNAMIC 0000h Set/Get
STANDARD 0001h
PRESENTATION 0002h
BLACK BOARD 0003h
GAME 0004h
CINEMA 0005h
CONTRAST 00h 10h VALUE 0000h-0064h(0-100)
BRIGHTNESS 00h 11h VALUE 0000h-0064h(0-100)
COLOR 00h 12h VALUE 0000h-0064h(0-100)
HUE 00h 13h VALUE 0000h-0064h(0-100)
SHARPNESS 00h 14h VALUE 0000h-000Ah(0-10)
COLOR TEMP 00h 17h HIGH 0000h
MID 0001h
LOW 0002h
ITEM List For Screen
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Byte
ASPECT 00h 20h FULL 0000h Set/Get
NORMAL 0001h
ZOOM 0003h
FULL1 0007h
FULL2 0008h
4:3 0009h
16:9 000Ah
FULL3 0010h

4 (E) VPL-EX225
ITEM List For Setup (VPL-EX221/EX225/EX241/EX245/EX271/EX275/EW225/EW245/EW275)
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Byte
INPUT TERMINAL 00h 01h VIDEO 0000h Set/Get
S VIDEO 0001h
INPUT A 0002h
INPUT B 0003h
INPUT C 0004h
USB (TYPE B) 0005h
NETWORK 0006h
USB (TYPE A) 0007h
VOLUME*100h 16h VALUE 0000h-0064h(0-100)
MIC VOLUME*100h 29h VALUE 0000h-000Ah(0-10)
BLANK 00h 30h OFF 0000h
ON 0001h
MUTING 00h 31h OFF 0000h
ON 0001h
INPUT A SIGNAL-SEL 00h 32h AUTO 0000h
COMPUTER 0001h
COMPONENT 0002h
VIDEO GBR 0003h
CC Display 00h 3Eh OFF 0000h
CC1 0001h
CC2 0002h
CC3 0003h
CC4 0004h
TEXT1 0005h
TEXT2 0006h
TEXT3 0007h
TEXT4 0008h
LAMP MODE 00h 40h HIGH 0000h
STANDARD 0001h
LOW 0002h
AUTO 0003h
*1: This item is disabled for VPL-EX221/EX241/EX271.

5 (E)
VPL-EX225
ITEM List For Setup (VPL-DX125/DX145/DW125)
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Byte
INPUT TERMINAL 00h 01h VIDEO 0000h Set/Get
INPUT A 0002h
INPUT B 0003h
USB (TYPE B) 0004h
NETWORK 0005h
USB (TYPE A) 0006h
VOLUME 00h 16h VALUE 0000h-0064h(0-100)
BLANK 00h 30h OFF 0000h
ON 0001h
MUTING 00h 31h OFF 0000h
ON 0001h
INPUT A SIGNAL-SEL 00h 32h AUTO 0000h
COMPUTER 0001h
COMPONENT 0002h
VIDEO GBR 0003h
CC Display 00h 3Eh OFF 0000h
CC1 0001h
CC2 0002h
CC3 0003h
CC4 0004h
TEXT1 0005h
TEXT2 0006h
TEXT3 0007h
TEXT4 0008h
LAMP MODE 00h 40h HIGH 0000h
STANDARD 0001h
LOW 0002h
AUTO 0003h

6 (E) VPL-EX225
ITEM List For Infrared Remote Command
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Upper byte Lower byte
Infrared Remote Command
(VPL-EX series, VPL-EW
series, or 15 bit PROJECTOR)
17h Refer to Section
2-1-2.*1
_00h 00h Set only
Infrared Remote Command
(VPL-EX series, VPL-EW series,
or 20 bit E PROJECTOR)
19h _00h 00h
Infrared Remote Command
(VPL-EX series, VPL-EW series,
or 20 bit EE PROJECTOR)
1Bh _00h 00h
*1: For using this item number, the simulation of the infrared remote controller is enable. Select the corresponding code in the table of
Section 2-1-2 and use it as the lower byte of the item number.
n
Other value (Upper byte) is assigned depending for item name.

7 (E)
VPL-EX225
ITEM List For Status
<Table 1> <Table 2> Remarks
Item Number Data
Item Upper byte Lower byte Data Byte
STATUS ERROR1 01h 01h NO ERROR 00h Get only
LAMP ERROR 01h
FAN ERROR 02h
COVER ERROR 04h
TEMP ERROR 08h
D5V ERROR 10h
POWER ERROR 20h
WARNING TEMP 40h
NVM DATA ERROR 80h
STATUS POWER 01h 02h STANDBY 00h
START UP 01h
STARTUP LAMP 02h
POWER ON 03h
COOLING1 04h
COOLING2 05h
SAVING COOLING1 06h
SAVING COOLING2 07h
SAVING STANDBY 08h
OPERATION TIMER 01h 12h VALUE xxh
LAMP TIMER 01h 13h VALUE xxh
SUB ROM VERSION 01h 1Dh VALUE xxh
MAIN ROM VERSION 01h 1Eh VALUE xxh
STATUS SECURITY 01h 1Fh DISABLE 00h
ENABLE 01h
STATUS ERROR2 01h 25h NO ERROR 00h
Don’t Use 02h
Don’t Use 04h
Don’t Use 08h
Don’t Use 10h
WARNING HIGHLAND 20h
Don’t Use 40h
Don’t Use 80h
NVM DATA VERSION 01h 27h VALUE xxh

8 (E) VPL-EX225
2-1-2. Infrared Remote Command Code 15bit PROJECTOR
x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
0x INPUT F*2
1x VOL:
LARGE*1
VOL:
SMALL*1
MUTING POWER
TOGGLE
CONTRAST
+
CONTRAST
_
COLOR
+
COLOR
_
BRIGHTNESS
+
BRIGHTNESS
_
2x HUE
+
HUE
_
SHARPNESS
+
SHARPNESS
_
BLANK STATUS
ON
STATUS
OFF
MENU VIDEO INPUT A INPUT B POWER
ON
POWER
OFF
3x CURSOR
→
CURSOR
←
CURSOR
↑
CURSOR
↓
4x PITCH SHIFT 5x INPUT
TOGGLE
ENTER S VIDEO*2
6x INPUT C 7x INPUT D INPUT E RESET TEST
PATTERN*3
*1: This item is disabled for VPL-EX221/EX241/EX271. *2: This item is disabled for VPL-DX125/DX145/DW125. 3: This item is disabled. 20bit PROJECTOR-E
x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
0x
V KEYSTONE
+
V KEYSTONE
_
ADJ
TOGGLE
1x 2x 3x
V KEYSTONE
4x 5x PICTURE
MODE
DYNAMIC
MODE
STANDARD
MODE
PRESENTATION
MODE
BLACK BOARD
MODE
GAME
MODE
CINEMA
MODE
TOGGLE
COLOR
TEMP
TOGGLE
6x APA PHASE FREEZE*1DIGITAL
ZOOM
+
DIGITAL
ZOOM
_
ASPECT
TOGGLE
7x
*1: This item is disabled. 20bit PROJECTOR-EE
x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
0x 1x ECO MODE 2x 3x 4x 5x 6x RETURN 7x

9 (E)
VPL-EX225
Correspondence tale of the infrared remote command and the input terminal
Infrared Remote Command
INPUT TERMINAL
VPL-EX221/EX225/EX241/
EX245/EX271/EX275/EW245/
EW275
VPL-DX125/DX145/DW125
VIDEO VIDEO VIDEO
S VIDEO S VIDEO _
INPUT A INPUT A INPUT A
INPUT B INPUT B INPUT B
INPUT C INPUT C TYPE B USB
INPUT D TYPE B USB NETWORK
INPUT E NETWORK TYPE A USB
INPUT F TYPE A USB _
2-2. Reply
<Table 3>
Item Number Data
Item Data Upper byte Lower byte
ACK Complete 00h 00h
NAK Undefined Command 01h 01h
Size Error 04h
Select Error 05h
Range Over 06h
Not Applicable 0Ah
Check Sum Error F0h 10h
Framing Error 20h
Parity Error 30h
Over Run Error 40h
Other Comm Error 50h
Error description
Check Sum Error
A check sum error occurred.
Framing Error
A framing error occurred.
Parity Error
A parity error occurred.
Over Run Error
An overrun error occurred.
Other Comm Error
Another error occurred.

10 (E) VPL-EX225
3. RS-232C (Except for VPL-DX125/VPL-DX145/VPL-DW125)
3-1. Connection
Communication is enabled by the use of a D-Sub 9 Pin cross (reverse) cable.
The pin assignment of D-Sub 9 Pin and D-Sub 25 Pin is as follows.
D-Sub 9 Pin D-Sub 25 Pin Name
Shell = FG 1 FG Grounding for safety protection or cable shield
3 2 TxD Transmission data
2 3 RxD Reception data
7 4 RTS Transmission request
8 5 CTS Transmission permission
6 6 DSR Data set ready
5 7 SG GND for signal
1 8 DCD Data channel signal carrier detection
4 20 DTR Data terminal ready
9 22 RI Calling display (Presence/absence of calling signal)
Pin numbers not indicated as D-Sub 25 Pin are not used.
Assured cable length: 15 m (However, assurance may not be applicable for some cables.)
The software for controlling the projector from a PC is intended for performing transmission and recep-
tion for only the TxD and RxD lines.
Therefore the handshake normally performed by RS-232C is not necessary.
3-2. Communication Specifications
.Full duplex communication channels (Flow control is not performed.)
.Start-stop synchronism system
.Baud rate: 38.4 kbps (Default)/19.2 kbps/9600 bps (bits per second)
n
The baud rate setting is able to be changed in the menu of service mode :
Device →Other →232C (38.4 k = 0/19.2 k = 1/9.6 k = 2).
.The bit configuration is defined as follows.
1 START Bit +8 DATA Bits +1 PARITY Bit +1 STOP Bit
EVEN Parity ...........Total number of “1”s from D0 to D7 is an even number. 80
...........Total number of “1”s from D0 to D7 is an odd number. 81
D4 D5 D6 D7
(MSB)(LSB) (EVEN) BIT
PARITY STOP
BIT
START D3D2D1D0

11 (E)
VPL-EX225
3-3. Communication Procedure
3-3-1. Outline of Communication
All communication between CONTROLLER (PC, etc.) and DEVICE (PROJECTOR) is performed by the
command block format. Communication is started by the issue of a command at CONTROLLER and
ended when the return data is sent to CONTROLLER after DEVICE receives the command.
CONTROLLER is prohibited from sending several commands at one time. This means that after CON-
TROLLER sends one command, it cannot send other commands until DEVICE returns the return data.
DEVICE sends the return data after processing the command. The time from when CONTROLLER sends
the command until the return data is returned differs according to the contents of the command.
n
When SIRCS direct command is sent, return data is not sent.
3-4. Communication Rules
.When sending a command from CONTROLLER, the return data from PROJECTOR should be received
first before sending the next command. Even if the next command is sent before receiving the return
data, since PROJECTOR will not be able to receive that command, it does not return a response to
CONTROLLER. Consequently, no error code is also sent.
For detail of the waiting times for PROJECTOR to return the return data after CONTROLLER sends
the command, refer to the section 3-5.
.When a communication error occurs, PROJECTOR ignores the data received until now, and set into the
reception standby state.
.For undefined commands or commands determined as invalid by PROJECTOR, PROJECTOR will
send the “NAK” return data to CONTROLLER .
.Take note that when data is written when the input signal of PROJECTOR is unstable, that data (value)
will not be incorporated.
.When SIRCS direct command is transmitted, leave an interval of 45 msec until the next transmission. (Do
not return the return data (ACK, NAK) when the SIRCS direct command is received.)
.For POWER ON/OFF/TOGGLE of the SIRCS direct command, send the command twice when this
unit is in standby mode (Low) state.
3-5. Approximate Return Waiting Times
The await-return time is approx. 30 to 1000 msec.
n
This is the case, unless the communications are interfered anyway.

12 (E) VPL-EX225
3-6. Command Block Format
The block format of Simplified Command for RS-232C as shown in the figure below. In this section, the
block format for Simplified Command is provided.
3-6-1. Simplified Command
[Send]
The block format for sending request is shown below.
[Receive (without data)]
The block format for response which includes no return data is shown below. Response is always sent by
PROJECTOR.
[Receive (with data)]
The block format for response which includes return data is shown below. Response is always sent by
PROJECTOR.
*1: CHECK SUM: B1 to B5 are calculated by OR. Refer to the example below.
<Example of Calculation>
0xA9 1010 1001 0xA9 1010 1001
0xA9 1010 1001 0x9A 1001 1010
Answer 1010 1001 Answer 1011 1011
0xA9 0xBB
START CODE
B0
B1
B2
B4
B3
DATA
ITEM NUMBER
TYPE
CHECK SUM
* 1
END CODE
B5
B6
B7
[A9h]
Put the item number.
Refer to the item list in the sections 2-1-1 and 2-1-2.
SET: 00h (Set data)
GET: 01h (Get data)
SET: Put the Data value described in the item list in the sections 2-1-1 and 2-1-2.
GET: Unused. Set Dummy data [00h, 00h]
Check Sum
[9Ah]
START CODEB0
B1
B2
B4
B3
DUMMY DATA
ACK/NAK
TYPE
CHECK SUM
* 1
END CODE
B5
B6
B7
[A9h]
Refer to the reply definition table in the section 2-2.
[03h]
This data does not mean any senses.
Dummy Data [00h, 00h] is stored.
Check Sum
[9Ah]
START CODEB0
B1
B2
B4
B3
DATA
ITEM NUMBER
TYPE
CHECK SUM
* 1
END CODE
B5
B6
B7
Check Sum
[9Ah]
[A9h]
Refer to the item list in the sections 2-1-1 and 2-1-2.
[02h]
Express data to be Reply data
Data value described in the item list
in the sections 2-1-1 and 2-1-2.

13 (E)
VPL-EX225
3-7. Packet Examples
3-7-1. Set ASPECT to “ZOOM”
START CODE = A9h
ITEM NUMBER = 0020h (ASPECT)
SET/GET = 00h (SET)
DATA = 0003h (ZOOM)
CHECK SUM = 23h
END CODE = 9Ah
You will receive the packet below if the process is successfully completed.
START CODE = A9h
ACK/NAK = 0000h (Complete)
ACK = 03h
DUMMY DATA = 0000h
CHECK SUM = 03h
END CODE = 9Ah
There’s another way that set ASPECT to ZOOM. There is “ASPECT” key on the infrared remote control-
ler. By using this key, ASPECT can be changed. Issue the Infrared Remote Command for this key several
times to set wide mode “ZOOM”. Packet format will make as follows. Refer to Section 2-1-2 for “AS-
PECT TOGGLE”.
START CODE = A9h
ITEM NUMBER = 196Eh (ASPECT TOGGLE)
SET/GET = 00h (SET)
DATA = 0000h
CHECK SUM = 7Fh
END CODE = 9Ah
3-8. AMX Device Discovery
This model is equipped with the protocol that conforms to the Device Discovery stipulated by AMX. Con-
tact AMX for details about the Device Discovery.

14 (E) VPL-EX225
4. Ethernet
4-1. Service
4-1-1. Advertisement
The advertisement service is provided to facilitate development of a PC application that can automatically
detect a projector on the network. This function is achieved by broadcasting the equipment information
periodically to the network.
This protocol is set to OFF by default.
[Information]
The equipment information shown below is transmitted as the broadcast packet periodically (at certain
intervals).
Information Description
Equipment category code Category code of the equipment
Equipment name Name of the equipment
Serial number Serial number of the equipment
Installation information Installation location of the equipment
Community Community name of the equipment
Power status Power status of the equipment
m
.The category code of projector is 0Ah.
.The power status sets FFFFh if communication error occurs.
[Protocol]
The SDAP protocol is defined in order to provide this service.
Item Description
Protocol name SDAP (Simple Display Advertisement Protocol)
Transport UDP
Port number 53862 (Factory-shipments value)
Broadcast interval Once every 30 seconds (Factory-shipments value)
[Setup Items]
The items that can be set for the advertisement service are described below.
Setup items Description
Community Community name
Port No. Port number
Interval Broadcast interval
Broadcast Address Adding the transmission place.

15 (E)
VPL-EX225
4-1-2. PJ Talk
By using PJ Talk, it is possible to communicate with PROJECTOR over Ethernet network. Both of set and
get method are provided.
This protocol is set to OFF by default.
[Protocol]
Item Description
Protocol name SDCP (Simple Display Control Protocol)
Transport TCP
Port number 53484 (Factory-shipments value)
TCP connection timeout 30 seconds (Factory-shipments value)
[Setup Items]
Setup item Description
Port No. Port number
Timeout TCP connection timeout time
Host Address Address of connectable PC
Community Header community

16 (E) VPL-EX225
4-2. Communication Procedure
Communication sequence is shown below. SDCP commands must be issued by CONTROLLER and
PROJECTOR responses to it. On the other hand, SDAP commands are sent by PROJECTOR and have no
response from CONTROLLER.
Fig. 4-1 Command Sequence
It is prohibited that CONTROLLER send another command before receiving the response to the previous
command. Since PROJECTOR executes the command before sending the return data, CONTROLLER
must wait a while before receiving the response. The waiting time depends on not only the commands but
also network traffic.
CONTROLLER PROJECTOR
SDCP SET/GET Request
Response
(OK/NG)
The command is executed if it’s valid.
Then, the receive command is sent to
the CONTROLLER.
SDAP Broadcast
SDAP Broadcast
