SRX-T615
Super-high Picture Quality 4K Digital Projector
FEATURES
High Picture Quality
The SRX-T615 features a high-contrast image of 12,000:1, high brightness of 18,000 lm, and
brightness uniformity with the new 4K optical engine.
Low Running Costs
Using multiple HPM lamps in individual cartridges means that lamp replacement is easier and
safer, and provides a longer lamp-exchange cycle. Lamp costs for the SRX-T615 are much lower
than with Xenon lamps. Also, durable parts incur fewer maintenance cycles which further reduces
running costs.
Application Versatility
The SRX-T615 offers the flexibility of tilted installation, distortion correction for 4K3D, and edge
blending for multi projection. It also provides a variety of lamp operations for precise luminance
control, such as a selectable number of lighting lamps and interleaved lamp control.

MK11064V2YIT13SEP
Distributed by ©2013 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for mass and dimension are approximate.
“SONY”,“make.believe”, and “SXRD” are trademarks of Sony Corporation.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
All other trademarks are the property of their respective owners.
SPECIFICATIONS
OPTIONAL ACCESSORIES
CONNECTOR PANEL
DIMENSIONS Unit: mm (inches)
570
48
64 ~120
922
1015
630
Surface to
attach a lens
Exhaust center 802
1119 (44 1/8)
104
450
548 (21 5/8)
45
Exhaust center
270
325
45
APPLICATIONS
Entertainment
•Amusement parks
•Planetariums
•Museums
Industrial design
•Digital mock-ups
•Automotive design
Visual simulation
•Simulators
•Scientific visualization
•Oil and Gas
Other
•Command and Control
•3D applications
•4K content viewing
SRX-T615
Display System 4K SXRD panel, projection system
Display elements Effective display size 1.48” x 3
Number of pixels 26,542,080 (4096 x 2160 x 3) pixels
Light source High-pressure mercury lamp, 6 x 450 W or 6 x 330 W type
Recommended lamp replacement time*12000 H (450 W) / 3000 H (330 W)
Light output 18,000 Center lumens / 17,000 lumens*3
(6 x 450 W lamp)
13,500 Center lumens / 12,500 lumens*3
(6 x 330 W lamp)
Contrast ratio 12,000:1
INPUT / OUTPUT
(Computer /
Video / Control)
HDMI (2 inputs) Digital RGB/Y Pb/Cb Pr/Cr
DisplayPort (4 inputs)*2Digital RGB/Y Pb/Cb Pr/Cr
REMOTE RS-232C,D-sub 9-pin (female)
LAN 10BASE-T / 100BASE-T
Operating temperature / Operating humidity 5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation)
Storage temperature / Storage humidity -20°C to +60°C (-4°F to +140°F) /
10% to 90% (no condensation)
Power requirements AC 200 V to 240 V, 21.5 A to 18 A, 50/60 Hz, Single Phase
Dimensions (W x H x D) 548 x 634 x 1119 mm
21 5/8 x 25 x 44 1/8 inches
Mass Approx.143 kg / 315.3 lb
*1 The figures are expected maintenance time and not guaranteed. They will
depend on the environment or how the projector is used.
*2 Available in 2013 with optional board manufactured by 3rd party.
*3 Those brightness are measured in accordance with ISO 21118. It is usually called
“ANSI lumen”.
2D Lens
LKRL-Z511 LKRL-Z514 LKRL-Z519
Throw ratio* 1.05 – 1.75 1.35 – 2.34 1.80 – 4.00
V shift +/- 35% +/- 35% +/- 35%
H shift +/- 7% +/- 7% +/- 7%
Dimensions W 256 x H 315 x D 429 mm W 256 x H 315 x D 454 mm W 256 x H 315 x D 413 mm
Mass 14.5 kg 14.0 kg 13.0 kg
3D Lens
LKRL-A502 LKRL-A503
Throw ratio* 1.03 – 1.85 1.70 – 3.76
V shift - 50% - 50%
H shift +/- 7% +/- 7%
Attached 3D filter LKRA-005 LKRA-005
Dimensions W 256 x H 340 x D 559 mm W 256 x H 340 x D 562 mm
Mass 12.0 kg 12.0 kg
* Throw distance definition needs not only lens throw ratio but also projection screen
aspect.
Lamp
LKRM-U450 LKRM-U330
Recommended replacement time 2,000 hours* 3,000 hours*
Dimensions W 89 x H 122 x D 148 mm W 89 x H 122 x D 148 mm
Mass 510 g 510 g
* Recommended replacement time are different for their usage environment.
