Sony VPL-SW535 Installation and operation manual

The VPL-SW535 widescreen WXGA projector is an
ideal choice for ultra close projection applications in
the corporate and educational markets. This projector
offers:
LOW TOTAL COST OF OWNERSHIP
The model has a low brightness mode which reduces
power consumption and extends the lamp lifetime to
approximately 6000 hours, which means lower oper-
ating costs across the board.
EASE OF OPERATION
This projector is ideal for small or difficult spaces - its
ultra short throw ratio can produce a 2.03M (80") di-
agonal screen size image from only 0.58M (1.9 feet)
away from the screen. It also has easy to operate
controls.
BRIGHT, CLEAR PRESENTATIONS
Excellent contrast, consistent colour stability, high
picture quality and longer durability will improve vis-
ibility and enhance teaching quality.
PRIMESUPPORT
All Sony business projectors come supplied with a
3-year support pack which offers unique extra ser-
vices and benefits
• 3 years’ cover
• Free telephone helpdesk support in English, Ger-
man, French, Italian and Spanish.
• Collection and delivery anywhere in EU, Norway
and Switzerland
Features
Maximum 3000 lumens brightness with High, Stand-
ard and Low modes
The VPL-SW535 features three brightness modes for
different use – ’High’ for naturally white presentations
in bright rooms, ’Standard’ for everyday use, and
’Low’ for video in darkened rooms.
0.27 - 0.29:1 throw ratio
The VPL-SW535 offers a 0.27 - 0.29:1 throw ratio
that produces a 2.03M (80”) diagonal screen size im-
age from only 0.58M (1.9 feet) away from the screen.
3LCD BrightEra Technology
Sony’s 0.75 inch BrightEra inorganic TFT 3-LCD pan-
els deliver improved panel light resistance, higher res-
olution, high brightness and increased panel
reliability.
WXGA Widescreen Resolution
The VPL-SW535 has a colour light output of 3000
ANSI lumens and with a native WXGA (1280 x 800)
widescreen resolution panel is perfect for video or
presentations direct from a laptop or PC.
6000 hours Lamp Life
New driving scheme reduces gap expansion that re-
duces brightness gradation and a new cooling system
allows uniformity in the temperature of the glass bulb
which prevents the glass from clouding.
Eco Mode Key
Users can easily select power-saving Eco Modes. The
most energy-efficient mode is accessible though a
single button-push, and further adjustments are avail-
able through an easily understood menu system.
ECO Lamp Dimming
This projector (if function is on) can reduce power
consumption and brightness by 10~15% without user
detection during a input image. After a user pre-set
time, the brightness and power consumption will re-
duce to 30%.
ECO Picture Mute - (Instant off / Instant On)
Picture Mute reduces power consumption down to
30% power usage, saving cost and lamp hours. This
feature can be used in the education market as in-
stant off / instant on in-between class changes, avoid-
ing the need to power off completely and then turn
back on - which does increase power consumption
and is time consuming.
Digital / HD Ready
HMDI input means the VPL-SW535 can accept High
Definition digital signals from PC or Video source.
Ultra short throw widescreen WXGA resolution
projector for educational and business
environments
VPL-SW535
www.pro.sony.eu/projectors 1

Automatic Keystone Adjustment
The projector can detect keystone distortion and can
correct it automatically. (Note that since this is an
electronic correction, it may reduce the picture quality
slightly).
Smart APA (Auto Pixel Alignment)
When a computer is used as a picture source, APA
automatically optimizes Phase, Pitch and Shift values.
These can also be adjusted manually.
Auto Input Search
Auto Input Search detects which input has an incom-
ing signal, and automatically switches to it. This
makes it easier for users to set up the projector prior
to making a presentation.
Picture Muting / Audio Muting
If there is a need to blackout the image or turn of the
audio from the projector, all it takes is a single
button-press on the remote control. One button will
mute audio and image at the same time. There is also
a separate “mute audio” button for audio-only
muting.
Six Picture Modes
The VPL-SW535 has six available picture modes for
correct picture quality; Dynamic, Standard, Game,
Living, Cinema, and Presentation. Six picture mode
and 3 brightness mode combined, the user can select
most suitable picture / brightness mode according to
the picture source and environment for perfect image.
Audio switcher facility
To avoid the need for a separate audio switcher, the
projector can be used to select between two audio
sources, routing them via a variable audio output to
the room amplification system.
Picture Freeze Function
Picture Freeze is useful during presentations if you
need to look at other material on your PC’s screen
without the viewing audience being aware. Freeze the
current image, and you can use your PC independ-
ently of the display from the projector.
Digital Zoom
With Digital Zoom, if you are displaying a computer-
sourced image, you can enlarge a selected area of the
screen image up to four times.
Off and Go
At the end of a presentation, you can turn off the
power supply to the projector immediately, instead of
going through a ‘power down’ cycle.
Direct Power On/Off
With this function, there is no need to go through
‘Standby’ mode when powering up the projector. The
projector can be set to activate as soon as power is
applied.
Filter cleaning at the same time as lamp
replacement
The filter only needs to be cleaned when a new lamp
is fitted, potentially halving disruption due to
maintenance.
Web Control and Monitoring / E-mail Report
A built-in Web Browser allows the user or AV manager
to check a projector status remotely. Power ON/
STANDBY, Input / output, Lamp usage (hours) can be
controlled. A E-mail address can also be set to notify
lamp exchange/replacement or any unexpected
problems.
Technical Specifications
Optical
Display System 3LCD system
Display device
Size of effective display
area
0.75” (15.0 mm) x 3,
BrightEra, Aspect ratio:
16:10
Number of pixels 3,072,000 (1280 x 800 x 3)
pixels
Projection Lens
Zoom X 1.05
Focus Manual
Digital Zoom X4
Lens Shift V: +/- 4.4%, H: +/- 2.7%
Lamp High-pressure mercury lamp
210 W type
Recommended lamp re-
placement time*1
3000 H / 4500 H / 6000 H
(Lamp mode: High / Stand-
ard / Low)
Filter cleaning cycle 6000 H - New Filter System
Screen Size 70” to 130” (1.8 m to 2.8 m)
Light output (Lamp
mode: High / Standard /
Low)
3000 lm / 2400 lm / 2000
lm
Colour light output
(Lamp mode: High /
Standard / Low)
3000 lm / 2400 lm / 2000
lm
Contrast ratio (full white
/ full black)*2
2500:1
Fan noise 28dB (low)
Speaker 1 W x 1 (monaural)
Displayable scanning frequency
Horizontal 14 kHz to 93 kHz
Vertical 47 Hz to 93 Hz
VPL-SW535
www.pro.sony.eu/projectors 2

Display resolution
Computer signal input Maximum input signal resol-
ution: 1600 x 1200 (resizing
display) fV60Hz Panel dis-
play resolution: 1280 x 800
pixels
Video signal input Video (Composite), 15K
(480/60i, 576/50i,), DTV
(480/60p, 576/50p, 720/
60p, 720/50p, 1080/60i,
1080/50i)
Colour system Auto / NTSC3.58, PAL,
SECAM, NTSC4.43, PAL-M,
PAL-N
Keystone correction Vertical: Max. +/- 5 degrees
OSD language 20-languages (English,
Dutch, French, Italian, Ger-
man, Spanish, Portuguese,
Turkish, Polish, Russian,
Swedish, Norwegian, Japan-
ese, Simplified Chinese, Tra-
ditional Chinese, Korean,
Thai, Vietnamese, Arabic,
Farsi)
Computer and video signal input/output
INPUT A RGB / Y PB PR input con-
nector: Mini D-sub 15-pin
(female), Audio input con-
nector: Stereo mini jack
INPUT B HDMI™
COMPOSITE VIDEO Video input connector: Pin
Jack Audio input connector:
Pin jack
S-VIDEO IN S video input connector:
Mini DIN-4 pin Audio input
connector: Pin jack (x2)
OUTPUT Monitor output connector*4:
Mini D-sub 15-pin (female),
Audio output connector*5:
Stereo mini jack (variable
out)
Control signal input/
output
RS-232C connector: D-sub
9-pin (female) LAN connect-
or: RJ45, 10BASE-T/
100BASE-TX
Operating temperature
(Operating humidity)
0°C to 40°C / 32°F to 104°F
(35% to 85%; no
condensation)
Storage temperature
(Storage humidity)
(-20°C to 60°C / -4°F to
140°F) (10% to 90%; no
condensation)
Power requirements AC 100 V to 240 V, 3.6- 1.4
A, 50 Hz /60 Hz
Power Usage
AC 100 V to 120 V 290W (High brightness
mode)
AC 220 V to 240 V 280W (High brightness
mode)
AC 100 V to 120 V 8 W / 0.3 W (Standby mode:
Standard / Low)
AC 220 V to 240 V 8 W / 0.3 W (Standby mode:
Standard / Low)
AC 100 V to 120 V 989 BTU (Heat Dissipation)
AC 220 V to 240 V 955 BTU (Heat Dissipation)
General
Outside dimensions W 384.4 x H 161.1 x D
423.4 mm / W 15 1/8 x H 6
11/32 x D 16 21/32 in , W
384.4 x H 122.5 x D 423.4
mm / W 15 1/8 x H 4 13/16
x D 16 21/32 in (without
protrusion)
Mass 7.0kg / 15lb 7oz
Notes
*1 The figures are expected
maintenance time and not
guaranteed. They will de-
pend on the environment or
how the projector is used.
*2 The value is average.
*3 Not available in standby.
*4 Works as audio switcher
function. From current chan-
nel only. Not available in
standby.
Supplied Accessories
Wall Mount Bracket
RM-PJ7 Remote Commander RM-PJ7
(1)
CR2025 Lithium Battery (1)
Mini D-sub 15-pin cable (1)
Lens Cap (1)
Operating Instructions (1)
WEEE, EU Battery Info, Ser-
vice Documentation
Quick Reference Manual (1)
AC power cord (1)
VPL-SW535
www.pro.sony.eu/projectors 3
