Sony VPL VPL-HW15 User manual

VPL-HW15
Home Theater SXRD Projector HW10
Key Features
Full HD 1080p with 3 SXRD™1920 x 1080 Panels
Up to 60,000:1 Contrast Ratio (Advanced Iris
On)
1
Brightness of 1,000 ANSI lumens
2
200W Ultra-High-Pressure Lamp
BRAVIA Engine ™2 fully digital video processor
Advanced Iris 3
24p True Cinema™
x.v.Color ™
3
Deep Color
ARC-F (All Range Crisp Focus) Lens
Key Technologies
Full HD 1080p with 3 SXRD ™1920 x 1080 Panels Three SXRD 1920 x 1080p micro - display panels
support Full HD 1080p resolution for an impressive combination of vivid color, film - like image quality,
and high - definition brilliance. Enjoy cinematic - quality images.
200W Ultra- High -Pressure Lamp A 200W Ultra - High - Pressure Lamp delivers natural color with a
brightness of 1000 ANSI lumens .
2
BRAVIA Engine ™2 BRAVIA Engine 2 fully digital video processor uses a collection of unique Sony ®
algorithms to significantly reduce noise, enhance overall image detail, and optimize contrast so
every scene produces sharp, vibrant, life - like images.
Advanced Iris 3 The Advanced Iris 3 function provides up to a 60,000:1 contrast ratio by optimizing
both dark and bright scenes to produce deep black levels with stunning details.
1
24p True Cinema™ 24p True Cinema technology provides a direct connection to 24p video
sources so you can avoid conversions and enjoy films at their intended 24 fps (frames per second).
x.v.Color™ x.v.Color technology takes HD color expression to new levels. When connected to
x.v.Color capable video sources, such as select Sony ® camcorders, the VPL - HW15 can display nearly
twice as many (1.8x) viewable colors as the existing RGB color standard, resulting in more natural,
life - like images.
3
Deep Color By combining a 10 - bit processor with 10 - bit SXRD™panels, the VPL - HW15 can create and
display 64 times the level of color expression of 8 - bit projectors, resulting in smoother color
gradations and helping to avoid a “paint - by - numbers”look.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 11/15/2010
VPL-HW15
Home Theater SXRD Projector HW10
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Specifications
General
Lens: 1.6 times zoom lens (manual),
f=18.5 to 29.6 mm / F2.50 to F3.40
Projection Picture Size: 40 to 300 inches
(1,016mm to 7,620mm) (measured
diagonally)
TelevisionType: HD Front Projectors
Display
Screen Size (measured diagonally): 40" to
200" measured diagonally (projected)
DisplayResolution: 1920 x 1080 (Full HD)
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s):
Phono type / HD D - sub 15 - pin
Composite Video Input(s): Phono Type
S- VideoInput(s): Y/C mini DIN 4 - pin type
Component/Progressive: Phono type / HD
D - sub 15 - pin
HDMI™Connection(s)(Total): 2
RS - 232CInput(s): D - sub 9 - pin
HDMI™Connection(s): Yes
Power
Power Consumption (in Operation): 300W
Power Consumption (in Standby): 8W;
:0.5W (low mode)
PowerRequirements: AC 100 to 240V, 3.0 -
1.3A, 50/60H z
Service and Warranty Information
Limited Warranty Term: Product Warranty -
1 Years Parts and Labor except the lamp.
Lamp Warranty - 90 Days from date of
purchase.
Video
ContrastRatio: Up to 60,000:1
Brightness: 1,000 Lumens
Dimensions
Weight: 22 lbs
Measurements: 16 1/8 x 71/8 x 18 3/8
inches
Supplied Accessories
Remote Commander RM - PJVW70 (1)
Size AA (R6) batteries (2)
AC power cord (1)
Lens Cap (1)
Operating Instructions (1)
Optional Accessories
LMP - H201 Projector Lamp
PSS - H10 Projector Suspension Support
UPC Code: 027242774339
1.60,000:1contrastratioachievedwithAdvancedIrisAutoON.
2.ANSIlumensisameasuringmethodoftheAmericanNational
StandardsInstituteIT7.228.Sincethereisnouniformmethodof
measuring brightness, specifications will vary among manufactures.
3.Whenusedwith supporting video sources such as select Sony
camcorders.
4.BRAVIATheatreSync™workswithselectSony HDTVs,front
projectors,and home theater products. Check owner ’ smanuals for
compatibility.
5.Pixelconvergenceto1/10thinchiscalculatedas ± 2.0dot by 0.1dot
pitch.Dependingon the adjustments made, the number of display
pixelsmaydecrease.Also,colorsmaybecomeunevenor the
resolution may change.
©2009SonyElectronics Inc. All rightsreserved.Reproductionin whole or
inpart without written permission is prohibited.
Sony,HDNA, BRAVIA, BRAVIAEngine,TheatreSync, Remote
Commander,SXRD,24pTrueCinema,x.v.Colorandtheir respective
logosare trademarks of Sony. Blu - rayDisc is atrademark.HDMI, the
HDMI logo, and High - DefinitionMultimedia Interface are trademarksof
HDMILicensing LLC. All othertrademarksaretrademarks of their
respectiveowners.
Non - metricweights and measurements are approximate and mayvary.
®
