Sony Effio-E SHR-704 User manual

110509-0463FG-0562-V3b
0
Digital WD Box Camera (Effio-E)
SHR-704
User Manual
Thanks for purchasing our product. Before operating the unit, please read the
instructions carefully and keep this manual for future reference.

110509-0463FG-0562-V3b
1
Safety Warning
1. Read this manual carefully before installing the unit
Please read this manual first for correct installation and operation.
2. Never install the camera on a ceiling that cannot hold its weight
The product may fall down and cause damages.
3. Never install the camera near electric or magnetic fields
Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,
audio speakers since the magnetic fields generate from above devices would distort the
video image.
4. Never install or use the camera in areas exposed to water, oil or gas
The water, oil or gas may result in operation failure, electric shock or fire. Do not use this
unit near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, near a swimming pool, in an unprotected outdoor installation, or any area
which is classified as a wet location.
5. Never face the camera toward the sun
Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.
6. Power Cord Protection
Touching the wet power cord with hands or touching the power cord with wet hands may
result in electric shock. Power supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, playing particular attention
to cords and plugs, convenience receptacles, and the point where they exit from the
appliance.
7. Attachments
Do not use attachment not recommended by the product manufacturer as they may cause
hazards.
8. Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind onto the product.
9. Do not operate the camera in environments where the temperature, humidity or
power source is beyond the specified ones
Use the camera in suitable environments where the temperature is within -10˚C~50˚C and
humidity below 80%. Use the input power source as this instruction indicated.

110509-0463FG-0562-V3b
2
10. Cleaning
Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
11. Never disassemble the camera nor put impurities in it
Disassembly or impurities may result in trouble or fire.
12. Stop using when the product emits smoke or abnormal heat
13. Servicing
Do not attempt to repair this unit yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
14. Retain Instructions
THE SAFETYAND OPERATING INSTRUCTIONS SHOULD BE RETAINED FOR FUTURE
REFERENCE.
NOTE:
The information in this manual was current when published. The manufacturer reserves the right
to revise and improve its products. All specifications are therefore subject to change without
notice.

110509-0463FG-0562-V3b
3
Table of Contents
1. INTRODUCTION................................................................................................................................. 1
1.1 MAIN FEATURES............................................................................................................................... 1
1.2 CONTENT LIST ................................................................................................................................. 1
1.3 SPECIFICATIONS............................................................................................................................... 2
2. CAMERA OVERVIEW......................................................................................................................... 3
2.1 DIMENSIONS .................................................................................................................................... 3
2.2 DESCRIPTION OF CAMERA PARTS...................................................................................................... 4
3. OSD OPERATION............................................................................................................................... 6
3.1 OSD CONTROL BUTTONS................................................................................................................. 6
3.2 OSD OPERATION............................................................................................................................. 7
4. CONFIGURATION .............................................................................................................................. 8
4.1 LENS.............................................................................................................................................. 8
4.1.1 AUTO IRIS........................................................................................................................... 8
4.2 SHUTTER/AGC.................................................................................................................... 10
4.2.1 AUTO SETUP.................................................................................................................... 10
4.2.2 MANUAL SETUP................................................................................................................11
4.3 NR .......................................................................................................................................... 12
4.4 WHITE BAL(WHITE BALANCE) ................................................................................................ 13
4.4.1 ATW (Auto Trace White Balance)...................................................................................... 14
4.4.2 PUSH................................................................................................................................. 14
4.4.3 USER1............................................................................................................................... 15
4.4.4 USER2............................................................................................................................... 15
4.4.5 MANUAL WB (Manual White Balance).............................................................................. 15
4.4.6 PUSH LOCK...................................................................................................................... 16
4.5 ATR......................................................................................................................................... 17
4.5.1 ATR ON.............................................................................................................................. 17
4.6 BACKLIGHT........................................................................................................................... 18
4.7 DAY/NIGHT............................................................................................................................ 19
4.7.1 B/W .................................................................................................................................... 19
4.7.2 DAY/NIGHT........................................................................................................................ 20
4.8 PICTADJUST......................................................................................................................... 21
4.9 MOTION DET (MOTION DETECTION)........................................................................................ 22
4.9.1 MOTION DET ON.............................................................................................................. 22
4.10 PRIVACY................................................................................................................................ 24
4.10.1 PRIVACY ON..................................................................................................................... 24

110509-0463FG-0562-V3b
4
4.11 CAMERAID............................................................................................................................ 26
4.11.1 CAMERA ID ON................................................................................................................. 26
4.12 LANGUAGE ........................................................................................................................... 28
4.13 CAMERARESET ................................................................................................................... 29
4.14 SAVEALL............................................................................................................................... 29
4.15 EXIT........................................................................................................................................ 29

110509-0463FG-0562-V3b
1
1. Introduction
SHR-704 built with Sony’s latest image processor, this super-wide dynamic camera
has the capability of achieving resolutions of over 640TVL. The features include 2D
noise reduction, spot removal, strong-light suppression, intelligent motion detection
and OSD functions. SHR-704 reproduces nearly perfect images like no other.
1.1 Main Features
1/3" Digital Wide Dynamic Color Camera (Sony Effio-E)
Color:640TVL
Color:0.03Lu[email protected]
Multi-Language OSD Control
ATR Digital Powerful 128x WDR (52dB)
Anti-Headlight (HLC)
2D Noise Reduction
High Contrast Images
Ideal for Backlight Environments
Mosaic Privacy Mask
Advanced Motion Detection Function
Picture Quality Adjustable (Contrast/Sharpness/Hue/Gain)
1.2 Content List
Digital WD Box Camera (Effio-E): SHR-704
User’s manual

110415-0463FG-0562-V3b
2
1.3 Specifications
TV System
PAL
NTSC
Image Sensor
1/3" Sony 760H Super HAD CCD II
Number Of Total Pixels
795(H)x596(V)
811(H)x508(V)
Resolution ; DSP
Color:640TVL ; Sony Effio-E
Minimum Illumination
Color:0.03Lux@F1.2
Wide Dynamic Range
ATR Digital WD (ATR:Adaptive Tone-curve Reproduction) ;
128x Normal Camera (52dB)
Video Output ; Connector
1.0Vp-p Composite, 75Ω; BNC
Signal Noise Ratio
More than 55dB (AGC off)
Gamma Correction
0.45
Menu
OSD Control
Title
TITLE (LOCATION)
Synchronizing System
INTERNAL
Digital Day&Night Mode
COLOR / B&W / AUTO
Electronic Shutter
AUTO (1/50(60)~1/100,000sec.) /
MANUAL: 1/50(60), FL 1/120(100), 1/250, 1/500, 1/1,000,
1/2,000, 1/4,000, 1/10,000sec.
Automatic Gain Control
AUTO (4 Steps)
White Balance
ATW / PUSH / USER1 / USER2 /ANTI CR /
MANUAL / PUSH LOCK
Back Light Compensation
HLC / BLC / OFF
Flickerless
ON / OFF
Dynamic Noise Reduction
2D
Language
ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN /
PORTUGUESE / SPANISH / SIMPLIFIED CHINESE
Motion Detection ; Privacy
ON / OFF (24x16 Zones) ;
ON / OFF (8 Zones Programmable, Mosaic)
Automatic IRIS ; Connector
VIDEO / DC ; D4 IRIS Jack
Lens Mount
CS / C mount (With Adaptor Ring)
Power Supply ; Consumption
12Vdc±10% ; 1.5W
Operation ; Storage
Temperature
-10˚C~50˚C ; -20˚C~60˚C
Operation ; Storage Humidity
Maximum:RH80% ; RH90%
Dimensions
64(W)×58(H)×123(L)mm
Net Weight
350g

110509-0463FG-0562-V3b
3
2. Camera Overview
2.1 Dimensions

110509-0463FG-0562-V3b
4
2.2 Description of Camera Parts
①Lens Mount
This mount is used to install a CS-mount lens. CS-adaptor ring is required when using a C
mount lens.
②Camera Mounting Screw Holes
Screw hole for mounting the camera.
③Mount Adaptor
The adaptor can be attached onto the top or the bottom of the unit.
④Auto Iris Lens Connector (4-pin type)
The lens connector supplies the auto-iris lens (not supplied) with DC control signal.
⑤OSD Control Buttons
ENTER button
UP & DOWN buttons
LEFT & RIGHT buttons
⑥Video Connector
Connect to the long-term video monitor. (75Ω)
⑦IRIS Mode Selection Switch
Select DC or VIDEO mode according to the lens.
PIN NO.
VIDEO
DC
1
DC + 12V
CONTROL -
2
NC
CONTROL +
3
IRIS
DRIVE +
4
GND
DRIVE -

110509-0463FG-0562-V3b
5
⑧Secondary Video Connector
Connect to the portable LCD for viewing on the spot. Designed for quick installation use.
(75Ω)
⑨Power Input Indicator Light
When the camera is connected to a power supply, the indicator light will be on.
⑩Power Input Terminal
Connect to the power supply.

110509-0463FG-0562-V3b
6
3. OSD Operation
3.1 OSD Control Buttons
①UP
Use this button to move the cursor upwards to the desired item.
②RIGHT
Use this button to move the cursor to the right to select or to adjust the parameters of the
selected item. The parameter increases when the right button is pressed.
③DOWN
Use this button to move the cursor downwards to the desired item.
④LEFT
Use this button to move the cursor to the left to select or to adjust the parameters of the
selected item. The parameter decreases when the left button is pressed.
⑤ENTER
Use this button to display the main menu, to confirm and to enter the submenus when
they’re available. Items with the symbol ―<┘‖in the end contain sub-menus. For further
settings of those items, select the desired item with the button or and press the
ENTER button to bring up the sub-menu and edit.

110509-0463FG-0562-V3b
7
3.2 OSD Operation
1. Start to operate the OSD menu
Press the ENTER button to bring up the OSD main menu to start operating OSD menus.
2. Select items with the cursor buttons
Use buttons and to move the cursor up and down.
Use buttons and to switch the modes or to adjust the parameters or the values
of the settings.
3. Switch to the sub-menu
Items with ―<┘‖ symbol in the end contain sub-menus. For further settings of those items,
select the desired item with the button or and press the ENTER button to bring up
the sub-menu and edit.
4. Return to the previous page
Select RETURN and press the ENTER button to return to the previous page.
5. Exit the OSD menu
Select EXIT with the button or and press the ENTER button to exit the OSD menu.
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL
Main Menu
AUTO IRIS
TYPE
DC
MODE
AUTO
SPEED
|||||||||||||||| 080
RETURN<┘
Sub-Menu
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL

110509-0463FG-0562-V3b
8
4. Configuration
4.1 LENS
When the SETUP MENU is displayed on the screen, use buttons and to select the
LENS and press the ENTER button to do further settings.
Select to set the mechanical iris of the lens.
Function
Option
LENS
MANUAL
AUTO<┘
MANUAL
Auto electronic shutter
AUTO<┘
Auto electronic shutter + Mechanical auto IRIS
When AUTO<┘ is selected, click ENTER to bring up the AUTO IRIS sub-menu for further
settings.
4.1.1 AUTO IRIS
Adjust the settings of the AUTO IRIS.
Function
Option
TYPE
DC
VIDEO
MODE
OPEN
CLOSE
AUTO
SPEED
000 –255
TYPE
Select to set the type of the mechanical iris.
- DC: DC Lens.
- VIDEO: VIDEO Lens.
Main Menu
AUTO IRIS
TYPE
DC
MODE
AUTO
SPEED
|||||||||||||||| 080
RETURN<┘
Sub-Menu
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL

110509-0463FG-0562-V3b
9
MODE
Select to set the type of control to be exercised over the mechanical iris.
- OPEN: The mechanical iris is fixed to open.
- CLOSE: The mechanical iris is fixed to close.
- AUTO: The mechanical iris is controlled automatically.
SPEED
Select to set the convergence speed of the mechanical iris.

110509-0463FG-0562-V3b
10
4.2 SHUTTER/AGC
When the SETUP MENU is displayed on the screen, use buttons and to select the
SHUTTER/AGC and press the ENTER button to do further settings.
Select to setAuto exposure or Manual exposure.
Function
Option
SHUTTER/AGC
AUTO<┘
MANUAL<┘
AUTO<┘:
When AUTO<┘ is selected, click ENTER to bring up the AUTO SETUP sub-menu for
further settings.
MANUAL<┘:
When MANUAL<┘ is selected, click ENTER to bring up the MANUAL SETUP sub-menu
for further settings.
4.2.1 AUTO SETUP
Adjust the settings of the AUTO SETUP.
Function
Option
HIGH
LUMINANCE
MODE
SHUT+AUTO IRIS
AUTO IRIS *
BRIGHTNESS
000 –255
LOW
LUMINANCE
MODE
OFF
AGC
BRIGHTNESS
x0.25 ; x0.50 ; x0.75 ; x1.00
HIGH LUMINANCE
- MODE
Select to specifyAE control on the medium- and high-brightness side.
SHUT + AUTO IRIS: Auto electronic shutter + Mechanical auto IRIS
AUTO IRIS: Shutter fix + Mechanical auto IRIS
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL

110509-0463FG-0562-V3b
11
NOTE:
If MANUAL has been selected as the LENS function setting, SHUT will be
displayed, and the settings made in this section will not take effect.
- BRIGHTNESS
Select to specify the high- and medium-brightness side reference.
The brightness changes depending on whether the ATR function is ON or OFF,
and whether the CRS mode has been selected as the AWB function.
Please note that the brightness will change when ATR or WHITE BAL is set to
ANTI CR (CRS mode), etc., after BRIGHTNESS has been set.
LOW LUMINANCE
- MODE
Select to specifyAE control on the low-brightness side.
OFF: OFF
AGC:Auto gain control
- BRIGHTNESS
Select to specify the low-brightness side reference.
4.2.2 MANUAL SETUP
Adjust the settings of the MANUAL SETUP.
Function
Option
MODE
SHUT+ AGC
SHUTTER
1/60* ; 1/100* ; 1/250 ; 1/500 ; 1/1000 ; 1/2000 ; 1/4000 ;
1/10000
AGC
6.00 ; 12.00 ; 18.00 ; 24.00 ; 30.00 ; 36.00 ; 42.00 ; 44.80
MODE
"SHUT+AGC" is the only option available for the ME operation mode.
There are no other options.
SHUTTER
Select to set the ME shutter speed (in fractions of a second).
AGC
Select to set the AGC value for ME.

110509-0463FG-0562-V3b
12
4.3 NR
This item is used to set the noise reduction.
Select to bring up the NR sub-menu for further settings.
Function
Option
NR MODE
OFF
Y
C
Y/C
Y LEVEL
000-015
C LEVEL
000-015
NR MODE
Select to set the 2D NR filter mode.
- OFF: Y and C filters OFF
- Y: Y filter ON
- C: C filter ON
- Y/C: Y and C filters ON
Y LEVEL
Select to set the Y filter strength.
C LEVEL
Select to set the C filter strength.
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL

110509-0463FG-0562-V3b
13
4.4 WHITE BAL (White Balance)
The screen color can be adjusted by using the WHITE BAL function.
1. Please use the and buttons to WHITE BAL on the SETUP MENU and press the
ENTER button to do further settings.
2. Please select the desired item and press and buttons to adjust the settings.
Select to set the white balance Mode.
Function
Option
WHITE BAL
ATW
PUSH
USER1
USER2
ANTI CR
MANUAL
PUSH LOCK
ATW (Auto Trace White balance)
When ATW<┘ is selected, click ENTER to bring up the ATW sub-menu for further
settings.
PUSH: All pull-in
Select to set the white balance mode to the PUSH mode.
USER1: Fluorescent light fixed gain (3200K)
When USER1<┘ is selected, click ENTER to bring up the USER1 WB sub-menu for
further settings.
USER2: Outdoor fixed gain (6300K)
When USER2<┘ is selected, click ENTER to bring up the USER2 WB sub-menu for
further settings.
SETUP MENU
LENS
AUTO<┘
SHUTTER/AGC
AUTO<┘
NR
<┘
WHITE BAL
ATW<┘
ATR
OFF
BACKLIGHT
OFF
DAY/NIGHT
AUTO<┘
NEXT<┘
EXIT<┘
SAVE ALL

110509-0463FG-0562-V3b
14
ANTI CR: Color rolling suppression
Select to set the white balance mode to the ANTI CR mode.
MANUAL: Manual white balance
When MANUAL<┘ is selected, click ENTER to bring up the MANUAL WB sub-menu for
further settings.
PUSH LOCK
Select to set the white balance mode to the PUSH LOCK mode.
4.4.1 ATW (Auto Trace White Balance)
Adjust the settings of the ATW.
Function
Option
SPEED
000-255
DELAY CNT
000-255
ATW FRAME
x0.50 ; x1.00 ; x1.50 ; x2.00
ENVIROMENT
INDOOR ; OUTDOOR
SPEED
Select to adjust the pull-in speed of ATW.
DELAY CNT
Select to set the time-based hysteresis of ATW.
ATW FRAME
Select to set the pull-in frame magnification.
ENVIROMENT
Select to set the pull-in frame (indoor/outdoor) ofATW.
4.4.2 PUSH
Select to allow the camera automatically adjust the white balance under all
conditions.

110509-0463FG-0562-V3b
15
4.4.3 USER1
The gain values for the fluorescent light fixed mode are used as the adjustment items
of USER1 WB on the internal OSD menu.
B-GAIN
Used for operating the B gain in the WB fixed gain mode.
R-GAIN
Used for operating the R gain in the WB fixed gain mode.
4.4.4 USER2
The gain values for the outdoor fixed mode are used as the adjustment items of
USER2 WB on the internal OSD menu.
B-GAIN
Used for operating the B gain in the WB fixed gain mode.
R-GAIN
Used for operating the R gain in the WB fixed gain mode.
4.4.5 MANUAL WB (Manual White Balance)
The B and R gain values for manual WB are set on this screen.
LEVEL
Select to set the B and R gain values for MANUAL WB.
By incrementing or decrementing the B gain value, the R gain value is also
adjusted in tandem.
Function
Option
B-GAIN
000-255
R-GAIN
000-255
Function
Option
B-GAIN
000-255
R-GAIN
000-255
Function
Option
LEVEL
000-255
