Sony Clie Clie Version 2.0 User manual

© 2001 Sony Corporation
Audio Player
Version2.0
User Guide
A-AVN-200-11

2
CLIE, Jog Dial, Memory Stick,the Memory Stick logo and PictureGear are trademarks of Sony
Corporation.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Graffiti, HotSync, and Palm OS are registered trademarks, and the HotSync logo and Palm are
trademarks of Palm, Inc. or its subsidiaries.
QuickTime and the QuickTime logo are trademarks used under license. QuickTIme is registered in
the U.S. and other countries.
All other trademarks are trademarks of their respective owners.
Before using this software, please read the Software License Agreement that is supplied with Sony
handheld.
❒Copying all or part of the contents of this software, sample images, and Operating
Manual, or renting the software are prohibited by copyright laws.
❒The Company is not liable for damage or loss resulting from the use of this software, or
for any claim from a third party.
❒The Company assumes no responsibility aside from the replacement of the media due to
manufacturing fault.
❒This software must not be used in a system other than that specified.
❒The software specifications may be subject to change without notice.

3
Table of contents
What you can do with
the Audio Player .................................. 4
To Listen to MP3 format audio files on
your CLIE handheld................................ 5
To Listen to ATRAC3 format audio files
managed by OpenMG Jukebox on your
CLIE handheld........................................ 6
Installing Audio Player Ver.2.0 to your
CLIE handheld........................................ 7
Installing the software......................... 7
System requirements ............................. 9
Installing RealJukebox software .......... 10
Installing OpenMG Jukebox software .. 12
Importing audio files into your
computer............................................ 15
If you manage your audio files with
RealJukebox software.......................... 15
If you manage your audio files with
OpenMG Jukebox software.................. 17
Preparing your CLIE handheld, and
placing it in the cradle ......................... 25
Transferring audio files from your
computer to your CLIE handheld ....... 25
Transferring MP3 format audio files to
your CLIE handheld.............................. 27
Playing audio files on your CLIE
handheld ............................................ 30
Connecting/attaching the supplied
headphones ......................................... 30
Playing audio files................................ 32
Playing in various modes ..................... 35
Selecting playback audio files (Pick up) 36
Switching the display view .................. 37
Switching the JogDial navigator
function for Audio Player ..................... 38
Playing audio files with the supplied
remote controller ................................. 40
Protecting your CLIE handheld from
accidental pressure on its controls....... 42
Switching the album (Custom album).. 43
Notes on “Memory Stick” media....... 44
Notes on using RealJukebox .............. 46
Notes on using OpenMG Jukebox...... 47
What is “Check-in/Check-out”?........... 47
On copyright protection....................... 48
Differences between the HotSync
operation and the check-in/out
procedure............................................. 49
Transferring songs from your CLIE
handheld to your computer (Check-in) 50
Notes on playing audio files ................ 52
Restrictions on copyright protection
by OpenMG ......................................... 54
Audio Player menu items ................... 55

4
What you can do with the Audio Player
Audio Player is an application used to play audio files on your CLIE
handheld. The following two versions of Audio Player are supplied with
your CLIE handheld.
This manual explains the operation for Audio Player Ver.2.0.
• Audio Player Version 1.1: you can play ATRAC 3 format audio files
managed by the OpenMG Jukebox software. This version of Audio Player
is pre-installed; you do not have to install it.
• Audio Player Version 2.0: you can play both MP3 and ATRAC 3 format
audio files. In addition, you can use various playback displays such as
Visual Effect view or List view. This version of Audio Player is supplied in
the CD-ROM; you have to install it.
Note
You cannot use both versions of Audio Player at the same time.
Audio Player Ver.2.0 supports MP3 files that meet following
specifications
• Format: MP3 ver.1, Layer 3
• Sampling frequency: 44.1 kHz
• Bit rate: 32 to 128 kbps
• File extension: .mp3 or .rmp
A “Memory Stick” media is required to play audio files on your CLIE
handheld
There are two types of “Memory Stick” media. One is the normal “Memory
Stick” media (purple), and the other is the “MagicGate Memory Stick”
media (white).
To play ATRAC 3 format audio files on your CLIE handheld, you have to
use a “MagicGate Memory Stick” media. Otherwise, you can use normal
“Memory Stick” media.
For details, see “Notes on “Memory Stick” media” on page 44.

5
To Listen to MP3 format audio files on your CLIE handheld
You need to use;
• Any software for managing MP3 format audio file on your computer. We
supplied RealJukebox software for it with CD-ROM.
• A “MagicGate Memory Stick” media (not supplied) or a standard
“Memory Stick” media (supplied).
To listen to MP3 format audio files with your CLIE handheld, please
follow these steps.
1Install Audio Player version .2.0 on your CLIE handheld. (See
page 7)
2Install any software for managing MP3 format audio file on
your computer.
We recommend RealJukebox supplied with CD-ROM. (See page 10)
3Ready any MP3 audio files on your computer.
For details of instructions, see software’s manuals or online help.
4Transferring audio files from your computer to your CLIE
handheld. (See page 27)
5Playing audio files on your CLIE handheld. (See page 32)
What you can do with the Audio Player

6
To Listen to ATRAC3 format audio files managed by
OpenMG Jukebox on your CLIE handheld
You need to use;
• OpenMG Jukebox software for managing ATRAC3 format audio file on
your computer. We supplied it with CD-ROM.
• “MagicGate Memory Stick” media (not supplied). A standard “Memory
Stick” media (supplied) is not available.
To listen to ATRAC3 format audio files managed by OpenMG
Jukebox on your CLIE handheld, please follow these steps.
1Install OpenMG Jukebox on your computer. (See page 12)
2Importing audio files into your jukebox. (See page 17)
3Transferring audio files from your computer to your CLIE
handheld. (See page 28)
4Playing audio files on your CLIE handheld. (See page 32)
What you can do with the Audio Player

7
Installing the software
Installing Audio Player Ver.2.0 to your CLIE handheld
Audio Player Ver.2.0 is automatically installed to your CLIE handheld when
you perform procedures in the Chapter 2 of Read This First manual on your
first setup of your CLIE handheld.
In following cases, install Audio Player Ver.2.0 manually in procedures
below:
• When you select the setting not to install Audio Player Ver.2.0 on your
first setup of your CLIE handheld
• When you hard-reset your CLIE handheld
• When you delete Audio Player Ver.2.0
For playing MP3 audio file with Audio Player Ver.2.0
Make sure finishing the installing Up-date file on supplied CD-ROM in
procedures on Read This First manual before installing Audio Player ver.2.0.
If you do not finish it, install “Update Yo-2.0.prc” with AudioPlayer20E.prc
and AudioPlayerSkin.prc in procedure below.
If you use Audio Player Ver.1.1
Before installing Audio Player Ver.2.0, tap to unselect “Enable background
play” check box in the Preferences screen by tapping Menu , Options,
and then Preferences of Audio Player Ver.1.1.
If the box is checked, malfunction may occur after installation.
1Double-click the CLIE Palm Desktop icon on the Windows
desktop.
The CLIE Palm Desktop software starts.
2Click Install.
The Install Tool dialog box appears.
3Select a user name from the user list.
Continued on next page

8
Installing the software
4Click Add.
Make sure that the Add-on folder is selected.
If the Add-on folder is not selected, select it manually.
At the default setup, the Add-on folder is stored in the Sony Handheld
folder of the Program Files folder.
5Double-click the AudioPlayer folder.
6Click AudioPlayer20E.prc.
AudioPlayer20E.prc is added to the File Name list.
7Repeat steps from 4 to 5, and then click AudioPlayerSkin.prc.
AudioPlayerSkin.prc is added to the File Name list.
8Click Done.
9Press the HotSync button on the cradle.
AudioPlayer20E.prc and AudioPlayerSkin.prc are installed on your CLIE
handheld during the HotSync operation.
10
After the HotSync operation ends, tap Reset on your CLIE
handheld screen.
After installation, performing soft-reset of your CLIE handheld is
required
If you install Audio Player Ver.2.0 using another procedure, you have to
perform soft-reset of your CLIE handheld after installation.
If you want to delete Audio Player Ver.2.0 from your CLIE handheld
• Refer to “Removing add-on applications” in Read This First manual.
•Before deleting Audio Player Ver.2.0, tap to unselect “Enable background
play” check box in the Preferences screen by tapping Menu , Options,
and then Preferences.
•After deleting Audio Player Ver.2.0, perform soft-reset of your CLIE
handheld
If you delete Audio Player Ver.2.0 manually not performing the
operation in Read This First manual
Delete AudioPlayerSkin.prc manually at the same time you delete Audio
Player Ver.2.0.
When you delete Audio Player Ver.2.0 performing the operation in Read
This First manual, these files are automatically deleted at the same time.

9
System requirements
Before installing RealJukebox software and/or OpenMG Jukebox software,
make sure that your computer meets the following hardware requirements.
• IBM computer/AT or Compatible
– CPU: MMX™ Pentium®233 MHz or higher
– Hard disk drive space: 60 MB or more
– RAM: 64 MB or higher
– CD-ROM drive
– Sound Board
– USB port
• Operating System: Windows®98/Windows®98 Second Edition/
Windows®2000 Professional/Windows®Me (manufacturer installed)
The following environments are not supported:
– Windows®95, Windows®NT
– A system upgraded from Windows®3.1/95 to Windows®98/Windows®
98 Second Edition/Windows®Me
– A dual boot with Windows®2000 and Windows®98/Windows®98
Second Edition/Windows®Me
• Display: High (16 bit) Color or better (800 ×600 pixels or higher)
• Internet access: for Web registration and EMD services
Notes
• We do not assure trouble-free operation for all computers satisfying the system
requirements.
• For the protection of copyrights, when you use a computer with an optical digital
output connector, the optical connector may be disabled during playback with this
software.
Installing the software

10
Installing the software
Installing RealJukebox software
Install the RealJukebox software to the hard disk of your computer.
Note
If the “Installing:” message continues to appear without advancing to the next step for
some time, click the “InstallShield Wizard” on the taskbar.
1Exit all applications and follow the steps below on your
computer.
2Insert the installation CD-ROM into the CD-ROM drive of your
computer.
The setup program starts automatically.
3Click to select Audio Software.
4Click to select RealJukebox for Sony.
The OpenMG installer appears.
5Click Next.
6Click to select all check boxes.
7Click Next.
Installation starts.
Follow the instructions displayed on the screen.
When the installation ends, your computer is automatically restarted.
Note
Do not delete, move, or edit the installed folders using Windows Explorer or any
other application. If you do so, the RealJukebox Basic database may become unstable
or corrupted.

11
Setting recording preferences
After installing the RealJukebox software, you have to change recording
preferences of the RealJukebox to encode in MP3 audio files.
1Double-click the RealJukebox icon on your Windows desktop,
or click Start, point to Programs, Real, RealJukebox, and then
click RealJukebox.
RealJukebox starts.
2Click Preferences from the Tool menu.
3Click the Audio Quality tab.
4Click MP3 Audio in the Select a Format group.
5Click OK.
6Exit the RealJukebox software.
Installing the software

12
Installing OpenMG Jukebox software
Notes on using OpenMG Jukebox with Windows 2000/Windows
Me
Notes on using OpenMG Jukebox with Windows 2000
OpenMG Jukebox software users with Windows 2000 models should be
aware of the following:
• Only Administrators are allowed to install and uninstall the OpenMG
Jukebox software.
• To use the application, log on with the user name Administrator or Power
User.
• Do not remove or insert a CD-ROM drive connected via a PC card while
OpenMG Jukebox is running.
• Only Windows 2000 Professional Edition is supported.
• Windows 2000 NTFS format is not supported. Use FAT32 format.
Notes on performing the System Restore function of System Tools on
Windows®Millennium Edition
If you perform the System Restore function of System Tools on Windows
Me™, the OpenMG Jukebox version 2.0 database may be corrupted and all
music files recorded or imported may not play. Follow the steps below to
back up and restore all audio files managed by OpenMG Jukebox.
1Before performing the System Resource function, back up
your audio files by using OpenMG Jukebox Backup Tool.
This will help prevent unwanted loss of your audio files.
2After performing the System Resource function, restore your
music files by using OpenMG Jukebox Backup Tool.
This will help ensure the reliability of playback.
For details on using OpenMG Jukebox Backup Tool, refer to the online
help for OpenMG Jukebox.
Installing the software
Continued on next page

13
Note
If songs become unplayable because you executed System Restore, an error dialog box
may be displayed when you try to play a audio file. In this case, follow the messages
displayed.
If you already have OpenMG Jukebox installed
To play audio files on your CLIE handheld, OpenMG Jukebox Ver.2.0
is necessary
If you have following devices, OpenMG Jukebox Ver.1.x may already be
installed on your computer.
• VAIO Music Clip MC-P10
• Network Walkman NW-E3
• Memory Stick Walkman NW-MS7
Get and install the plug-in files for your devices. To get the plug-in files,
refer to the following Web page.
http://sony.com/walkmanproductsupport
Notes on managing audio files with OpenMG Jukebox Ver. 1.x
• Audio files registered using OpenMG Jukebox Version 1.X can
automatically be converted to Version 2.0, so you can continue to use
them. However, to be safe, it is recommended to make backup of your
audio files using the OpenMG Jukebox Backup Tool.
• Be sure to check in any items checked out using OpenMG Jukebox Version
1.X before upgrading. You may not be able to check in a audio file checked
out using OpenMG Jukebox Version 1.X after upgrading.
Notes
• After you have installed the OpenMG Jukebox Version 2.0 software, do not install
OpenMG Jukebox Version 1.X to overwrite the existing Version 2.0. If OpenMG
Jukebox Version 2.0 is overwritten, registered songs may be lost. If installation is
accidentally started, be sure to halt the installation.
• If you need to install an older version of the software using its CD-ROM after
uninstalling the existing Ver.2.0, make sure to back up audio files first, using the
OpenMG Jukebox Backup Tool so that you will not loose any audio files registered
in OpenMG Jukebox. For details on how to backup your audio files, see the online
Help for OpenMG Jukebox.
Installing the software

14
Installing the software
Installing the OpenMG Jukebox software
Install the OpenMG Jukebox software to the hard disk of your computer.
Notes
• Be sure to install the software before placing your CLIE handheld which is in the
transfer mode in the cradle. Do not install the software while a dedicated USB cable
is connected to your computer.
• If the “Installing:” message continues to appear without advancing to the next step
for some time, click the “InstallShield Wizard” on the taskbar.
1Exit all applications and follow the steps below on your
computer.
2Insert the installation CD-ROM into the CD-ROM drive of
your computer.
The setup program starts automatically.
3Click to select Audio Software.
4Click to select Install OpenMG Jukebox for CLIE.
The installation starts.
Follow the instructions displayed on the screen.
After the installation is completed, the installation screen reappears.
If you have already used OpenMG Jukebox Ver.1.x
After the installation is completed, click Exit to close the installation program.
Then install the plug-in file according to the instructions on page 13.
5After the installation is completed, click to select “Yes, restart
computer now,” and then click Finish.
The installation ends and your computer is restarted.
Note
Do not delete, move, or edit the installed folders using Windows Explorer or any
other application. If you do so, the OpenMG Jukebox database may become unstable
or corrupted.

15
Importing audio files into your computer
If you manage your audio files with RealJukebox software
This manual describes the basic operations. For more information regarding
RealJukebox, please refer to the online manual.
• And a RealJukebox FAQ and user help section can be found at
http://service.real.com/rjoptions.html
• Support service for RealJukebox is also available through e-mail at
http://service.real.com/help/call/html
The RealJukebox software is the product of RealNetworks, Inc.
Recording audio CDs onto the hard drive
Audio files recorded and converted into the MP3 format from audio CDs
can be registered on the hard disk to Playlists and managed with
RealJukebox software.
Note
• You cannot play audio files recorded in the following procedures with Audio Player
1.1. Use Audio Player 2.0 to play MP3 format audio files.
• If you want to play audio files recorded in the following procedures with Audio
Player 1.1, import and convert them into the ATRAC 3 format by OpenMG Jukebox
software.
1Double-click the RealJukebox icon on your Windows desktop,
or click Start, point to Programs, Real, RealJukebox, and then
click RealJukebox.
RealJukebox starts.
2Insert the CD you want to record into the CD-ROM drive of
your computer.
The Auto-record dialog box appears.
3Click “Yes, record the CD now” and then click OK.
Recording starts.
After recording ends, recorded MP3 format audio files are saved in the
folder.

16
Importing audio files into your computer
To pause recording
Click (Pause).
The recording is paused. To resume recording, click (Record) again.
When recording is resumed, it starts from the beginning of the song that was
previously paused.
If you want to select the songs to be recorded
1Click “No, I do not record the CD at this time” in step 3
above.
2Click to clear the check box of songs that you do not want to
record.
If you accidentally clear the check box of a song that you want to record,
just click the check box again.
3Click (Record).
Recording starts and only selected songs are recorded.
The first you click (Record), “Use of Generic CD-ROM driver” dialog
box appears. In this case, click OK. Restart your computer after updating
the driver.

17
If you manage your audio files with OpenMG Jukebox software
Note
Do not remove your CLIE handheld while you use OpenMG Jukebox software.
Recording audio CDs onto the hard drive
Songs recorded from audio CDs can be registered on the hard disk to
Playlists and managed with OpenMG Jukebox.
1Double-click the OpenMG Jukebox icon on the Windows
desktop, or click Start, point to Programs, OpenMG Jukebox,
and then click OpenMG Jukebox.
OpenMG Jukebox starts.
2Insert the CD you want to record into the CD-ROM drive of
your computer.
The CD window and the tracks of the audio CD appear.
If the CD window is not displayed automatically, click the CD tab to
display the CD window.
3Select the recording bit rate.
From the drop-down list, select the bit rate for recording.
CD tab
(Rec Stop)
button
(Rec to
Jukebox)
button Bit Rate drop-
down list
Importing audio files into your computer
Continued on next page

18
Start Rec button
4Confirm that a check mark appears by the songs you want
to record.
To clear the songs you do not want to record, click the song numbers
(track numbers). The disappears.
If you accidentally clear the of a song you want to record, just click the
song number again.
5Click (Rec to Jukebox).
The Select Playlist dialog box appears.
Note
When you record from an audio CD in your CD-ROM drive for the first time, the
CD Drive Optimization dialog box appears when you click (Rec to Jukebox),
in order to verify that the CD-ROM drive can perform recording properly. Click
Start to verify your CD-ROM drive. After the verification is performed, recording
starts.
6Register the songs to the Playlist.
If you want to create a new Playlist, click Create a New Playlist and type
the name of the Playlist you want to create.
If you want to add songs to an existing Playlist, click Add to Playlist and
select the Playlist from the drop-down list.
7Click Start Rec.
Recording starts.
Importing audio files into your computer

19
To stop recording
Click (Rec Stop).
The recording is stopped. To resume recording, click (Rec to Jukebox)
again.
When recording is resumed, it starts from the beginning of the song that was
previously stopped.
About Bit Rates
In OpenMG Jukebox, the bit rate for recording an audio CD can be chosen from
among 132 kbps/105 kbps/66 kbps. The sound quality and available recording time
after the conversion will be different depending on the selected bit rate. A Higher
value makes the sound quality better, but the size of the recorded data file will be
bigger thus shortening the total check-out time available on your CLIE handheld.
Likewise, a lower value means lower sound quality, but lengthens the total check-out
time available on your CLIE handheld.
When you use an optional 128 MB ”MG Memory Stick” media, you can record for
approximately the following length of time:
• When you record at 132 kbps: approx. 120 min.
• When you record at 105 kbps: approx. 160 min.
• When you record at 66 kbps: approx. 240 min.
Importing songs via EMD
What is an Electronic Music Distribution (EMD) service?
EMD stands for Electronic Music Distribution, which is a generic name for
services that distribute digital audio content via the Internet or other kinds
of networks.
To use an EMD service supporting OpenMG
You must be able to access the Internet from your computer. Sign up with an
Internet service provider, properly configure your computer, and configure
the settings of your Web browser before using this service. After the
connection to the Internet is set up, view the OpenMG Home Page (http://
www.openmg.com/) using the “Internet” screen of OpenMG Jukebox or
another Web browser. You can access Web sites of EMD services linked
from the OpenMG Home Page.
Importing audio files into your computer

20
To use an EMD service
1Click the Internet tab to display the Internet window.
An introduction to the OpenMG Home Page appears on the window.
2Click the button or logo on the window.
The connection to the Internet starts and the OpenMG Home Page
appears.
The OpenMG Home Page provides a guide to EMD service Web sites that
support OpenMG and information on how to use EMD services.
Refer to this OpenMG Home Page for more information about importing
audio files using EMD services.
To download audio files from EMD service Web sites
1Display the Web page of an EMD service on the Internet
window.
2Click an audio file for downloading (e.g., MP3 files or WMA
files compatible with WMT).
Downloading starts automatically.
If you click an audio file that requires purchasing, the default Web
browser starts up to display the online transaction page. After the process
is completed, the audio file is allowed to be imported into OpenMG
Jukebox.
[Internet] tab
Importing audio files into your computer
Continued on next page
