Sony SS-RS880 User manual

SS-RS880
US Model
E Model
Australian Model
SERVICE MANUAL
SPEAKER SYSTEM
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-877-804-01
2004D02-1
© 2004.04
SPECIFICATIONS
Ver 1.0 2004. 04
•SS-RS880 is surround speaker system
in MHC-GN770/GN880/GX9000.
Speaker system 2-way, 2-unit, bass-reflex type
Speaker units
Woofer 13 cm, cone type
Tweeter 2.5 cm, horn type
Nominal impedance 24 ohms
Dimensions (w/h/d) (Approx.)
201 x 430 x 229 mm
Mass (Approx.) 4.2 kg net per speaker
Design and specifications are subject to change without notice.

2
SS-RS880
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
EXPLODED VIEWS
NOTE:
•-XX, -X mean standardized parts, so they may
have some difference from the original one.
•Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delayshouldbeanticipatedwhenorderingthese
items.
not supplied
1
1
2
3
4
5
5
6
67
•The mechanical parts with no reference number in
the exploded views are not supplied.
14-984-567-01 SCREW (4X20), TAPPING
2A-4713-727-A FRONT PANEL ASSY
34-951-620-01 SCREW (2.6X8), +BVTP
41-825-826-11 SPEAKER (2.5cm)
54-874-614-71 SCREW
64-874-614-21 SCREW (1) (3.5X14), TAPPING
71-825-766-11 SPEAKER (13cm)

3
SS-RS880
MEMO

SS-RS880
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2004.04 New
