1
Mini Hi-Fi
Component
System
4-235-112-11(1)
MHC-DX101
© 2001 Sony Corporation
Operating Instructions

2
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
This appliance is classified as
a CLASS 1 LASER product.
The CLASS 1 LASER
PRODUCT MARKING is
located on the rear exterior.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.

3
Table of Contents
Parts Identification
Main unit ............................................... 4
Remote Control ..................................... 5
Getting Started
Hooking up the system .......................... 6
Inserting two R6 (size AA) batteries
into the remote ................................ 7
Setting the time...................................... 8
Saving the power in standby mode........ 8
CD
Loading a CD ........................................ 9
Playing a CD
–– Normal Play/Shuffle Play/
Repeat Play ..................................... 9
Programing CD tracks
–– Program Play ............................ 10
Using the CD display .......................... 11
Tuner
Presetting radio stations....................... 11
Listening to the radio
— Preset Tuning ........................... 12
Tape
Loading a tape ..................................... 13
Playing a tape ...................................... 13
Recording to a tape
— CD Synchro Recording/
Recording Manually/
Program Edit ................................. 14
Timer-recording radio programs ......... 15
Sound Adjustment
Adjusting the sound............................. 16
Selecting the sound effect....................16
Adjusting the graphic equalizer and
storing............................................17
Selecting the surround effect ...............18
Other Features
Enhancing video game sound
— Game Sync ............................... 18
Changing the spectrum analyzer
display ........................................... 18
Singing along: Karaoke ......................18
Falling asleep to music
— Sleep Timer .............................. 20
Waking up to music
— Daily Timer .............................. 20
Optional Components
Hooking up the optional
A/V components ........................... 21
Connecting a video game machine......22
Additional Information
Precautions ..........................................23
Troubleshooting................................... 24
Messages ............................................. 25
Specifications ......................................26

4
Parts Identification
The items are arranged in alphabetical order. Refer to the pages indicated in parentheses for details.
Main unit
ql
w;
qj
qh
qk
qg
qd
qf
wawswdwf
wg
whwj wk
eg
ef
ed
es
e;
wl
1234 6589q;qaqs7
ea
AUDIO jacks ed (22)
CD qs (9 –11, 14, 15)
CD SYNCwf (14, 15)
Deck Awl (13, 14)
Deck B w; (13 –16)
DIRECTION 7(13 –15, 19)
DISC 1 –3 wa (9, 10)
DISC SKIP EX-CHANGE ea
(9, 10)
Disc tray 8(9)
DISPLAY 7(11)
EDIT 7(15)
EFFECT ON/OFF 4
(17, 19)
ENTER0(8, 10 –12,
15 –17, 20, 21)
GAME eg (18, 22)
GAME EQ 2(16, 17)
GROOVE 3(16)
KARAOKE PONes (19)
MD (VIDEO)qg (21, 22)
MICjack e; (18)
MIC LEVEL control wj (18, 19)
MOVIE EQ 9(16, 17)
MUSIC EQ 6(16, 17)
P FILE qa (17)
PHONES jackqk
PLAY MODE 7(9, 10)
REC PAUSE/STARTwd (14)
REPEAT 7(10)
SPECTRUM7(18)
STEREO/MONO 7(12)
TAPE A/Bqf (13, 14)
TUNER MEMORY 7(11)
TUNER/BAND qd (11, 12)
VIDEO jack ef (22)
VOLUME control qh
BUTTON DESCRIPTIONS
v/V/b/B5
Z(deck A) wk
Z(deck B) ql
M (fast forward) ws
.(go back) wg
ZOPEN/CLOSE qj
?/1 (power) 1
x(stop) wg
nN (play) wg
X(pause) wg
>(go forward) wg
m (rewind) wh

5
Parts Identification
Remote Control
5
6
7
8
9
0
qa
qs
12 34
qd
qf
qg
qh
ql
qk
qj
CD qj (9 –11, 14, 15)
CLEAR 6(10)
CLOCK/TIMER SELECT 2
(16, 21)
CLOCK/TIMER SET 3(8, 15,
20)
D.SKIP ql (9, 10)
EFFECT ON/OFF qa (17, 19)
ENTER qf (8, 10 –12, 15 –17,
20, 21)
GAME qk (18, 22)
MD (VIDEO) 9(21, 22)
P FILE qd (17)
PRESET EQ qg (16)
SLEEP 1(20)
SURROUND 0(18)
TAPE A/B 8(13, 14)
TUNER/BAND qh (11, 12)
VOL +/–7
BUTTON DESCRIPTIONS
v/V/b/Bqs
M(fast forward)/TUNING
+ 5
.(go back)/PRESET
–5
?/1 (power) 4
x(stop) 5
nN (play) 5
X(pause) 5
>(go forward)/PRESET
+ 5
m(rewind)/TUNING –5

6
Front speaker (Right)
FM antenna
AM loop antenna
Front speaker (Left)
1Connect the front speakers.
Connect the speaker cords to the SPEAKER
jacks as shown below.
R
+
L
+
—
Insert only the stripped portion.
Red/Solid
(3)
Black/Stripe (#)
Getting Started
Hooking up the system
Perform the following procedure 1to 3to hook up your system using the supplied cords and
accessories.
2
3
1
2Connect the FM/AM antennas.
Set up the AM loop antenna, then connect
it.
FM75
AM
AM loop antenna Extend the FM lead antenna horizontally

7
Getting Started
3Connect the power cord to a wall outlet.
The demonstration appears in the display.
When you press ?/1, the system turns on
and the demonstration automatically ends.
To connect optional components
See page 21.
To attach the front speaker pads
Attach the supplied front speaker pads to the
bottom of the speakers to stabilize the speakers
and prevent them from slipping.
Notes
•Keep the speaker cords away from the antennas to
prevent noise.
•Do not place the surround speakers on top of a TV.
This may cause distortion of the colors in the TV
screen.
•Be sure to connect both left and right surround
speakers. Otherwise, the sound will not be heard.
When carrying this system
Perform the following procedure to protect the
CD mechanism.
1Make sure that all discs are removed from
the unit.
2Hold down CD and then press ?/1 until
“STANDBY” appears.
When you release the buttons, “LOCK”
appears.
3Unplug the AC power cord.
Inserting two R6 (size AA)
batteries into the remote
E
e
eE
Tip
With normal use, the batteries should last for about
six months. When the remote no longer operates the
system, replace both batteries with new ones.
Note
If you do not use the remote for a long period of time,
remove the batteries to avoid possible damage from
battery leakage.

8
Setting the time
1Turn on the system.
2Press CLOCK/TIMER SET on the
remote.
Proceed to step 5 when “CLOCK”appears
in the display.
3Press vor Vrepeatedly to select “SET
CLOCK”.
4Press ENTER.
5Press vor Vrepeatedly to set the hour.
6Press B.
The minute indication flashes.
7Press vor Vrepeatedly to set the
minute.
8Press ENTER.
Tip
If you made a mistake or want to change the time,
start over from step 1.
Note
The clock settings are canceled when you disconnect
the power cord or if a power failure occurs.
Saving the power in
standby mode
Press DISPLAY repeatedly when the
system is off. Each time you press the
button, the system switches cyclically as
follows:
Demonstration tClock t Power Saving
Mode
Tips
•?/1 indicator lights up even in the Power Saving
Mode.
•The timer functions in the Power Saving Mode.
Note
You cannot set the time in the Power Saving Mode.
To cancel the Power Saving Mode
Press DISPLAY once to show the
demonstration or twice to show the clock
display.

9
Getting Started/CD
CD
Loading a CD
1Press ZOPEN/CLOSE.
The disc tray opens.
2Place a CD with the label side up on the
disc tray.
When you play a CD
single (8 cm CD),
place it on the inner
circle of the tray.
To insert additional discs, press DISC SKIP
EX-CHANGE to rotate the disc tray.
3Press ZOPEN/CLOSE to close the disc
tray.
Playing a CD
–– Normal Play/Shuffle Play/Repeat
Play
This system lets you play the CD in different
play modes.
Disc tray number
Disc presence
indicator Track number Playing time
1Press CD.
2Press PLAY MODE repeatedly until the
mode you want appears in the display.
Select To play
CONTINUE
ALL DISCS
(Normal Play)
All CDs in the disc tray
continuously.
CONTINUE
1DISC
(Normal Play)
The CD you have selected
in original order.
SHUFFLE
ALL DISCS
(Shuffle Play)
The tracks on all CDs in
random order.
SHUFFLE
1DISC
(Shuffle Play)
The tracks on the CD you
have selected in random
order.
PROGRAM
(Program Play) The tracks on all CDs in the order you want them to be
played (see “Programing
CD tracks” on page 10).
3Press nN.
Other Operations
To Do this
Stop play Press x.
Pause Press X. Press again to resume
play.
Select a track During play or pause, press >
(to go forward) or .(to go
back).
Find a point
in a track During play, press and hold M
(to go forward) or m(to go
back). Release it when you find the
desired point.
Select a CD in
stop mode Press DISC 1 – 3 or DISC SKIP
EX-CHANGE (or D.SKIP on the
remote).
continued

10
To Do this
Playing a CD (continued)
Switch to CD
function from
another source
3Press one of DISC 1 –3 to select a CD.
To program all the tracks on a CD at once,
proceed to step 5 with “AL”displayed.
4Press . or >until the desired
track appears in the display.
Disc number Total playing time
(including selected track)
Track number
5Press ENTER.
The track is programed. The program step
number appears, followed by the total
playing time.
6To program additional tracks, repeat
steps 3 to 5.
Skip step 3 to select tracks from the same
disc.
7Press nN.
To Do this
Cancel Program
Play
Clear a track from
the end Press CLEAR on the remote in
stop mode.
Add a track to
the program in
stop mode
Do steps 3 to 5.
Clear the entire
program Press xonce in stop mode or
twice during play.
Press DISC 1 –3 (Automatic
Source Selection). However, if a
CD is used in a program, play does
not start even if you press CD 1 –
3.
Remove a CD Press ZOPEN/CLOSE.
Exchange other
CDs while
playing
Press DISC SKIP EX-CHANGE
(or D.SKIP on the remote).
Play repeatedly
(Repeat Play) Press REPEAT during play until “REPEAT ALL”or “REPEAT 1”
appears.
REPEAT ALL*: For all the tracks
on the CD up to five times.
REPEAT 1**: For a single track
only.
To cancel playing repeatedly, press
REPEAT until “REPEAT ALL”or
“REPEAT 1”disappears.
* You cannot select “REPEAT ALL”and
“SHUFFLE ALL DISCS”at the same time.
**When you select “REPEAT 1”, that track is
repeated endlessly until REPEAT 1 is canceled.
Note
The play mode cannot be changed while playing a
disc. To change the play mode, press xfirst to stop
play.
Programing CD tracks
–– Program Play
You can make a program of up to 32 tracks
from all the CDs in the order you want to play
them.
1Press CD, then place a CD.
2Press PLAY MODE repeatedly until
“PROGRAM”appears in the display.
Press PLAY MODE repeatedly
until “PROGRAM”and
“SHUFFLE”disappear.
