SonyElectronicsInc.
•
16530ViaEsprillo
•
SanDiego,CA92127
•
1.800.222.7669
•
www.sony.com
MHC
-EC55
MiniHi
-FiComponentSystem
PleasevisittheDealerNetworkforcurrentinformationatwww.sony.com/dn
130WattsTotalPower 65WattsperChannelx2
NewSlimStyleMainUnit with20cmwidtheasilyfitsintoanyroom.
16cmWoofer fillsanyroomwithpowerfulsound
3DiscCDChanger providesaneasywaytokeepthemusicgoingalldayorall
night.
CD-R/CD-RW withMP3PlaybackCapability PlaysbackMP3filesrecorded
ontoCD-
R/RWdiscs.
LineInforDigitalMusicPlayerorPC allowsforsimpleplug-and-play
integrationwithadigitalmusicplayerorPCviaa3.5mmjack.
2-WayBassReflexSpeakerSystem Atypeofspeakerenclosurethatincludes
a"tuned"porttoincreaseandextendbassresponsebyreleasingsomeofthe
energycreatedbytheinwardmovementofthewoofercone.
DSGXBassBoostFunction
IncreasestheBasstofillanyroomwithpowerful
sound.
DigitalAM/FMStereoTuner Providesaccurate,drift-freetuningofAMandFM
stationsandletsyouchoosefromawidevarietyofradio,talkandmusic
programmingwiththeaddedenjoymentofstereosound.
4PresetEQsettings Createsenhancedsoundmodesfordiffernttypesof
music,suchasrockandpop.
Specifications
General
Type of Use: Shelf System
Tray Type:
Tray Loading 3 Disc CD Changer with Play Exchange
(Semiconductor Laser 780nm)
Disc Capacity: 3
Audio
Digital
-to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz (
±
0.5dB); Cassette: 50-13000Hz
(
±
0.3db)
Format(s) Supported: CD-DA, CD-R/RW, CD's WITH MP3 Playback
Capability
Tuning: Auto Scan Radio
Antenna System: AM: Loop Antenna, FM: Lead Antenna
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
Station Preset(s):
30 (10 AM, 20 FM)
Sound Enhancer: Groove Bass Boost Function, Virtual Surround
Sound Mode
Equalizer:
9 Presets (Rock, Pop, Jazz, Dance, Soul, Oriental, Reggae,
Salsa, Samba), 3 Personal File Settings
Tuner Type: FM/AM Superheterodyne Tuner
Convenience Features
Timer Events:
Record/Play/Sleep (Wake-up or Fall Asleep To Music-
Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Hardware
Display:
LCD
Remote Control: Yes (Remote Commander®)
Power
Power Requirements: AC 120V, 60Hz
Output Power: 130 Watts Total: 65 Watts per Channel x 2 (RMS 10%
THD, 120-10 kHz)
Power Consumption: 205W
Manual: 210W
Battery Type:
Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels driven
from 120-10000 Hz; rated 150 W per channel-minimum RMS power,
with no more than 10% total harmonic distortion from 250
milliwatts to rated output.
Speaker
Speaker System:
2 Way Bass Reflex Type
Speaker Dimensions: 2" (5cm)
Woofer Size(s): 6.3" (16cm)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
Headphone Input(s): 1 (Front, Stereo Mini)
PC Audio Input(s): Yes
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
Dimensions
Weight:
Speaker: 8 lbs 6 oz (3.8 Kg) (each x 2); Main Unit: 22 lbs 1 oz (10
Kg)
Measurements: Speaker: W 9 1/16" x H 13 7/12" x D 9 1/4" (230 x 345 x
235mm) (each x 2); Main Unit: W 11" x H 12 4/5" x D 16 13/14" (280 x 325
x 430mm)
Supplied Accessories
Instruction Manual
Remote Commander®Remote Control (RM-SC50)
AM Roop Antenna
FM Lead Antenna
UPC Code: 027242705777
1.CD
-
R/RWmedia/formats are not universallycompatible.
©2007Sony Electronics Inc.
Reproductionin whole or inpart without written permissionis prohibited. Allrightsreserved. Sony, Remote
Commander,and like.no.other are trademarksof Sony.
Featuresand specifications are subjectto change without notice.Non
-
metricweights and measuresare
approximate.
