Sony MHC-GX750 User manual

Mini Hi-Fi Component System
• Wireless Transmitter for PC/Portable Product Conenction
• 500 Watts Total: 160 Watts Per Channel x 2 (Front + 180W Subwoofer)
• 3 Way Main Speakers with Hybrid Dual Woofer Design
• Bundled 8" Subwoofer
• Game Sync™ Mixing with Front A/V Inputs for Video Games
Variable Attenuation Control System (VACS) Sony has designed an exclusive circuit that maintains bass and
midrange quality in high volume listening. VACS detects frequencies and levels that may introduce distortion and
adjusts them automatically to ensure consistent sound quality.
Game Sync™ Mixing Mix game audio with a CD, tape, or tuner. 3 different modes can be selected — low,
medium, or high. The 3 different settings allow preset levels of game sound to mix with your music. LOW — Music
Source is mixed louder than the game sound. MEDIUM — Music source mixed at same level as the game. HIGH —
Music source is much lower than the game sound.
MP3 Playback Management When the MP3 encoded disc is first inserted, the player reads through all files on
disc. Allow for up to 150 folders maximum with a maximum number of 300 total (files and folders). After this
reading process occurs, the user may then select through the discs selections of folders and files.
MHC-GX750W

Mini Hi-Fi Component System
For more information:
http://www.sony.com/dn
MHC-GX750W
Features
General
• Wireless Transmitter RF Type for
transmitting from PC/Personal
Audio Products to Mini System
• 400 Watts Total 200 Watts Per
Channel x 2 (FTC 10% THD
120-10kHz)
• 3 Way Main Speakers with 7"
Woofer
• 60-Disc CD Changer with MP3
Playback
• Tuner with 20 FM + 10 AM Station
Presets
• Center Volume Knob with
Illumination
• CD-R & CD-RW Plus MP3
Playback*
• Function CD, Tuner, Tape A/B,
Game
• Single Well Auto Reverse Tape
Deck
Audio
• Groove Bass Enhancement
• 8 Preset EQ with 3 Band Control
• Surround Audio Effect
• VACS - Variable Attenuation
Control System
Inputs and Outputs
• Analog Line Input (RCA Type) x 1
for Game Sync™ Mixing
• Optical Digital Output for CD Audio
• Mini-pin Headphone Jack
• Video Line Input x 1 (Game Sync™
Mixing)
• Video Line Output x 1 (Game
Sync™ Mixing)
• Digital Output (Optical) x 1 (For CD)
Convenience
• Color Fluorescent Display
• CD Synchro Recording
• Remote Commander® Remote
Control
• Power Save Mode
• CD Text
• Play Modes (Shuffle, Program,
Repeat)
• Play Exchange Mode
Specifications
General
• Power Requirements AC120V, 60
Hz
• Power Consumption (In Operation)
230W
CD Player
• Frequency Response 20Hz -
20kHz (±0.5dB)
Tape Player
• Recording System 4 Track, 2
Channel Stereo
• Wow and Flutter ±.15%
w/Peak(IEC)/.1%
W.RMS(NAB)/±0.2% W.Peak(DIN)
• Frequency Response 40 - 13,000
Hz(±3dB),using Sony Type I
Cassette
Tuner
• Tuning Range 87.5-108.0 MHZ
• Tuning Range 530-1,710 kHz
• FM Tuning Range FM Stereo,
FM/AM Superheterodyne Tuner
Amplifier Section
• Power Output 160 Watts Per
Channel x 2 (RMS 10% THD,
120-10kHz)
• Power Output Subwoofer: 180
Watts (RMS)
Speaker
• Speaker System 3 Way Type
• Speaker Unit Dual 5" Woofer
Drivers; 2" Midrange Tweeter
• Front Speaker 10.5" x 14.3" x
11.6" (267 x 365 x 295 mm)
• Front Speaker 11.24 lbs. (5.1 kg)
• Speaker System Subwoofer:
Approx. Dimensions
10.5"x12.8"x14.3"
(267x327x365mm)
• Speaker System Subwoofer:
Approx. Weight 16.53 lbs. (7.5 kg)
Supplied Accessories
• Instruction Manual
• Remote Commander® Remote
Control RM-SC3
Weights & Measures
• 25.05 lbs. (10 kg)
• 11" x12.8" x 16.7"
(280x327x425mm)
©2004 Sony Electronics Inc. All rights
reserved. Features and specifications are
subject to change without notice. All
trademarks referenced herein are trademarks
of Sony or their respective owners.
*CD-R/RW playback may not be compatible
with all discs, depending on recording
conditions.
