SERVICE MANUAL
Ver 1.0 2003.04
MICRO Hi-Fi COMPONENT SYSTEM
CMT-CPX1
CMT-CPX1
COMPACT DISC DECK HCD-CPX1
RECEIVER
SPEAKER SYSTEM SS-CPX1
US Model
Canadian Model
E Model
Australian Model
•CMT-CPX1 is composed of following models.
As service manuals are issued for each component model,
please refer to them.
COMPONENT MODEL NAME ACCESSORIES
Part No. Description Remark
9-877-172-01 Sony Corporation
2003D0500-1 Home Audio Company
C2003.04 Published by Sony Engineering Corporation
1-477-715-11 COMMANDER, STANDARD (RM-SMR1)
1-754-059-12 ANTENNA, LOOP (AM)
1-793-184-22 CONNECTOR (F TYPE ADAPTOR) (FM)
4-210-254-02 CUSHION (FOOT) (for SS-CPX1)
4-228-952-01 COVER, BATTERY (for RM-SMR1)
4-244-991-11 MANUAL, INSTRUCTION (ENGLISH)
4-244-991-21 MANUAL, INSTRUCTION (FRENCH) (US, Canadian)
4-244-991-31 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(Singapore)
4-244-991-41 MANUAL, INSTRUCTION (TRADITIONAL CHINESE)
(Singapore)
4-244-991-51 MANUAL, INSTRUCTION (KOREAN) (Korean)
SPECIFICATIONS
Power requirements
North American model: 120 V AC, 60 Hz
Australian model: 230 – 240 V AC, 50/60 Hz
Other models: 220 – 240 V AC, 50/60 Hz
Korean model: 220 V AC, 60 Hz
Power consumption: 50 W
Dimensions (w/h/d) incl. projecting parts and controls
Amplifier/Tuner/Tape/CD section:
Approx. 174 ×
××
240.5 ×291
mm
Speakers: Approx. 160 240 240
mm
Mass
Amplifier/Tuner/Tape/CD section:
Approx. 4.3 kg
Speakers: Approx. 3.1 kg net per
speaker
Supplied accessories Remote (1)
R6 (size AA) batteries (2)
AM loop antenna (1)
FM lead antenna (1)
Speaker pads (8)
Design and specifications are subject to change
without notice.

2
CMT-CPX1
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2003.04 New

SERVICE MANUAL
CD
Section
Tape deck
Section
COMPACT DISC DECK RECEIVER
US Model
Canadian Model
E Model
Australian Model
SPECIFICATIONS
HCD-CPX1
Ver 1.0 2003.04
HCD-CPX1 is the Amplifier, CD
player, Tape Deck and Tuner section
in CMT-CPX1.
Model Name Using Similar Mechanism NEW
CD Mechanism Type CDM55A-K6BD44S
Base Unit Name BU-K6BD44S
Optical Block Name KSM-213DCP
Optical Pick-up Name KSS-213D
Model Name Using Similar Mechanism NEW
9-877-173-01 Sony Corporation
2003D0500-1 Home Audio Company
C2003.04 Published by Sony Engineering Corporation
CD player section
Laser Semiconductor laser
(CD: λ=780 nm)
Emission duration:
continuous
Frequency response CD: 2 Hz – 20 kHz
Wavelength 780 – 790 nm
Tape deck section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassettes
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
North American model: 87.5 – 108.0 MHz
(100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz
step)
Antenna FM wire antenna
Antenna terminals 75 ohms unbalanced
Intermediate frequency 10.7 MHz
Other models: 530 – 1,710 kHz
(with the tuning interval
set at 10 kHz)
531 – 1,602 kHz
(with the tuning interval
set at 9 kHz)
Antenna AM loop antenna, external
antenna terminal
Intermediate frequency 450 kHz
AM tuner section
Tuning range
Pan-American model: 530 – 1,710 kHz
(with the tuning interval
set at 10 kHz)
General
Power requirements
North American model: 120 V AC, 60 Hz
Australian model: 230 – 240 V AC, 50/60 Hz
Korean model: 220 V AC, 60 Hz
Other models: 220 – 240 V AC, 50/60 Hz
Power consumption: 50 W
Dimensions (w/h/d): Approx. 174 ×240.5 ×291
mm
Mass: Approx. 4.3 kg
Design and specifications are subject to change
without notice.
Amplifier section
For the U.S. model
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 4-ohm loads, both channels driven, from
100 – 10,000 Hz: rated 70 watts per channel
minimum RMS power, with no more than 10%
total harmonic distortion from 250 milliwatts to
rated output.
North American model:
Continuous RMS power output (reference):
70 + 70 W
(4 ohms at 1 kHz, 10%
THD)
Total harmonic distortion less than 0.9% (4 ohms at
1kHz,35 W)
Other models:
The following measured at 220 – 240 V AC, 50/60 Hz
DIN power output (rated): 55 + 55 W
(4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
70 + 70 W
(4 ohms at 1 kHz, 10%
THD)
Inputs
MD (VIDEO) IN (phono jacks):
Sensitivity 450/250 mV,
impedance 47 kilohms
Outputs
CD DIGITAL OUT: Optical Wavelength:
660 nm
PHONES: accepts headphones with
an impedance of 8 ohms or
more
SPEAKER: accepts impedance of
4ohms

2
HCD-CPX1
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270 ˚C dur-
ing repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
This appliance is
classified as a CLASS 1
LASER product. This
label is located on the
rear exterior.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts forAC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring thevoltagedropacross aresistor bymeans ofaVOM
or battery-operatedAC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low-voltage scale.
The Simpson 250 and Sanwa SH-63Trd are examples of a
passiveVOM that is suitable. Nearly all battery operated digital
multimeters that have a 2VAC range are suitable. (See Fig.A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k Ω 0.15 µ FAC
voltmete
r
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40 ˚C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 ˚C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscou-s (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges oc-
cur such as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.

3
HCD-CPX1
TABLE OF CONTENTS
1. SERVICING NOTES ............................................... 4
2. GENERAL
Location of Controls ....................................................... 8
Setting the Clock............................................................. 9
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 10
3-2. Case ................................................................................. 11
3-3. Front Panel Section ......................................................... 11
3-4. TC Board, Mechanical Deck .......................................... 12
3-5. MAIN Board ................................................................... 12
3-6. Tuner Unit ....................................................................... 13
3-7. CD Mechanism Deck (CDM55A-K6BD44S)................ 13
3-8. Loading Board................................................................. 14
3-9. Cam (CDM55) ................................................................ 14
3-10. Base Unit (BU-K6BD44S) ............................................. 15
3-11. Motor Gear Assy (Sled) (M102), BD Board .................. 15
3-12. Optical Pick-up (KSS-213D) .......................................... 16
4. TEST MODE.............................................................. 17
5. ELECTRICAL ADJUSTMENTS
Deck Section ................................................................... 19
CD Section ...................................................................... 20
6. DIAGRAMS
6-1. Block Diagram – CD Servo Section –........................... 21
6-2. Block Diagram – TUNER/TAPE DECK Section – ...... 22
6-3. Block Diagram – MAIN Section – ................................ 23
6-4. Block Diagram
– DISPLAY/POWER SUPPLY Section – ...................... 24
6-5. Note for Printed Wiring Boards and
Schematic Diagrams ....................................................... 25
6-6. Printed Wiring Board – BD Board – ............................. 26
6-7. Schematic Diagram – BD Board – ................................ 27
6-8. Printed Wiring Board – TC Board – .............................. 28
6-9. Schematic Diagram – TC Board –................................. 29
6-10. Printed Wiring Boards
– LOADING/MAIN Boards – ....................................... 31
6-11. Schematic Diagram – MAIN Board (1/2) – .................. 32
6-12. Schematic Diagram
– LOADING/MAIN (2/2) Boards – ............................... 33
6-13. Printed Wiring Board – AMP Board – .......................... 34
6-14. Schematic Diagram – AMP Board – ............................. 35
6-15. Printed Wiring Boards
– BACK LIGHT/LCD/SWITCH Boards – .................... 36
6-16. Schematic Diagram
– BACK LIGHT/LCD/SWITCH Boards – ................... 37
6-17. Printed Wiring Boards
– HP/SP OUT/POWER Boards – .................................. 38
6-18. Schematic Diagram
– HP/SP OUT/POWER Boards – ................................. 39
6-19. IC Pin Function Description ........................................... 44
7. EXPLODED VIEWS
7-1. Case Section .................................................................... 47
7-2. Front Panel Section-1...................................................... 48
7-3. Front Panel Section-2...................................................... 49
7-4. Lid (TC) Section ............................................................. 50
7-5. Chassis Section-1 ............................................................ 51
7-6. Chassis Section-2 ............................................................ 52
7-7. Chassis Section-3 ............................................................ 53
7-8. CD Mechanism Deck Section
(CDM55A-K6BD44S) .................................................... 54
7-9. Base Unit (BU-K6BD44S) ............................................. 55
8. ELECTRICAL PARTS LIST ............................... 56

4
HCD-CPX1 SECTION 1
SERVICING NOTES
The laser diode in the optical pick-up block may suffer electro-
static break-down because of the potential difference generated
by the charged electrostatic load, etc. on clothing and the human
body.
During repair, pay attention to electrostatic break-down and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical
pick-up block. Therefore, when checking the laser diode emis-
sion, observe from more than 30 cm away from the objective lens.
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
NOTE ON INSTALLING AND REMOVING THE TAPE MECHANICAL DECK
To prevent four screws of +BVTP 3 ×8 TYPE 2 TT (B), that fix the mechanical deck to the front panel, from being magnetized, must not
use a magnetic screwdriver.
screw +BVTP 3 × 8 TYPE 2 TT (B
)
screw +BVTP 3 × 8 TYPE 2 TT (B)
non-magnetic screwdriver
MODEL IDENTIFICATION
– Back Panel –
Part No.
Model Name Part No.
US and Canadian models 4-244-015-1[]
Singapore model 4-244-015-2[]
Australian model 4-244-015-3[]
Korean model 4-244-015-4[]

5
HCD-CPX1
TAPE MECHANICAL DECK SERVICE POSITION
Set up the service position with putting an insulator under the mechanical deck as the figure shown below.
tape mechanical deck
insulator
CD MECHANISM DECK SERVICE POSITION
Set up the service position for the CD mechanism deck with disassembling the entire set as the figure shown below.
AMP section
CD mechanism deck
main board
front pane
l

6
HCD-CPX1
NOTE ON LEADING THE WIRE (FLAT TYPE) (9 CORE)
Lead the wire (flat type) (9 core) properly to prevent the wire from coming out from the right side of the guides on the sub panel or sagging
inside of the lid.
NOTE ON INSTALLING THE HP BOARD
Note: Follow the assembly procedure in the numerical order given.
lid (TC)
guides
wire (flat type) (9 core)
sub panel
3 three screws
(BVTP2.6
× 8)
1 Lead the cable trough out
the ditch of the HP board
to prevent the cable from
contacting with the CD
mechanism deck.
2 HP board
ditch cable
HP board

7
HCD-CPX1
CLINCHING THE WIRE (FLAT TYPE) (21 CORE)
HANDLING TWO CABLES FROM THE SUB POWER AND THE SWITCHING REGULATOR TO THE MAIN BOARD
heat sink
AMP board
Clinch the wire (flat type) (21 core)
to prevent the wire from contacting with
the heat sink of the AMP board.
cable from the switching
regulator to the main board
lead pin
cable from the sub power
to the main board
fabric no woven (10 – 20)
Note: Do not reuse the current fabri
c
because it may fall off.
Note: Fix two cables with the lead pin and the fabric non woven (10 – 20),
or they may sag and contact with the CD mechanism deck.

8
HCD-CPX1 SECTION 2
GENERAL
•LOCATION OF CONTROLS
– FrontView –
This section is extracted from
instruction manual.
BASS +/– wa
CD SYNCHRO qa
Disc tray ql
DISPLAY wf
Display window 3
DSG ws
FM MODE qs
FUNCTION 0
PHONES jack qk
PLAY MODE/DIRECTION wd
Remote sensor 2
REPEAT qs
TREBLE +/– w;
TUNER/BAND 9
TUNING MODE wd
TUNING +/– qd
VOLUME +/– qf
?/1 (power) 1
TAPE Z(eject) 4
TAPE nN (play) 5
TAPE x(stop) 6
TAPE X(pause) 7
TAPE zREC (record) 8
lm/ML (rewind/fast
forward, go back/go forward)
qd
CD NX (play pause) qg
CD x(stop) qh
CD Z(eject) qj
ALPHABETICAL ORDER
A – Q R – Z
BUTTON DESCRIPTIONS
1
qa
qs
0
5
6
7
8
9
qg
qd
qh
qj
234
qf
w;
ql
qk
wa
ws
wd
wf

9
HCD-CPX1
– Remote Control –
CD ws
CLEAR w;
CLOCK/TIMER SELECT 2
CLOCK/TIMER SET 3
DISPLAY 6
ENTER qd
EQ qh
EQ + qg
EQ – ql
FUNCTION wg
PLAY MODE wa
REPEAT qs
SLEEP 1
TAPE wf
TUNER/BAND wd
TUNER MEMORY 5
TUNING MODE wa
TUNING +/– 9
VOL +/– qk
?/1 (power) 4
TAPE nN (play) 7
TAPE x(stop) 8
CD NX (play pause) 0
CD x(stop) qa
./> (go back/go forward)
qf
m/M (rewind/fast forward)
qj
ALPHABETICAL ORDER
A – E F – Z
BUTTON DESCRIPTIONS
2 3
6
8
5
w;
wa
qk
14
7
9
qa
0
ws
wd
wf
wg
ql
qd
qg
qs
qf
qh
qj
1Press ?/1 to turn on the system.
2Press CLOCK/TIMER SET.
3Press .or >repeatedly to set the
hour.
4Press ENTER.
5Press .or >repeatedly to set the
minute.
6Press ENTER.
The clock starts working.
To adjust the clock
1Press CLOCK/TIMER SET.
2Press .or >until “CLOCK” appears,
then press ENTER.
3Do the same procedures as step 3 to 6
above.
Note
The clock is not displayed in Power Saving Mode.
Setting the clock

HCD-CPX1
10
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Set
3-4. TC BOARD, MECHANICAL DECK
(Page 12)
3-3. FRONT PANEL SECTION
(Page 11)
3-2. CASE
(Page 11)
3-7. CD MECHANISM DECK
(CDM55A-K6BD44S)
(Page 13)
3-6. TUNER UNIT
(Page 13)
3-8. LOADING BOARD
(Page 14)
3-9. CAM (CDM55)
(Page 14)
3-10. BASE UNIT (BU-K6BD44S)
(Page 15)
3-11. MOTOR GEAR ASSY (SLED) (M102),
BD BOARD
(Page 15)
3-12. OPTICAL PICK-UP (KSS-213D)
(Page 16)
3-5. MAIN BOARD
(Page 12)

HCD-CPX1
11
3-3. FRONT PANEL SECTION
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
1 two case screws
3
3
4 case
2 three screws
(BVTP3
× 6)
1 two case screws
1 screw
(BVTP3
× 6)
2 ground wire lead
6 front panel section
5 four screws
(BVTP3
× 6)
4 connector
(CN102)
3 wire (flat type) (19 core)
(CN402)
3 wire (flat type) (9 core
)
(CN403)
3 wire (flat type) (19 core)
(CN221)

HCD-CPX1
12
1 screw
(BVTP3
× 6)
2 screw
(BVTP3
× 8)
1 two screws (BVTP3 × 6)
1 three screws (BVTP3 × 6
)
2 screw (BVTP3 × 8)
8 main board
4 two screws (BVTP3 × 6)
5
6 wire (flat type)
(11 core)
(CN211)
6 wire (flat type)
(21 core)
(CN202)
7 connector
(CN201)
6 wire (flat type) (21 core)
(CN101)
7 two connectors
(CN301, CN401)
3 back panel
3-4. TC BOARD, MECHANICAL DECK
3-5. MAIN BOARD
2 wire (flat type) (8 core)
(CN602)
1 wire (flat type) (19 core)
(CN603)
4 three screw
s
(PTPWH 2)
5 TC board
3 connector
8 mechanical deck
6 four screws
(BVTP3
× 8)
Note: Must not use a magnetic
screwdriver to prevent the screws
from being magnetized.
7 ground wire lead

HCD-CPX1
13
3-6. TUNER UNIT
3-7. CD MECHANISM DECK (CDM55A-K6BD44S)
2 two screws
(BVTP3
× 6)
3 bracket
5 two screws
(BVTP3
× 6)
1 connector
(CN990)
2 two screws
(BVTP3
× 6)
6 tuner unit
4 wire (flat type) (11 core
)
3 screw
4 two bosses
8 wire (flat type) (21 core
)
(CN1101)
7
5
6 two claws
9 CD mechanism deck
(CDM55A-K6BD44S)
2 CD lid
1 two claws

HCD-CPX1
14
3-8. LOADING BOARD
3-9. CAM (CDM55)
2 belt (CDM55)
B
3 Pull the tray (CDM55D) pushing B .
4 two screws
(BTP2.6
× 8)
5 loading board
1 Rotate the gear(A) in
the direction of arrow
A .
A
2 lever (SW)
1 torsion spring
6 gear (A)
3 spacer (55)
4 pulley (LDG)
5 gear (B)
7 roller
8 cam (CDM55
)

HCD-CPX1
15
3-10. BASE UNIT (BU-K6BD44S)
1 two floating screws
(PTPWHM2.6)
5 two insulators
4
5 two insulators
6 base unit
(BU-K6BD44S)
3 two stoppers (BU)
2 two screws
(BTTP M2.6)
1 Remove two
solders.
4 BD board
8 two screws
(M2
× 3)
5 claw
6 gear (A)
7 gear (B)
3 wire (flat type) (16 core
)
(CN102)
9 motor gear assy (SLED)
(M102)
1 Remove two solders.
2
3-11. MOTOR GEAR ASSY (SLED) (M102), BD BOARD

HCD-CPX1
16
2 sled shaft
1 Slide the lever
in the direction of arrow
A .
3 Remove the optical pick-up
(KSS-213D) in the direction
of arrow
B .
A
B
3-12. OPTICAL PICK-UP (KSS-213D)

17
HCD-CPX1
[CMN (MC)TEST MODE]
•This mode is used to check operations of Amplifier.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press three keys of [DSG], [REPEAT] and [DISPLAY]
simultaneously.
3. When the CMN (MC) test mode is activated, “s” blinks on
the liquid crystal display.
4. Turn the [BASS] knob counterclockwise, “TONE MIN” is
displayed on the liquid crystal display. Turn the [BASS] knob
clockwise, “TONE MAX” is displayed on the liquid crystal
display.
Turn the [TREBLE] knob clockwise or counterclockwise,
“TONEFLAT” is displayed on the liquid crystal display.
Turn the [VOLUME] knob counterclockwise, “VOL MIN” is
displayed on the liquid crystal display. Turn the [VOLUME]
knob clockwise, “VOL MAX” is displayed on the liquid crystal
display.
5. To release this mode, press the ?/1key.
[PANEL (GC)TEST MODE]
•This mode is used to check the liquid crystal display, LED,
model, destination, software version and key.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press threekeys of [DSG], [PLAY MODE] and [DISPLAY]
simultaneously.
3. Liquid crystal display and LEDs are all turned on.
4. When you want to enter the model, destination and version
display mode, press the [REPEAT] key. The model and
destinationaredisplayed alternately on the liquid crystal display.
5. Eachtime [REPEAT] key ispressed, the displaychanges starting
from MD version, MC version, GC version, CD version, CDD
version, CDMA version, CDMB version, BDA version, BDB
version, ST version, TA version, TM version, and TC version
this order, and returns to the MD version display on the liquid
crystal display.
6. When [FUNCTION] key is pressed while the version numbers
are being displayed except model and destination, year, month
and day of the software creation display. When [FUNCTION]
key is pressed again, the display returns to the software version
display.When [REPEAT] key is pressed while year, month and
dayof thesoftware creationarebeing displayed,the year,month
and day of creation of the software versions are displayed on
the liquid crystal display in the same order of version display.
7. Press the [PLAY MODE] key, the key check mode is activated.
8. In the key check mode, the liquid crystal display displays “K0”.
Each time a key is pressed, “K” value increases. However, once
a key is pressed, it is no longer taken into account.
9. To release this mode, press three keys in the same manner as
step 2, or disconnect the power cord.
[COLD RESET]
•The cold reset clears all data including preset data stored in the
RAM to initial conditions. Execute this mode when returning
the set to the customer.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Pressthreekeys of ?/1,x(CD)and x(TAPE)simultaneously.
3. The liquid crystal display becomes blank instantaneously, and
the set is reset.
[SHIP MODE (NO MEMORY CLEAR) ]
•This mode moves the optical pick-up to the position durable to
vibration. Use this mode when returning the set to the customer
after repair.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Press three keys of Z(CD), x(CD) and [DISPLAY]
simultaneously.
4. After the “STANDBY” display blinks, “LOCK” is displayed
on the liquid crystal display, and the ship mode is set.
[SHIP MODE (MEMORY CLEAR) ]
•This mode moves the optical pick-up to the position durable to
vibration. Use this mode when returning the set to the customer
after repair.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Press three keys of Z(CD), CD NX and [DISPLAY]
simultaneously.
4. After the “STANDBY” display blinks, “LOCK” is displayed
on the liquid crystal display, and the ship mode is set.
[CDTRAY LOCK MODE]
•This mode is used to unable to take sample disc out of tray in
the shop.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. While pressing the Z(CD) key, press the x(CD) key for 5
seconds.
4. The message “LOCKED” is displayed on the liquid crystal
display and the tray is locked. (Even if pressing the Z(CD)
key, the message “LOCKED” is displayed on the liquid crystal
display and the tray is locked)
5. To release from this mode, pressing the Z(CD) key, press the
x(CD) key for 5 seconds.
6. The message “UNLOCKED” is displayed on the liquid crystal
display and the tray is unlocked.
[TUNER STEP CHANGE MODE]
(Singapore, Korean and Australian models)
•Astep ofAM channels can be changed over between 9 kHz and
10 kHz.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “TUNER”, and press the
[BAND] key to select “AM”.
3. Press the ?/1key to turn the power OFF.
4. Press two keys of ?/1and MLsimultaneously.
5. The message “AM 9K STEP” or “AM 10K STEP” is displayed
on the liquid crystal display,and thusthechannel step ischanged
over.
[CD SERVICE MODE]
•This mode can run the CD sled motor freely. Use this mode, for
instance, when cleaning the optical pick-up.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Press three keys of [DSG] , [REPEAT] and x(TAPE) simul-
taneously.
4. Press the MLkey to move the optical pick-up to outside
track, or press the lmkey to inside track.
5. To release this mode, press the ?/1key.
SECTION 4
TEST MODE

18
HCD-CPX1
[AGING MODE]
•This mode can be used for operation check of CD section and
tape deck section.
CD section and tape deck section work in parallel.
If an error occurred:
The aging operation stops only an error occurred sections and
display then status.
If no error occurs:
The aging operation continues repeatedly.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Set disc on the tray and set tape into the deck.
4. Press the [REPEAT] key to “REPEAT” off.
5. Press three keys of [DSG], [PLAY MODE] and x(TAPE)
simultaneously.
6. Aging operations of CD and tape are started at the same time.
7. To release this mode, press the ?/1key.
1. Display at the Aging Mode
Display operating state of CD section and tape deck section
alternately.
If an error occurred, stop display which that section.
2. CD Section
The sequence during the aging mode is following as below.
Display at the aging mode is the same as the normal operation.
Aging mode sequence (CD section) :
Start
Disc chucking
TOC read
Play first track for 2 seconds
Play last track for 2 seconds
Open the disc tray
Close the disc tray
3. Tape Deck Section
The sequence during the aging mode is following as below.
If an error occurred, stop display that step.
Display at the aging mode is “TAPE AG—”.
Aging mode sequence (Tape deck section) :
Start
Rewind the tape
Shut off
FWD play the tape
2 minutes
Fast forward the tape
Shut off or 20 seconds
REV play the tape
2 minutes
[CD ERROR CODE MODE]
•This mode can be used for error display of CD section.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Press three keys of [DSG], [REPEAT] and Xsimultaneously.
Note: Error code is not displayed on the liquid crystal display.
[CD SERVOTEST MODE]
•This mode used to ckeck operation of optical pick-up.
Procedure:
1. Press the ?/1key to turn the power ON.
2. Press the [FUNCTION] key to select “CD”.
3. Pressthreekeysof[DSG],[PLAY MODE] and Xsimultaneously.
4. Whenthe CD servotest mode isactivated,optical pick-upmoves.
[5 REPEAT OFF MODE]
•Number of repeat for CD playback is 5 times when the repeat
mode is “REPEAT”. This mode is used to enables CD to repeat
playback for limitless times.
Procedure:
1. Press the ?/1key to turn the power on.
2. Press the [FUNCTION] key to select “CD”.
3. Press three keys of [DSG], MLand x(TAPE)
simultaneously.
4. When the 5 repeat off mode is activated, “LIMIT OF” is
displayed on the liquid crystal display.
[CHANGE-OVER FUNCTION OF EXTERNAL INPUT]
•This mode is used to enable function of external input to change
over between MD and VIDEO.
Procedure:
1. Set to standby state.
2. Press two keys of ?/1and [FUNCTION] simultaneously.
3. The function of external input changes over to MD orVIDEO.
