Sony SA-WM500 User manual

SA-WM500
SERVICE MANUAL
SPECIFICATIONS
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
ACTIVE SUBWOOFER
Ver. 1.3 2006.08
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 6 ohm loads, from 20 – 200 Hz; rated 150 watts, minimum RMS
power, with no more than 0.7 % total harmonic distortion from 250
milliwatts to rated output.
System
Type
Active Subwoofer (magnetically shielded design)
Speaker unit
Woofer: 30 cm dia. (12 in.), cone type
Amplifier section
Continuous RMS output : (0.7%) 150W
Reproduction frequency range
20 Hz – 200 Hz
High frequency cut-off frequency
50 Hz – 200 Hz
Phase selector
NORMAL, REVERSE
Inputs
Input jacks
LINE IN: input pin jack
SPEAKER IN: input terminals
Output jacks
LINE OUT: output pin jack
SPEAKER OUT: output terminals
General
Power requirements
USA and Canada models: 120 V AC, 60 Hz
AEP, UK, MY, SP, TH models: 230 V AC, 50/60 Hz
AUS model : 240V AC, 50/60 Hz
TW model : 110 V AC, 60Hz
Power consumption
120 W
Dimensions
Approx. 360 x 425 x 412 mm
(14 1/ 4x 16 3/ 4x 16 1/ 4in.) (w/h/d)
Mass
18 kg (39.6 lb 1oz)
Supplied accessories
Foot pads (4)
Audio connecting cord (1 phono – 1 phono),
2 m (6 ft 6 1/ 2in.) (1)
Speaker cords, 2.5 m (8 ft 2 1/ 2in.) (2)
Design and specifications are subject to change without notice.
Sony Corporation
Home Audio Division
Published by Sony Techno Create Corporation
9-877-136-04
2006H02-1
© 2006.08

2
SA-WM500
Specifications ........................................................................... 1
1. GENERAL ...................................................................... 3
2. DIAGRAMS
2-1. Circuit Boards Location ............................................. 4
2-2. Printed Wiring Boards ................................................ 5
2-3. Schematic Diagram ..................................................... 6
3. EXPLODED VIEWS
3-1. Main Section ............................................................... 7
4. ELECTRICAL PARTS LIST ..................................... 8
TABLE OF CONTENTS
SAFETY CHECK-OUT
(US model)
After correcting the original service problem, perform the
following safety checks before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage. Check
leakage as described below.
LEAKAGE
The AC leakage from any exposed metal part to earth Ground
and from all exposed metal parts to any exposed metal part
having a return to chassis, must not exceed 0.5 mA (500
microampers). Leakage current can be measured by any one of
three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers’ instructions to
use these instruments.
2. A battery-operated AC milliammeter. The Data Precision
245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit”
indication is 0.75 V, so analog meters must have an accurate
low-voltage scale. The Simpson 250 and Sanwa SH-63Trd
are examples of a passive VOM that is suitable. Nearly all
battery operated digital multimeters that have a 2V AC range
are suitable. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
0.15µF
To Exposed Metal
Parts on Set
1.5kΩ
AC
voltmeter
(0.75V)
Earth Ground
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR
LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES
PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE
FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS
QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT
DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS
PUBLIÉS PAR SONY.

SA-WM500
3
SECTION 1
GENERAL This section is extracted from
instruction manual.
• Location of controls
POWER POWER indicator
POWER
LEVEL
MIN MAX
CUT OFF FREQ
50Hz
PHASE
200Hz
REVERSENORMAL
CUT OFF FREQLEVEL PHASE
AUTO
OFF
POWER SAVE

4
SA-WM500
SECTION 2
DIAGRAMS
For Schematic Diagrams.
Note:
•All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or
less are not indicated except for electrolytics and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise specified.
•C: panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
For Printed Wiring Boards.
Note :
•X: parts extracted from the component side.
•x: parts extracted from the conductor side.
•: Pattern from the side which enables seeing.
•A: B+ Line.
•B: B– Line.
•Voltages are dc with respect to ground under no-signal conditions.
•no mark : Power on
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production tolerances.
•Signal path.
F: AUDIO
•Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
AUS : Australian model
TW : Taiwan model
TH : Thai model
Note:
The components identi-
fied by mark 0or dotted
line with mark 0are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
2-1. CIRCUIT BOARDS LOCATION
CONTROL board
MAIN board
POWER AMP boar
d
POWER SUPPLY board
POWER SWITCH board
LED board
Ver. 1.3

55
SA-WM500
2-2. PRINTED WIRING BOARDS zSee page 4 for Notes. z See page 4 for Circuit Boards Location.
IC502
R521
RY400
C532
JW031
C521
JW030
JW029
BC903
C901
D901
CN905
RY901
D302
D302
R302
R301
R303
BC301
S301
BC302
BC802
R802
JW001
C805
JW002
JW003
JW004
C802
C801
C811
C812
R801
C806
D803
D801
D804
D802
C809
D821
D822
G1
C807
R803
C803
JW006
R804
Q801
C808
S531
S531
Q802
JW008
JW007
C810
JW009
JW010
JW011
TM501
JW012
CN803
JW020
R406
JW016
JW017
JW018
R511
R503
R506
R510
R509
R504
C403
R502
C401
Q403
Q401
Q404
R403
R402 R501
C503
R505
JW045
C531
R405
R404
R534
R535
Q532
JW54
D532
R533
R532
Q531
D531
R531
IC503
R537
Q533
R539 R538
C402
JW032
D503
D504
D502
D501
C501
C522
R522
D506
D505
JW028
R527
C502
R512
R508
R507
J501
CN501
R528
JW027
R523
R520
C520
R526
R525
C523
C524
IC501
JW024
Q402
R536
R524
JW026
BC401
JW015
R400
JW013
JW014
D400
R800
D401
R401
C804
Q301
Q302
D301
BC502
JW019
C301
JW005
BC901
BC902
F11
F12
JW053
JW052
JW051
C902
D805
JW047
JW063
C525
IC701
C709
C702
C711
R703
C703
JW036
JW035
C701
C708
BC701
C712
C704
R704
R713
R705
JW049
R708
R714
D702
D701
C706
JW034
R707
C710
R710
D703 R711
Q701
R709
C705
E
R702
R701
C707
JW048
R712
JW033
R706
BC801
++
--
++
--
OUT
SPEAKER
IN
L
R
OUT
LINE
IN
POWER SAVE
AUTO
OFF
t
SP401
SPEAKER
IC601
JW037
C604 C605
S601
RV601
RV602
R605
R606
R607
R601
R602
R604
R603
C606
C601
R609
C602
IC602
JW038
C608
BC601
C607
R611
R612
C603
JW039
R608
R610
JW040
LEVE
PHASE
CUT OFF FREQ
NORMAL REVERSE
t
1
4
58
1
4
58
1
4
58
1
4
58
1
4
58
T202
SUB
TRANSFORMER
T101
MAIN
TRANSFORMER
AC IN
1
14
1
4
5
1
1
5
5
1
12
112
MAIN BOARD
LED BOARD POWER AMP BOARD
CONTROL BOARD
POWER SWITCH BOARD
POWER SUPPLY BOARD
1
5
E
E
E
E
E
E
E
E
E
POWER
POWER
E
E
11
(11)
1-686-989-
11
(11)
1-686-991-
11
(11)
1-686-987- 11
(11)
1-686-988-
11
(11)
1-686-992-
11
(11)
1-686-990-
1
13 10
23 4 5 6 7 8910 11 12
A
1
B
C
D
E
F
G
H
I
Ref. No. Location
zSemiconductor
Location
D301 A-3
D302 B-2
D400 D-4
D401 B-3
D501 H-5
D502 H-5
D503 H-5
D504 H-5
D505 H-5
D506 H-5
D531 F-3
D532 G-3
D701 B-10
D702 B-10
D703 C-11
D801 B-5
D802 B-5
D803 B-5
D804 B-5
D805 B-3
D821 C-5
D822 C-5
D901 E-8
IC501 H-3
IC502 H-4
IC503 G-3
IC601 I-9
IC602 I-8
IC701 B-9
Q301 A-3
Q302 A-3
Q401 F-4
Q402 G-4
Q403 F-4
Q404 F-4
Q531 F-3
Q532 G-4
Q533 G-3
Q701 B-11
Q801 C-5
Q802 D-5
Ver. 1.3

66
SA-WM500
2-3. SCHEMATIC DIAGRAM zSee page 4 for Notes.
BC401
R400
D400
RY400
D401
R401
R402
R403
Q401
C401
C402
R405
Q403
C403
R406
R404
C809
C810
D821
D822
Q801
Q802
R803
C807
C808
R804
C806
D801
D802
C805
D804
D803
R802
C812
R801
C811
C804
C803
Q404
R800 C802
C801
D805
BC801
CN904
D901
RY901
C902
BC902
BC302
T101
T202
C901
BC901
S301
C301
D302
R303
R301
R302
BC301
BC502
D301
Q302
Q301
R539
R538
IC503(1/2)
Q532
R535
R532
D532 R533
R534
R536
C532
S531
C531
D531
R531
IC503(2/2)
R612
C608
RV602
C607
IC602(1/2)
R611
R609
R608
R610
C605
R607
C606
IC601(2/2)
R606
R605
C603
C604
IC601(1/2)
C602
C601
R601
R602
R603
BC601
CN501
R604
R537
CN803
BC701
IC501(1/2)
R522
R521
IC501(2/2)
C522
R523 C523
C524
R524 R525
R527 R526
D506
C501 R512
C502
R508
R507
R509
J501
R510
R511 C503
R504
R506
R503
C521
R520
C520
D502 D504
D505
D501
D503
R501
R502
R505
TM501
IC701
C705
R708 C710
D702 D701
D703
R711
R710
R709
C707
C709
C708
R706
R712 C711
R713
C712
C706
R705 R704
C704 C703
R703
R702
R701
C701
C702
IC502(1/2)
Q402
Q531
Q533
IC602(2/2)
CN905
BC802
R707
IC502(2/2)
BC903
RV601
S601
Q701
F901
R528
R714
SP401
B2P-VH
1k
1W
1SS133T
24V
SPK RLY
1SS133T
12k
56k
100k
2SC2785
2.2
35V
330
35V
22k
2SC2785
220
10V
22k
100k
10
35V
10
35V
MTZJ-T-72-12B
MTZJ-T-72-12B
2SC1815
2SA1015
2.2k
10
50V
10
50V
2.2k
220
25V
11ES2
11ES2
220
25V
11ES2
11ES2
10
1/4W
0.1
10
1/4W
0.1
0.1
0.1
DTC124ES
56k 10000
71V
10000
71V
RBV602
B3B-XH-A
B3B-XH-A
1SS133T
24V
POWER RLY
0.01
2P
2P
MAIN TRANSFORMER
SUB TRANSFORMER
0.01
B2P3-VH
0.01
SPR-325MVW
2.2k
1k
2.2k
B4B-EH
B3(4)B-EH
1SS133T
BNIF4M
BNIF4M
22k
1M
BA15218
2SA1175F
10k
150k
1SS133T 1M
100k
10k
330
16V
22
25V
1SS133T
470k
BA15218
100k
4.7
50V
10k
22
50V
BA15218
10k
10k
10k
4.7k
0.1
220k
22
50V
BA15218
4.7k
4.7k
4.7
50V
0.1
BA15218
0.1
0.1
10k
100k
120k
B5B-EH
B5B-EH
100k
100k
B12B-XH-A
B12B-XH-A
BA15218
10k
4.7k
BA15218
10
35V
15k 0.01
0.01
22k 33k
4.7k 10k
1SS133T
10
35V
100k
220p
1k
1k
4.7k
4.7k
4.7k 220p
33k
4.7k
1/2W
33k
220p
4.7k
220p
1SS133T 1SS133T
1SS133T
1SS133T
1SS133T
33k
33k
4.7k
1/2W
TERMINAL BOARD
STK404-140
2.2
50V
56k 470p
1SS133T 1SS133T
1SS133T
4.7k
1k
22k
100
100V
100
25V
10
100V
100
1W
1
1/4W
10
100V
4.7
1W
0.1
220
25V
680 56k
3p 47
100V
8.2k
8.2k
0.22*2
220p
220p
BA15218
2SC2784
DTC124ES
DTC124ES
BA15218
B5(6)H-EH
B5(6)B-EH
1k
BA15218
20k
2SC2785
PROTECTOR
680
33
SPEAKER
*
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
3
7
8
5
6
7
8
5
6
7
8
5
6
7
8
5
6
7
8
5
6
POWER
POWER
US,CND
AEP,MY,SP,UK,AUS,TH
*F901
4A/125V
2.5A/250V
TW
3.15A/250V
Ver. 1.3

SA-WM500
7
SECTION 3
EXPLODED VIEWS
NOTE :
•-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•Color indication of Appearance Parts
Example :
KNOB, BALANCE (WHITE) … (RED)
↑↑
Parts color Cabinet's color
•Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
•The mechanical parts with no reference number in the
exploded views are not supplied.
•Hardware (# mark) list and accessories and packing
materials are given in the last of this parts list.
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
AUS : Australian model
TW : Taiwan model
TH : Thai model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3-1. MAIN SECTION
489
12
10
16
1
1
1
1
11
2
15
5
3
14
14
14
14
#2
#2
#2
#2
#2
#1
#2
#2
#2
#2
#3
#4
#4
#4
not supplied
not supplied
not
supplied
not
supplied
F901
T202
SP401
not
supplied
not
supplied
not
supplied
not
supplied
T101
not supplied not supplied
15
7
6
6
1
1
1
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
14-235-677-01 SCREW (4X20) (TYPE1), +BVTP
2A-4736-352-A GRILLE (FRAME) ASSY (BLACK)
2A-4736-564-A GRILLE (FRAME) ASSY (WOOD)
3A-1186-852-A SPEAKER (CABINET) ASSY (WOOD/MI)
(MY,SP,TH)
3A-4736-349-A SPEAKER (CABINET) ASSY (BLACK)
3A-4736-563-A SPEAKER (CABINET) ASSY (WOOD/M)
4A-4731-771-A MAIN BOARD, COMPLETE
5A-4731-772-A CONTROL BOARD, COMPLETE
64-229-774-01 SCREW, TAPPING, HEXAGON SOCKET
74-235-903-01 SCREW (3.5X20)
84-228-148-21 COVER, REAR (EXCEPT US,CND)
84-228-148-31 COVER, REAR (US,CND)
94-250-465-01 KNOB (VOL)
10 4-228-141-01 DUCT (A)
*11 3-703-244-00 BUSHING (2104), CORD
012 1-696-874-11 CORD, POWER (AUS)
012 1-777-071-13 CORD, POWER (AEP,MY,SP,UK,TH)
012 1-783-532-11 CORD, POWER (CND,US)
012 1-783-820-11 CORD, POWER (TW)
14 4-874-614-21 SCREW
15 4-235-677-01 SCREW +BVTP 4X20 (TYPE1)
*16 3-703-044-26 LABEL, CAUTION (US,CND)
0F901 1-532-464-31 FUSE (T2.5AL/250V) (AEP,MY,SP,UK,AUS,TH)
0F901 1-532-465-31 FUSE (T3.15AL/250V) (TW)
0F901 1-532-746-11 FUSE, GLASS TUBE (4A/125V) (US,CND)
SP401 1-825-344-11 SPEAKER (30cm)
0T101 1-439-749-11 POWER TRANSFORMER (AEP,SP,MY,UK,AUS,TH)
0T101 1-439-750-11 POWER TRANSFORMER (US,CND)
0T101 1-443-026-11 POWER TRANSFORMER (TW)
0T202 1-439-706-11 SUB POWER TRANSFORMER (US,CND)
0T202 1-439-707-11 SUB POWER TRANSFORMER
(AEP,SP,MY,UK,AUS,TH)
0T202 1-443-027-11 SUB POWER TRANSFORMER (TW)
#1 7-685-881-09 SCREW +BVTT 4X8 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
Ver. 1.3
HOW TO DISTINGUISH CABINET COLOR (WOOD/MI or WOOD/M)
There are WOOD/M and WOOD/MI in the cabinet color for SP, MY and TH
model.
Only the serial number of WOOD/MI is shown.
SP, MY (WOOD/MI): Since 3400958
TH (WOOD/MI): Since 4400001

8
SA-WM500
SECTION 4
ELECTRICAL PARTS LIST
MAIN
NOTE :
•Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
•Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
•SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
•CAPACITORS
uF : µF
•COILS
uH : µH
When indicating parts by reference num-
ber, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
AUS : Australian model
TW : Taiwan model
TH : Thai model
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
CONTROL
A-4731-772-A CONTROL BOARD, COMPLETE
**********************
< CONNECTOR >
*BC601 1-564-508-11 PLUG, CONNECTOR 5P
< CAPACITOR >
C601 1-130-495-00 MYLAR 0.1uF 5% 50V
C602 1-130-495-00 MYLAR 0.1uF 5% 50V
C603 1-126-963-11 ELECT 4.7uF 20% 50V
C604 1-130-495-00 MYLAR 0.1uF 5% 50V
C605 1-130-495-00 MYLAR 0.1uF 5% 50V
C606 1-126-965-91 ELECT 22uF 20% 50V
C607 1-126-965-91 ELECT 22uF 20% 50V
C608 1-126-963-11 ELECT 4.7uF 20% 50V
< IC >
IC601 8-759-943-94 IC BA15218
IC602 8-759-943-94 IC BA15218
< RESISTOR >
R601 1-249-429-11 CARBON 10K 5% 1/4W
R602 1-249-441-11 CARBON 100K 5% 1/4W
R603 1-247-881-00 CARBON 120K 5% 1/4W
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-249-425-11 CARBON 4.7K 5% 1/4W F
R606 1-249-425-11 CARBON 4.7K 5% 1/4W F
R607 1-247-887-00 CARBON 220K 5% 1/4W
R608 1-249-429-11 CARBON 10K 5% 1/4W
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-249-425-11 CARBON 4.7K 5% 1/4W F
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-441-11 CARBON 100K 5% 1/4W
< VARIABLE RESISTOR >
RV601 1-227-572-11 RES,VAR 20K (CUTOFF FREQ)
RV602 1-227-573-11 RES,VAR 10K (LEVEL)
< SWITCH >
S601 1-786-490-11 SWITCH, SLIDE (PHASE)
*****************************************************
LED BOARD
*********
< CONNECTOR >
*BC301 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
*D302 8-719-064-11 DIODE SPR-325MVW (POWER)
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R302 1-249-421-11 CARBON 2.2K 5% 1/4W F
R303 1-249-421-11 CARBON 2.2K 5% 1/4W F
*****************************************************
A-4731-771-A MAIN BOARD, COMPLETE
*******************
< CAPACITOR >
BC401 1-564-320-00 PIN, CONNECTOR(3.96mm PITCH)2P
*BC801 1-564-104-00 PIN, CONNECTOR(3.96mm PITCH)3P
BC802 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< CAPACITOR >
C401 1-124-257-00 ELECT 2.2uF 20% 50V
C402 1-126-950-11 ELECT 330uF 20% 35V
C403 1-126-934-11 ELECT 220uF 20% 10V
C501 1-124-247-91 ELECT 10uF 20% 35V
C502 1-102-978-00 CERAMIC 220PF 5% 50V
C503 1-102-978-00 CERAMIC 220PF 5% 50V
C520 1-102-978-00 CERAMIC 220PF 5% 50V
C521 1-102-978-00 CERAMIC 220PF 5% 50V
C522 1-124-247-91 ELECT 10uF 20% 35V
C523 1-130-483-00 MYLAR 0.01uF 5% 50V
C524 1-130-483-00 MYLAR 0.01uF 5% 50V
C531 1-128-551-11 ELECT 22uF 20% 25V
C532 1-104-661-91 ELECT 330uF 20% 16V
C801 1-109-932-13 ELECT(BLOCK) 10000uF 20% 71V
C802 1-109-932-13 ELECT(BLOCK) 10000uF 20% 71V
C803 1-130-777-00 MYLAR 0.1uF 10% 100V
C804 1-130-777-00 MYLAR 0.1uF 10% 100V
C805 1-104-666-11 ELECT 220uF 20% 25V
C806 1-104-666-11 ELECT 220uF 20% 25V
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-126-964-11 ELECT 10uF 20% 50V
C809 1-124-247-91 ELECT 10uF 20% 35V
C810 1-124-247-91 ELECT 10uF 20% 35V
LED
Ver. 1.3

9
SA-WM500
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
MAIN
C811 1-136-165-00 FILM 0.1uF 5% 50V
C812 1-136-165-00 FILM 0.1uF 5% 50V
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D400 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-991-33 DIODE 1SS133T-77
D504 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
D531 8-719-991-33 DIODE 1SS133T-77
D532 8-719-991-33 DIODE 1SS133T-77
D801 8-719-024-99 DIODE 11ES2-NTA2B
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
D805 8-719-072-05 DIODE RBV-602LF-A
D821 8-719-110-31 DIODE RD12ESB2
D822 8-719-110-31 DIODE RD12ESB2
< TERMINAL >
*G1 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 6-704-502-01 IC NJM022D
IC502 6-704-502-01 IC NJM022D
IC503 6-704-502-01 IC NJM022D
< JACK >
J501 1-770-157-21 JACK, PIN 2P (LINE)
< TRANSISTOR >
Q301 8-729-900-63 TRANSISTOR DTA124ES
Q302 8-729-900-63 TRANSISTOR DTA124ES
Q401 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q402 8-729-178-42 TRANSISTOR 2SC2784-F
Q403 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q404 8-729-029-86 TRANSISTOR DTC124ESA
Q531 8-729-029-86 TRANSISTOR DTC124ESA
Q532 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q533 8-729-029-86 TRANSISTOR DTC124ESA
Q801 8-729-281-53 TRANSISTOR 2SC1815-GR
Q802 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
0R400 1-215-869-11 METAL OXIDE 1K 5% 1W
R401 1-249-430-11 CARBON 12K 5% 1/4W
R402 1-249-438-11 CARBON 56K 5% 1/4W
R403 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-441-11 CARBON 100K 5% 1/4W
R405 1-249-433-11 CARBON 22K 5% 1/4W
R406 1-249-433-11 CARBON 22K 5% 1/4W
R501 1-249-435-11 CARBON 33K 5% 1/4W
R502 1-249-435-11 CARBON 33K 5% 1/4W
R503 1-249-435-11 CARBON 33K 5% 1/4W
R504 1-249-435-11 CARBON 33K 5% 1/4W
R505 1-260-107-11 CARBON 4.7K 5% 1/2W
R506 1-260-107-11 CARBON 4.7K 5% 1/2W
R507 1-249-417-11 CARBON 1K 5% 1/4W F
R508 1-249-417-11 CARBON 1K 5% 1/4W F
R509 1-249-425-11 CARBON 4.7K 5% 1/4W F
R510 1-249-425-11 CARBON 4.7K 5% 1/4W F
R511 1-249-425-11 CARBON 4.7K 5% 1/4W F
R512 1-249-441-11 CARBON 100K 5% 1/4W
R520 1-249-425-11 CARBON 4.7K 5% 1/4W F
R521 1-249-425-11 CARBON 4.7K 5% 1/4W F
R522 1-249-429-11 CARBON 10K 5% 1/4W
R523 1-249-431-11 CARBON 15K 5% 1/4W
R524 1-249-433-11 CARBON 22K 5% 1/4W
R525 1-249-435-11 CARBON 33K 5% 1/4W
R526 1-249-429-11 CARBON 10K 5% 1/4W
R527 1-249-425-11 CARBON 4.7K 5% 1/4W F
R528 1-249-415-11 CARBON 680 5% 1/4W F
R531 1-247-895-00 CARBON 470K 5% 1/4W
R532 1-247-883-00 CARBON 150K 5% 1/4W
R533 1-247-903-00 CARBON 1M 5% 1/4W
R534 1-249-441-11 CARBON 100K 5% 1/4W
R535 1-249-429-11 CARBON 10K 5% 1/4W
R536 1-249-429-11 CARBON 10K 5% 1/4W
R537 1-249-441-11 CARBON 100K 5% 1/4W
R538 1-247-903-00 CARBON 1M 5% 1/4W
R539 1-249-433-11 CARBON 22K 5% 1/4W
R800 1-249-438-11 CARBON 56K 5% 1/4W
0R801 1-212-857-00 FUSIBLE 10 5% 1/4W
0R802 1-212-857-00 FUSIBLE 10 5% 1/4W
R803 1-249-421-11 CARBON 2.2K 5% 1/4W F
R804 1-249-421-11 CARBON 2.2K 5% 1/4W F
< RELAY >
RY400 1-515-920-11 RELAY (24V)
< SWITCH >
S531 1-786-490-11 SWITCH, SLIDE (POWER SAVE)
< TERMINAL >
TM501 1-537-376-11 TERMINAL BOARD (SPAKER)
******************************************************
POWER AMP BOARD
***************
< CONNECTOR >
BC701 1-691-590-11 POST (WITH BASE)(B12B-XH-A)12P
< CAPACITOR >
C701 1-102-978-00 CERAMIC 220PF 5% 50V
C702 1-102-978-00 CERAMIC 220PF 5% 50V
C703 1-128-562-11 ELECT 47uF 20% 100V
C704 1-102-936-00 CERAMIC 3.0PF +-0.25PF50V
C705 1-126-961-11 ELECT 2.2uF 20% 50V
C706 1-104-666-11 ELECT 220uF 20% 25V
C707 1-128-563-11 ELECT 100uF 20% 100V
C708 1-128-582-11 ELECT 10uF 20% 100V
POWER AMP

10
SA-WM500
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
C709 1-104-665-11 ELECT 100uF 20% 25V
C710 1-102-824-00 CERAMIC 470PF 5% 50V
C711 1-128-582-11 ELECT 10uF 20% 100V
C712 1-130-777-00 MYLAR 0.1uF 10% 100V
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
< FUSE HOLDER >
F11 1-533-233-11 FUSE HOLDER
F12 1-533-233-11 FUSE HOLDER
< IC >
IC701 6-600-182-01 IC STK-404-140S
< TRANSISTOR >
Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0R701 1-234-182-11 ENCAPSULATED COMPONENT
R702 1-216-110-11 CARBON 8.2K 5% 1/2W
R703 1-216-110-11 CARBON 8.2K 5% 1/2W
R704 1-249-438-11 CARBON 56K 5% 1/4W
R705 1-249-415-11 CARBON 680 5% 1/4W F
R706 1-215-886-11 METAL OXIDE 100 5% 2W
R707 1-249-417-11 CARBON 1K 5% 1/4W F
R708 1-249-438-11 CARBON 56K 5% 1/4W
R709 1-249-433-11 CARBON 22K 5% 1/4W
R710 1-249-417-11 CARBON 1K 5% 1/4W F
R711 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R712 1-202-972-61 FUSIBLE 1 5% 1/4W
R713 1-216-357-00 METAL OXIDE 4.7 5% 1W
R714 1-249-399-11 CARBON 33 5% 1/4W
*****************************************************
POWER SUPPLY BOARD
*****************
< CONNECTOR>
BC901 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
*BC902 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
*BC903 1-565-792-11 PIN, CONNECTOR(3.96mm PITCH)2P
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
0C902 1-113-925-11 CERAMIC 0.01uF 20% 250V
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
<RELAY >
0RY901 1-755-458-11 RELAY
*****************************************************
POWER SWITCH BOARD
******************
< CONNECTOR>
*BC302 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< CAPACITOR >
0C301 1-113-925-11 CERAMIC 0.01uF 20% 250V
< SWITCH >
0S301 1-554-920-11 SWITCH, PUSH (AC POWER)(1 KEY) (POWER)
******************************************************
MISCELLANEOUS
*************
012 1-696-874-11 CORD, POWER (AUS)
012 1-777-071-13 CORD, POWER (AEP,MY,SP,UK,TH)
012 1-783-532-11 CORD, POWER (US,CND)
012 1-783-820-11 CORD, POWER (TW)
0F901 1-532-464-31 FUSE (T2.5AL/250V) (AEP,MY,SP,UK,AUS,TH)
0F901 1-532-465-31 FUSE (T3.15AL/250V) (TW)
0F901 1-532-746-11 FUSE, GLASS TUBE (4A/125V) (US,CND)
SP401 1-825-344-11 SPEAKER (30cm)
0T101 1-443-026-11 POWER TRANSFORMER (TW)
0T101 1-439-749-11 POWER TRANSFORMER
(AEP,SP,MY,UK,AUS,TH)
0T101 1-439-750-11 POWER TRANSFORMER (US,CND)
0T202 1-443-027-11 SUB POWER TRANSFORMER (TW)
0T202 1-439-706-11 SUB POWER TRANSFORMER (US,CND)
0T202 1-439-707-11 SUB POWER TRANSFORMER
(AEP,SP,MY,UK,AUS,TH)
*****************************************************
ACCESSORIES
***********
01-569-008-12 ADAPTOR, CONVERSION 2P (AUS)
1-751-598-53 CORD, CONNECTION (PIN-PIN)
1-769-433-23 CORD, SPEAKER
4-244-254-11 INSTRUCTION, MANUAL (ENGLISH, FRENCH)
(US,CND,UK,AUS)
4-244-254-21 INSTRUCTION, MANUAL
(ENGLISH, FRENCH,GERMAN,ITALIAN) (AEP)
4-244-254-31 INSTRUCTION, MANUAL
(SPANISH,DUTCH,SWEDISH,POLISH) (AEP)
4-244-254-41 INSTRUCTION, MANUAL(PORTUGUESE,
DANISH,FINNISH,RUSSIAN)(AEP)
4-244-254-51 INSTRUCTION, MANUAL(ENGLISH,FRENCH,
SPANISH,TRADITIONAL CHINESE)
(SP,MY,TW,TH)
4-981-864-01 FOOT
POWER AMP POWER SUPPLY POWER SWITCH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ver. 1.3

11
SA-WM500
MEMO

SA-WM500
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2003.03 New
1.1 2003.06 Addition of Australian and Taiwan models. (ENG-03006)
1.2 2004.09 Suffix change of Part No. (Ref. No. 8) and addition of destination.
(SPM-04095)
1.3 2006.08 Addition of Singapore (MI) and Thai (MI) models.
