SERVICE MANUAL
LCD Digital Color TV
AZ1-H Chassis
9-888-269-05
Version Date Subject
1.0 1/21/2010 No revisions or updates
2.0 3/10/2010 Added Safety-Related Warning regarding caution when handling the LCD Panel (Reissue entire manual)
Added caution for handling Glass Assembly
Added Service Adjustment information for Adjustments After Replacing the BUHS Board or LCD Panel
3.0 3/31/2010 Corrected caution for handling Glass Assembly (Replaced page 4)
Corrected Part Number for Rear Cover Assemblies. (Replaced page 13)
4.0 9/20/2010 Reissue entire manual to include the following:
Updated Table of Contents. Replaced Page ii.
Corrected Section 2-1-1. ‘Viewing the Service Menus’. Replaced Page 19.
Added Frame Diagram to Section 3 ‘Diagrams’. Added Page 28.
5.0 9/28/2010 Corrected Model name information on page 9.
ORIGINAL MANUAL ISSUE DATE: 1/2010
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL
LCD Digital Color TV
AZ1-H Chassis
9-888-269-05
Self Diagnosis
Supported model

MODEL LIST
MODEL COMMANDER DESTINATION MODEL COMMANDER DESTINATION
9-888-269-05
KDL-40NX700 RM-YD037 US
KDL-40NX700 RM-YD052 CND
KDL-40NX700 RM-YD052 MX
KDL-40NX700 RM-YD052 LATIN AMERICA
KDL-46NX700 RM-YD037 US
KDL-46NX700 RM-YD052 CND
KDL-46NX700 RM-YD052 MX
KDL-46NX700 RM-YD052 LATIN AMERICA

KDL-40NX700/46NX700 i
TABLE OF CONTENTS
Specications..................................................................................................................................................................................1
Warnings and Cautions ..................................................................................................................................................................2
Safety-Related Warning ..................................................................................................................................................................5
Safety Check-Out ............................................................................................................................................................................6
Self Diagnosis Functions ...............................................................................................................................................................8
SEC 1. Disassembly/Part Number Information ..........................................................................................................................12
1-1. Table-Top Stand Assembly Removal.............................................................................................................................12
1-2. Rear Cover, Vesa Brackets, Switch Unit and Power Switch Removal ..........................................................................13
1-3. Speakers, HLR Board, WIFI Card, Antennas and Panel Holder Removal ....................................................................14
1-4. GE3A/GE2B (Power) Boards, BUHS Board, and LCD Panel Removal ........................................................................15
1-5. Cleaning the LCD Panel................................................................................................................................................16
1-6. Screw Legend................................................................................................................................................................16
1-7. Connectors ....................................................................................................................................................................16
1-8. Accessories and Packing ..............................................................................................................................................17
1-9. Miscellaneous................................................................................................................................................................17
1-10. Remote Commander .....................................................................................................................................................17
SEC 2. Service Adjustments ........................................................................................................................................................18
2-1. Accessing Service Adjustment Mode ............................................................................................................................18
2-1-1. Viewing the Service Menus........................................................................................................................................................ 19
2-1-2. Using the Remote Commander to View or Change Service Data ............................................................................................. 20

KDL-40NX700/46NX700 ii
TABLE OF CONTENTS
2-2. Adjustments After Replacing the BUHS Board or LCD Panel .......................................................................................20
2-2-1. Updating the Software ............................................................................................................................................................... 20
2-2-2. Selecting the Model ................................................................................................................................................................... 21
2-2-3. Setting the Destination............................................................................................................................................................... 22
2-2-4. Verifying the Model and Panel Information ................................................................................................................................ 22
2-2-5. Reconnecting All Cables ............................................................................................................................................................ 23
2-3. White Balance Adjustments...........................................................................................................................................24
2-4. Resetting the TV to Factory Condition...........................................................................................................................25
2-4-1. Resetting the TV to Factory Condition Using Service Mode...................................................................................................... 25
SEC 3. Diagrams ...........................................................................................................................................................................26
3-1. Circuit Boards Location .................................................................................................................................................26
3-2. Block Diagram ...............................................................................................................................................................27
3-3. Frame Diagram..............................................................................................................................................................28

KDL-40NX700/46NX700 1
SPECIFICATIONS
Licensing Information
Macintosh is a trademark of Apple Inc.,
registered in the U.S. and other countries.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing,
LLC.
Fergason Patent Properties, LLC:
U.S. Patent No. 5,717,422
U.S. Patent No. 6,816,141
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
In the United States, TV Guide and TV Guide
On Screen are registered trademarks of TV
Guide Entertainment Group, Inc. and/or its
subsidiaries or affiliates, and are used under a
license by Gemstar-TV Guide International,
Inc. and/or its subsidiaries. In Canada, TV
Guide is a registered mark of
Transcontinental Inc., and is used under a
license by Gemstar-TV Guide International,
Inc. and/or its subsidiaries.
The TV Guide On Screen system is
manufactured under license from Gemstar-
TV Guide International, Inc. and/or its
subsidiaries.
The TV Guide On Screen system is protected
by one or more of the following United States
patents 6,498,895; 6,850,693; 6,396,546;
5,940,073; 6,239,794 to Gemstar-TV Guide
International, Inc. and/or its subsidiaries.
Gemstar-TV Guide International, Inc. and/or
its related affiliates are not in any way liable
for the accuracy or availability of the program
schedule information or other data in the TV
Guide On Screen system and cannot
guarantee service availability in your area. In
no event shall Gemstar-TV Guide
International, Inc. and/or its related affiliates
be liable for any damages in connection with
the accuracy or availability of the program
schedule information or other data in the TV
Guide On Screen system.
Blu-ray Disc is a trademark.
“BRAVIA” and
, S-Force,
Mo
tionflow, BRAVIA Sync, and are
trademarks or registered marks of Sony
Corporation.
“XrossMediaBar” is a trademark of Sony
Corporation. “XMB” is a trademark of Sony
Corporation and Sony Computer
Entertainment Inc.
“PlayStation” is a registered trademark and
“PS3” is a trademark of Sony Computer
Entertainment Inc.
DLNA
®
, the DLNA Logo and DLNA
CERTIFIED™ are trademarks, service
marks, or certification marks of the Digital
Living Network Alliance.
Your BRAVIA TV is
ENERGY STAR
®
qualified
in the “Home” mode.
It meets strict energy
efficiency guidelines set by
the U.S. Environmental
Protection Agency and
Department of Energy. ENERGY STAR is a
joint program of these government agencies,
designed to promote energy efficient products
and practices.
Changes to certain features, settings, and
functionalities of this TV (i.e. TV Guide,
Picture/Sound, Light Sensor, Power
Savings)
can increase or change the power
consumption.
Depending upon such changed settings, the
power consumption may exceed the limits
required for the ENERGY STAR
qualification in the “Home” mode.
*1 For LAN connections, use a Category 7 10BASE-T/100BASE-TX cable (not supplied).
*2 Download Acquisition Mode (DAM) is used for software updates and/or collecting data for TV Guide On Screen.
• Optional accessories availability depends on its stock.
• Design and specifications are subject to change without notice.
Model name KDL-46NX70040NX700
System
Television system NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality)
Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69
Analog Cable: 1 - 135 / Digital Cable: 1 - 135
Panel system LCD (Liquid Crystal Display) Panel
Speaker output10 W + 10 W
Input/Output jacks
CABLE/ANTENNA 75-ohm external terminal for RF inputs
VIDEO IN 1/2 VIDEO / AUDIO
COMPONENT IN YPBPR (Component Video) / Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
HDMI IN 1/2/3/4 HDMI: Video: 480i, 480p, 720p, 1080i, 1080p, 1080/24p
HDMI: Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24 bits, Dolby Digital
AUDIO (HDMI IN 2)
AUDIO OUT 500 mVrms (typical)
DIGITAL AUDIO OUT (OPTICAL) PCM/Dolby Digital optical signal
PC IN D-sub 15-pin, analog RGB
PC/HDMI 2 AUDIO IN Stereo mini jack
LAN
10BASE-T/100BASE-TX connector (Connection speed may differ depending on the network
environment. 10BASE-T/100BASE-TX communication rate and communication quality are not
guaranteed for this TV.)*
1
USB/DLNA Refer to the i-Manual for supported format.
Power and others
Power requirement110-240 V AC, 50/60 Hz (U.S.A./Canada 120 V AC, 60 Hz)
Power consumption
in use
in DAM*218 W
(You may hear a clicking noise during the download but this is normal.)
in standby
Less than 0.17 W with 120 V AC and
less than 0.23 W with 240 V AC
Screen size
(inches measured diagonally)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Speaker
Full range with speaker (mm)
box (2) (inches)
34 × 160
13/8 × 6 3/8
Dimensions with stand (mm)
(inches)
1,127 × 748 × 320
44
3
/ 8 × 29
1
/ 2 × 12
5
/ 8
994 × 673 × 290
39
1
/ 4 × 26
1
/ 2 × 11
1
/ 2
without stand (mm)
(inches)
1,127 × 716 × 64
44
3
/ 8 × 28
1
/ 4 × 2
5
/ 8
994 × 641 × 64
39
1
/ 4 × 25
1
/ 4 × 2
5
/ 8
wall-mount hole pattern (mm)
300 × 300
wall-mount screw size (mm) M6 (length: refer to diagram on page 15.)
Mass with stand (kg)/(lb.)
without stand (kg)/(lb.
Supplied accessories See “Checking the accessories” (page 4).
Optional accessories Connecting cables / Support Belt Kit / Wall-Mount Bracket
129W 109W
Less than 0.13 W with 120 V AC and
less than 0.2 W with 240 V AC
46 inches 40 inches
22.6/49.8
27.8/61.3
19.2/42.3
24.0/52.9

KDL-40NX700/46NX700 2
CAUTION!!
These servicing instructions are for use by qualied service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualied to do so.
CARRYING THE TV
•Carry the TV with the adequate number of people; larger size TVs require two or more people.
•C
orrect hand placement while carrying the TV is very important for safety and to avoid
damage.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this
receiver is directly connected to the AC power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identied by shading and ! mark on the exploded views are critical for safe operation.
Replace all components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. It is
essential that all critical parts be replaced only with the part number specied in this manual to prevent electric shock, re, or other hazard.
Circuit adjustments that are critical for safe operation are identied in this manual.
Follow these procedures whenever critical components are replaced or improper operation is suspected.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
WARNINGS AND CAUTIONS

KDL-40NX700/46NX700 3
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualié seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualié faire ainsi.
POUR TRANSPORTER LE TÉLÉVISEUR
•Transportez le téléviseur avec le nombre de personnes approprié ; un téléviseur de grande
taille doit être transporté par au moins deux personnes.
•L
ors du transport du téléviseur, l’emplacement des mains est très important pour votre
sécurité, ainsi que pour éviter de causer des dommages.
ALERTE!!
An d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout
dépannage. Le chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont
d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est
indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la
securite du fonctionnement sont identies dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants
critiques, ou lorsqu’un mauvais fonctionnement suspecte.
WARNING AND CAUTIONS

KDL-40NX700/46NX700 4
WARNING AND CAUTIONS
HANDLING THE GLASS ASSEMBLY
Use the following precautionary guidelines when replacing the Glass Assembly to avoid material degradation or screen coating
degradation, and ensure that dust, dirt, or ngerprints are not left between the glass and the LCD Panel.
RReplace the Glass Assembly in a brightly lit and clean room.
RPlace the replacement Glass Assembly on a dark cloth to make it easier to see dust and dirt particles.
R Wear anti static gloves to avoid leaving nger prints on the glass.
RUse a dry, soft MicroFiber cloth, such as a lint free polishing cloth, to gently wipe the glass to remove any dust or dirt particles.
RIf the glass needs additional cleaning, slightly moisten the cloth with a diluted mild soap or mild detergent solution, or use a compressed
air duster (spray can type).
R After replacing the Glass Assembly, verify there are no dark spots or nger prints visible on the screen.
CAUTION:
WDo Not use paper towels, any type of abrasive pad, rags, rubber or vinyl materials to clean the screen. Using these materials could
easily scratch the screen which may result in permanent damage.
WDo Not use any cleaning product containing alkaline/acid cleaner, scouring powder, or volatile solvent, such as alcohol, ammonia,
benzene, thinner or insecticide. Using any of these harsh cleaners may result in permanent damage to the screen.
WDo Not spray water or detergent directly onto the TV screen . If liquid drips into the bottom of the screen it may cause a failure.

KDL-40NX700/46NX700 5
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD Panel, be sure you are grounded by using a wrist band.
When installing the LCD Panel on a wall, the LCD Panel must be secured using the 4 mounting holes on the rear cover.
1) Do not press on the panel or frame edge to avoid the risk of electric shock.
2) Do not scratch or press on the panel with any sharp objects.
3) Do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
4) Do not expose the LCD Panel to direct sunlight.
5) Avoid contact with water. It may cause a short circuit within the module.
SAFETY-RELATED WARNING
6) Disconnect the AC power when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
7) Always clean the LCD Panel with a soft cloth material.
8) Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
9) Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
10) During the repair, DO NOT leave the Power On for more than 1 hour while the TV is face down on a cloth.

KDL-40NX700/46NX700 6
After correcting the original service problem, perform the following safety checks before releasing the set to the customer:
SAFETY CHECK-OUT
1. Check the area of your repair for unsoldered or poorly soldered connections.
Check the entire board surface for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or touching
high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and mounting
hardware have been replaced. Be absolutely certain that you have replaced
all the insulators.
4. Look for unauthorized replacement parts, particularly transistors, that
were installed during a previous repair. Point them out to the customer and
recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of deterioration.
Point them out to the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion. Recommend the replacement
of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and
all other exposed metal parts for AC leakage. Check leakage as described
below.
To Exposed Metal
Parts on Set
0.15 µF
Earth Ground
AC
Voltmete
r
(0.75V)
Figure A. Using an AC voltmeter to check AC leakage.

KDL-40NX700/46NX700 7
SAFETY CHECK-OUT
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and from all
exposed metal parts to any exposed metal part having a return to chassis, must
not exceed 0.5 mA(500 microamperes). Leakage current can be measured by
any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A.
Follow the manufacturers’ instructions to use these instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245 digital
multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM or
battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog
meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of passive VOMs
that are suitable. Nearly all battery-operated digital multimeters that have a
2 VAC range are suitable (see Figure A).
HOW TO FIND A GOOD EARTH GROUND
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw
on most AC outlet boxes is also at earth ground.
If the retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe with an
ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60-to 100-watt trouble-light (not
a neon lamp) between the hot side of the receptacle and the retaining screw.
Try both slots, if necessary, to locate the hot side on the line; the lamp should
light at normal brilliance if the screw is at ground potential (see Figure B).
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure B. Checking for earth ground.

KDL-40NX700/46NX700 8
SELF DIAGNOSIS FUNCTIONS
SELF DIAGNOSIS FUNCTION
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY LED will automatically begin to ash. The number
of times the LED ashes translates to a probable source of the problem. A denition of the STANDBY LED ash indicators is listed in the
instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the remote commander can be used to
review the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
DIAGNOSTIC TEST INDICATORS
When an error occurs, the STANDBY LED will ash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the LED will identify the rst of the problem areas.
Result for all of the following diagnostic items are displayed on screen.
If the screen displays a “0”, no error has occurred .
Diagnostic Item
Diagnostic Item
Description
Number of times Standby
LED blinks Possible Location
MAIN_POWER Main Power Over Voltage Protection 2
BUHS Board
GE3A (Power) Board (KDL-40NX700 Only)
GE2B (Power) Board (KDL-46NX700 Only)
trelACDTRELA_CD
rorrETTDTDW-TTD
AUD_PROT Audio Error Detection
4rorrErecnalaBlenaPRECNALAB BUHS Board
rorrENOCTRRENOCT
rorrERFHRRERFH
P_ID_ERR Panel ID NVM Error
6rorrEthgilkcaBETILKCAB BUHS Board
LCD Panel
draoBSHUB7rorrEerutarepmeTRRE_PMET
ANAN)sledomesehtnidesUtoN(rorrEnaFRRE_NAF
ANANrorrEKCArosneSBGRNES_BGR
3
5
BUHS Board
GE3A (Power) Board (KDL-40NX700 Only)
GE2B (Power) Board (KDL-46NX700 Only)
BUHS Board
LCD Panel
TCON Control MT Board
Self Diagnosis
Supported model

KDL-40NX700/46NX700 9
SELF DIAGNOSIS FUNCTIONS
STANDBY LED FLASH COUNT
Ambient Sensor/
(IR) Infrared Receiver
Picture Off /
Timer LED Standby LED Power LED
2 times
5 times
LED ON 0.3 sec.
LED OFF 0.3 sec. LED OFF
3 sec.

KDL-40NX700/46NX700 10
SELF DIAGNOSIS FUNCTIONS
VIEWING THE SELF CHECK DIAGNOSTIC LIST
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be conrmed, it is possible to
bring up past occurrences of a failure for conrmation on the Self Check diagnostic screen:
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second of each other:
DISPLAY Channel 5Volume -POWER .
* NOTE: This differs from accessing Service Adjustments Mode (Volume +)
Total operation time by hour (MAX:65535)
Boot count (MAX:65535)
Panel operation time by hour (MAX:65535)
Total operation time by hour (MAX:65535)
Boot count (MAX:65535)
Panel operation time by hour (MAX:65535)
0501210811 0412311234 0311111825 00
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
002 MAIN_POWE
003 DC_ALERT1
003 AUD_PROT
004 BALANCER
005 HFR_ERR
005 P_ID_ERR
12345-00333-0678912345-00333-06789--
-------------- -------------- -------------- 00
003 DTT_WDT
-------------- -------------- -------------- 00
005 TCON_ERR
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
006 BACKLITE
007 TEMP_ERR
010 RESERVED
-------------- -------------- -------------- 00
007 FAN_ERR
-------------- -------------- -------------- 00
-------------- -------------- -------------- 00
000 RGB_SEN
011 RESERVED -------------- -------------- -------------- 00
SELF CHECK
StandBy LED Flash Count
Diagnostic Item
Error history (Most recent time the failure occurred)
Error history (Failure time before the last occurrence)
Error history (Failure time before the 2nd to last occurrence
)
Error Count (00-99)

KDL-40NX700/46NX700 11
CLEARING THE SELF CHECK DIAGNOSTIC LIST
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen after you have
completed the repairs to be sure you have cleared the result display to “0”.
1. To clear the Error history and Error count: Press the Channel 8Channel 0.
2. To clear the Panel operation time: Press the Channel 7Channel 0.
EXITING THE SELF CHECK DIAGNOSTIC SCREEN
1. To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on
th e T V.
SELF DIAGNOSIS FUNCTIONS

KDL-40NX700/46NX700 12
Components not identied by a part number or
description are not stocked because they are seldom
required for routine service.
The component parts of an assembly are indicated by the
reference numbers in the far right column of the parts list
and within the dotted lines of the diagram.
* Items marked with an asterisk are not stocked since
they are seldom required for routine service. Expect
some delay when ordering these components.
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: The components identied by a red outline and a mark contain
condential information. Specic instructions must be adhered to whenever
these components are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
(Check the Sony Electronics Service Information website for any additional service related issues for this model.)
SEC 1. DISASSEMBLY/PART NUMBER INFORMATION
1-1. TABLE-TOP STAND ASSEMBLY REMOVAL
ARemove 4 screws from
Table-Top Stand Assembly
BLift up TV set to detach from
Table-Top Stand Assembly
REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES]
CGently place the TV set face down onto a soft cloth
1 X-2546-759-1 BASE (L1) ASSEMBLY (GM)
(KDL-46NX700 ONLY))
1 X-2546-758-1 BASE (ML1) ASSEMBLY (GM)
(KDL-40NX700 ONLY))
2 4-170-474-21 COVER, NECK (ML1 FRONT)
3 4-170-481-21 COVER, NECK (ML1 REAR)
4 4-170-445-01 NECK (ML1)
5 2-580-608-01 SCREW, +PSW M5X16
(SCREWS TO ATTACH TABLE-TOP STAND TO LCD TV)
For product protection and safety reasons, Sony strongly recommends
that you use the screws provided with the TV
CAUTION: These screws cannot be used to secure the TV to
the Wall Mount Brackets
2-580-608-01 SCREW, +PSW M5X16
B
A
Soft Cloth
C
1
4
2
3
5

KDL-40NX700/46NX700 13
DISASSEMBLY/PART NUMBER INFORMATION
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: The components identied by a red outline and a mark contain
condential information. Specic instructions must be adhered to whenever
these components are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
(Check the Sony Electronics Service Information website for any additional service related issues for this model.)
REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES]
1-2. REAR COVER, VESA BRACKETS, SWITCH UNIT AND POWER SWITCH REMOVAL
ARemove screws from Rear Cover.
8 from (KDL-40NX700 ONLY).
10 from (KDL-46NX700 ONLY).
BRemove 1 screw from Terminal position.
CRemove 1 screw from Side Jack position.
DRemove 4 screws from Under Cover to detach from Bottom Frame.
ESlide Vesa Bracket (S) sideways to remove from Rear Cover.
FLift AC Inlet to remove from Under Cover.
GLift up Switch Unit and disconnect 1 connector to remove from Bezel.
HSlide out Power Switch and disconnect 1 connector to remove from Switch Unit.
51 X-2546-727-1 REAR COVER(40) ASSEMBLY
(KDL-40NX700 ONLY)
51 X-2546-730-1 REAR COVER (46) ASSEMBLY
(KDL-46NX700 ONLY)
52 4-170-646-01 COVER, UNDER
53 4-168-272-01 BRACKET,VESA(S)
!54 1-842-031-11 AC INLET (2P)
55 1-487-804-11 SWITCH UNIT
56 1-798-309-11 POWER SWITCH
2-580-603-01 SCREW, +PSW M4X16
2-580-639-01 SCREW, +BVTP 4X12 TYPE2 IT-3
4-159-298-01 SCREW, +PSW M4X10
A
B
E
C
D
F
G
H
53
52
51
54
55
56

KDL-40NX700/46NX700 14
DISASSEMBLY/PART NUMBER INFORMATION
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: The components identied by a red outline and a mark contain
condential information. Specic instructions must be adhered to whenever
these components are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
(Check the Sony Electronics Service Information website for any additional service related issues for this model.)
REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES]
1-3. SPEAKERS, HLR BOARD, WIFI CARD, ANTENNAS AND PANEL HOLDER REMOVAL
ALift up right-side Speaker to remove from Bezel.
BRemove 1 screw from Bottom Frame to detach from Panel.
CRemove 2 screws from Bottom Frame to detach from Bezel.
DLift up left-side Speaker to remove from Bezel.
ERemove 1 screw from Antenna to detach from Bezel bottom.
FDisconnect 1 connector from HLR Board and release from LED Guide.
GRemove 1 screw from Antenna to detach from Bezel side.
HRemove 2 screws from WIFI Card to detach from Panel.
IRemove 1 screw from Panel Support to detach from Bezel.
101 1-858-379-11 LOUDSPEAKER
102 1-754-692-21 ANTENNA
103 A-1744-407-A HLR BOARD, MOUNTED
104 1-754-692-11 ANTENNA
105 1-487-819-11 CARD, WIRELESS LAN
106 4-165-971-01 HOLDER, PANEL (S)
2-580-639-01 SCREW, +BVTP 4X12 TYPE2 IT-3
2-345-219-11 +B IB 3X-- CM3
2-580-592-01 SCREW, +PSW M3X8
4-159-298-01 SCREW, +PSW M4X10
C
D
F
E
B
A
G
H
I
103
102
101
104
105
106

KDL-40NX700/46NX700 15
DISASSEMBLY/PART NUMBER INFORMATION
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: The components identied by a red outline and a mark contain
condential information. Specic instructions must be adhered to whenever
these components are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
(Check the Sony Electronics Service Information website for any additional service related issues for this model.)
REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES]
ARemove screws from Power Boards.
4 from GE3A Board (KDL-40NX700 ONLY)
5 from GE2B Board (KDL-46NX700 ONLY)
BDisconnect 5 connectors from Power Boards.
CSlide Terminal Bracket to left-side to remove from BUHS Board.
DRemove 8 screws from BUHS Board.
EDisconnect 5 connectors from BUHS Board.
FSlide Side Jack Bracket to right-side to remove from BUHS Board.
GCarefully Lift up Panel to remove from Bezel.
CAUTION: Refer to page 4, Handling the Glass Assembly, for cautions regarding replacing the
Glass Assembly.
1-4. GE3A/GE2B (POWER) BOARDS, BUHS BOARD, AND LCD PANEL REMOVAL
151 A-1773-991-A GLASS (40MAR) ASSEMBLY
(KDL-40NX700 ONLY)
151 A-1773-992-A GLASS (46MAR) ASSEMBLY
(KDL-46NX700 ONLY)
152 N/A LCD PANEL
FOR ALL LCD PANEL PART NUMBER INFORMATION
REFER TO THE LCD PANELS SERVICE MANUAL
153 X-2547-018-1 BRACKET, SIDE JACK T ASSEMBLY
154 A-1765-668-A BUHS BOARD, COMPLETE
NOTE: For BUHS Board replacement, please refer to section
2-2. Setting the Destination after Replacing the BUHS Board or LCD Panel.
NOTE: Final software is not installed on this BUHS Board.
Install the update after replacing this board using the instructions
provided with the software.
155 4-172-021-21 BRACKET, TERMINAL T (for US/CND MODELS ONLY)
155 4-172-021-51 BRACKET, TERMINAL T (for MX/LA MODELS ONLY)
156 1-474-213-11 GE3A (POWER) BOARD, COMPLETE
(KDL-40NX700 ONLY)
156 1-474-212-11 GE2B (POWER) BOARD, COMPLETE
(KDL-46NX700 ONLY)
2-580-592-01 SCREW, +PSW M3X8
D
E
F
G
BC
A
154
153
152
151
156
155
