KV-30XBR910 DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
30" Trinitron®XBR
Monitor/Receiver
35 3/8" x 23 7/8" x 22 1/4"
152 lbs
120VAC
60Hz
TBD
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
SIDE VIEW
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
35 3/8”
FRONT VIEW
TOP VIEW
Trinitron
IR RECEIVER
JACK PACK
26 5/8 "
15 " 23 7/8 "
Pre-Release Cut Sheet!
XBR
RM-Y188 REMOTE CONTROL
Pre-Release Cut Sheet!
22 1/4”
21 5/8 "
23 "
5 3/8 "
VHF/UHF
IN
AUX
IN
TO
CONVERTER
Video
VIDEO IN
Audio
L
(MONO)
R
MONITOR
OUT
S Video
AUDIO
OUT
Y
Pb
Pr
DVI IN
COMPONENT / HD IN
R L
AUDIO
CONTROL S
IN OUT
