SERVICE MANUAL BG-2S CHASSIS
TRINITRON ® COLOR TV

KV-G14L2J/G21M2J
RM-869
– 2 –
KV-G14L2J KV-G21M2J Note
Power requirements 110-240 V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G B/G, I, D/K, M
Color system PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58 (AV IN) PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58
Channel coverage
B/G VHF: E2 to E12 / UHF: E21 to E69 / CATV: S01 to S03, S1 to S41
I– UHF: B21 to B68 / CATV: S01 to S03, S1 to S41
D/K VHF: C1 to C12, R1 to R12/
– UHF: C13 to C57, R21 to R60/
CATV: Z1 to Z39, S01 to S03, S1 to S41
M–VHF: A2 to A13 / UHF: A14 to A79 /
CATV:A-8 toA-2,A to W+ 4,W+ 6 to W+ 84
Audio output (speaker) 3W
Inputs ˘(antenna): 75 ohms external terminal
…(video input) jacks: phono jacks
D (video): 1 Vp-p, 75 ohms
≥(audio): 500 mVrms, high impedance
Outputs A(earphone) jack: mini jack
Ú(monitor output) jacks: phono jacks
D(video): 1 Vp-p, 75 ohms
≥(audio): 500 mVrms
Picture tube 14 in. 21in
Tube size (cm) 37 54 Measured
diagonally
Screen size (cm) 34 51 Measured
diagonally
Dimensions (w/h/d, mm) 373 ×346 ×412 516 ×464 ×478
Mass (kg) 11 22
SPECIFICATIONS
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAPTOTHE METAL CHASSIS, CRT SHIELD, OR
CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK !ON
THE SCHEMATIC DIAGRAMS,EXPLODEDVIEWS AND INTHE
PARTS LIST ARE CRITICALTO SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
Design and specifications are subject to change without notice.

KV-G14L2J/G21M2J
RM-869
– 3 –
TABLE OF CONTENTS
1. GENERAL.................................................................... 4
2. DISASSEMBLY
2-1. Rear Cover Removal ........................................... 9
2-2. A Board Removal ................................................ 9
2-3. Service Position ................................................... 9
2-4. Replacement of Parts ........................................... 10
2-5. Terminal Board Bracket Removal ....................... 10
2-6. Demagnetization Coil Removal .......................... 10
2-7. Picture Tube Removal.......................................... 11
3. SET-UP ADJUSTMENTS
3-1. Beam Landing ...................................................... 12
3-2. Convergence ........................................................ 13
3-3. Focus Adjustment ................................................ 14
3-4. G2 (Screen) and White Balance Adjustments..... 15
4. SELF DIAGNOSIS FUNCTION............................ 16
5. CIRCUIT ADJUSTMENTS
5-1. Adjustments with Commander ............................ 17
5-2. Adjustment Method ............................................. 18
5-3. A Board Adjustment after IC003 (Memory)
Replacement......................................................... 22
5-4. Picture Distortion Adjustment ............................. 22
6. DIAGRAMS
6-1. Block Diagram ...................................................... 23
6-2. Circuit Boards Location ....................................... 26
6-3. Schematic Diagrams and Printed Wiring Boards 26
(1) Schematic Diagram of A Board ........................... 31
(2) Schematic Diagram of C Board ........................... 36
6-4. Semiconductors..................................................... 40
7. EXPLODED VIEW
7-1. Chassis .................................................................. 42
8. ELECTRICAL PARTS LIST ................................... 43
Section Title Page Section Title Page

– 4 –
KV-G14L2J/G21M2J
RM-869
SECTION 1
GENERAL
The operating instructions mentioned here are partial abstracts from the
Operating Instructions Manual. The page numbers of the Operating
Instruction Manual remain as in this manual.
3
1
– PROGR +
SELECT
– PROGR +
– VOLUME +
TV/VIDEO
SELECT
VHF LOW B/G
1
2
3
1
2
˘

KV-G14L2J/G21M2J
RM-869
– 5 –
5
Getting Started -EN
Connecting optional equipment
You can connect optional audio/video equipment to your TV such as a VCR, multi disc player, camcorder, or video
game.
Connecting video equipment using the
…
(video input) jack
D
…
≥
to video and
audio outputs
: Signal flow
to
…
(video input)
D
(video) and
≥
(audio) inputs
to antenna
output
to video
and audio
outputs
VCR
≥
ÖÚ
…
D
: Signal flow
to
…
(video input)
D
(video) and
≥ (audio) inputs
When connecting video equipment to the
… (video input) jack
Do not connect video equipment to the
… (video input) jacks at the front and the rear of your TV simultaneously; otherwise the picture
will not be displayed properly on the screen.
Connecting audio/video equipment using the
Ú (monitor output) jack
Rear of TV
to antenna socket
Camcorder
Front of TV
When recording through the
Ú (monitor output) jack
Do not change the channel or video input while recording with a VCR; otherwise the channel or video input you are recording also will be
changed.
: Signal flow
VCR
to antenna
output
≥
ÖÚ
…
D
to video
and audio
inputs
to
Ú
(monitor output)
D
(video) and
≥ (audio) outputs
to antenna socket
Rear of TV
Getting Started
4
-EN
Connections
Connecting a VHF antenna or a combination VHF/UHF antenna
— 75-ohm coaxial cable (round)
Attach an optional IEC antenna connector to the 75-ohm coaxial cable.
Plug the connector into the (antenna) socket at the rear of the TV.
Connecting an indoor antenna
On a wall
3
1
2
Note
•You are advised to use an outdoor antenna for better reception.
or
Getting Started
Rear of TV Rear of TV

– 6 –
KV-G14L2J/G21M2J
RM-869
Getting Started
6
-EN
Presetting channels
Presetting channels automatically
1 Press SELECT on the remote commander or
the TV until “AUTO PROGRAM” appears on
the screen.
2 Press +/– on the remote commander or
.+/– on the TV.
3 Press +/– on the remote commander or
.+/– on the TV again.
To start presetting channels automatically
from the specified program position
Press PROGR +/– or number buttons on the remote
commander or PROGR +/– on the TV until the
required program position appears on the screen after
step 2 of “Presetting channels automatically”.
You can preset up to 100 TV channels in numerical
sequence from program position 1 using the buttons on
the remote commander or the TV.
You can preset TV channels quickly, automatically or
manually.
Quick channel presetting
1 Press Uto turn on the TV.
When the TV is turned on in standby mode, press
uon the remote commander.
2 Press SELECT and PROGR + on the TV
simultaneously for one to two seconds.
1 2 3 1
– PROGR +
SELECT
+/–
SELECT
Front of TV
Remote commander
or
or
or
123
46
789
÷0
5
PROGR
– PROGR +
or
or
TV
– PROGR +
–
. +
TV/VIDEO
SELECT
R

U
u
U
VHF LOW B/G
1
– . +
123 1
– . +
AUTO PROGRAM
SELECT SELECT
Number
PROGR +/–
7
Getting Started -EN
Presetting channels manually
1 Press SELECT on the remote commander or
the TV until “MANUAL PROGRAM” appears
on the screen.
2 Press +/– on the remote commander or
.+/– on the TV.
3
Press PROGR +/– or number buttons on the
remote commander or PROGR +/– on the TV
until the required program position
appears on the screen.
4 Press +/– on the remote commander or
.+/– on the TV until the required channel
picture appears on the screen .
5 Press SELECT on the remote commander or
the TV.
Disabling program positions
1 Press PROGR +/– or number buttons on the
remote commander or PROGR +/– on the TV
until the unused or unwanted program
position appears on the screen.
2 Press SELECT on the remote commander or
the TV until “MANUAL PROGRAM” appears
on the screen.
3 Press +/– on the remote commander or
.+/– on the TV.
4 Press PIC MODE on the remote commander.
5 Press SELECT on the remote commander or
the TV.
To preset the disabled program position again
Preset the channel quickly, automatically or manually
.
MANUAL PROGRAM
SELECT SELECT
or
123
46
789
÷0
5
PROGR
– PROGR +
or
or
VHF LOW B/G
– . +
1
SELECT SELECT
or
or
or
– . +

KV-G14L2J/G21M2J
RM-869
– 7 –
Operations
8
-EN
Watching the TV
Operations
Turning off the TV
To turn off the TV temporarily
Press uon the remote commander. The uindicator
on the TV lights up.
To turn off the TV completely
Press Uon the TV.
If the power on the TV is turned off in standby mode,
the uindicator on the TV may remain alight for a
while.
Watching the video input
Press … F.
To watch TV
Press ;
.
Muting the sound
Press ¤ .
1 Press Uto turn on the TV.
When the TV is turned on in standby mode, press
uon the remote commander.
2 Select the TV program you want to watch.
To select a program position directly
Press the number button.
To select a two-digit program position, press
“-/--” before the number buttons.
For example: to select program position 25, press
“-/--,” and then “2” and “5.”
To scan through program positions
Press PROGR +/– until the program position you
want appears.
3 Press .+/– to adjust the volume.
123
46
789
÷0
5
÷2 5
PROGR
MUTING
U
.
;
¤
u
U
VIDEO 1
… F
9
-EN
Operations
•If no buttons or controls are pressed for more than two hours
after the TV is turned on using the Wake Up Timer, the TV
automatically turns into standby mode. If you want to
continue watching the TV, press any button or control on the
TV or remote commander.
Displaying on-screen information
Press EG.
The program position, local system, and TV settings are
displayed on the screen.
Setting the Wake Up Timer
You can set the TV automatically turned on as you
program.
1 Press
B ©repeatedly to set the timer.
The on-screen display appears and the
B indicator
on the TV lights up.
2 If you want a particular TV program or video
input to be displayed using the Wake Up
Timer, select the TV program or video input.
3 Press uon the remote commander or set
the Sleep Timer to turn off the TV in
standby mode.
To cancel the Wake Up Timer, press
B
©repeatedly
until “WAKE UP TIMER: OFF” appears, or turn off the
main power of the TV.
Notes
•The Wake Up Timer starts immediately after the on-screen
display disappears.
•The last TV program position or video input just before the TV
turns into standby mode will appear when the TV is turned on
using the Wake Up Timer.
1
AUTO B/G
DYNAMIC
Setting the Sleep Timer
You can set the TV automatically turned off as you
program.
Press
C I.
To cancel the Sleep Timer, press
C Irepeatedly
until “SLEEP TIMER: OFF” appears, or turn off the TV.
Changing the on-screen display
language
If you prefer Chinese to English, you can use buttons
on the remote commander or the TV to change the
on-screen display language.
1 Press SELECT until the screen appears as
follows:
2 Press +/– to select “⁄⁄⁄ ”.
Note
•You can also use SELECT and
¸ +/– on the TV to select the
on-screen display language.
After 30 minutes After 60 minutes
After 90 minutes
No sleep timer
SLEEP TIMER:30M SLEEP TIMER:60M
SLEEP TIMER:OFF SLEEP TIMER:90M
EG
+/–
SELECT
SELECT
LANGUAGE
/ »y¤¥ : ENGLISH
No wake up timer After 12 hours
After 10 minutes
WAKE UP TIMER:10M
WAKE UP TIMER:OFF WAKE UP TIMER:12H00M
B í©
C I
»y¤¥ / LANGUAGE :
⁄⁄⁄

– 8 –
KV-G14L2J/G21M2J
RM-869
Operations
10
-EN
Adjusting the picture setting
1 Press SELECT until the item you want to
adjust appears.
Each time you press SELECT, the screen changes as
follows:
2 Press +/– to adjust the item.
3 To adjust other items, repeat steps 1 and 2.
Note
•You can also use SELECT and
. +/– on the TV to adjust the
picture setting.
If the picture color is abnormal when receiving
programs through the ˘(antenna) terminal or
the …(video input) jack
Change the “COLOR SYSTEM” setting or adjust the
“COLOR” level in the on-screen display until the color
becomes normal.
Note
•Normally set “COLOR SYSTEM” to “AUTO”.
PICTURE COLOR BRIGHT
HUE
SHARPNESS
(Operative for
NTSC signal
only)
SELECT
Adjusting the
Note on the SOUND MODE button
•The sound mode feature is unavailable for your TV. Thus, the
SOUND MODE button on the remote commander is not used
for your TV.
Selecting the picture mode
Press PIC MODE until the mode you want
appears.
Each time you press PIC MODE, the screen changes as
follows:
Note
•If you change the picture mode after the following
adjustments, the adjustment changes in accordance with the
picture mode.
÷0
SOUND
MODE
SELECT
PIC MODE
PIC MODE
High contrast
Soft picture
(good for video
games)
DYNAMIC STANDARD SOFT
+/–
Front of TV
…
SELECT –
PROGR +
–
. +
Normal
12
-EN Additional Information
Troubleshooting
No picture
No sound
/Press Uor u.
/Check the antenna connection.
/Check the VCR connections.
/Check the power cord connection.
/Check the standby mode.
No color
/Adjust the “COLOR” level in the on-
screen display.
/Check the “COLOR SYSTEM” setting.
TV cabinet creaks
/Even if the picture or the sound is normal,
changes in the room temperature
sometimes make the TV cabinet expand or
contract, making a noise. This does not
indicate a malfunction.
Note on the remote commander
•The supplied remote commander is used on several models of
the TV. If you do not find instructions for some controls that
are on the remote commander, that means your TV does not
employ the features of those controls, e.g.
L
and SOUND
MODE.
Notes
•When you turn on the TV, you may hear the “boon” sound
that is caused by the demagnetization of the TV. This does not
indicate a malfunction.
•The picture color may become abnormal if you change the
direction of your TV. To obtain the normal picture color, press
U
on the TV to turn off the TV for five minutes and then turn
it on again.
•Design and specifications are subject to change without notice.
•All contents in the instruction manual are subject to change
without notice.
WARNING
Do not install the appliance in a confined space, such as
a bookcase or built-in cabinet.
Additional Information
If you have any problems, read this manual again and
check the countermeasure for each of the symptoms
listed below.
If the problem persists after trying the methods below,
contact your nearest authorized service center or dealer.
Snowy picture
Noisy sound
/Check the antenna.
/Check the antenna connection on the TV
and on the wall.
Dotted lines or stripes
/This may be caused by local interference
(e.g. cars, neon signs and hair dryers).
Adjust the antenna for minimum
interference.
Double images or “ghosts”
/This may be caused by reflections from
nearby mountains or buildings. A highly
directional antenna may improve the
picture.
Good picture
No sound
/Press .
+.
/Press ¤.

– 9 –
KV-G14L2J/G21M2J
RM-869
2-1. REAR COVER REMOVAL
2-2. A BOARD REMOVAL
SECTION 2
DISASSEMBLY
Four screws
(BVTP 4×16)
1
2Two screws
(BVTP 4×16)
Lever
Lever
A board
2-3. SERVICE POSITION
A board

– 10 –
KV-G14L2J/G21M2J
RM-869
Multi button
Three screws
(BVTP 3×12)
•SCREWING TORQUE
7±1 kg•cm
2-4. REPLACEMENT OF PARTS
For replacement of the Multi Button and Light Guide, cut the welded portions
from them, exchange with the new parts, and fix them with screws (+BVTP) respectively.
2-4-1. REPLACEMENT OF MULTI BUTTON
2-4-2. REPLACEMENT OF LIGHT GUIDE
2-5. TERMINAL BOARD BRACKET REMOVAL
Cut
Cut
Multi button
Light guide
Cut
Cut
Light guide
Two screws
(BVTP 3×12)
•SCREWING TORQUE
7±1 kg•cm
2-6. DEMAGNETIZATION COIL REMOVAL
Two claws
A board
Terminal board bracket
A board
Terminal board bracket
1Demagnetization coil
2Tension spring
Picture tube

– 11 –
KV-G14L2J/G21M2J
RM-869
2-7. PICTURETUBE REMOVAL
2Using a thumb press down, then pull up the rubber cap firmly in the direction indicated
by the arrow b.
3When one side of the rubber cap is separated from the anode button, the anode-cap
can be removed by turning up the rubber cap and pulling it up in the direction of the
arrow c.
•HOW TO HANDLE AN ANODE-CAP
1Do not damage the surface of anode-cap with sharp shaped objects.
2Do not press the rubber too hard so as not to damage the inside of anode-cap.
A metal fitting called the shatter-hook terminal is built into the rubber.
3Do not turn the foot of rubber over too hard.
The shatter-hook terminal will stick out or damage the rubber.
•REMOVAL OF ANODE-CAP
NOTE : After removing the anode, short circuit the anode of the picture tube and the
anode cap to the metal chassis, CRT shield or carbon paint on the CRT.
•REMOVING PROCEDURES
1Turn up one side of the rubber cap in the direction indicated by the arrow a.
2A board
3C board
4Deflection yoke
Cushion
5Four screws
(Tapping screws)
1Anode cap
a
a
b
b
c
Anode button

– 12 –
KV-G14L2J/G21M2J
RM-869
Perform the adjustments in the following order:
1. Beam Landing
2. Convergence
3. Focus
4. White Balance
Note : Test Equipment Required:
1. Color-bar/Pattern Generator
2. Degausser
3. Oscilloscope
SECTION 3
SET-UP ADJUSTMENTS
Fig. 3-4
Fig. 3-3
Fig. 3-2
Fig. 3-1
}normal
•The following adjustments should be made when a complete
realignment is required or a new picture tube is installed.
•These adjustments should be performed with rated power
supply voltage unless otherwise noted.
Controls and switch should be set as follows unless otherwise noted:
PICTURE control........................................................... normal
BRIGHTNESS control................................................... normal
Preparation :
•In order to reduce the influence of geomagnetism on the set's
picture tube, face it east or west.
•Switch on the power and degauss with the degausser.
3-1. BEAM LANDING
1. Input a white signal with the pattern generator.
Contrast
Brightness
2. Set the pattern generator raster signal to green.
3. Move the deflection yoke to the rear and adjust with the purity
control so that the green is at the center and the blue and the red
take up equally sized areas on each side.
(See Figures 3-1 through 3-3.)
4. Move the deflection yoke forward and adjust so that entire
screen is green. (See Figure 3-1.)
5. Switch the raster signal to blue, then to red and verify the
condition.
6. When the position of the deflection yoke has been decided,
fasten the deflection yoke with the screws.
7. If the beam does not land correctly in all the corners, use a
magnet to adjust it. (See Figure 3-4.)
...............................................................................................................................................................................................................................
Purity control
Deflection yoke positioning
corrects these areas.
Purity control corrects
this area. Disk magnets or rotatable
disk magnets correct
these areas (a-d).
b
c
a
d
ba
cd
GREEN
BLUE RED

– 13 –
KV-G14L2J/G21M2J
RM-869
•Operation of V.STAT magnet.
If the V.STAT magnet is moved in the direction of the aand
barrows, the red, green and blue dots move as shown below.
•Operation of BMC (Hexapole) magnet.
If the blue or red dot does not converge with the other two dots,
perform following steps.
Move BMC magnet (a) to correct insufficient H.static
convergence.
Rotate BMC magnet (b) to correct insufficient V.static
convergence.
In either case, repeat Beam Landing Adjustment.
1. (Moving vertically), adjust theV.STAT magnet so that the red,
green and blue dots are on top of each other at the center of the
screen.
2. (Moving horizontally), adjust the H.STAT VR so that the red,
green and blue dots are on top of each other at the center of the
screen.
3-2. CONVERGENCE
Preparation :
•Before starting this adjustment, adjust the focus, horizontal size,
and vertical size.
•Minimize the brightness setting.
•Provide dot pattern.
(1) Horizontal and Vertical Static Convergence
R G B
G
R
B
Center dot
C board
RV 701
SCREEN (G2)
V.STAT Magnet
V.STAT
Purity
B
R
B
R
ab
bb
a
b
a
b
a
R
G
B
b
B
G
R
b
ba
a
1
2
3
GG
B G R
R G B
a
BMC magnet
b

– 14 –
KV-G14L2J/G21M2J
RM-869
3-3. FOCUS ADJUSTMENT
Adjust FOCUS control on the flyback transformer for the best
focus.
(3) Screen-corner Convergence
(2) Dynamic Convergence Adjustment
Preparation :
•Before starting this adjustment, adjust the horizontal static
convergence and the vertical static convergence.
1. Slightly loosen the deflection yoke screws.
2. Remove the deflection yoke spacer.
3. Move the deflection yoke as shown in the figure below and
optimize the convergence.
4. Tighten the deflection yoke screws.
5. Install the deflection yoke spacer.
B G R B
G
R
R
G
BR G B
R G B R
G
B
B
G
RB G R
R G BB G R
B G RR G B
a-d : screen-corner
misconvergence
ba
cd
a
d
c
b
a to d : Permalloy assembly
Fix a Permalloy assy
corresponding to the
misconverged areas
Note: Screen VR is not used.
FOCUS
SCREEN
(NOT USED)

– 15 –
KV-G14L2J/G21M2J
RM-869
0
V
a. AN ITEM OF ADJUSTMENT
b. METHOD OF CANCELLATION FROM SERVICE
MODE
Set the standby condition (Press
POWER
button on the
commander) and then press
POWER
button again, hereupon it
becomes TV mode.
c. METHOD OF WRITE FOR MEMORY
1) Set to Service Mode.
2) Press 1(UP) and 4(DOWN)toselect an item of adjustments.
3) Press
MUTING
button and it will indicateWRITE on screen.
4) Press -button to write into memory.
d. MEMORY WRITE CONFIRMATION METHOD
1) After adjustment, pull out the plug from AC outlet, and then
plug into AC outlet again.
2) Turn the power switch ON and set to Service Mode.
3) Call the adjusted items again, confirm they were adjusted.
Note
WHITE POINT R
WHITE POINT G
WHITE POINT B
Initial DATA
3F
3F
3F
3-4. G2 (SCREEN) AND WHITE BALANCE
ADJUSTMENTS
1. G2 (SCREEN) ADJUSTMENT (RV701)
1) Set the PICTURE and BRIGHTNESS to normal.
2) Put to VIDEO input mode without signals.
3) Connect R, G and B of the C board cathode to the oscilloscope.
4) Adjust G2 (RV701) volume to the value below.
Item
number
09
0A
0B
Adjustment
Item
RDR
GDR
BDR
2. WHITE BALANCE ADJUSTMENTS
1) Set to Service Mode.
2) Input an entire white signal.
3) Set the PICTURE to maximum.
4) Select RDR(09) with 1and 4, and then set the level to 25
with 3and 6.
5) Select GDR(0A) and BDR(0B) with 1and 4, and adjust
the level with 3and 6for the best white balance.
6) Write into the memory by pressing
MUTING
, then -.
SERVICE
MUTING
1 FRDR09 6000V3.2C052S
6000V3.2C052S
OEM CODE
PAL or
NTSC
German A2 Stereo
Software Version #
WRITE1 FRDR09
0
Executes the writing
Green
WRITE1 FRDR09
0
Executes the writing
(bottom line disappears)
165 ±2 V DC (14 inch)
177 ±2 V DC (21 inch)

– 16 –
KV-G14L2J/G21M2J
RM-869
If no acknowledgement is returned from a device which is turned "ON", the device has a problem.
In this case, one of the LED's responding to the problem device will flicker a defined number of times.
Flickering is operated by lighting the LED's for 60ms each time.
The flickering frequency responding to each failed device is shown below.
SECTION 4
SELF DIAGNOSIS FUNCTION
Board name
Ref. No.
Device
Flickering Frequency
A Board
IC003
NONVOLATILE
MEMORY
(ST24C04FB6)
1
A Board
IC300
Y/C JUNGLE
(TDA8374A)
3
All the devices are checked one after another from the left of the table.
If an error is found, the responding LED will start flickering.
So, if more than 1 device have failed, only the one on the left side will flicker.

– 17 –
KV-G14L2J/G21M2J
RM-869
Entering service mode
With the unit on standby
↓
DISPLAY
↓
5
↓
VOL
( + )
↓
POWER
The operation sequence puts the unit into service mode.
SECTION 5
CIRCUIT ADJUSTMENTS
5-1. ADJUSTMENTS WITH COMMANDER
Service adjustments are made with the RM-869 that comes with
this unit.
RM-869
¤EG u
V…F;
B©SELECT p
PIC MODE p
SOUND
MODE
.PROGR
A/B H
CI
++
123
46
789
0
+ p
– p
5
TV
1, 4Raise/lower the service item number
3, 6Raise/lower the data
[MUTING] Writes
-Executes the writing
7, -All data becomes the values in memory
8, -All user control goes to the standard state
5, -Service data initialization (Be sure not to use
usually.)
2, -Write 50Hz adjustment data to 60Hz, or
viceversa.
The screen display is :
1, 4Select the adjustment item.
↓
3, 6Raise/lower the data.
↓
MUTING
Writes
↓
-Executes the writing.
SERVICE Mode08
Data
HSF
50 Depends on the signals
PAL, SECAM : 50
NTSC : 60
Adjustment item
00
ModeItem #
00V3.2C052S
OEM CODE
German A2 Stereo
Software Version #
1
SERVICE00OP0
50
3D
0000000000
2
(Bit options adjustable)

– 18 –
KV-G14L2J/G21M2J
RM-869
Use the same method for Items Number 00-40. Use 1and 4to
select the adjustment item, use 3and 6to adjust, write with
MUTING
, then execute the write with -.
WRITE
WRITE
GREEN0CVSF08
SERVICE
50
50
GREEN0CVSF08
Adjusted with
3 and 6 buttons
Written with MUTING
Write executed with
0
GREEN
The WRITE display
will change back to
SERVICE.
(2nd line disappear
when written)
0CVSF08
00V3.2C052S
00V3.2C052S
Blank
5-2. ADJUSTMENT METHOD
Item Number 08
This explanation uses V-SHIFT as an example.
1. Select 08 V-SHIFT with the 1and 4buttons.
2. Raise/lower the data with the 3and 6buttons.
3. Select the optimum state. (The standard is 0F for PAL
reception.)
4. Write with the
MUTING
button.
5. Execute the writing with the -button. (The WRITE
display returns to green SERVICE.)

– 19 –
KV-G14L2J/G21M2J
RM-869
Item Adj Initial Note for Different Data Standard Data Standard Data Function Device
No. Item Data (KV-G14L2J) (KV-G21M2J)
00 HSF 24 50/60Hz/RGB 50/RGB 60 1F/28/1F/28 2C/33/31/38 H Shift
01 HSZ 23 50/60Hz/RGB 50/RGB 60 20/20/20/20 35/35/35/35 H Size
02 PAP 21 50/60Hz 20/20 25/25 Pin Amplitude
03 CNP 29 50/60Hz 20/20 10/0C Corner Pin
04 TLT 20 50/60Hz 20/20 20/2D Tilt
05 VSL 20 50/60Hz 1F/1F 1F/1F V Slope
06 VAP ID 50/60Hz 2A/2A 1C/1B V Amplitude
07 SCR 20 50/60Hz 15/15 16/16 S Correction
08 VSF 20 50/60Hz 23/23 10/10 V Shift
09 RDR 25 28 R Drive
0A GDR 20 G Drive
0B BDR 20 B Drive
0C F0 00 TV/Video/Teletext 00/00/00 00/00/00 ø1 Time Constant
0D AGC 06 TV/Video/Teletext 28/28/28 28/28/28 AGC Take Over
0E VSW 0 TV/Video/Teletext 0/1/0 0/1/0 Video Mute Switch
0F FOR 00 03 03 Forced field Frequency
10 DL 0 De-interlace
11 POC 0 Fixed ø 1 Synchro. mode
12 COR 0 TV/Video/Teletext 01/00/00 01/00/00 Noise Coring
13 VPX 00 Extra Bits (see below)
14 PMX 27 TV/Video/Teletext 20/20/20 2B/2B/2B Picture Maximum Data
15 PMI 05 04 04 Picture Minimum Data
16 SBR 4B Sub Brightness
17 SHU 07 Sub Hue
18 SSH 01 TV/Video 01/03 01/03 Sub Sharpness
19 SC1 1F 50/60Hz 26/29 26/29 Sub Color Lower
1A SC2 0B 50/60Hz 0C/0D 0C/0D Sub Color Higher
1B AIP 40 3F 3F Adjustment IF-PLL
1C VZM 20 19 19 Vertical Zoom
1D WST 15 W/G Stereo Threshold
1E WBT EA W/G Bilingual Threshold
1F WLL 05 W/G Monaural Threshold
20 ACG 1 AGC Switch auto/constant
21 CDB 28 AGC Gain at Constant Mode
22 FGP 1B FM Prescale for B/G.I.D/K
23 FMP 32 FM Prescale for M
24 FMH 36 FM Prescale for HDEV Mode
25 FMM 65 FM Prescale for HDEV Mode
26 WGP 2A W/G Prescale
27 NIP 6D NICAM Prescale
28 SCP 3B SCART Input Prescale
29 SCV 2A SCART Output Prescale
2A CRM 0 Carrier Muting on/off
2B ACO 1 Audio Clock-out on/off
2C WAC 00 W/G Agreement Count
2D NFT 50 Auto FM Switch Threshold
2E DLG 30 W/G Search Delay
2F DLN 20 NICAM Search Delay
30 DLS 10 Stereo Status Read Delay
31 SMX 73 DFP Vloume Maximum
32 ING 00 M System/non-M/Video Input Fain
33 VOM 01 M System only Volume Output Gain
34 TXH 01 Teletext Horizonal Position
35 BKP 00 Picture Data at Blanking OFF
36 ODL 10 Power ON Delay
37 OFR 00 RGB Output Time (STBY OFF)
38 OFM 00 RGB Output Time (AC OFF)
Adjustment Item Table

– 20 –
KV-G14L2J/G21M2J
RM-869
NOTE
• Note for Different Data Those are the standard data values written on the microprocessor.Therefore, the data values of
the modes are stored respectively in the memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some
items.
• 50..............50 Hz data
• 60..............60 Hz data
• Note for Different Data listed on the adjustment item table are reference values, therefore it is different for every model.
Item Adj Initial Note for Different Data Standard Data Standard Data Function Device
No. Item Data (KV-G14L2J) (KV-G21M2J)
39 OSH 0A OSD H Position
3A DKS 1 0 0 D/K Stereo enable/disable
3B MUT 0 Muting on/off at No Sync
3C ABL 0 Bright ABL Switch
3D SCM 0 SECAM Trap active/inactive
3E FBT 1 FBT L/S C/M strict/plain
3F OP0 2F 28 Optional Flags 0 (see below)
40 OP1 0F 0F Optional Flags 1 (see below)
41 OP2 00 00 Optional Flags 2 (see below)
